AMX MAX-BSM User manual

max-ims integrated music server
INSTANT GRATIFICATION
Meet MAX by AMX, the Integrated Music Server (MAX - IMS). MAX works
to keep your library of CDs simple to use, well organized, and always fun
– wherever you are, whenever you want. From single to multi-room music
systems, MAX manages your ever-growing music collection with amazing
efficiency. Add as many CDs as you desire, searching and selecting your
favorite tracks quickly and effortlessly.
HIGHEST AUDIO STANDARD
MAX only knows one way to achieve the best possible audio – through
native CD quality. Compared to “compressed” MP3 files, native CD
quality represents the highest standard of sound possible. MAX preserves
the depth, dynamics and quality of the original music. Built with a robust
internal hard drive, MAX has the ability to categorize and manage from
500 CDs to beyond 2,500. Of course, if you also have an existing MP3
collection, MAX is capable of playing this file format without any
compatibility issues.
MUSIC FOR ALL
Even the latest CD changers only offer the option to play one CD at a
time. MAX welcomes you to the future of distributing music, where
multiple CDs can be selected simultaneously, from anywhere at any time.

MAX - IMS - INTEGRATED MUSIC SERVER
OVERVIEW
• Hard drive based music server with lossless compression to
allow playback at full CD quality.
• Progressive text search locates the disc you're looking
for instantly.
• Control any MAX product over Ethernet or RS-232 via your
AMX or Crestron control System, a Windows PC, or an on-
screen interface.
• Includes powerful Windows software for PC control. CD
recognition is available instantly from the CD database within
the unit. The CD database is updated monthly as well as any
software upgrades and web based technical support.
• Two units can be joined together to allow for greater capacity
and more outputs.
• Available with 2 or 4 independent audio outputs
(analog and S/PDIF digital).
• Includes CD-RW drive for creating custom CDs.
AUDIO FEATURES
• 24bit D/A conversion
• 48khz sampling rate
• Output level -10dBV nominal
• Signal to Noise Ratio 110db A-weighted
DIMENSIONS
• 1.75” H x 19” W x 18.50” D (4.45cm x 48.26cm x 46.99cm)
POWER
• 110-240VAC 60/50hz 4.3A
• 150 WATTS
WEIGHT
• MAX - IMS 500 – 19lbs (8.61kg)
• MAX - IMS 1000 – 21lbs (9.52kg)
• MAX - IMS 1500 – 23lbs (10.43kg)
• MAX - IMS 2500 – 24lbs (10.88kg)
FRONT PANEL
• Blue Power LED
• Power switch
• CD-RW drive
REAR PANEL CONNECTIONS
• AC power
• RJ45 Ethernet for external control
• DB9 RS-232 port for external control
• RCA PCM digital output for each stream
• (2) RCA stereo analog outputs for each stream
HARD DRIVE CAPACITY
• MAX - IMS 500 160GB – 500 CD capacity
• MAX - IMS 1000 320GB – 1000 CD capacity
• MAX - IMS 1500 480GB – 1500 CD capacity
• MAX - IMS 2500 750GB – 2500 CD capacity
INCLUDED ITEMS
• Power cord
• CD-ROM with instruction manual, control software
MAX - BSM - BACKUP
OVERVIEW
• Archive your IMS CD database.
• Provides quick and easy backup restoration.
DIMENSIONS
• 1.75” H x 19” W x 18.50” D (4.45cm x 48.26cm x 46.99cm)
POWER
• 110-240VAC 60/50hz 4.3A
• 150 WATTS
WEIGHT
• MAX - BSM 500 – 19lbs (8.61kg)
• MAX - BSM 1000 – 21lbs (9.52kg)
• MAX - BSM 1500 – 23lbs (10.43kg)
• MAX - BSM 2500 – 24lbs (10.88kg)
FRONT PANEL
• Blue power LED
• Power switch
REAR PANEL CONNECTIONS
• AC power
• RJ45 Ethernet for external control
• DB9 RS-232 port for external control
HARD DRIVE CAPACITY
• MAX - BSM 500160GB – 500 CD capacity
• MAX - BSM 1000 320GB – 1000 CD capacity
• MAX - BSM 1500 480GB – 1500 CD capacity
• MAX - BSM 2500 750GB – 2500 CD capacity
INCLUDED ITEMS
• Power cord
