MATRIX Infrared Patio Heater
Safety Instructions
and Operation Manual
Model: PVMA2000 AGR STD PVMA1500 AGR STD
PVMA2000 WHT STD PVMA1500 WHT STD
PVMA2000 BLK STD PVMA1500 BLK STD
PVMA1500 SLV STD
(Note:This product is strictly prohibited to cover )
Thank you for purchasing our products.Please read carefully this instruction
before using and operate strictly accordance with the instructions,and especially pay
attention to "Important Safety Instructions".Please be careful collection after
reading so as to for future reference.

1
Brief Introduction
This product is infrared radiant heater with remote control and IP 65 approved .It is
almost unlimited used in outdoor ,such as open bars, courtyard, plaza, station, and
construction site in winter etc. This patio heater is energy-efficient, convenient,
environmentally friendly and for better life etc.
Important Safety Instructions
When using electrical appliances, basic safety precautions should always be followed
to reduce the risk of fire, electric shock, or injury to persons, including the following:.
Read all instructions before using this heater
⚫This heater is hot when in use .To avoid burns,do not let bare skin touch hot
surfaces.If provided ,use handles when moving this heater.Keep combustible
materials,such as furniture,pillows ,bedding ,papers,clothes and curtains at
least 0.9m from the front of the heater.
⚫Extreme caution is necessary when any heater is used by or near children or
invalids and whenever the heater is left operating and unattended.
⚫Always unplug heater when not in use
⚫Do not operate any heater with a damaged cord or plug or after the heater
malfunctions, has been dropped or damaged in any manner. Discard heater, or
return to authorized service facility for examination and/or repair.
⚫This heater is not intended for use in bathrooms, laundry areas and similar
locations. Never locate heater where it may fall into a bathtub or other water
container.
⚫Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or
similar coverings. Do not route cord under furniture or appliances. Arrange cord
away from traffic area and where it will not be tripped over.
⚫Connect to properly grounded outlets only.
⚫To disconnect heater, turn controls off, then remove plug from outlet.
⚫Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the heater.
⚫To prevent a possible fire, do not block air intakes or exhaust in any manner. Do
not use on soft surfaces, like a bed, where openings may become blocked.
⚫A heater has hot and arcing or sparking parts inside. Do not use it in areas
where gasoline, paint, or flammable liquids are used or stored.
⚫Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or injury to

⚫persons.
⚫Always plug heaters directly into a wall outlet/receptacle. Never use with an
extension cord or relocatable power tap (outlet/power strip).
⚫Check if the voltage indicated on the nameplate of the appliance corresponds
to the local mains voltage before you connect the appliance.
⚫The appliance is not located immediately below a wall socket-outlet.
⚫The casing and the front cover of the appliance become extremely hot during
operation. Pay attention that, no combustible material due to wind or other
environmental influences covers or obstructs the appliance, such as curtains,
marquees, flags, plastic foil etc. Do not touch the appliance. Caution! Risk of
scald injury!
⚫In case of improper use, there is a risk of electrical shock and/or fire hazard.
Operation of the appliance must be discontinued and remove the mains plug
immediately. Do not try to repair the appliance by your-self. Please contact with
the service agent or a suitably qualified electrician for maintenance.
⚫Remove the plug from the power outlet and wait until the appliance is
sufficiently cooled off before cleaning.
⚫Keep out of reach of children. In order to keep children from the dangers of
electrical appliances, never leave them unsupervised with the machine.
Consequently, when selecting the location for your machine, do so in such a
way that children do not have access to the machine. Children being supervised
not to play with the appliance.
⚫The appliance must only be mounted by an authorized specialist, paying
attention to the relevant regulations of the power supply companies and the
regional construction regulations.

Save These Instructions
SPECIFCATIONS
Specification
□PVMA2000 AGR STD
□PVMA2000 WHT STD
□PVMA2000 BLK STD
□PVMA1500 AGR STD
□PVMA1500 WHT STD
□PVMA1500 BLK STD
□PVMA1500 SLV STD
Voltage (V)
□ 220-240V～
Power consumption (W)
□ 1500W □ 2000W
Dimensions L×W×H (mm)
□660.0×140.0×110.0
Weight (kg)
□ 3.5KG
IP code
□IP65
Infrared receiving Angle
□60°±5°
RESET OPERATION
⚫Press the Reset button shortly,the power will be adjusted
accordingly(Low,Middle ,High,ON/OFF)
⚫Press the Rest button for at least 4 seconds ,the heater will restore factory
settings

Remote Control Instructions
Button
Graphic
Feature
Up Arrow
Up one heating level
Max
The heater goes directly to the highest heating
level.
Down
Arrow
Down one heating level
On
To switch the heater on:
Press ON. The patio heater has a soft start
function of 33% power. 4 seconds after the
heater has been turned on, it will automatically
switch to the last heating level used. In case of
the first-time use, after 4seconds the heater will
automatically switch to 100% power.
Off
To switch the heater off:
Press OFF. The heater will switch to standby
mode(the receiver indicator will light up).
Notice：
⚫Use 2 pieces AAA size1.5V batteries in the remote control.
Remove the battery when not use for long time,
thus the lifespan of remote control can be extended.
⚫Choose the same specification battery when replacing the
battery inside,otherwise it may cause remote control not
work ,thereby affect the normal use of the heater.
⚫Please contact service agent for further help if you need
the function.
⚫The remote control function may be out of work if there is a
barrier between the remote control and heater .
⚫Replacing the batteries duly so as not to affect the normal use of
heater and remote control.

Operation Instruction
⚫Remove all package material (including anti-vibration object of the lamp) and
check the appliance, supply cord and the plug for signs of damage.
⚫Pay attention to the mounting place and all mounting material(dowels, screws).
Ensure they are suitable and stable enough for mounting and lastingly holding
of the appliance.
⚫Before mounting, the minimum safe mounting distances and tilt angles shown
in the figures must be strictly followed.
⚫The distance between the bottom edge of the appliance and the floor must be
at least 1.8 M. See figure 2.
⚫There must be a distance of at least 0.25 M between the appliance and the
ceilings, roofs or other covers. See figure 2.
⚫There must be a distance of at least 0.5 M at each side between the appliance
and walls or the like. See figure 2.
⚫Recommended degree to mounting surface is 45°. See figure 3.
⚫Pay attention that, the installation of the appliance must not add excessive
wind load. (can not use fan to blow the heater or add spare part inside the
heater)
⚫Fix the mounting bracket to the ceiling l first. Ensure that the place to be
installed is secure and firm. Or connect the appliance to the stand.
⚫Adjust the desired angle of radiation and fest screw all screws. Check regularly
the screw's connection. Mechanical bearing pressure and oscillation due to
wind or rain could lead to loose.
⚫Plug in the power source and operate the remote control. Then observe,
whether during the first 10-15 minutes the appliance works trouble-free.
⚫If you do not use,please remove batteries from the socket of remote control.
⚫Do not mount face down, only at 45 degree angle!

Figure1: Mounting bracket and anchor
dowels provided. Connection from the wall
to the infrared heater.
Figure2: Min. distance to floor, ceiling and
wall.
Figure3: Tilt angle.
Figure 4: Max.remote distance

Do not mount face down,
only at 45 degree angle!
Cleaning and Maintenance
⚫This appliance is consist of a robust and maintenance-free aluminum casing
with a protection cover. No user serviceable parts inside.
⚫Before cleaning,remove the plug from the power outlet and wait until the
appliance is sufficiently cooled off.
⚫Wipe the appliance only with clean and lint-free cloth or a soft brush.
⚫Never use abrasive cleaners, scrubbing brushes and chemical cleaners for
cleaning!
⚫Can use alcohol to clean the appliance.
⚫To protect against electrical shock and danger of life, do not immerse cord, plug,
or any part of the appliance in water or other liquid.
⚫For heating element replacement ,please contact the manufacturer or its
service agent or a similarly qualified person.
⚫Any other service, please contact with the service agent or a suitably qualified
electrician.

Storage
Do not route cord when heater storage, or heater is not in use.
Disposal
In accordance with European Directive 2011/65/EU concerning used electrical
and electronic appliances (waste electrical and electronic equipment –
WEEE), please return any electrical equipment that you will no longer use to
the collection points provided for their disposal.
This symbol indicates that the appliance cannot be treated as normal
domestic trash, but must be handed to a collection point for recycling
electric and electronic appliances.
Information concerning where the equipment can be disposed of can be
obtained from your local authority.
Customer Service
⚫Repairs must be carried out by authorized specialists, thus ensuring electrical
safety.
⚫Please contact with the service agent or a suitably qualified electrician.
⚫Improper repairs could lead to danger to the user.
⚫This warranty does not cover damage of failure which results from alteration,
accident, misuse, abuse, neglect, commercial use or improper maintenance.
⚫In line with our policy of continuous product development we reserve the right
to change the product and documentation specifications without notice.
Warning!
When you switch off the heater by only using the remote, the heater will remain
stand-by. Always switch off the heater by using the remote as well as the main switch
on the side of the unit and unplug it from the electrical outlet.
Do not leave the heater unattended and always use the main switch on the side of the
unit to switch off the heater.
