PRYME BLU BT-523 User manual

QUICK START
1. Connect the PRYME BLU adapter to a compatible two-way radio.
2. Pair the PRYME BLU Adapter with a compatible wireless audio accessory.
3. Connect a wired audio or PTT accessory to the Quick-Disconnect accessory port on the
PRYME BLU Adapter (optional).
4. Test and use.
STEP ONE: Connecting to Two-Way Radio
To connect your PRYME BLU Adapter to a two-way radio, follow these steps:
*Always turn o your two-way radio before connecting the PRYME BLU Adapter.
*Plug the PRYME BLU adapter into the speaker-microphone / audio accessory jack of your two-way radio.
*On some models of two-way radio, you may need to tighten a retaining screw to ensure that the
PRYME BLU adapter remains attached to the radio
*Turn on your two-way radio and verify that the radio transmits and receives with the adapter attached.
*Because no wireless audio accessory will yet be paired to the PRYME BLU Adapter, received signals
should be heard over the radio’s internal speaker and transmitted signals will be sent using the radio’s
internal microphone.
*The Talk button on the PRYME BLU Adapter will not function as a Push-to-Talk button for your two-way
radio until a wireless audio accessory is successfully paired to the adapter, or a wired audio accessory is
plugged into the Quick-Disconnect port.
2
3 4
PRYME BLU ADAPTER USER’S GUIDE For Compatible Wireless Audio Accessories
Quick Disconnect Accessory Port
Allows the connection of a PRYME QD
series wired audio accessory, such
as a Push-to-Talk, earphone,
or auxiliary microphone.
Bluetooth Adapter Model No.: BT-523 Made in Taiwan FCC ID: N2E-BT-523
Radio Connector
This port connects the PRYME BLU
Adapter to a compatible two-way radio.
Multi-Function Talk Switch / Status LED
Used to place the PRYME BLU Adapter in pairing mode.
The LED ashes messages that let the user know the
current status of the PRYME BLU Adapter. Once paired
with an audio accessory, this switch is used to activate
the Push-To-Talk function of the two-way radio.
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. To maintain compliance with FCC RF exposure compliance requirements, please avoid direct contact to the transmitting antenna during transmitting. RF Exposure Warning! Please keep product 20cm away from your body or bystander during the radio operation.The typical handheld two-way radios were certied under mobile usage condition (i.e. keep 20cm away from the user body) and use of such radio closer than 20cm may exceed the US RF exposure limit and shall be avoided.
STEP TWO: Pairing with an Audio Accessory
* Turn o the radio that the PRYME BLU Adapter is connected to. Wait at least three seconds.
* Turn the radio on while holding down the Talk button on the PRYME BLU Adapter.
* Continue to hold the Talk button down for approximately three seconds. Release the Talk button
when the status LED begins to ash two times per second.
* The PRYME BLU Adapter is now in audio accessory pairing mode. Activate the pairing mode on
your compatible wireless audio accessory.
* Once the wireless audio accessory and PRYME BLU Adapter are paired with each other, the status
LED on the adapter will show a constant blue light for three seconds.
*If the PRYME BLU Adapter does not detect a compatible wireless accessory within 60 seconds
of being put into pairing mode, the adapter will exit the pairing mode and resume normal operation.
* Once successfully paired, you will be able to operate your two-way radio using your compatible
wireless accessory.
Pairing With an Audio Accessory
Connecting the Adapter to Radio
Controls and Connection
The PRYME BLU Adapter allows you to use a compatible wireless headset or other audio accessory with your two-way radio.
version 1.0 July 2009
PRYME® and PRYME BLU™ are trademarks owned by PRYME Radio Products, Brea CA. All other product or service names are the property of their respective owners. © 2009 PRYME Radio Products, Brea CA. All Rights Reserved
911 Mariner St., Brea, CA 92821
PH: 714.257.0300 FAX: [phone]
TOLL FREE: 800.666.2654
WWW.PRYME.COM

6
STEP THREE: Using a PRYME Quick-Disconnect Wired Audio Accessory (Optional)
The Quick-Disconnect port on the PRYME BLU Adapter allows the connection of a compatible
wired PRYME QD series accessory. This includes compatible earphones, surveillance kits, remote
microphones, and Push-To-Talk accessories.
*To connect a wired accessory, rst turn o the two-way radio that the PRYME BLU Adapter
is connected to.
*Lift up and remove the protective jacket covering the Quick-Disconnect port on the PRYME BLU
Adapter to expose the connector.
*Align the Quick-Disconnect connector of the audio adapter with the Quick-Disconnect port
on the PRYME BLU Adapter and push the connectors together gently until they click into place.
NOTE: the male and female ends of the quick release connectors are keyed so they must be
properly aligned before the two halves can be pushed together.
*To remove a wired accessory that has been installed, gently lift up on the outer cover of the
Quick-Disconnect connector until the accessory is released and then pull up to remove the accessory.
5
STATUS LED MESSAGES
The meanings of the various status LED messages shown by the PRYME BLU Adapter
are shown on the following table:
TROUBLESHOOTING
My wireless audio accessory will not pair with the PRYME BLU Adapter.
Follow the instructions to place the PRYME BLU Adapter into the correct pairing mode
and then activate the pairing mode on the accessory. Make sure that the PRYME BLU Adapter
and accessory being paired are within one meter of each other.
My wireless audio accessory or worked before, but is not working now.
Make sure that the PRYME BLU adapter is properly connected to the two-way radio and
that the radio is turned on. Ensure that your wireless audio accessory has a fully charged
battery and is turned on. If the devices will still not work, re-pair the PRYME BLU adapter
to the wireless accessories.
7
LED INDICATION
One flash per minute
Two flashes per minute
One long flash for three seconds
No indication
MEANING
Normal operation
Audio accessory pairing mode active
Successfully paired or re-paired
Radio is turned off
Status LED
SUPPORT AND WARRANTY
PRYME Radio Products warrants this product against defects in materials or workmanship
for a period of one year from the date of retail purchase. PRYME will repair or replace a
defective unit, at our option, without charge for parts or labor. The limited warranty is
extended only to the original purchaser and is valid only to consumers in the United
States and Canada. It does not cover damage or failure caused by or attributable to Acts
of God, abuse, misuse, improper or abnormal usage, faulty installation, improper
maintenance, lightning, or other incidences of excessive voltage, or any tampering or
repairs by other than a PRYME authorized repair facility. It does not cover replacement of
consumable parts, transportation costs, or damage in transit.
Repair or replacement under the terms of this warranty does not extend the terms of this
warranty. This warranty can only be modied by an ocer of PRYME Radio Products, and
then only in writing. Should this product prove defective in workmanship or material, the
consumer’s sole remedies shall be such repair or replacement as provided by the terms of
this warranty. Under no circumstances shall PRYME Radio Products be liable for any loss or
damage, direct, consequential, or incidental, arising out of the use of or inability to use this
product. Some states do not allow limitations on how long an implied warranty lasts or
the exclusions or limitations of incidental or consequential damages, so the above
limitations or exclusions may not apply to you. This warranty gives you specic legal rights.
You may also have other rights, which may vary, from state to state.
For support or warranty service on your PRYME product, contact us at 1-800-666-2654
or visit us on the web at www.PRYME.com.
COPYRIGHT AND TRADEMARK INFO
© 2009 PRYME Radio Products, Brea CA. All rights reserved.
PRYME® and PRYME BLU™ are trademarks owned by PRYME Radio Products. All other
product or service names are the property of their respective owners.
DISCLAIMER: The wireless link used by PRYME BLU products is an open standard,
unsecured technology. As such, it is not recommended for rst-responder or other
mission critical users.
STEP FOUR: Transmit and Receive Operation
The PRYME BLU Adapter will automatically route radio calls based on the following priority:
*If an audio accessory is connected to the Quick-Disconnect Port of the PRYME BLU Adapter,
radio calls will be routed to this accessory.
*If no wired accessory is connected, calls will be routed to a wireless accessory, if one is paired
with the PRYME BLU Adapter.
*If no wireless headset or audio accessory is paired to the PRYME BLU Adapter or the wireless
accessory is turned o, calls will be routed to the internal speaker of the two-way radio.
NOTE: When a new accessory is connected, paired, disconnected, or powered o, it may take
several seconds for the audio from received radio calls to be routed appropriately.
Push-to-Talk can be activated by any of the following methods:
*Pressing and holding the Talk button of the PRYME BLU Adapter
*Using the PTT button on a wired PRYME Quick-Disconnect accessory (if one is connected to
the PRYME BLU Adapter)
When transmitting, the operator’s voice is picked-up by:
*The microphone in the wired-audio accessory connected to the Quick-Disconnect port on
the PRYME BLU Adapter.
* If no wired audio accessory with a microphone is connected, the microphone in the paired
wireless audio accessory will be used.
* If no audio accessory is paired with the PRYME BLU Adapter, or the paired wireless audio
