Pullman Holt Gloss Boss Application guide

Replacement Parts List

01
SINGLE BRUSH BASE ASSEMBLY
39
43
14
47
46
29
45
44
32
36
5
30
31
3
10
38
26
15
21
2
37
25
12
6
34
16
7
17
4
15
1
8
19
11
24
27
22
9
25
28
35
33
18
13
41
42
49
23
20
48
50

01
REF PART NO. DESCRIPTION QTY REF PART NO. DESCRIPTION QTY
1 202475 SPRING 1 26 409150 WASHER 2
2 204329 SPACER 3 27 409156 WASHER 1
3 206829 FLANGE 1 28 409175 WASHER 1
4 212363 ENTRETOISE 1 29 409212 WASHER 1
5 212364 BUSHING 1 30 409236 SHIM 3
6 212365 SPACER 1 31 409328 SHIM 1
7 212375 FLANGE 1 32 GB14-409831 COVER 1
8 212413 PIN 1 33 410443 NUT 1
9 213120 SUPPORT 1 34 415783 SCREW 3
10 213121 SUPPORT 1 35 416431 SCREW 2
11 213122 TIGHTENER 1 36 420647 SUPPORT 1
12 213170 PULLEY 1 37 GB14-421111 BELT 1
13 213251 PIPE 1 38 GB14-421121 SOLENOID VALVE 1
14 213391 PIPE 1 39 421576 PIPE 1
15 407663 SCREW 4 41 GB-421743 MALE COUPLING 1
16 408420 BEARING 3 42 422091 SPLASH GUARD 1
17 408435 BEARING 2 43 422183 COCK 1
18 408506 SCREW 2 44 422184 ELBOW 1
19 408674 SCREW 1 45 422186 FITTING 1
20 408966 SCREW 1 46 422187 COVER 1
21 408983 SCREW 3 47 422206 BUSHING 1
22 408986 SCREW 1 48 422462 CARBON BRUSH 4
23 409080 LOCK NUT 2 49 422660 MOTOR 1
24 409082 LOCK NUT 1 50 422790 CARBON BRUSH HOLDER 1
25 409085 LOCK NUT 4
SINGLE BRUSH BASE ASSEMBLY

02
ASSEMBLY FRAME
38
26
13
36
27
19
24
27
14
4
8
235
29
22
17
1
16 21
10 30
17
2236
18
23
33
3
34
31
25
42
41
40 12
43
28
5
32
11
20
15
7
6
39
21
26
44
9
37

02
REF PART NO. DESCRIPTION QTY REF PART NO. DESCRIPTION QTY
1 212368 BUSHING 2 23 409192 WASHER 2
2 212373 PIN 1 24 409666 CONNECTOR 2
3 212412 BUSHING 2 25 409683 HANDLE 1
4 213323 PROFILE 1 26 410277 CLAMP 6
5 214124 PLAQUE 1 27 415897 LOCK NUT 8
6 214125 SUPPORT 1 28 416319 RUBBER CAP 2
7 405832 DEADENING 1 29 420585 BATTERY BASE 1
8 407661 SCREW 1 30 420599 PLAQUE 1
9 407665 SCREW 1 31 GB14-420601 COVER 1
10 408674 SCREW 2 32 420672 SUCTION MOTOR 1
11 408690 SCREW 1 33 420674 WHEEL 200X42 2
12 408884 SCREW 2 34 421080 SCREW 2
13 408893 SCREW 2 35 421082 SCREW 2
14 408922 SCREW 8 36 421083 SCREW 4
15 409082 LOCK NUT 3 37 421106 CARBON BRUSH HOLDER 1
16 409085 LOCK NUT 2 38 GB14-421671 BATTERY CHARGER 1
17 409087 LOCK NUT 4 39 422078 SCREW 2
18 409091 LOCK NUT 2 40 422120 BUSHING 2
19 409138 WASHER 4 41 422540 CAP 2
20 409156 WASHER 3 42 422541 HOOK 2
21 409175 WASHER 3 43 423354 FRAME 1
22 409177 WASHER 4 44 423870 DEADENING 1
ASSEMBLY FRAME

03
ASSEMBLY TANKS - ACCESSORIES
2
53
7
9
8
2.7
2.2
2.6
2.8
2.1
2.4
2.5
2.3
2.9
11
10 15
13
1
12
14
64

03
REF PART NO. DESCRIPTION QTY REF PART NO. DESCRIPTION QTY
1 213041 SUCTION HOSE 1 4 415952 RIVET 4
2 213190 CAP 1 5 420609 HOOK 2
2.1 212372 SUPPORT 1 6 421675 COVER 2
2.2 405466 GASKET 1 7 421744 FEMALE COUPLING 1
2.3 411988 CLAMP 1 8 421746 PIPE 1
2.4 416771 V-RING 1 9 421933 SOLUTION TANK 1
2.5 420604 CAP 1 10 421935 RECOVERY TANK 1
2.6 420606 FITTING 1 11 422004 CAP 1
2.7 420607 FITTING 1 12 422064 O-RING 1
2.8 421109 V-RING 1 13 422693 PROTECTION 1
2.9 421662 FILTER ASSEMBLY 1 14 423100 FILTER 1
3 408963 SCREW 4 15 423102 COVER 1
ASSEMBLY TANKS - ACCESSORIES

04
SQUEEGEE ASSEMBLY
6
3
4
13
14
12
11
5
1
2
7
10
8
8
1
9
15
16
59
5
17

04
REF PART NO. DESCRIPTION QTY REF PART NO. DESCRIPTION QTY
1 GB14-14-212936 BUSHING 3 10 GB14-421733 WING NUT 6
2 213231 SQUEEGEE BODY 1 11 421930 SCREW 2
3 407667 SCREW 2 12 GB14-421931 SCREW 2
4 408905 DOWEL 2 13 GB14-422112 OPENING 1
5 GB14-409157 WASHER 5 14 GB14-422113 O-RING 1
6 GB14-420648 FRONT RUBBER 1 15 GB14-423193 BLADE 1
7 GB14-420649 REAR RUBBER 1 16 GB14-423263 BLADE 1
8 GB14-421080 SCREW 3 17 424040 SCREW 2
9 GB14-421101 WHEEL 3 213157 SQUEEGEE ASSEMBLY 1
SQUEEGEE ASSEMBLY

05
SQUEEGEE CONTROL ASSEMBLY
13
2
5
1
10
7
3
11 14 8
6
12
4
9

05
REF PART NO. DESCRIPTION QTY REF PART NO. DESCRIPTION QTY
1 213690 ARM 1 8 409162 WASHER 1
2 213691 SUPPORT 1 9 409382 SPLIT PIN 1
3 213723 SUPPORT 1 10 410225 KNOB 2
4 408517 SCREW 1 11 414689 SPACER 1
5 408651 SCREW 2 12 416781 LOCK NUT 1
6 409082 LOCK NUT 2 13 GB14-420695 CABLE 1
7 409156 WASHER 2 14 421730 SPRING 1
SQUEEGEE CONTROL ASSEMBLY

06
HANDLE BAR ASSEMBLY
5
1
11
9
3
16
19
4
13
2
20
13
14
10
6
17
5.9
5.8
5.7
5.2
5.4
5.1
5.5
5.3
5.6
7
22
15 24
21
23
18
8
12

06
REF PART NO. DESCRIPTION QTY REF PART NO. DESCRIPTION QTY
1 212367 ROD 1 9 408670 SCREW 4
2 212369 TIE ROD 1 10 408798 SCREW 2
3 212370 PIN 1 11 408802 SCREW 2
4 212371 PIPE 1 12 408965 SCREW 1
5 213171 JOINT 1 13 409082 LOCK NUT 5
5.1 416497 LEFT SUPPORT 1 14 409085 LOCK NUT 4
5.2 204457 PIN 1 15 409156 WASHER 1
5.3 416727 SPRING 1 16 410265 KNOB 1
5.4 416774 O-RING 2 17 415805 SCREW 2
5.5 416698 SCREW 1 18 415855 SCREW 2
5.6 409180 WASHER 1 19 416820 FAIRLEAD 1
5.7 212971 JOINT 1 20 420608 SUPPORT 2
5.8 416499 RIGHT SUPPORT 1 21 GB14-423322 COVER 1
5.9 409085 LOCK NUT 1 22 GB14-423323 LEVER 1
6 214261 STEERING WHEEL ASSEMBLY 1 23 423840 PLAQUE 1
7 GB14-407644 SCREW 1 24 423847 SPACER 1
8 407661 SCREW 1
HANDLE BAR ASSEMBLY

06A
HANDLE BAR ASSEMBLY
10
14
6
6
11
17
2
13
12
3
4
1
19
7
8
5
16
9
6
6
20
18 15
21
22

06A
REF PART NO. DESCRIPTION QTY REF PART NO. DESCRIPTION QTY
1 214541 LEVER 1 12 414688 SPACER 1
2 400738 CABLE FASTENER 1 13 414707 BUSHING 1
3 408109 SPRING 1 14 415753 SCREW 1
4 GB14-408174 HANDLE BAR BODY 1 15 415866 SCREW 4
5 408834 SCREW 1 16 415898 LOCK NUT 1
6 408871 SCREW 12 17 416316 COVER 1
7 409077 LOCK NUT 1 18 GB14-421244 CARD 1
8 409139 WASHER 2 19 GB14-421748 MICROSWITCH 1
9 409144 WASHER 1 20 422110 CAP 1
10 409153 WASHER 1 21 GB14-423061 HANDLE BAR COVER 1
11 409827 PLUG 1 22 GB14-423065 DECAL 1
HANDLE BAR ASSEMBLY (close-up)

07
ELECTRONICAL CONTROL ASSEMBLY
4
7
2
1
6
3
5

08
ACCESSORIES
6 5 7
4
3
2
1

07
REF PART NO. DESCRIPTION QTY REF PART NO. DESCRIPTION QTY
1 407663 SCREW 1 5 GB14-423047 CABLE 1
2 409082 LOCK NUT 1 6 423067 PANEL 1
3 409156 WASHER 1 7 423068 COVER 1
4 421243 RELAY CARD 1
08
REF PART NO. DESCRIPTION QTY REF PART NO. DESCRIPTION QTY
1 1 5 GB14-421701 BRUSH 1
2 410575 CENTER LOCK 1 6 422001 PAD HOLDER 1
3 421359 CABLE 1 7 422213 PAD HOLDER 1
4 421360 CABLE 1
ELECTRONIC CONTROL ASSEMBLY
ACCESSORIES

A1
ASSEMBLY BATTERY CHARGER
11
4
27
9
7
10
6
17
13
24
1
26
21
3
18
5
15
12
20
16
25
8
17
23
2
28
14
11
1
24
22
19
19
14 30
29
31
5

A1
REF PART NO. DESCRIPTION QTY REF PART NO. DESCRIPTION QTY
1 212368 BUSHING 2 17 415897 LOCK NUT 8
2 213322 PROFILE 2 18 415952 RIVET 4
3 213323 PROFILE 1 19 416048 CONNECTOR CONTACT 2
4 408893 SCREW 2 20 416319 RUBBER CAP 4
5 408922 SCREW 8 21 421080 SCREW 2
6 409040 NUT 2 22 421604 CABLE 1
7 409054 NUT 4 23 GB14-421671 BATTERY CHARGER 1
8 409138 WASHER 4 24 422540 CAP 2
9 409181 LOCK WASHER 4 25 422693 PROTECTION 1
10 409666 CONNECTOR 1 26 423660 BATTERY BASE 1
11 410272 HANDLE 2 27 423661 COVER 1
12 410277 CLAMP 1 28 423670 COVER 1
13 410329 HOOK 2 29 423787 DECAL 1
14 415765 SCREW 4 30 423788 DECAL 1
15 415817 SCREW 4 31 423789 DECAL 1
16 415886 NUT 4
ASSEMBLY - BATTERY CHARGER
