PULSE+ PLS00572 User manual

1
Model: PLS00572
Double-face LED Moving Wash/Beam Light

Please read these instructions carefully before use and retain for future
reference.
IMPORTANT SAFETY INFORMATION
•
When using electrical appliances basic safety precautions should always be
followed.
•
Check the product before use for any damage. Should you notice any damage on
the cable or casing, do not use.
•
Check that the voltage indicated on the rating plate corresponds with that of the
local network before connecting the product to the power supply.
•
Keep this product away from rain and moisture.
•
Caution: Never look directly into the light source.
•
Always disconnect from power when the product is not in use or before
cleaning.
•
Do not operate or store in an environment of high humidity or where moisture may
enter the product as this can reduce insulation and lead to electric shock.
Safety Information for Installation and Operation
•
When installing, make sure that the product is not exposed to extreme heat,
moisture or dust.
•
If you’re using a smoke machine, make sure that the product is never exposed to
the direct smoke jet and is installed at least 1.5'away.
•
The ambient temperature must always be between 23°F and 113°F. Keep away
from air-conditioning units and heaters.
•
The relative humidity must not exceed 50% with an ambient temperature of 113°F.
•
This product must only be operated in an altitude between -65' and 6560'above
sea level.
•
The minimum distance between the light-output and the illuminated surface must
be more than 1.5'.
•
This product is allowed to be installed via a mounting bracket. In order to have
sufficient ventilation, leave 20" of free space around the device.
•
The housing must not touch any surrounding surfaces or objects.
•
Operate the product only after having familiarized yourself with its functions. Do not
allow operation by persons unqualified.
•
A secondary means of suspension must be provided, such that in the event of a
failure of the primary suspension, no part of the luminaire can fall.
•
The operator must make sure that safety related matters are observed and that
the installation is approved by a qualified installer before taking into operation for
the first time.
2

PRODUCT OVERVIEW
SETUP
Fuse Replacement
• With a at head screwdriver, prise the fuse holder out of its housing.
• Remove the defective fuse from its holder and replace with the same fuse
specication.
• Put the fuse holder back in its place and reconnect the power.
Fixture Linking
• You will need a serial data link to run light shows of one or more xtures using a
DMX-512 controller or to run synchronized shows on two or more xtures set to a
master/slave operating mode.
• The combined number of channels required by all the xtures on a serial data link
determines the number of xtures the data link can support.
• Important: Fixtures on a serial data link must be daisy chained in one single
line. To comply with the EIA-485 standard no more than 32 devices should be
connected on one data link. Connecting more than 32 xtures on one serial data
link without the use of a DMX optically-isolated splitter may result in deterioration
of the digital DMX signal.
• Maximum recommended serial data link distance: 1640ft
Data Cabling
• To link xtures together you must obtain data cables.If you choose to create your
own cable please use data-grade cables that can carry a high quality signal and
are less prone to electromagnetic interference.
3
MENU UPDOWN ENTER

4
CABLE CONNECTIONS
• Cabling must have a male XLR connector on one end and a female XLR
connector on the other end.
• Caution: Do not allow contact between the common and the xture’s chassis
ground. Grounding the common can cause a ground loop, and your xture may
perform erratically. Test cables with an ohm meter to verify correct polarity and to
make sure the pins are not grounded or shorted to the shield or each other.
3-PIN TO 5-PIN CONVERSION CHART
• Note: If you use a controller with a 5pin DMX output connector, you will need to
use a 5-pin to 3-pin adapter.
Conductor 3-pin female (output) 5-pin male (input)
Ground/Shield Pin 1 Pin 1
Data (-) signal Pin 2 Pin 2
Data (+) signal Pin 3 Pin 3
Termination reduces signal errors. To
avoid signal transmission problems and
interference, it is always advisable to
connect a DMX signal terminator to the
output of the nal xture in the chain.
DMX Data Cable
• Use a Belden 9841 or equivalent cable that meets the specications for EIA RS-
485 applications. The cable will have the following characteristics:
- 2-conductor trwitsed pair plus a shield
- Maximum capacitance between conductors - 30pF/ft
- Maximum capacitance between conductor and shield - 55pF/ft
- Maximum resistance of 20Ω / 1000ft
- Nominal impedance 100-140Ω.
• Standard microphone cable cannot transmit DMX data reliably over long
distances.
SETUP

5
SETTING UP A DMX SERIAL DATA LINK
• Connect the (male) 3-pin connector side of
the DMX cable to the output (female) 3-pin
connector of the controller.
• Connect the end of the cable coming from
the controller, which will have a (female) 3-pin
connector, to the input connecotr of the next
xture consisting of (male) 3-pin connector.
• Then proceed to connect from the output
as stated above to the input of the following
xture and so on.
MASTER/SLAVE FIXTURE LINKING
• Connect the (male) 3-pin connector side of the DMX cable to the output (female)
3-pin connector of the rst xture.
• Connect the end of the cable coming from the rst xture, which will have a
(female) 3-pin connector, to the input connector of the next xture consisting of a
(male) 3-pin connector.
• Then proceed to connect from the output as stated above to the input of the
following xture and so on.
• Often, the setup for Master-Slave and Standalone operation requires that the rst
xture in the chain is initialised for this purpose via either the settings in the control
panel, or DIP switches.
• Secondly, the xtures that follow may also require a slave setting. See “Operating
Instructions” on page 6 for guidance on this type of setup.
MOUNTING
Orientation
• This xture may be mounted on a suitable base in any position provided there is
adequate room for ventilation.

6
OPERATING INSTRUCTIONS
Navigating the Control Panel
• Access the control panel functions using the four panel buttons located directly
beneath the LCD.
MODE/ESC Used to access the menu or to go to
a previous menu option.
UP Scrolls through the menu options in
ascending order
DOWN Scrolls through the menu options in
descending order
ENTER Used to select and store the current
menu or option within a menu
• The control panel LED display shows the menu item that you have selected.
• When a menu item is selected, the display will show immediately the rst available
option for the selected menu function. To select a menu item, press ENTER.
• Press the MODE/ESC button repeatedly until you reach the desired menu
function. Use the UP and DOWN buttons to navigate the menu options.
• Press the ENTER button to select the menu function currently displayed, or to
enable a menu option.
• To return to the previous option or menu without changing the value, press the
MODE/ESC button.
PHOTOMETRIC DIAGRAM
Addr
Chnd
15CH
21CH
A001-A512
SLnd MAST
Soun
SL 2
SL 1

7
SHnd SH 0
SH 2
SH 1
SH 3
bLAnd
0-99SEnS
bLAc
Soun
Auto
HoLd
OFF
ON
no
YES
no
YES
no
YES
YES
LEd
dISP
rPAN
rTiL
REST

8
USER CONFIGURATION
To set the PAN to inverting or non-inverting
• Press the MODE button until it shows “Pan Inverse”, then press ENTER and the
LCD will show “OFF” or “ON”.
• Use the UP/DOWN buttons to set the desired inversion and press ENTER to
conrm.
To set the Tilt to inverting or non-inverting
• Press the MODE button until it shows “Tilt Inverse”, then press ENTER and the
LCD will show “OFF” or “ON”.
• Use the UP/DOWN buttons to set the desired inversion and press ENTER to
conrm.
To set the DMX channel configuration
• Press the MODE button until it shows “Channel set”, then press ENTER and the
LCD will show “9CH” or “16CH”.
• Use the UP/DOWN buttons to set the desired channel mode and press ENTER to
conrm.
SERVICE FUNCTIONS
To reset the xture:
• Press the MODE button until the display shows “FIXTURE REST”.
• Press ENTER to conrm your selection.
To restore all settings to their factory defaults:
• Press the MODE button until the display reads “DEFAULT CONFIRM”.
• Press ENTER to conrm your selection.
OPERATION MODE
• Press the MODE button until it reads “Show Mode”, then press ENTER and the
LCD will show modes for you to choose.
• Use the UP/DOWN buttons to set the desired inversion, then press ENTER to
conrm.
Fast Mode/Slow Mode (Auto Mode):
• This mode allows a single unit to run to a factory installed programme in one of
two speeds:
“1) To set a xture in Fast Mode, then the light will run in a fast speed running.”
“2) To set a xture in Slow Mode, then the light will run in a fast speed running.”
Master/Slave Mode
• This mode will allow you to link up to 32 units together without a controller.
• Use standard DMX cables to daisy chain your units together via the DMX
connector on the rear of the units. Proper performance it may be necessary to use
a terminator at the last xture.

9
• Choose a unit to function as the Master, then select one mode as auto running
programme.
• Finally, chain the units together using DMX cable, Fast Mode or Slow mode can be
the Master one’s programming.
• The other units are set to the same DMX Address (001 or 017).
DMX MODE
• This mode allows the unit to be controlled by any universal DMX controller.
• The default mode for the xture is DMX, which appears as “001” on the LCD.
DMX CHANNEL VALUES (15 CHANNELS)
Channel Range Function
1 0~255 X motor
2 0~255 Y motor
3 0~255 XY motor speed
40~255 Y axis innite rotation
5 0~255 Dimmer total
60~255 Strobe
7 0~255 Red 12 dimmer total
80~255 Green 12 dimmer total
9 0~255 Blue 12 dimmer total
10 0~255 White 12 dimmer total
11 16~255 Motor auto run
12 0~255 Motor auto run speed
13 8~255 Light bulb auto run
14 0~255 Light bulb auto run speed
15 250~255 (5 sec) Reset

10
CLEANING & MAINTENANCE
• Disconnect from power before starting the maintenance operation.
• Frequent cleaning is recommended. Use a soft lint-free moistened cloth.
• Do not use any chemicals, abrasives or solvents that could damage the device.
• There are no user-serviceable parts in this product. Refer all servicing to qualied
personnel.
DMX CHANNEL VALUES (21 CHANNELS)
Channel Range Function
1 0~255 X motor
2 0~255 X motor ne
3 0~255 Y motor
40~255 Y motor ne
5 0~255 XY motor speed
60~255 Y axis innite rotation
7 0~255 Dimmer total
80~255 Strobe
9 0~255 Red 1 dimmer total
10 0~255 Green 1 dimmer total
11 0~255 Blue 1 dimmer total
12 0~255 White 1 dimmer total
13 0~255 Red 2 dimmer total
14 0~255 Green 2 dimmer total
15 0~255 Blue 2 dimmer total
16 0~255 White 2 dimmer total
17 16~255 Motor auto run
18 0~255 Motor auto run speed
19 8~255 Light bulb auto run
20 0~255 Light bulb auto run speed
21 250~255 (5 sec) Reset

11
SPECIFICATION
Voltage
Power Consumption
Light source
DMX mode
Control
Display
Rotating angle
Function
Work environment
Dimension
Weight
AC 100-240V 50-60Hz
70W
1pcs x 10W RGBW CREE LED + 4pcs x RGBW 10W
LED
17/23 Channel
DMX 512, Master-slave, Auto run, Sound
Digital display
X axis: 540°, Y axis: infinite rotation
8 internal program, sound controlled by DMX 512
50°F - 104°F
12.8" x 9.8" x 10.6"
5.51 lbs.

12
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF
ELECTRICAL & ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical
& Electronic Equipment (WEEE). Any WEEE marked products must not be mixed with
general household waste, but kept separate for the treatment, recovery and recycling
of the materials used. Contact your local authority for details of recycling schemes in
your area.
Made in China. PR2 9PP
Man Rev 1.0
