Pumps Australia AV Series User manual

pumpsaustralia.com.au
1800 790 915
AVSERIES
USER MANUAL

PAGE
2PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
INTRODUCTION:
This manual explains how to use this equipment and gives instructions on the
precautions to take during use. To understand all the features of the AV Series pumps and how to use it in the
most e󰀨ective manner, read this manual before using the equipment. This equipment should not be used for
applications other than those listed in this manual.
We recommend that the manual be kept on hand so that you may be able to refer to it at a later date. Should
the equipment be on sold or used by other personnel, please make sure that the manual is also passed on. In
case this manual is lost or damaged, please contact theequipment dealer from whom you purchased the AV
Series pump.
This manual was prepared with the utmost attention to detail. However, if you nd any errors or omissions,
contact the dealer from whom you purchased the equipment. The AV Series pump, can be supplied as a bare
shaft unit or mounted to a petrol or a diesel engine. This AV Series pump is extensively used by commercial
and industrial plant operators like builders, civil contractors, the hire industry and municipal services. This
pump is a semi– open impeller, self-priming with a suction check valve. The basic materials of construction is
aluminium casing, with cast iron impeller and chromate steel discharge port.
Our AV Series pumps have been designed and manufactured with safety in mind, however there are certain
basic precautions which should be taken by the user.
CONDITIONS FOR USE:
· Maximum ambient temperature: 50 C.
· Maximum operating temperature: 35 C.
· Minimum operating temperature: -10 C.
SAFETY INFORMATION:
Operating Safety
Failure to follow instructions in this manual may lead to serious injury or even death!
This equipment is to be operated by trained and qualied personnel only! The following safety guidelines
should always be used when operating any of the AV Series pumps:
· Never operate this machine in applications for which it is not intended or before
reading the manual in full.
· It is important that no one can operate this equipment without proper training. People operating this
equipment must be over 18 years of age and must be familiar with the risks and the hazards associated with it.

OPERATING INSTRUCTIONS
Connect the delivery hose to the outlet of the pump, again ensuring that the joint is airtight
(to prevent water spraying at this joint.)
Warning: Read the Engine Manufactures manual before attempting to start the unit. Obey any cautionary
instructions appertaining to the power unit (such as checking fuel in tank, and oil levels etc.) Start the power unit.
PAGE
3
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL
WARNING: To reduce the risk of injury, read operating instructions carefully before using.
Read the owner’s manual thoroughly. Failure to follow instructions could cause
malfunction of the machine and result in death, serious bodily injury and/or property
damage.
WARNING: This machine exceeds 85 dB appropriate ear protection must be worn.
WARNING: Risk of injury. Hot surfaces can cause burns. Use only designated gripping
areas of spray gun and wand. Do not place hands or feet on non-insulated areas of the
pressure washer.
To reduce the risk of injury, close supervision is necessary when a machine is used near children.
Do not allow children to operate the unit. This machine must be attended during operation.
WARNING: Risk of asphyxiation. Use this product only in a well ventilated area.
Avoid installing machines in small areas or near exhaust fans. Adequate oxygen is needed for
combustion or dangerous carbon monoxide will result.

Trouble Cause Solution
Unable to self prime
(suck) Liquid
Pump casing with insu󰀩cient
priminng liquid Add more priming uid
Inlet strainer or valve is fully or
partially blocked Clean or change the strainer or foot valve
Leakage in the inlet pipe or hose Elimate the leakage
Suction hose is broken Change the suction hose
Broken mechanical seal or gasket
leak due to wear and tear
check and change the
mechanical seal or gaskets
Underszied impeller
Fit with full size 177mm impeller. Smaller
impellers to be used with ooded suction
pumps only
Priming hole inside sump is blocked
Unblock the 12mm priming hole between
the front and back chamber inside the
pump
Suction head (friction losses) are too
high
Re-calulate the pipe friction losses, x
suction pipe
accordingly
Can not pump water
or can no reach to
rated capacity (ow)
and head
Check all items above Check all the items above
Suction pipe is not immersed deep
enough and is vortexing Check and submerge inlet deeper
Impeller is damaged or worn Change the worn parts
Impeller is jammed Clean impeller chamber
Rotational speed is too low Check the driver speed / rating
Outlet head is too high Reduce pump head or t a bypass system
in discharge pipework
Suction head is too high Check if the water level from the source
has dropped
Increase in power
absorbed (engine
struggling)
Rotary speed is too high Check the driver power output or the cou-
pling or belt system
Head is too low (ow is too high) Throttle the discharge valve to reduce ow
Liquid is too thick Dilute lquid if necessary
Bearing is failing Check and replace bearings
Pump Jammed Liquid is too viscose Dilute liquid if necessary
Flow is too low
Increase the ow from the pump through
the throttle valve or increase the pump
speed
Foot, Check valve or straier is
blocked Clean valves and strainer
PAGE
4PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD

Trouble Cause Solution
Excessive Noise
Pump is cavitating
Reduce suction head and
suction pipeline friction losses by
increasing the pipe size.
Air leakages in suction Check and eliminate leakage points
Faulty pump - motor / engine
coupling undersized Install correct sized coupling
Impeller blocked or damaged Eliminate block or replace impeller
Pitting of Impeller
and/or
Casing
Pump is cavitating
Reduce suction head and suction pipeline
friction losses by increasing the pipe sizes
Bearing is getting
hotter
(Long Coupled
Models only)
Bearing temperature rise
Test bearing temperature on a regular
basis to ensure that bearing remains within
the normal temperature range
Insu󰀩cient bearing lubrication Check and Correct
Engine / motor shaft vibration Correct vibration
Presence of water in pump bearing
housing
Contact Pumps Australia
Ph. 1800 790 915
Di󰀩cult to Start Engine Problems Check engine manufacturer’s manual
No Fuel in the engine Refuel Tank
Low engine Oil Level Rell to correct oil level
Engine On/O󰀨 switch Turn switch on
Spark Plug fouled (Petrol Only) Clean spark plug and reset gap
Injectors Blocked (Diesel Only) Clean injectors, replace lter
The engine operates
but pressure not to
capacity
Pump sucking air
Pump is blocked
Strainer is dirty / blocked
Check that all hoses / pipes and ttings on
the inlet side of pump are air tight.
Check and clean Pump
Check and clean strainer
Fuel leaking from fuel
tank or lines Fuel leaks Fix fuel leaks or Contact Pumps Australia
PAGE
5
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL

PUMPS AUSTRALIA PTY LTD
PAGE
6
USER MANUAL
Daily Weekly Quarterly Annually
Check hose and water connections for leaks X
Check and clean inlet water strainer X
Check bearing temperatures (Long coupled) X
Inpsect the pump casing for leaks X
Inspect the condition of wear on the impeller (measure
wear gap)
X
or every
2000 Hours
MAINTAINENCE SCHEDULE
The following regular maintenance schedule is recommended as a minimum to keep your
pump in top condition.
The maintenance should be undertaken by suitably qualied sta󰀨. If you are unsure about
how to undertake the maintenance, we suggest that you get in contact with Pumps Australia. It is important
to use original spare parts to maintain the unit in a safe working order and also to maintain your Pumps Aus-
tralia warranty.
PAGE
6PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD

PAGE
7
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL
Coupling Assy. (Engine Side)
Postion Qty Description
A1 Coupling Assy – Extension
B1 Housing Assy – Extension
1 1 Spindle Assy – Extension
2 1 O-Ring – 2.359” x 0.139”
3 1 Pin – Rolled 5/32” x 3/4”
4 1 Spring – Torsion – Modied (Clip O󰀨 Tails)
5 1 Hold Bar
61 Circlip – Internal – Diam 47mm
7 1 Bearing – 20 x 47 x 14S
8 1 Circlip – External – Diam 20mm
9 1 O-Ring – 1.687” x 0.139”
10 1 Adaptor – Housing P212
11 1 O-Ring – 1.049” x 0.103”
Qty Description Includes Parts
1Service Kit – Ext Shaft Trigger 3,4,5
1 Service Kit – Ext Shaft Coupling 2,6,7,8,9,11
Service Kit
PAGE
7
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL

Coupling Assy. (Pump Side)
Postion Qty Description
A1 Coupling Assy
B1 Spindle Assy
1 1 Dog Drive
2 1 Spindle
3 1 Bearing 20 x 42 x 12mm Sealed
4 1 Spacer
5 1 Housing
61 O-Ring - 1.049” x 0.103”
7 1 Grub Screw - 0.312” x 0.312” BSW
8 1 Circlip - External - Diam 20mm
PAGE
8PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
Qty Description Includes Parts
1 Service Kit – Coupling Assy. 3,6,8
Service Kit

Flexible Shaft Assy.
Postion Qty Description
A1Flexshaft Assy (3M Length)
Flexshaft Assy (6M Length)
B1Casing Assy (3M Length)
Casing Assy (6M Length)
C 1 Inner Core Assy (3M Length)
Inner Core Assy (6M Length)
1 1 Ferrule Assy
2 1 Outer Proective Spring (Chromate Plated)
3 1 Core End
PAGE
9
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL

PUMPS AUSTRALIAPTY LTD
PARTS BREAKDOWN
1800 790 915 pumpsaustralia.com.au [email protected]
PUMPS AUSTRALIA PTY LTD
1800 790 915 pumpsaustralia.com.au [email protected]
PUMPS AUSTRALIA PTY LTD
Model: AV50 - 2” Flexi Drive Pump / AV80 - 3” Flexi Drive Pump
26
Postion Qty Description Price (AUD)
1 4 Bolt $4.95 ea
2 4 Flat Washer $1.95 ea
3 1 Subplate $65.00
4 1 Water Net $50.00
5 1 Pump Body $395.00
6 1 2” or 3" Outlet Connector $29.00
7 1 Pump Impeller $265.00
8 3 Oil Seal $14.00 ea
9 1 Pump Body Connector $190.00
10 4 Washer $1.95 ea
11 4 Bolt $4.95 ea
12 2 Bearing $49.00 ea
13 1 Main Shaft $165.00
14 1 Circlip $6.50
15 1 Oil Seal Ring $9.00
16 1 Connector $79.00
17 1 Nut $65.00
18 1 Hose Protector N/A
19 1 Shaft Adaptor N/A
20 1 Flexible Shaft $395.00
21 1 Flexible Hose $395.00
22 1 Hex Plug N/A
23 1 Conical Sleeve N/A
24 1 Shaft Adaptor $49.00
25 1 Coupling Head $98.00
26 1 Hex Plug Connector $24.00
27 2 Bearing $35.00 ea
28 1 Spacer $11.50
29 1 Circlip For Hole $4.90
30 1 Clutch $45.00
Optional Extra’s
Code: Description: Price:
AV/BENDPRO Bend Protector $90.00
AV50/PUMP or AV80/PUMP AV50/AV80 Pump Only $595.00
AV/6MTRDRIVEASSY 6M Drive Only $695.00
AV/6MTREXTEND 6M Ext. Drive (Includes Joiner) $695.00
AV/3MTREXTEND 3M Ext. Drive (Includes Joiner) $495.00
AV/INTCABLE 6M Internal Cable $395.00
AV/COUPLING Engine Coupling Assy. $165.00
AV50/AV80 Complete Kit: $995.00
*All prices exclude GST
Model Weight
(KG)
L
(mm)
W
(mm)
H
(mm)
AV50/AV80 32 810 710 200
Package Information
1800 790 915 pumpsaustralia.com.au [email protected]
PUMPS AUSTRALIAPTY LTD
PARTS BREAKDOWN
1800 790 915 pumpsaustralia.com.au [email protected]
PUMPS AUSTRALIA PTY LTD
Model: AV50 - 2” Flexi Drive Pump / AV80 - 3” Flexi Drive Pump
27
PAGE
10 PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD

PUMPS AUSTRALIAPTY LTD
PARTS BREAKDOWN
1800 790 915 pumpsaustralia.com.au [email protected]
PUMPS AUSTRALIA PTY LTD
1800 790 915 pumpsaustralia.com.au [email protected]
PUMPS AUSTRALIA PTY LTD
Model: AV50 - 2” Flexi Drive Pump / AV80 - 3” Flexi Drive Pump
26
Postion Qty Description Price (AUD)
1 4 Bolt $4.95 ea
2 4 Flat Washer $1.95 ea
3 1 Subplate $65.00
4 1 Water Net $50.00
5 1 Pump Body $395.00
6 1 2” or 3" Outlet Connector $29.00
7 1 Pump Impeller $265.00
8 3 Oil Seal $14.00 ea
9 1 Pump Body Connector $190.00
10 4 Washer $1.95 ea
11 4 Bolt $4.95 ea
12 2 Bearing $49.00 ea
13 1 Main Shaft $165.00
14 1 Circlip $6.50
15 1 Oil Seal Ring $9.00
16 1 Connector $79.00
17 1 Nut $65.00
18 1 Hose Protector N/A
19 1 Shaft Adaptor N/A
20 1 Flexible Shaft $395.00
21 1 Flexible Hose $395.00
22 1 Hex Plug N/A
23 1 Conical Sleeve N/A
24 1 Shaft Adaptor $49.00
25 1 Coupling Head $98.00
26 1 Hex Plug Connector $24.00
27 2 Bearing $35.00 ea
28 1 Spacer $11.50
29 1 Circlip For Hole $4.90
30 1 Clutch $45.00
Optional Extra’s
Code: Description: Price:
AV/BENDPRO Bend Protector $90.00
AV50/PUMP or AV80/PUMP AV50/AV80 Pump Only $595.00
AV/6MTRDRIVEASSY 6M Drive Only $695.00
AV/6MTREXTEND 6M Ext. Drive (Includes Joiner) $695.00
AV/3MTREXTEND 3M Ext. Drive (Includes Joiner) $495.00
AV/INTCABLE 6M Internal Cable $395.00
AV/COUPLING Engine Coupling Assy. $165.00
AV50/AV80 Complete Kit: $995.00
*All prices exclude GST
Model Weight
(KG)
L
(mm)
W
(mm)
H
(mm)
AV50/AV80 32 810 710 200
Package Information
1800 790 915 pumpsaustralia.com.au [email protected]
PUMPS AUSTRALIAPTY LTD
PARTS BREAKDOWN
1800 790 915 pumpsaustralia.com.au [email protected]
PUMPS AUSTRALIA PTY LTD
Model: AV50 - 2” Flexi Drive Pump / AV80 - 3” Flexi Drive Pump
27
PAGE
11
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL

Step 1 Allign Both Drive’s Teeth.
Step 2 Put Coupling Guard to One side, and connect teeth
Step 3 Once teeth have been alligned, move guard over
Step 4 Insert 1 Locking Bolt and Feel out the Locking Groove
Step 5 Once In Position, Insert the 2nd Locking Bolt.
Step 1
- Make sure you have 1x Coupling Guard, 2x Eye Bolts.
- Turn all Cables by Hand to loosen any joints.
Step 2
- Put the Coupling Guard on one of the drives and expose the joiners.
- Allign both of the drive’s teeths
(It’s recommended to turn the other side of your power drive end to
make sure everything is turning and in order)
Step 3
- Once Alligned and checked everything is moving correctly, slide the
Coupling Guard over the Join.
Step 4
- Insert one of the eye bolts in, Using it as a Guide pin.
Step 5
- Insert your second eye bolt and then lock down both bolts into
position.
Installation of the Drive Extension Coupling
PAGE
12 PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD

Notes:
PAGE
13
PHONE: [phone]
PUMPS AUSTRALIA PTY LTD
USER MANUAL

WE SERVICE & REPAIR
ALL MAKES AND MODELS IN OUR FULLY STOCKED WORKSHOP IN WA!
AUSTRALIAN OWNED
& OPERATED
Established in 1997 as a backyard
business, Pumps Australia has had steady
growth over 20 years by supplying quality
products with quality service using quality
people.
Being a rm believer of always having what
you need in stock, our large warehouse locat-
ed in WelAVool carries a HUGE inventory of
stock for our customers. With shipping
overnight.
Carrying stock in Australia isn’t the only thing
that seperates us from the pack.
Our technical expertise with all our products
means we’re there to back you up!
Clinton Farmer; Kutkabubba Aboriginal Corp.
FIRE FIGHTING PUMPS
TRANSFER PUMPS
TRASH PUMPS
CHEMICAL PUMPS
HOUSEHOLD PUMPS
HIGH PRESS. BLASTERS
HIGH PRESS. ACCESSORIES
SERVICE & REPAIR
PETROL & DIESEL ENGINES
AIRLESS PAINT SPRAYERS
AG SPRAYERS
FUEL TRANSFER PUMPS
PUMPSAUSTRALIA.COM.AU
212 WelAVool Rd, WelAVool WA 6106
FREE CALL 1800 790 915 FOR MORE INFORMATION
