Pura CB106 Operation manual

Bath waste with chrome clicker
waste
Product Code: CB106
Please retain this booklet for future aftercare reference

2
INSTALLATION
1. Identify all your core components and check the waste is complete.
2. Fit the brass waste body (12) through the bath and screw into the plastic
waste body (15), using a suitable leak sealant between the brass waste
fitting and your bath and tighten securely. For a very thin bath the option
al washer (13) may be fitted between the brass waste body fitting (12)
and the bath.
3. Attach the overflow fitting (5) to the underside of the over flow hole of
your bath and secure by using the retaining bar. The overflow cover can
now be attached to the retaining bar with a firm push. washer (4) is
placed between he bath and the overflow fitting, using silicone sealant
where necessary.
4. Connect the overflow tube to both the over flow elbow and plastic waste
body
NB - do not over tighten the overflow cover retaining screw (2)
(2)
4 .Check all joints and connections for leaks.
5. See over the page for aftercare instructions.
COMPONENTS
1WS191 OVERFLOW COVER FOR CB106
2WS192 OVERFLOW COVER RETAINING SCREW FOR CB106
3WS193 RETAINING BAR FOR CB106 OVERFLOW COVER
4WS194 BLACK OVERFLOW SEALING WASHER FOR CB106
5WS195 CB106 OVERFLOW FITTING
6WS196 OVERFLOW TUBE FOR CB106
7WS197 OVERFLOW TUBE FIXING NUT FOR CB106
8WS198 OVERLOW PIPE SEALING WASHER FOR CB106
9WS199 DOME PLUG FOR CB106
10 WS200 PLUG SEALING WASHER FOR CB106
11 WS100 CLICKER MECHANISM
12 WS201 CHROME WASTE BODY FOR CB106
13 WS202 BATH SEALING WASHER FOR CB106
14 WS203 WASTE BODY WASHER FOR CB106
15 WS204 ABS WASTE BODY FOR CB106
To order spare part please call our technical helpline on 01892611240 selecting option 2

3
EXPLODED COMPONENT VIEW

AFTERCARE INSTRUCTIONS
This waste fitting has a high quality finish and therefore should be treated with care to
preserve the chrome plated surfaces. All surface finishes will wear if not cleaned cor-
rectly, the only safe way to clean your waste is to wipe with a soft damp cloth. Stains
can be removed using a neutral washing up liquid. All bath cleaning powders and liq-
uids will damage the surface of your fitting even the non-scratch cleaners.
GUARANTEE
All products are manufactured to the highest standards and a 10-year guarantee covers
any defect in manufacture. If you should experience any problems with your waste,
contact our technical help line quoting the product or component code. All working parts
such as seals which are subject to normal wear and tear, are covered for 12 months
from proof of purchase date.
Pura Bathrooms Limited
15 Millbrook Industrial Estate
Crowborough
East Sussex
TN6 3DU
Office Tel: [phone]
Office Fax: [phone]
Email: [e-mail]
[e-mail]
Website: www.purabathrooms.com
