Pure AV AV24502uk User manual

HDMI™ Interface 3-to-1 Video Switch
Connect up to 3 devices with HDMI connectors to an HDTV with 1 HDMI input
User Manual
AV24502uk
P75199uk_AV24502uk_man.indd 1 30/6/06 1:49:00 pm

HDMI™ Interface 3-to-1 Video Switch
2
Table of Contents
Page
Package Contents ............................................................. 2
Introduction ...........................................................................3
Installation ......................................................................... 4
Remote Control ................................................................. 5
Specifications ................................................................... 6
Information ........................................................................ 6
Package Contents
• HDMI Interface 3-to-1 Video Switch
• 6V DC Switch-Mode-Regulated Power Supply
• Infrared Remote Control
• 2 AAA Batteries
• User Manual
• 6 ft/ 1.8 m HDMI Interface-to-HDMI Interface Cable
IMPORTANT NOTE: Use only HDMI Interface-compatible
cables.
Use only HDMI or HDMI Interface-DVI cables, which are
authorized by HDMI, LLC (USA), as licensed under the HDMI
Specification (1.1 or later) of the HDMI Adopter Agreement.
All PureAV HDMI Interface Cables comply with or exceed
these international specifications, and are recommended for
best results. Failure to use approved cables may result in a void
of warranty.
P75199uk_AV24502uk_man.indd 2 30/6/06 1:49:00 pm

HDMI™ Interface 3-to-1 Video Switch
3
Introduction
Congratulations and thank you for purchasing the HDMI
Interface 3-to-1 Video Switch.
This unit allows you to connect and switch among three
separate high-definition digital video sources into one HDMI* or
DVI** connection on your HDTV.
*HDMI Interface is the first industry-supported, full-digital
format with HDTV connectivity. Its exceptionally wide
bandwidth of 1.65Gbps permits the transmission of up to 1080p
video signals, along with eight channels of high-resolution
digital audio.
It also contains a bidirectional data bus, which supports picture
format settings, and features HDCP (High-Definition Content
Protection) compliance.
**Although there are only HDMI connections on this device, you
can use an HDMI Interface-to DVI cable to connect and switch
between DVI components.
Benefits
• Connects 3 HD video sources into 1 HDMI port on your HDTV
• Supports 480i, 480p, 720i, 720p, 1080i, and 1080p
resolutions
• Maintains highest HDMI single-link video resolution
• Works with HDCP-compliant devices
• Connects and switches both HDMI and HDMI
Interface-to-DVI cables
• Selects inputs from the IR remote controller (supplied)
or via the front-panel “Input Select” button
P75199uk_AV24502uk_man.indd 3 30/6/06 1:49:00 pm

Current Input
Indicator
IR Window
Input Select
Button
Power
Indicator
Out to Display
Device/HDTV
In from HD Digital
Video Sources,
such as
DVD Player, Cable/Satellite
Box, Entertainment
Computer
HDMI™ Interface 3-to-1 Video Switch
4
Installation
Mount the HDMI Interface 3-to-1 Video Switch away from
sources of electromagnetic or radio frequency interference,
and also away from heat and moisture. You can mount the
HDMI Interface 3-to-1 Video Switch either on a flat horizontal
surface, or hang on a vertical surface using the keyhole slots in
the base of the unit (mounting hardware not included).
Front Panel
Back Panel
P75199uk_AV24502uk_man.indd 4 30/6/06 1:49:06 pm

Direct Input
Select
Next/Previous
Input Select
HDMI™ Interface 3-to-1 Video Switch
5
Remote Control
Selecting the Desired Input
From the front panel: Press the “Input Select” button
repeatedly until the desired input is selected. Each press
progresses to the next input in turn (i.e., 1-2-3, then back to 1).
The current input can be identifi ed by the lighted LED on the
front panel.
From the remote control:
1. Press the desired input button to go directly to the
required input (1-3), or;
2. Press the < or > button to select the next/previous input.
P75199uk_AV24502uk_man.indd 5 30/6/06 1:49:10 pm

HDMI™ Interface 3-to-1 Video Switch
6
Specifications
Video Amplifier Bandwidth ...............1.65Gbps
Input Video Signal Specification .....v1.2
Input Connector Type ........................ HDMI Interface
Output Connector Type ..................... HDMI Interface
Power Consumption ...........................3.0W Max
Power Supply .......................................6V DC, 1A
Dimensions (LxWxH) .......................... 7.15 in. x 3 in. x 0.9 in.
(181.6mm x 77.1mm x 23.7mm)
Product Weight (Net) ......................... 15.3oz. (435g)
Information
Europe-European Union Notice
Products with the CE marking comply with the EMC Directive
(89/336/EEC) and the Low Voltage Directive (72/23/EEC) issued
by the Commission on the European Community. Compliance with
these directives implies conformity to the following European
Norms (in brackets are the equivalent international standards).
• EN 55013 (CISPR 13) - Disturbance characteristics
• EN 55020 (CISPR 20) - Electromagnetic Immunity
• EN 61000-3-2 (IEC61000-3-2) - Power Line Harmonics
• EN 61000-3-3 (IEC61000) - Power Line Flicker
Following information is only for EU-member states:
The use of the symbol indicates that this product may not be
treated as household waste. By ensuring this product is disposed
of correctly, you ill help prevent potential negative consequences
for the environment and human health, which could otherwise
be caused by inappropriate waste handling of this product,.
For more detailed information about recycling of this product,
please visit our web at www.belkin.com
(or contact your local city office, your household
waste disposal service or the shop where you
purchased the product)
P75199uk_AV24502uk_man.indd 6 30/6/06 1:49:10 pm

HDMI™ Interface 3-to-1 Video Switch
7
Information (continued)
Belkin Corporation Limited Lifetime Product Warranty
What this warranty covers?
Belkin Corporation warrants to the original purchaser of this
Belkin product that the product shall be free of defects in design,
assembly, material, or workmanship.
What the period of coverage is.
Belkin Corporation warrants the Belkin product for the lifetime of
the product.
What will we do to correct problems?
Product Warranty.
Belkin will repair or replace, at its option, any defective product
free of charge (except for shipping charges for the product).
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is
not provided to Belkin Corporation for inspection upon Belkin’s
request at the sole expense of the purchaser, or if Belkin
Corporation determines that the Belkin product has been
improperly installed, altered in any way, or tampered with.
The Belkin Product Warranty does not protect against acts of God
such as flood, earthquake, war, vandalism, theft, normal-use wear
and tear, erosion, depletion, obsolescence, abuse, damage due to
low voltage disturbances (i.e. brownouts or sags), non-authorized
program, or system equipment modification or alteration.
How to get service.
To get service for your Belkin product you must take the
following steps:
1. Contact Belkin Ltd, Express Business Park, Shipton Way,
Rushden, NN10 6GL, United Kingdom, Attn: Customer Service,
or call 0845 607 7787 within 15 days of the Occurrence.
Be prepared to provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2. Your Belkin Customer Service Representative will then instruct
you on how to forward your receipt and Belkin product and
how to proceed with your claim.
P75199uk_AV24502uk_man.indd 7 30/6/06 1:49:10 pm

HDMI™ Interface 3-to-1 Video Switch
8
Information (continued)
Belkin Corporation reserves the right to review the damaged
Belkin product. All costs of shipping the Belkin product to
Belkin Corporation for inspection shall be borne solely by
the purchaser. If Belkin determines, in its sole discretion, that
it is impractical to ship the damaged equipment to Belkin
Corporation, Belkin may designate, in its sole discretion, an
equipment repair facility to inspect and estimate the cost
to repair such equipment. The cost, if any, of shipping the
equipment to and from such repair facility and of such estimate
shall be borne solely by the purchaser. Damaged equipment
must remain available for inspection until the claim is finalized.
Whenever claims are settled, Belkin Corporation reserves the
right to be subrogated under any existing insurance policies the
purchaser may have.
