PURPLE LEAF E Series Installation and operating instructions

PURPLE LEAF
©Copyright 2016-2022 Purple Leaf Inc.
Cantilever Umbrella
Assembly and Operation Manual
10'×10' LED
E Series

CHECK LIST
A
B
C
D
E
×1
F×4
G×8
H×1
(M8×14)
(Ø8)
(M8×20)
×1
×1
×1
×4
*black bolts

K×1
N×1
L×1
M×1
J×1
(T6)
I×1

Option 1
Cross Base
G
F
A
B
1Base Tube Assembly
C
Notice:Make sure you have
enough space to operate the
pedal before installation.
Adding something heavy on
crossbase like water tank

G
E
D
H
1
Base Tube Assembly
*black bolts

Horizontal
Concrete >700lbs
Option 2
Inground Base
(Sold Separately)
1Base Tube Assembly
28‘’
24‘’
filling the bottom of
the hole with gravel
gently
put it down

G
F
C
C
D
1
Base Tube Assembly
G
E*black bolts

4.44 in4.44 in
6.29 in6.29 in
Ø1/2 inØ1/2 in
Option 3
Baseplate
(Sold Separately)
1Base Tube Assembly

Use lag screws with washers
to mount the umbrella(
included in package) .
×16
G
F
C
D
1
Base Tube Assembly
G
E
*black bolts

ImportantImportant
Prior to assembly it is important to decide on the
location of the umbrella.
•Allow ample height to avoid damage to your umbrella
during assembly and usage.
•Choose a location that is level and sturdy.
•Consider a location that will maximize the umbrella’s
rotating swivel function.Placing the umbrella between two
entertaining areas is ideal.
•To avoid personal injury or damage to the umbrella, make
sure the area around you is clear from any outdoor structure
or furniture.
•Keep all flame and heart sources away from this umbrella.
STORAGE: Properly store umbrella when not in use. Close
umbrella, tie string around canopy and cover umbrella with
provided protective cover.
NOTE: DO NOT discard any packaging or box until assembly
is complete.
CAUTION: Moving the umbrella fully assembled will increase
the risk of damage to your umbrella and/or can cause serious
injury. We recommend a two-person team for assembly and
disassembly.
1Base Tube Assembly

3.Put the solar umbrella in the sunlight to charge
the battery for 8 hours before the first use.
4.You can use the screw to get the battery out of the holder, then
charge it with USB wire.
1.Insert the plug into the socket under the solar panel as shown below.
2.Put the solar panel on the top of umbrella and hide the plug and wire
inside the groove at the top of umbrella. Then turn the solar panel clockwise.
Do not over tighten.
I
M
Solar panel Assembly 2

CAUTION:
YOU MUST CHARGE BATTERY BEFORE FIRST
USE.
Please note that battery can discharge if they are left
unused or uncharged for a long period of time.
Since there can be a six-month period between
production and final customer purchase, we
recommend you charge your solar umbrella for at least
8 hours in direct sunlight before the first use.
Failure to charge the battery will result in premature
dimming of the lights in your new solar umbrella.
Make sure the light switch is in the off position when
charging the solar panel. For everyday normal use, turn
the light switch on at night when you want to use the
solar light and turn off the switch after use.
MAKE SURE THE LIGHT SWITCH IS IN THE OFF
POSITION IN THE DAYTIME FOR THE SOLAR
PANEL TO RECHARGE THE BATTERY.
Solar panel Assembly
2

K
J
Two-persons recommended for team lift and to
complete assembly.
Insert the main pole onto the base tube(D) with
the cover plate(H) installed.
Please Remove all of foam material from the
frame before opening umbrella.
3
Umbrella Assembly

CAUTION: Stop turning the crank handle as soon as
the umbrella cover is completely open and the sleeve
on the umbrella pole has reached its maximum height.
IMPORTANT: PRIOR TO USING THE TILT FEATURE.
To avoid personal injury or damage to the umbrella,
make sure the area behind you is clear and free from
any furniture or structure.
4Operation

To Open Canopy
1. Slide the umbrella handle to the top of the pole by
squeezing the trigger.
2.Insert the hand crank(L) into the small hole of the
handle on the post.
lift
push
Note: be sure to remove all tape, form or cardboard
from the umbrella before opening.
be sure to remove all the
protective material inside
squeeze
the
trigger
4
Operation

L
4Operation

To Tilt Canopy
Press on the handle button and move the trigger handle up and down to
adjust the angle of the umbrella canopy.
IMPORTANT: PRIOR TO USING THE TILT FEATURE.
To avoid personal injury or damage to the umbrella,
make sure the area behind you is clear and free from any furniture or
structure.
4
Operation

4Operation

4
Operation

Use the switch to turn on/off the LED light
4Operation
