INSTRUCTION MANUAL
MODEL: PAV-EX40-HDR
GIVES BACK
TO CHARITY
100% PERFORMANCE
GUARANTEE
SEAMLESS
SUPPORT
3 YEAR
WARRANTY
DAILY IN-STOCK
PROMISE

www.purposeav.ca [e-mail] [phone]
OVERVIEW
• The PAV-EX40-HDR-KIT is an HDMI extender featuring HDBaseT technology, allowing for the
extension of 4K HDR HDMI signals up to 40 Meters. Equipped with Bi-directional POC, IR,
RS232, and comprehensive EDID management the PAV-EX40-HDR-KIT is an unmatched tool
in any installation.
MODEL NUMBERS
• PAV-EX40-HDR-T – HDBaseT Transmitter w/ IR and RS232
• PAV-EX40-HDR-R – HDBaseT Receiver w/ IR and RS232
FEATURES
PACKAGE CONTENTS
• HDMI 2.0b
• Max Resolution 4K60 4:4:4
• HDCP 1.X/2.2 Support
• CEC Pass-Through
• Up to 40M (Cat6a) at 4K
• Up to 70M (Cat6a) at 1080p
• Bi-Directional POC
• 3-20V IR Support with Direct Control System Support
• Bi-Directional RS232 Transport
• Supports audio formats up to uncompressed LPCM 7.1, Dolby TrueHD (including Atmos), and
DTS (up to DTS:X)
• Power Supply
• X2 IR Target (Eye/Receiver)
• X2 IR Blaster (Emitter)
• X2 Velcro Strip
• Mounting Brackets
• X2 3.5MM TRS (Stereo) to Open Cable

www.purposeav.ca [e-mail] [phone]
Video Resolutions Up to 4K60 4:4:4
VESA Resolutions Up to 4096X2160 (DCI 4K)
Chroma Supported 4:4:4, 4:2:2, 4:2:0, RGB (Limited and Full)
Deep Color Up to 16 Bit (1080p) Up to 12 Bit (4K)
HDR Support HDR10, HDR10+, HLG, Dolby Vision
LPCM (Up to 192KHz 24 bit) 2.0, 5.1, 7.1
Dolby Dolby Digital, Dolby Digital Plus, Dolby TrueHD,
Dolby Atmos
DTS DTS 6.1 ES, DTS HRA, DTS Master Audio, DTS:X
4K Resolutions 40 Meters (131 Feet)
1080p Resolutions 70 Meters (230 Feet)
SPECIFICATIONS
VIDEO
AUDIO
HDBASET DISTANCE (CAT 6A)

www.purposeav.ca [e-mail] [phone]
Power LED – Indicates that power is connected to the unit.
1. Light is On = Power Supply/POC Connected and Unit is operating
2. Light is Off = Power Supply is not connected, or no power is present
HDMI Sync LED – Indicates that an HDMI Source is connected to the Transmitter.
1. Light is On = HDMI Source is Active on the HDMI Input
2. Light is Off = HDMI Input sense no active HDMI Source
HDBaseT Link LED – Indicates that the HDBaseT Transmitter is linked with an HDBaseT Receiver.
1. Light is On = Unit has linked with an HDBaseT Receiver and is sending Data
2. Light is Off = Unit has not linked with an HDBaseT Receiver
TRANSMITTER
INDICATOR LIGHTS (FRONT OF UNIT)
DIP SWITCH TABLE
EDID IR
DipSwitch 1-4 EDID Dipswitch 5 IR Input Selection
0000 EDID Bypass 0 IR Target (Eye)
0001 1080p 444 2CH 1 IR from Control System
0010 1080p 444 6CH
0011 1080p 444 8CH
0100 4K30 444 2CH
0101 4K30 444 6CH
0110 4K30 444 8CH
0111 4K30 HDR 2CH
1000 4K30 HDR 6CH
1001 4K30 HDR 8CH
1010 4k60 444 2CH
1011 4k60 444 6CH
1100 4k60 444 8CH
1101 4k60 HDR 2CH
1110 4k60 HDR 6CH
1111 EDID Copy

www.purposeav.ca [e-mail] [phone]
Power LED – Indicates that power is connected to the unit.
1. Light is On = Power Supply/POC Connected and Unit is operating
2. Light is Off = Power Supply is not connected, or no power is present
HDMI Sync LED – Indicates that an HDMI Source is connected to the Transmitter.
1. Light is On = HDMI Output is connected to an active HDMI Input
2. Light is Off = HDMI Output does not sense an active HDMI Input
HDBaseT Link LED – Indicates that the HDBaseT Transmitter is linked with an HDBaseT Receiver.
1. Light is On = Unit has linked with an HDBaseT Transmitter and is receiving Data
2. Light is Off = Unit has not linked with an HDBaseT Transmitter
RECEIVER
INDICATOR LIGHTS (FRONT OF UNIT)
RS232 CONFIGURATION
• RS232 can be used to pass control signals bi-directionally between any two RS232 compati-
ble devices. Commonly used in extending control from a control system
• The RS232 ports on the PAV-EX40-HDR-KIT are pinned null modem:
Control System RS232 Port 3.5MM TRS PIN
Receive Transmit Tip
Ground Ground Ring
Transmit Receive Sleeve

www.purposeav.ca [e-mail] [phone]
1. Downstream (From transmitter)
• Plug an IR Receiving Eye or Control System IR output direct into the IR Sensor port of the
PAV-EX40-HDR-T to pass infrared signals to the IR Out port on the Receiver
• Set IR Dipswitch according to input signal device
• Connect the IR Out Port of the Receiver to an IR Emitter or Direct IR Input
2. Upstream (From Receiver)
• Plug an IR Receiving Eye into the IR Sensor port of the PAV-EX40-HDR-R to pass infrared
signals to the IR Out port on the Transmitter
• Connect the IR Out Port of the Transmitter to an IR Emitter or Direct IR Input
IR CONFIGURATION
IR COMMUNICATION CAN BE SENT TWO WAYS
• IR Input (Receiving Eye) (Dipswitch 5 = 0)
• IR Direct Input from Control System
(Transmitter Only) (Mono Tip to Tip/
Sleeve to Sleeve) (Dipswitch 5 = 1)

www.purposeav.ca [e-mail] [phone]
• IR Output to Emitter
No Power LED
1. Ensure PSU is sending proper voltage
2. If using POC, ensure that the unit sending POC is connected to power
3. If using POC, try powering the unit direct to ensure unit operates stand alone
No HDMI LED
1. Plug Source direct into display to ensure operability
2. Change the resolution of the source device to 1080p or 4K30 (No HDR)
3. Set a canned EDID. Source may require power cycle
4. Swap HDMI cable between Transmitter and Source. HDMI Handshakes with cables under 2
Meters may not sync properly
TROUBLESHOOTING
TRANSMITTER
No HDBT Link
1. Check cable Length. Max Distances are 40M at 4K or 70M at 1080p. HDBaseT Recommends
Cat 6A; Cat 6 and Cat 5e may experience a 5-20% loss of distance
2. Remove Excess Service Loops and Bundles of Cable. HDBaseT Recommends up to 6 runs of
Cat in a single bundle
3. Bypass all patch-panels and punch down blocks
4. Re-terminate connectors. IP Continuity testers may indicate correct pinouts; However, HDBas-
eT Signals are transmitted differently than Ethernet Signals

www.purposeav.ca [e-mail] [phone]
No Power LED
1. Ensure PSU is sending proper voltage
2. If using POC, ensure that the unit sending POC is connected to power
3. If using POC, try powering the unit direct to ensure unit operates stand alone
No HDMI LED
1. Plug Source direct into display to ensure operability
2. Change the resolution of the source device to 1080p or 4K30 (No HDR)
3. Set a canned EDID. Source may require power cycle
4. Swap HDMI cable between Transmitter and Source. HDMI Handshakes with cables under 2
Meters may not sync properly
No HDBT Link
1. Check cable Length. Max Distances are 40M at 4K or 70M at 1080p. HDBaseT Recommends
Cat 6A; Cat 6 and Cat 5e may experience a 5-20% loss of distance
2. Remove Excess Service Loops and Bundles of Cable. HDBaseT Recommends up to 6 runs of
Cat in a single bundle
3. Bypass all patch-panels and punch down blocks
4. Re-terminate connectors. IP Continuity testers may indicate correct pinouts; However, HDBas-
eT Signals are transmitted differently than Ethernet Signals
TROUBLESHOOTING
RECEIVER
• Ensure correct pinout between both the transmitter and receiver side. A null modem adaptor
may be used for quick pinout changing
• If sending downstream, ensure dipswitch is in the correct position for Input device type
• The Visible IR Emitters can be used to ensure signal is being sent from one point to the other
IR TRANSMISSION
RS232 TRANSMISSION
