PWAY PW-DT216W-A User manual

Contact : Joan Xia Email :[email protected] ,[email protected] Skype:joanjinxia
50M HDMI Wireless Extender With H.264
Modle Number : PW-DT216W-A
USER MANUAL
1. Description
This Wireless HD Video Solution enables wireless transmission of video/audio from any HDMI
video source , such as PC/HDTV to display devices that includes HDTV/HD Monitor over the 5.8GHz
band, with very low latency.
It does not require any special configuration of software driver installation-simply connect the
transmitter to the HDMI output of the video source and the receiver to the HDMI input of the
Panel/TV/Monitor. Its Plug & Play operation makes it the ultimate solution for the most demanding
indoor/outdoor professional environments.
This Wireless HD Video Transmission Solution is widely applicable to family entertainments, office
presentation, lecture, education, medical treatment, party, conference etc.
2. Features
Apply H.264 technology.
Effective Range: 50meters in 5G ; Air line distance is 100meters.
Support 1 sender to 2 recievers transmission.
Support HD devices with HDMI input/output, include Blu-ray player, DVD player, PC, laptop,
HDTV etc.
Support resolution: 480i@60Hz, 480P@60Hz, 576i@50Hz, 576P@50Hz, 720P@50/60Hz,
1080i@50/60Hz, 1080P@50/60Hz
Support wide infrared remote control function to control source device content from long
distance.
Latency：≤100ms in without obstacle room.Usually latency is 0.2s in the obstacle and wifi room.
could pass through 1 solid wall between the two rooms within 1 0-20m
No cable between sender (TX) and receiver (RX)
Easy and clean installation
Plug & Play –full hardware design, no software is required
Note:
Transmission distance will be different due to the environment
Wall, brick or glass will shorten the signal cover range or cause big signal loss

3. Panel
Transmitter
Receiver
Port name
Description
HDMI IN / OUT
HDMI signal input/output
IR IN / OUT
IR signal input/output;TX/RX matching connectors
DC 5V
Power adapter socket
RESET
Reset button/ pairing key
LED indicator
Description
LINK
Connect light
STA
Video signal connection indicator
PWR
System power indicator

4. Specifications
5. Packing list
Wireless transmitter * 1 pc Wireless receiver * 1 pc
IR blaster extension * 1 pc IR receiver extension * 1 pc
DC 5V/2A power adapter * 2pcs User manual * 1pc
Parameter
Description
Video
Standard Protocol
HDMI 1.3; HDCP 1.2
Maximum pixel clock
165MHz
Maximum data rate
6.75Gbps
Resolution
480i@60Hz,480P@60Hz,576i@50Hz,
576P@50Hz,720P@50/60Hz,1080i@50/60Hz,
1080P@50/60Hz
Connector
HDMI-A
Impedance
100Ω
Compress Formats
H.264
IR
Interface
3.5mm earphone seat
Signal direction
Unidirectional
IR frequency
20-60KHz
WIFI
Frequency
5GHz
Transmission distance
Usually : 50m ; Air line : 100m
Wireless Standard
RX- 802.11AC; TX-802.11N on 5Ghz,
Other
Power supply
The power adapter: DC 5V/2A
Power dissipation
MAX 6W
Temperature
Operating: -5℃~ +70℃
Humidity
Operating: 5% ~ 90%
Dimension
L96*H20*W97mm
The warranty
1 year warranty

6. Installation
1、Connect the provided DC/5V power supplies to the power socket of the transmitter and the
receiver,
2、Connect an HDMI cable between the HDMI input port of transmitter
3、Connect the HDMI output port of receiver to the display device with HDMI cable,
4、IR function---connect the IR TX (the bigger) cable to the HDMI receiver, connect IR RX cable to
the HDMI transmitter and the IR TX must face to the controlled device.
7. Diagram
Point to point
1 Sender to 2 receivers
