Pyle SereneLife SLBCAM10 User manual
by
www.PyleUSA.com
OPERATING MODE
The sober design of our product easily integrates with all interiors and
allows you to keep a watchful eye on your babies. Communication
between transmitter and receiver through radio waves at a max
distance of 260 m (distance in open eld). The digital connection
provides transmission without interference. The camera is equipped
with infrared LEDs that automatically switch on in case of insucient
light conditions. Choose from eight integrated melodies to activate a
lullaby on the transmitter. The two-way intercom allows you to talk and
soothe your baby. You can check the temperature in your baby’s room
at any time thanks to the built-in transmitter thermometer. The monitor
has a portable battery, so you can always keep it on hand.
Before using this product, carefully read the precautions for use and
charge completely the monitor battery.
PRECAUTIONS FOR USE
This baby monitor satises all needs and complies with the rules related
to this type of product. When used according to the instructions
described in this manual, the product is safe.
Read carefully this manual with special attention to the following
points:
• The installation must be made by an adult.
• This product is not a toy. Do not allow children play with it.
• This baby monitor does not replace adult supervision.
• Do not place the camera or cables inside the bed or at the child’s
reach. Leave at least 1 meter distance.
• Keep cables out of children’s reach.
• Do not use the baby monitor near water or near a source of heat.
• Use exclusively the adapters supplied with the product.
• Do not touch the connectors with sharp or metal objects.
• Do not attempt to open the casings.
1
www.PyleUSA.com
2
PACKAGE CONTENT
DESCRIPTION
Monitor view
1 Monitor X1
2 Camera X1
3 Power adapter X2
1 LCD display
2 LED for in Charging.
3 LED power indicator
4 Key Power On/Off
5 Key menu / OK
6 Key Return - undo.
7 Key volume –
8 Key volume +
9 Key brightness +
10 Key brightness –
11 Key Music
12 Key intercom
13 Microphone
14 Loudspeaker
15 Power connector
www.PyleUSA.com
CAMERA VIEW
Before installing the camera, test the device to make sure that position
is suitable. Check the correct signal reception. If necessary, move the
camera to improve reception.
3
1 Light sensor
2 Camera lens
3 Infrared LEDs
4 Power LED
5 Microphone
6 Loudspeaker
7 Paring key
8 Key power on/off
9 Temperature sensor
10 Power connector
Connect the camera power to
the transformer supplied. The
blue LED turns on to indicate
that it is running.
www.PyleUSA.com
4
PACKAGE CONTENT
MAIN SCREEN
Connect the monitor power.
The display turns on for a few
seconds to indicate battery
charge level. We recommend
that you completely recharge
the battery before rst use.
Push the power key up to turn
the monitor and camera on
1 Signal level
2 Temperature measured in child’s room
3 Playhead of a melody in progress
4 Alarm activated
5 Level of battery charge
6 Activated intercom function
7 Date and time
www.PyleUSA.com
MAIN MENU
To access, press « menu ». This menu contains 6 icons:
PARING WITH CAMERA
The display and the camera are paired at the factory. You don’t need to
repeat this procedure unless they both loose connection. In this case,
do as follows.
• Press the key “menu” to enter the
main menu.
• Select the icon “camera.”
• Press “OK” to enter the menu.
• Press “OK” again to start recording.
A message appears asking if you
want to re-register the camera.
Press “YES”.
• You now have 10 seconds to press
the paring key of the camera.
• A message conrms the successful
completion of the operation.
5
1 Camera
2 Alarm
3 Setting
4 VOX setting
5 Languages
6 Information
Press the key « up » and « and » to select
the option.
www.PyleUSA.com
6
MUSIC PLAYING
Press the music key to activate a lullaby on the camera, Press this key
again to stop the melody.
INTERCOM FUNCTION
Press the PTT Key to activate the intercom function. The icon displayed
indicates that the microphone is active. Keep this key pressed until you
have nished speaking. Do not release too quickly not to interrupt the
conversation.
VOLUME
When the camera is operating, you can press Volume + key on monitor
to increase and press Volume – key to decrease the audio volume from
the camera.
ALARM
This option allows setting one or more alarms.
Choose the alarm that you wish to change and
press « change ».
• To activate the alarm, press the key “Up”
• To change the line, press the key “right”
• To change time, press “Up/Down”
• Press to switch to minutes “Left/Right”
• When settings are nished, press « Done ».
www.PyleUSA.com
ADVANCED PARAMETERS
• Date and Time: Allows setting of date and time of your product.
• To change the line, press the key “right”
• To change time, press “Up/Down”
• Press to switch to minutes “Left/Right”
• To activate summer time, select the line with the key ”right”
and press “Down
• When settings are nished, press « Done ».
• Temperature scale: Celsius or Fahrenheit degrees.
• Anti-ickering: the ickering is due to articial lighting.
In Europe, use 50Hz.
• Display backlight: to set screen lighting and length of activity
VOX
• System mode: Allows the activation of the VOX mode. The VOX mode
automatically puts the display in sleep mode to save battery. It reacti
vates automatically, when it detects noise in the baby’s room.
• VOX sensitivity: to set the VOX mode sensitivity. The more sensible it is,
the more the display will turn on at the slightest noise.
7
www.PyleUSA.com
8
LANGUAGES
SYSTEM INFORMATION
The system information icon contains data of the software installed in
the product.
TECHNICAL FEATURES
• Display LCD 2 inches
• Resolution: 220X176@20fps
• Frequency: 2.4 GHz Digital
• Range: 260m in open eld
• Consumption max: 550mA@5VDC
• Battery Li-Po 550mAh
• Sensor: 0.3Mpix CMOS
• LED infrared
• Lighting sensor
• Temperature sensor
• Operating temperature: -50 to +113°F
CLEANING AND MAINTENANCE
• Do not clean with abrasive or corrosive substances.
• Use a slightly moistened soft cloth.
• Do not spray with aerosol as this will damage the interior of the
product.
• Avoid direct contact with camera lens.
• Fully charge the battery before rst use.
• Recharge the battery at least once every 3 months.
• Do not install the product with a at battery.
• Recharge far from humidity.
• Do not expose to rain.
• Never open the casing to prevent the risk of electric shock
Choosing a menu language:
English \ French \ Spanish \ Portuguesa \
Italian \ Deutsch
