Pyle PLCD44 User manual

P / N : 570-961612-05
Page. 1
OWNER'S MANUAL
MODEL: PLCD44
ANTI-SHOCK COMPACT DISC PLAYER
SUPER POWER OUTPUT
AUXILIARY INPUT
FACE DETACHABLE PANEL
FM-AM FM-MPX RADIO RECEIVER
WITH REMOTE CONTROL

Page. 2
P / N : 570-961612-05
OPERATING INSTRUCTIONS
LOCATION OF CONTROLS
7. DISPLAY CONTROL
During radio and CD operation, press this button to call the time display on the incorporated quartz clock.
SETTING CLOCK TIME
1. Press CLOCK button and hold it until the display flash and release.
2. Press “+” button to set HOUR and press “ ” to set MINUTE.
8. STEREO/MONO CONTROL
Press this button to select “FM STEREO” or “MONO” reception.
9. EJECT BUTTON
Press the button to eject the disc inside disc slot.
1. POWER ON/OFF CONTROL
Press the button to turn the power “ON” or “OFF”.
No e : The unit can be turn on by pressing any keys on the panel (except panel release button & disc eject button). It will help
the user who cannot find the power button in dark.
2. BAND SELECTOR
Each time this button is pressed, the radio band is changed. The indication “FM1”, “FM2”, “FM3”, “MW1” or “MW2” will
appear on the display according to your selection.
3. SCAN CONTROL
Press this button to scan the receivable FM / MW stations. When receivable stations are tuned in, they are monitored for
approximately 5 seconds before advancing to the next receivable station. Press SCAN button once again to stop scanning as
desired.
4. PRE-SCAN/AUTO-STORE BUTTON
This button allows you to enjoy “Preset Memory Scan” function by pushing it shortly, and “Auto Store Memory” function by
pushing it more than 2 seconds.
* PS (PRESET MEMORY SCAN ) It calls the memorized station frequencies ( from 1 6 ) automatically every 5 seconds.
* AS (AUTO STORE MEMORY ) It searches all station frequencies upward and memorize automatically 6 stations by
catching the frequency which has scan stop level, the memorized station is shown on LCD as “CH1...6”. After memorizing,
auto store memory function will be changed to “Preset Memory Scan” function automatically.
5. DISC SLOT
Holding the disc and insert into the disc slot. The CD mechanism will automatically engage into CD play mode.
6. LCD DIGITAL DISPLAY
The unit utilizes a digital type display which shows numerical indication of station FREQUENCY and other FUNCTIONS.

P / N : 570-961612-05
Page. 3
13. LOUD CONTROL
Press this button to activate the loudness circuitry which compensates for loss of high and low frequencies during low volume
levels.
14. MUTE CONTROL
Press this button to mute the volume control and “MUT” will appear on LCD display.
15. AUDIO / SETTING SELECT
Briefly press the button to select volume, bass, treble, balance or fader adjustment in cyclical mode.
When pressing the button for more than 2 seconds, it activates as unit setting selection in cyclical mode as following. The unit setting can
be changed by using either “VOL +” or “VOL –” button.
••
••
•DSP OFF/ POP M/ ROCK M/ CLASS M/ FLAT M
••
••
•BEEP OFF/ BEEP ON (not available for this model)
••
••
•SEEK 1 (tune up/down button performs fast tune function) / SEEK 2 (performs auto tuning function when tune up/down button
pressed more than 1 second)
••
••
•COLOR 1 / COLOR 2 (not available for this model)
••
••
•VOL LAST / VOL ADJ (preset volume level when unit turn on)
16/17. AUDIO LEVEL DOWN/UP CONTROL ( - Bu on ) / ( + Bu on )
Press “SEL” button shortly and then pressing “+” or “ ” button to adjust level of volume, bass, treble, balance or fader.
• VOLUME Press the (+) button to increase, or ( ) button to decrease volume level.
• BASS While “BASS” is being displayed, press (+) button to increase or ( ) button to decrease the bass level.
• TREBLE While “TREB” is being displayed, press (+) button to increase or ( ) button to decrease the treble level.
• BALANCE While “BAL” is being displayed, press (+) or ( ) button to level balance of speaker right and left.
• FADER - While “FAD” is being displayed, press (+) or ( ) button to level fader of speaker front and rear.
18/19. MANUAL UP/DOWN TUNING / TRACK SEEK UP/DOWN CONTROL
On radio mode, press the button will tune one frequency step higher or lower. Pressing the button more than 1 second can
performs fast tuning function or auto tuning function.
On CD mode, press this button will locate the beginning of the track being played or will locate the beginning of the next track.
When pressing more than 2 seconds, it will move fast forward or fast backward to a specific position of a CD/MP3 track.
20. STATION PRESET BUTTON (1-6)
The PRESET BUTTONS on the unit are used to store station frequencies which you may wish to recall. Each preset button can
store FM1, FM2, FM3, MW1, MW2 station frequency. Pressing the button momentarily recalls the station frequency which was
memorized. There are 6 preset buttons, giving you capability of storing 18FM / 12MW.
NOTE: When the preset button to be memorized is kept pressed for more than 2 seconds, the receiving station frequency will be
stored in the button pressed. After this, the memorized station can be recalled by pressing the button once.
On CD Mode
• Prese 1 press this button to pause the disc played.
• Prese 2 press this button to scan the first 10 seconds of all the tracks on the currently selected disc.
• Prese 3 press this button to repeat the current track of the disc.
• Prese 4 press this button to play disc at random order Disc shuffle play.
10. PANEL RELEASE BUTTON
This button is used to release the panel from the unit. To detach the front panel, press the button so that the left side of the
panel is released. Grasp the released side and pull it off of the chassis. To re attach the panel, insert the right side of the panel
in place first and then press the left side of the panel until the chassis hold the panel firmly.
11. MODE SELECTION
Press this button to select Radio (TUNER), CD (S CDP), or Auxiliary input (AUX) mode.
12. LOCAL/DISTANT SELECTOR
Press this button to prevent strong local stations from overlapping weaker stations. For normal operation, press this button again
for distance.

Page. 4
P / N : 570-961612-05
P / N : 5 0-961612-05
RESET FUNCTION
INSTALLATION
UNIT REMOVAL
1. Remove Front Control Panel.
2. Slightly insert the key into the slot and
gently to release.
3. Separate the sleeve from the unit. Keep
release key in a safe place as you may
need for future removal of unit.
REMOTE CONTROL
WIRE CONNECTION
CAUTION : Do not connect the speaker wires to
chassis or car body. Each speaker wire cannot be
soldered together with other wires. Otherwise, the
nit will be damaged and no so nd will come o t
anymore.
The RESET button is located on the front of main panel. It
is recessed in order to prevent accidental engagement,
and can be activated with the tip of a ball-point pen or any
similar pointed object. This reset circuitry is provided in
order to protect the unit's microprocessor, and should only
be activated under the following conditions :
a) Initial installation after all wiring is completed.
b) Abnormal operation is encountered such as numerical
indication on display is erratic.
c) Whenever the reset button is activated, all preset
memory content will be erased and must be
reprogrammed.
CAUTION : DO NOT PLACE THE UNIT OVER THE
MAXIMUM INSTALLATION ANGLE OF 30°.
OTHERWISE, THE UNIT MAY NOT WORK
PROPERLY.
WARNING!!
Due to protection of CD Mechanism, two small screws on the top
of the unit must be released before operate the unit. Otherwise, the
CD Mechanism can not be working properly.
