Pyle PLINDVTB10 User manual

PLINDVTB10
10.1-inchAdjustableSingleDINCarStereoReceiverwithWirelessBT
WIFI/GPS/AM/FM, Car Radio with 1080P HD Touch Screen,
Multimedia Player + Mirror Link forAndroid/iOS phones,
Front/t Rear DVR Recorder included, Dual USB; 2GB RAM, 32GB ROM.

www.PyleUSA.com
1
Note: This unit is based on Android platform. Besides the standard Apps we provided with the unit, you
can also download thousands of Apps and install it on our platform. Please kindly note NOT all Apps are
compatible with this platform. If you have any compatibility problem with a 3rd party App, please
contact your App provider. For the operation instruction of a certain 3rd party App, please also contact
your App provider. We are not responsible for any problem with your 3rd party Apps.
To enjoy the unit's features, along with proper and safe operation, please be sure to read through this manual
before use. It is especially important to thoroughly understand and follow all system warnings and precautions.
Keep the manual in a safe location for future reference when necessary. Contact your dealer or the nearest
authorized repair center for any service, repair or technical support assistance.
CONTENTS
System Installation
Installation Guide
Front Panel and Buttons
Turning Power On
User Interface
Navigation
Local music
Online music
Video playback
Calendar
Radio
Wireless BT
DSP 32bands
Phone Link APP
Third Party Apps
Steering wheel learning
Brightness setting
Volume settings
GPS monitoring
Sound settings
Memory clean
Desktop wallpaper
Reset
Time setting
Troubleshooting
Wiring
Note:
We are constantly aiming to improve the customer experience and your receiver's features and specications
are continually changing for the better, with improvements to the user interface experience, software updates,
bug xes, etc. System descriptions and features reected as herein stated by this user manual serves to
express our Headunit Receiver features at the current production period. We reserve the right to change terms
and conditions of system specications, features and descriptions at any time, as we continue to improve
and provide our customers with upgrades in safety, performance and system operation in general.
2
2
2
2
3
3
3
4
4
4
4
5
6
6
6
6
6
6
6
6
7
7
7
7
8
9

System Installation:
Before starting: To prevent short circuits, be sure to disconnect the battery terminal before starting.
Installation Guide
Caution:
1. Consult your vehicle dealership before making any modications to your car’s body (ex. Drilling holes)
2. Use included screws in installation. Improper operation may damage machine or cause accidents.
Do not install unit in any area where:
• It may obstruct the steering wheel and gearshift lever operations
• It may obstruct the operation of safety devices such as air bags
• It may obstruct visibility
Front Panel and Buttons
Button & Feature Layout
RST Use a pin to insert into reset port to trigger unit reset. (Hold for 20 secs. to reset)
Hold to power up.
Home
Return
Volume up
Volume down
Turning Power On
1. Turn on the engine key to the “ACC” or “ON” position
2. Press and hold the power button for 3 seconds
• When the engine key is turned to o position, the unit Status Bar is turned o
(on the top of radio screen and app screen) you can swipe down for more.
www.PyleUSA.com 2

App Screen - Interface Layout
Swipe UP/DOWN to access more apps
Navigation
Click the main interface “navigation”to enter the navigation interface.
If the memory card does not have map data, it will prompt download and enter the map management
interface after conrming.
Clicking icon description
1. Map download: Click the top left corner, “ ” then click oine data, and then click on the oine map,
select the city map data you need to download.
2. Download Management: Download all or pause, also you can click the city to cancel or pause the
download.
3. Download Manager: You can update all apps, click the city to select “delete data” or “update”.
Top left corner, “ ” Return to the previous level interface.
Local music
Click the main interface "music" to enter the local music interface.
This operation is valid when the unit has a SD card or USB interface and the corresponding media les.
www.PyleUSA.com
3
Phone

Online music
Click on the main interface "online music" to enter the online music interface.
Need to connect to the internet.
Music player button function description
Folder
Enter the sound settings
Loop playback mode switch
Previous/next song
Pause (Play)
Video playback
Click "Video Player" to enter the video player interface (supports 1080P HD video).
This operation is valid when the unit has a SD card or USB interface and the corresponding media les.
Click the "All icon" to switch between All/SD/U Disk/File Browser. When the video le is read, the system
automatically plays the le that has not been played last time the video player is opened again.
Clicking icon description
Menu
Last track
Play/Pause
Next song
Full screen
Calendar
Displays the day, month and year. Use forward and back arrows the view past or future months.
Selected dates are highlighted in blue.
Radio
Click the main interface "radio" to enter the local radio
Clicking icon description interface (FM / AM band can store 40 eective platforms each)
Click to search channel backwards then stop
when nd clear channel.
BAND to switch between mode FM1/FM 2
Search for radio station
Click to search channel forwards then stop
when nd strong and clear channe1.
Forward tuning radio
Backward tuning radio
Locate and DX
Audio settings
www.PyleUSA.com 4

Wireless BT
Click the main interface "Bluetooth®" to enter the Wireless BT connection interface.
When the BT is not connected: Enter the Wireless BT interface, there is no BT connection device displayed.
Click the Wireless BT interface, such as the dial key, you will be prompted "Please connect HFP."
www.PyleUSA.com
5

www.PyleUSA.com 6
DSP 32bands
Golden nger
Swipe your nger to easily make DJ adjustments
Phone Link APP
For the detailed operation instruction for Phone Link, please follow the instruction on actual unit.
Third Party Apps
For the detailed operation instruction for a certain 3rd party App, such as Google map, Youtube etc., please
contact your 3rd party App provider for further service.
Steering wheel learning
Steering wheel learning steps are as follows:
1. Press any key on the steering wheel, the interface will display “please long-press and hold a direction key”,
without pressing the steering wheel button for a certain period of time will lead to failure.
2. Click on the screen to access docking function
3. Press the corresponding function button on the steering wheel.
Follow the steps 1 - 3 until all control buttons on the steering wheel is nished.
Note: Click ” ” will reset all the saved keys.
If you perform a "System Reset" operation in "Factory Mode Settings", please resave the steering wheel
before using again.
The realization of this feature:
1. For non-bus control of the original car steering wheel.
2. The original car steering wheel keys need to be voltage input control.
Brightness setting: Click the “+” or “ -” icon to adjust the value.
Volume settings: Slide the button directly to adjust the media volume and call volume.
GPS monitoring: View related GPS information, click ” ” to restart GPS.
Sound settings
1. Click the slider to adjust Subwoofer, bass, midrange, treble.
2. Settings can be made in Rock/Custom/Classic/Jazz/Pop by clicking the corresponding icon.
3. Click the upper right comer of the speaker to“ ”et four icons or dick the centre dot to adjust the
speaker position settings.
4. Click the "default" icon will restore the sound settings parameters to the system default state.

www.PyleUSA.com
7
Memory clean
Cleaning up memory speeds up the system.
Desktop wallpaper
According to your personal preference, you can go from "wallpaper" to "dynamic wallpaper" the "gallery"
sets the wallpaper as prompted.
Reset
Reset Network: This will reset all network settings, including (WLAN, Mobile Data Network, Wireless BT)
Restore factory settings: This will restore the system to factory settings and clear all data in your device's
memory.
Time setting
Determining the date and time automatically can be turned on, optionally using the network or provided by
GPS. If you need to adjust the time manually, it need to be switched o, click directly to mobilize the time or
date. Determining the time zone automatically can also be opened. It can be manually adjusted after
switching o. It can also open or close the 24-hour system.
Dual HD DVR Camera
• Front camera + Rear Camera,
• Best Parking Assistance For Lady Driver
• These two cameras work as DVR camera as well
Front and Rear dual HD DVR camera
• Dual camera cover both front and rear angle for great protection and peace of mind on the road.
• Monitoring the roads ahead and behind the car simultaneously.
• The videos taken by the rear camera are stored alongside those from the front camera on the memory
card for easy access.
Gravity Sensor
With built-in G-sensor, it can automatically detect a sudden shake/collision and lock the footage to prevent
the video from being overwritten even in cycle recording. Accident scene can be truly restored.
Cycle Recording
Automatically overwrite the oldest le when the memory disc is full, never need to worry about memory
capacity.
24-Hours Parking Monitor
• Parking mode monitors your car's surroundings while car is parked.
• If someone hits your car and impact reaches the G-Sensor, the front and rear camera will turn on and
record a short video, then lock and save it, and turn o automatically.

www.PyleUSA.com 8
Troubleshooting
Q: Unit doesn’t power up.
A: Use a multi-meter to check for 12v+ to red and yellow wires. Check for proper Ground on the Black wire.
Q: My video does not play.
A: Attach “PARK” wire to parking break. When this wire is grounded the video will play
(Grounding trigger of the parking brake)
Q: Reverse camera does not come up on the screen.
A: Attach “BACK UP CAMERA” wire to reverse tail light 12v+ (Make sure camera is and sending video signal)
Q: Can I set up steering wheel control?
A: Key 1 and Key 2 wires need to be wired to your vehicle’s steering wheel column
Q: The time I set is not saved after device reboot.
A: Are other setting saved? If not: Check that yellow memory wire is attached to 12v+ constant
A: Turn o GPS auto update
Go to radio settings > Set Time > switch o auto update
Q: My GPS gets no reception.
A: Check if the antenna properly connected.
A: Mount Antenna directly to your vehicle (GPS antenna is to be magnetically mounted, it will boost GPS
reception when attached)
A: Check alternate antenna placement to test for interference
Q: How to I set the time?
A: System setting, set time
Q: How do I turn up GPS instruction volume (I Can’t hear it over music)
A: Change GPS sound settings
Go to Navi > Settings > Sounds > Set GPS voice level to max > Set radio volume to min (Adjust accordingly)
Q: Where can I download rmware updates?
A: This unit’s hardware does not allow it to be updated with new OS or rmware.
Q: How do I play video les? My unit cannot read my digital video les.
A: Make sure SD card is compatible
A: Check le format of your le. (You may need to convert your video le to an alternate le format)
You have entered the 'Touch Screen Calibration Menu'. For optimum touchscreen performance, this
feature enables you to enjoy the best functionality of your device's touch screen.
To complete the touchscreen calibration, an "X" will appear in the circles on the screen in numbered
order, continue to press the center of the "X" as it passes through each numbered circle.
(In circle number one, you will see an "X", touch the center of the "X", then the "X" will move to circle
number two. Continue to touch the center of the "X" as it will move to the other circles in numbered order.
If calibration senses an error, the process may restart; Repeat if necessary.)

www.PyleUSA.com
9
Wiring - Back Panel:
1. For GPS antenna
2. For radio antenna
3. For power cable
3
ANT GPS 4G
2
1
1. AMP_+12V
2. R_AXU_R
3. R_AXU_L
4. NA
5. NA
6. NA
7. NA
8. NA
9. NA
10. MIC-
11. GND
12. RCA_FL
13. RCA_FR
14. GND
15. GND
16. GND
17. CVBS_OUT1
18. SUB_OUT
19. AUXINCVBS
20. MIC+
A B C D
1. NA
2. NA
3. NA
4. GND
5. GND
6. Power 5V
7. NA
8. NA
9. NA
10. Rear Camera
11. Front Camera
12. Power 5V
1. GND
2. RCA_RL
3. FRONT_IR
4. CAN_TXD
5. NC
6. RCA_RR
7. NC
8. CAN_RXD
1. USB_5V
2. GND
3. USB0+ DP0
4. USB0- DM0
E
F
1. USB_5V
2. GND
3. USB2- DM2
4. USB1+ DP1
5.USB1- DM1
6. USB2+ DP2
1. TXD_TPMS
2. RXD_TPMS
3. IR
4. CAM_12V
5. PBK
6. WIFI_ANT
7. GND
8. NA
9. GND
10. BT_ANT

1. For power cable
WIRING
* Pink wire tells the monitor when to activate and display rearview camera on the display (optional)
www.PyleUSA.com 10

Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]
