Pyle PHPD82A User manual

Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]
Dual 8’’ Wireless BT Portable PA Party Speaker
Portable PA & Karaoke Party Audio Speaker,
with Built-in Rechargeable Battery, Flashing Party Circular Rotary Lights,
MP3/USB/ /FM Radio (300 Watt MAX)

WARNING
1. DO NOT place objects on top of the device, as objects may
scratch the device.
2. DO NOT expose the device to dirty or dusty environments.
3. DO NOT insert any foreign objects into the device.
4. DO NOT expose the device to strong magnetic or electrical eld.
5. DO NOT use the device in the rain
6. Please check with your Local Authority or retailer for proper
disposaI of electronic products.
7. DO NOT disassemble the device. Only a certied service
technician should perform repair.
8. The device has apertures to disperse heat. DO NOT block the
device ventilation, the device may become hot and malfunction
as a result.
CONTROL BOARD FUNCTIONS
1. Power Switch
2. Master volume control
3. DC 13.5V input jack
4. Bass volume control knob
5. Treble volume control knob
6. Microphone Echo control knob
7. USB and Micro SD Memory Card Slot
8. 3.5MM AUX input jack
9. 6.5MM microphone input jack
10. LED light switch
11. Microphone volume control knob
12. LED MODE
13. Mode button: Short press to choose BT, FM, AUX, USB, SD mode
14. Previous
15. Play/Pause/press and hold for TWS function
16. Next
17. Short press to start recording, and short press again to save and play recording
Press and hold press to play recording les, and press and hold again to quit
recording
18. Microphone priority button: Short press to start microphone priority.
When playing the recorded le, press and hold to delete current recording.
19. X-BASS
20. Guitar input
21. Guitar Volume
www.PyleUSA.com
2www.PyleUSA.com 3
ILLEGAL OPERATION MAY CAUSE PERSONAL INJURY, WHICH COULD BE FATAL.
ILLEGAL OPERATION MAY CAUSE DAMAGE TO PROPERTY
7
9
•
19
20
21

TROUBLESHOOTINGREMOTE CONTROL FUNCTIONS
TWS FUNCTION
For increase sound eect, our unit provides TWS function as follows:
Step-1: Turn ON BT mode on your device and connect the machine.
Step-2: Press and hold each control board“TWS” button more than 3's, and you will
see "ON" on display, unit will start to connect the other unit automatically,
now you can enjoy stereo sound, and adjusting one unit volume will aect
the other unit.
Remark:
1. After connection, press and hold again one of control board "TWS" button more
than 3's, you will see "OFF" on display, unit's TWS dis-connection.
www.PyleUSA.com
4www.PyleUSA.com 5
1. Power: Used to turn on/o the MP3
player power.
2. MODE: Used to switch the AUX/USB/BT/
Radio
3. Mute button
4. In FM mode, press to search radio station
automatically and save.
5. Next song of USB/In FM mode, short
press to select next frequency, press and
hold to fast-forward frequency
6. Previous song in USB//In FM mode, short
press to select last frequency, press and
hold to fast backtrack frequency.
7. EQ solution
8. Repeat song
9. Increase volume
10. Decrease volume
11. Play/Pause/In FM Mode, press to select
saved radio station.
12. Choose song number directly/In FM
mode, choose FM frequency directly. Wireless BT Connectivity:
• Built-in BT for Wireless Music Streaming
• Simple & Hassle-Free Pairing
• Works with All of Today’s Latest Devices
• Smartphones, Tablets, Laptops, Computers, etc.
• Wireless BT Version: 5.1
• Wireless BT Network Name: ‘PYLEUSA’
• Wireless Range: Up to 32’ft.
1. The audio format in the USB
is incorrect.
2. Improper operation has caused
a process disorder.
3. USB disc is disconnected.
1. Convert audio format into Mp3
format.
2. Reboot the machine.
3. Insert USB disc properly.
MP3
does not
play
Fault Possible Cause Solution
No sound
Distortion
of sound
Karaoke
does not
work
1. No input sound source.
2. Volume is too low.
1. Volume too high.
2. Speaker may be damaged
1. Microphone plug is not fully
inserted.
2. Microphone switch is not on.
3. Microphone volume knob is at
the lowest position.
1. Use a better music signal.
2. Adjust volume.
1. Turn down the volume.
2. If speaker is damaged, repair
or replace it.
1. Plug microphone properly into
the socket.
2. Turn on microphone switch.
3. Adjust microphone volume
properly.
This product can expose you to a chemical or group of chemicals, which may include
“Lead and lead compounds” which is known in the state of California to cause cancer, birth
defects, or other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.
