QA OCEANAIRE PAC Series Manual

ENGINEERING, INSTALLATION AND SERVICE MANUAL
PAC series
Portable Air-Cooled Spot Cooler
Form EISM-PAC-02112021

TABLE OF CONTENTS
PAGE
GENERAL INFORMATION …................................ 1
PRODUCT DATA AND SPECIFICATIONS............ 2
UNIT DESCRIPTION
Standard Features................................... 3
Applications / Operation.......................... 4
Electrical Configurations......................... 5
Use of Extension Cords…………………. 6
Condensate............................................. 7
Accessories……….................................. 8 - 14
Inspection/Installation.............................. 15
Thermostat Operation……...................... 16
SERVICE
Replacement Parts Procedure................. 17
Troubleshooting Guide............................. 18
Preventive Maintenance........................... 19
Interior View.............................................. 20
DIAGRAMS/SCHEMATICS
Piping Schematic………………………… 21
Single Phase Wiring Diagrams................ 22-23
Three Phase Monitor............................... 24
Three Phase Wiring Diagrams................. 25 - 28
WARRANTY…......................................................... 29
END USER INFORMATION and TECH NOTES..... Back Page
FORWARD
This manual provides the user with basic details for the installation and opera-
tion of the OceanAire PAC spot cooler. It is recommended to read and fully
understand the instructions outlined within this manual, before operating the
PAC unit.
As with all commercial air conditioning equipment, it is recommended to have
the PAC sized and installed by a licensed specifying engineer and contractor, in
accordance with all local and state codes. The length of service received can
be extended by following the installation and preventive maintenance
instructions.
NOTICE
In our ongoing process of continuous improvement, the items and procedures
described in this manual are subject to change without notice. Please note
model and serial number of the PAC unit when contacting the factory.

NOMENCLATURE
P AC 18 1 1
PORTABLE VOLTAGE
AIR-COOLED PHASE 1 or 3
NOMINAL CAPACITY
CAPACITY RATING
12..........12,000 BTU/HR
18..........18,000 BTU/HR
24..........24,000 BTU/HR
36..........36,000 BTU/HR
60……...60,000 BTU/HR
GENERAL INFORMATION
The OceanAire PAC series is a portable air-cooled spot cooler designed for
permanent or temporary cooling applications. The entire air conditioning unit
has been built in a premium sheet metal cabinet, equipped with heavy-duty
casters for mobility. All PAC models come standard with a 10-foot power cord
for electrical connection and added mobility in service. These spot-coolers are
designed to direct air to specific areas or objects through a discharge grille lo-
cated on the upper-front of the unit, while rejecting heat from the top of the unit.
The PAC models range in cooling capacities from 12,000 BTU/HR to 60,000
BTU/HR to satisfy most space cooling requirements.
The PAC series is a self-contained unit with the entire cooling system (blower
assemblies, electrical and refrigerant components) neatly arranged in a gray
polyester powder coated metal cabinet. When connected to the proper source
of electrical power, a 24-volt thermostat controls the PAC unit to provide the
desired level of comfort and cooling.
A wide variety of accessories and factory installed options are available for the
PAC series allowing for improved performance and versatility.
WARRANTY CARD
It is important that the warranty card be filled out completely and returned to
the factory within fourteen (14) days of installation of the unit in order to
receive the benefits of the warranty.
1

2
SPECIFICATIONS PAC
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Cooling Capacity is total BTUH at 80ºDB/67ºWB return air, 95ºF Outdoor at
high fan speed
Dedicated Circuit and Time Delay fuses/circuit breakers are recommended
EER is determined at high fan speed, with condenser discharge air ducted into
another area
CFM with free discharge
COOLING AMBIENT OPERATING RANGE 65º TO 105º
NOT APPROVED FOR OUTDOOR USE
MODEL: PAC 1211 1811 2412 3612 3632 3634 6012 6032 6034
COOLING CAPACITY 11,800 16,800 24,020
VOLTAGE (V/Phase) at 60Hz 208-230/3 460/3 208-230/1 208-230/3 460/3
AMPS 10.4 14.1 14.9 19.6 17.2 8.7 32 20.4 14.8
TOTAL WATTS 1180 1670 2700
IN-RUSH CURRENT (AMPS) 60 75 68 113 93 60 178 162 87
PLUG TYPE 5-15P LCDI 5-20P LCDI 6-20P LCDI 6-30P LCDI L15-30P L16-20P 6-50P L15-30P L16-20P
EER 8.9
COMPRESSOR ROTARY ROTARY ROTARY
COMPRESSOR HP 1 1.5 2 3 3 3 5 5 5
COMPRESSOR LRA 50 63 48 83 77 35 158 137 60
EVAP CFM 400 600 810
EVAP MOTOR HP
CONDENSER CFM 580 930 1010
COND MOTOR HP 1/3
CONDENSATE
R-410A CHARGE (oz.) 18 40 37
(A) HEIGHT (in.) 37-3/4
(B) WIDTH (in.) 20
(C) DEPTH (in.) 25
NET WEIGHT (lb.) 180 400 520
365
30
35
39-1/2
260
485
60,100
36,050
3620
6000
24
27-1/2
2200
1
1
1/8
1/3
1390
1/8
PACSPECS03012020
115/1
1200
1950
208-230/1
10.0
10.0
SCROLL
SCROLL
5 Gallon Condensate Tank - STANDARD (Pump Optional)
Pump - STANDARD (20 ft. Lift)
66
80
45-3/4
50-1/4
51-3/4
WARRANTY
All Oceanaire products are
covered by the Oceanaire
Limited Warranty
1 YEAR ON THE FULL
PRODUCT
Plus, 4 additional years
for the compressor
(Restrictions Apply)
PRODUCT FEATURES
• 24 VOLT NON-PROGRAMMABLE ELECTRONIC
THERMOSTAT
• SWIVEL BALL BEARING CASTERS WITH
LOCKING FRONTS
• 2 SPEED FAN SWITCH
• CONDENSATE OVERFLOW ALERT LIGHT
• LCDI POWER CORD (SOME MODELS)
• HIGH PRESSURE SAFETY SWITCH
• WASHABLE ELECTROSTATIC AIR FILTER
• THREE PHASE MONITOR (SOME MODELS)

STANDARD FEATURES
CABINET
The PAC series cabinet is constructed of 18 gauge steel with a gray polyester
powder coated finish that will compliment any decor. The entire cabinet is insulated
with sound- absorbing insulation for cool, quiet comfort. All units come equipped
with handles and swivel casters for portability and convenient set-up.
ELECTRONIC THERMOSTAT
All PAC units are equipped with a non-programmable electronic thermostat. When
power is connected to the unit, the thermostat will control the unit to cool a space to
the desired temperature. The thermostat is also capable of controlling the fan to
operate automatically when needed, or continuously. To protect the compressor
from short-cycling, there is a built-in time delay.
FAN SPEED CONTROL
A two position rocker switch, located next to the thermostat, provides the user with
the option of running the evaporator fan at high-speed or low-speed.
CONDENSATE TANK/PUMP
PAC series units come equipped with a means for handling the condensate gener-
ated during the cooling process. All units, except the PAC60 models, come
equipped with a condensate tank. The tank can be easily removed from the unit
and emptied as needed.
The PAC60 models come equipped with an Automatic Condensate Pump that re-
moves the condensate. The pump comes with a 20 foot long vinyl hose that allows
for the removal of the condensate water to a drain. The automatic pump is capable
of a 20ft vertical lift, to handle various installation requirements.
CONDENSATE ALARM LIGHT
On the front of all PAC models, there is a Condensate Alarm Light (RED) located
near the thermostat. For models other than PAC60, the light indicates that the con-
densate tank is full, and needs to be emptied. PAC60 units, the light indicates a
condensate pump over-flow condition where the pump is either disabled or restrict-
ed, and cannot remove the condensate water, and must be serviced.
FILTERS
All PAC series units are equipped with washable filters at the air intakes. Electro-
static mesh air filter located behind the evaporator return air grille serves to filter
the air before it is cooled. A 1/2” aluminum mesh filter serves to protect the con-
denser coil from dust build-up. Both filters can be easily removed and cleaned.
HIGH PRESSURE SAFETY SWITCH
Located on the back of the PAC unit is a manual re-set high pressure switch, used
for the protection of the compressor. If the condensing pressure exceeds the limit
setting, the switch will cycle the compressor off, while the evaporator fan remains
running. The compressor can be re-started, once the condensing pressure has
equalized, by depressing the “RESET” button.
POWER CORDS
All PAC units come standard with a power cord for a convenient connection. All
models, except for the 3-phase units and 5-ton units, are equipped with a LCDI for
added safety features.
3

4
APPLICATIONS
COOLING MODE—SPOT COOLER
The PAC can be used in an open environment to cool specific objects or "spots". Spot
Cooling is a convenient and economical way to provide air conditioning, where cooling the
entire space is impractical. Cool air is discharged from the unit and is directed where it is
needed. Nozzle kits can be used for directional cooling.
AREA COOLER
When the PAC is installed in an open area, the condenser exhaust duct directs the warm
air away from the space, allowing the evaporator air to cool the specific area.
ROOM AIR CONDITIONER
When ducted properly, the PAC can be used as a room air conditioner to cool an enclosed
space. Using the condenser return air plenum, additional ceiling kit, and other
accessories, the PAC can then operate as a room air conditioner with the condenser air
isolated from the conditioned space.
PAC SERIES—OPERATION / DESCRIPTION
CONDENSER
AIR INLET
(Back of Unit)
CONDENSER FAN DISCHARGE
“HOT”
EVAPORATOR
FAN DISCHARGE
“COOL”
WASHABLE
GRILLE
AND FILTER
CONDENSATE
ALARM LIGHT FAN SPEED
SWITCH
ELECTRONIC
THERMOSTAT
EVAPORATOR
RETURN

SERVICE CORD
All PAC series units are equipped with a standard 10-foot long service cord with plug
configurations and receptacle requirements as shown in this chart. PAC1211,
PAC1811, PAC2412 and PAC3612 units come with LCDI (Leakage Current Detection
& Interruption) devices that serve as a means of electrical protection.
CAUTION—DO NOT USE THE LCDI AS AN ON/OFF SWITCH
FOR THE UNIT
All 3-phase models are equipped with locking plugs for added connection reliability.
Refer to the chart below for plug and receptacle details for all PAC models.
A DAMAGED LCDI POWER SUPPLY CORD MUST BE
REPLACED WITH A NEW POWER SUPPLY CORD
OBTAINED FROM OCEANAIRE, AND NOT REPAIRED
UNIT/MODEL PLUG CONFIGURATION RECEPTACLE
115 VOLT
PAC1211 NEMA 5-15R
115 VOLT
PAC1811
NEMA 5-20R
208-230 VOLT SINGLE PHASE
PAC2412
NEMA 6-20R
208-230 VOLT SINGLE PHASE
PAC3612
NEMA 6-30R
208-230 VOLT SINGLE PHASE
PAC6012
NEMA 6-50R
208-230 VOLT 3-PHASE
PAC3632
PAC6032 NEMA L15-30R
460 VOLT 3-PHASE
PAC3634
PAC6034
NEMA L16-20R
5
ELECTRICAL CONFIGURATION
15A-125 VOLT
NEMA 5-15P
20A-125 VOLT
NEMA 5-20P
20A-250 VOLT
NEMA 6-20P
30A-250 VOLT
NEMA 6-30P
50A-250 VOLT
NEMA 6-50P
30A-250 VOLT
NEMA L15-30P
20A-460 VOLT
NEMA L16-20P

6
USE OF EXTENSION CORDS
CAUTION
FOR MODEL PAC1211 AN EXTENSION CORD CAN BE USED, PROVIDED IT
IS RATED AT LEAST 15 AMPS @ 115 VOLTS WITH GROUNDING-TYPE
ATTACHMENT PLUG AND GROUNDING TYPE CONNECTOR (LOAD FITTING)
FOR MODEL PAC1811 AN EXTENSION CORD CAN BE USED, PROVIDED IT
IS RATED AT LEAST 20 AMPS @ 115 VOLTS WITH GROUNDING-TYPE
ATTACHMENT PLUG AND GROUNDING TYPE CONNECTOR (LOAD FITTING)
FOR MODEL PAC2412 AN EXTENSION CORD CAN BE USED, PROVIDED IT
IS RATED AT LEAST 20 AMPS @ 250 VOLTS WITH GROUNDING-TYPE
ATTACHMENT PLUG AND GROUNDING TYPE CONNECTOR (LOAD FITTING)
FOR MODEL PAC3612 AN EXTENSION CORD CAN BE USED, PROVIDED IT
IS RATED AT LEAST 30 AMPS @ 250 VOLTS WITH GROUNDING-TYPE
ATTACHMENT PLUG AND GROUNDING TYPE CONNECTOR (LOAD FITTING)
FOR MODEL PAC6012 AN EXTENSION CORD CAN BE USED, PROVIDED IT
IS RATED AT LEAST 50 AMPS @ 250 VOLTS WITH GROUNDING-TYPE
ATTACHMENT PLUG AND GROUNDING TYPE CONNECTOR (LOAD FITTING)
FOR MODELS PAC3632 AND PAC6032 AN EXTENSION CORD CAN BE
USED, PROVIDED IT IS RATED AT LEAST 30 AMPS @ 250 VOLTS, 3 PHASE
FOR MODELS PAC3634 AND PAC6034 AN EXTENSION CORD CAN BE
USED, PROVIDED IT IS RATED AT LEAST 20 AMPS @ 600 VOLTS, 3 PHASE
SPECIAL NOTICE—THREE PHASE OPERATION
Models PAC3632, PAC3634, PAC6032 and PAC6034
All three-phase PAC models are equipped with a three-phase monitor for added com-
pressor protection. The phase monitor, located in the control box, has a multi-color
LED that reports status. The monitor protects the compressor from reverse operation,
phase loss, and low voltage situations. Further description of the three-phase monitor
is located in the electrical section of this manual.
NOTICE - DO NOT OPERATE ANY THREE-PHASE UNIT WHILE BYPASSING
THE MONITOR. THIS WILL VOID THE WARRANTY.

7
MAXIMUM WATER LEVEL
4” FROM TOP OF TANK
This Side Up
FRONT
CONDENSATE TANK
“FULL” SWITCH
SPRING
CAP
HANDLE
WATER LEVEL
ADJUSTMENT
SCREW
HINGE
CONDENSATE TRAY
TANK LEVEL ADJUSTMENT INSTRUCTIONS
An adjustment screw is provided to vary the cut-off level
of the tank full switch. If less water is desired, turn the
adjusting screw clockwise (CW).
Turning the screw clockwise (CW),
will make the tank easier to remove.
MAXIMUM WATER LEVEL
4” FROM TOP OF TANK
CAUTION
UNPLUG UNIT BEFORE REMOVING
TANK TO ADJUST THE SET SCREW.
CONDENSATE
SUMP
TOP OF TANK
(WHEN PLACED IN UNIT)
SUMP DRAIN HOLE
COMPRESSOR/
CONDENSER FAN
CIRCUIT WILL TRIP,
AND RED ALARM
LIGHT WILL TURN
ON
CONDENSATE
For Models PAC1211, PAC1811, PAC2412, AND PAC3612, a 5-gallon polyethylene tank
is provided to collect condensate. The tank is located in the lower front section of the unit,
and can be accessed though the condensate tank door. When the high water level is
reached, a cut-out switch will AUTOMATICALLY cycle off the compressor/condenser fan.

8
NOTE - IT IS IMPORTANT TO SPECIFY MODEL NUMBER
AND SERIAL NUMBER WHEN ORDERING ACCESSORIES
PAC series Optional ACCESSORIES

PAC series Optional ACCESSORIES
NOZZLE KIT
2NK-1 (2 X 4-Inch) PAC12
2NK-2 (2 X 6-Inch) PAC18, 24
2NK-3 (2 X 8-Inch) PAC36, 60
EVAPORATOR RETURN AIR PLENUM
DEP-10 (10-Inch Round) PAC12
2DEP-12 (12-Inch Round) PAC18, 24
DEP-16 (16-Inch Round) PAC36, 60
DISCHARGE DUCT ADAPTER
2DDA-6 (6-Inch Round) PAC12
2DDA-10 (10-Inch Round) PAC18, 24
2DDA-16 (16-Inch Round) PAC36, 60
CONDENSATE PUMP KIT *
UPK-115 115V Models
UPK-230 230V Model
CEILING PANEL KIT
CK-12 Kit for PAC12, 18, 24
CK-16 Kit for PAC36, 60
DUCT FLANGE
DF-12 12-Inch Duct Flange
DF-16 16-Inch Duct Flange
CONDENSER RETURN AIR PLENUM
2DCP-1 (12-Inch Round) PAC12
2DCP-2 (12-inch Round) PAC18, 24
DCP-5 (16-Inch Round) PAC36, 60
9

10
ACCESSORIES
CEILING PANEL DUCT KIT
A ceiling panel kit is available for discharging the
condenser air above a drop ceiling. The ceiling
panel duct kits are furnished with a white vinyl
coated flexible duct that allows for convenient
installation. A 2ft X 2ft ceiling duct- panel is
included to replace a 2ft X 2ft drop-ceiling panel
where the connection is desired.
The CK-12 is available for PAC12,18, and 24.
The ceiling panel kit consists of 8 feet of flexible
duct, and a 2' X 2' lay in ceiling panel.
The CK-16 (for 3 and 5-ton units) consists of a
ceiling duct-panel, and a 16 inch flexible duct.
Note—Drop ceiling spaces should be
vented or large enough to handle the warm
condenser air. Check local codes to assure
compliance.
If longer runs of duct are required, table below
lists maximum duct run with no bends. For every
90° elbow, subtract 6 feet from the run.
Ceiling
Kit
Model
Flexible Duct
Diameter X
Length
Fits
PAC12
Fits
PAC18
Fits
PAC24
Fits
PAC36
Fits
PAC60
CK-12 12 inch X 8 feet ✓✓✓No No
CK-16 16 Inch X 8 feet No No No ✓✓
25
(.20)
50
(.25)
60
(.25)
70
(.25)
80
(.50)
Maximum Equivalent
Feet (approx)
(ESP)
2 x 2 CEILING
DUCT-PANEL
VINYL COATED
FABRIC DUCT
DUCT FLANGE
DUCT STRAP

ACCESSORIES
DISCHARGE AIR NOZZLE KIT ASSEMBLY
The optional discharge nozzle kits are used to direct the conditioned
air to a specific target area. By concentrating the airflow, the nozzles
increase the air velocity towards production lines to cool personnel
and/or equipment. In server rooms, the nozzles can be used to
direct the airflow through the rack to remove the hot air from the
area of the equipment.
2NK-1 for model PAC12, (2) 4-inch diameter nozzles with an
approximate compressed length of 15 inches. The approximate
extended length is 21 inches.
2NK-2 for models PAC18, PAC24 (2) 6-inch diameter nozzles
with an approximate compressed length of 22 inches. The
approximate extended length is 32 inches.
2NK-3 for models PAC36 and PAC60, (2) 8-inch diameter
nozzles with an approximate compressed length of 20 inches. The
extended length is approximately 29 inches.
The nozzle kits come pre-assembled with the nozzles secured to a
mounting plate and with edge guards. By removing the discharge
grille, you can insert the nozzle kit into the opening without the use
of tools.
Nozzle Kit
Kit Voltage
UPK-115 115V
UPK-230 208/230V
Replacement Pump Only
057-008R 115V
057-012R 230V
CONDENSATE PUMP KIT
A plug-in condensate pump kit is available for applications where emptying the 5 gallon
condensate tank is not practical. The pump kit consists of a condensate pump with
mounting hardware and electrical connections, along with the tubing required for the drain
and discharge of the condensate water.
PARTS LIST
• Condensate Pump with Mounting
Hardware/Screws
• Drain hose
• Tubing
• Wiring Harness
• Low Voltage Jumper
• Hose Clamps
Pump Kit
The condensate pump provides for the
automatic removal of condensate water during
the cooling process. The pump is capable of
pumping to a 20 foot height, allowing for the
routing of the drain line above the drop-ceiling
to a nearby drain. The pump is controlled by
an internal float-switch/check valve, which
turns the pump on and off automatically. The
pump is also equipped with a condensate over
-flow safety switch that will shut down the unit
compressor when the pump is not working
properly.
11

ACCESSORIES
CONDENSER RETURN AIR PLENUM
Condenser return air plenums are available for installations where it is required to duct air
to the inlet of the condenser. The plenum easily fits into place on the back of the unit, and
is provided with a flange for connecting 12-inch or 16-inch flexible ducting. A condenser
return air plenum can substantially reduce air noise and allow the unit to operate without
drawing condenser air from the conditioned space. Refer to the table below for
configuration and application information.
NOTE — When installing the condenser return air plenum with a ceiling panel kit,
allow for a minimum separation distance of 2 feet between the unit discharge duct
and the return air duct. It is also recommended to direct the condenser discharge
air away from the condenser return air duct.
Plenum Kit Duct/Flange PAC12 PAC18 PAC24 PAC36 PAC60
2DCP-1 12-Inch ✓
2DCP-2 12-Inch ✓ ✓
DCP-5 16-Inch ✓ ✓
Maximum Approximate
Equivalent Feet
25 50 60 70 80
Estimated External Static
Pressure (.20) (.25) (.25) (.25) (.50)
2DCP-1, 2DCP-2 and DCP-5
To estimate the “equivalent feet” of condenser duct, add the length of the
condenser intake duct run and the length of the condenser discharge duct run, and
add 6 equivalent feet per bend in the duct. Make sure that you do not exceed the
rated E.S.P. to avoid shut down due to the high pressure cut-out
12

ACCESSORIES
EVAPORATOR RETURN AIR PLENUM
Evaporator return air plenums are available for installations where it is required to duct air to
the inlet of the evaporator. The evaporator return air plenums allow the user to connect
round ducts (flexible or rigid) to the return air intake to reduce air noise and increase the
number of options for solving difficult cooling problems. The plenum attaches to the front of
the unit, replacing the return air grille. Refer to the table below for configuration and
application information
DEP-10 for PAC12 transitions the return air opening to 10-inch round duct.
2DEP-12 for PAC18 and PAC24 transitions the return opening to a 12-inch round duct.
DEP-16 for PAC36 and PAC60 transitions the return opening to a 16-inch round duct.
NOTE—When a DEP is installed, it is recommended to set the evaporator blower
speed to high, to avoid evaporator coil freeze-up.
FILTER(S)
DEP—EVAPORATOR
RETURN AIR PLENUM
13
Plenum Kit
Duct/
Flange
PAC12 PAC18 PAC24 PAC36 PAC60 FILTERS
DEP-10
10 inch ✓ (1) 10 x 20 x 1”
2DEP-12
12 inch ✓ ✓ (1) 16 x 24 x 1”
DEP-16
16 inch ✓ ✓ (1) 10 x 30 x 1”
(1) 12 x 30 x 1”
Maximum
Equivalent
Feet
25 50 60 70 80
Est. External
Static
Pressure
(.20) (.25) (.25) (.25) (.50)

ACCESSORIES
DISCHARGE DUCT ADAPTER
Discharge duct adapters are available for applications where ducted evaporator discharge
is required. The adapters can be easily installed on the unit without fasteners, and be
installed for either vertical or horizontal ducting. The standard discharge grille is removed
and the DDA is attached in the grille opening.
2DDA-6 for PAC1211, converts the evaporator discharge to a 6-inch diameter
round duct.
2DDA-10 for PAC1811 and PAC2412, converts the evaporator to a 10-inch
diameter round duct.
2DDA-16 for PAC36 and PAC60 models, converts the evaporator discharge to a
16-inch round duct.
When used in conjunction with the evaporator return air plenum, DEP/2DEP, the unit can
provide closed-loop cooling to and from a given space without the influence of any
outside air.
14
Adapter
Model
Round
Duct
Size
PAC12 PAC18 PAC24 PAC36 PAC60
2DDA-66-inch ✓
2DDA-10 10-inch ✓✓
2DDA-16 16-inch ✓✓
Maximum
Equivalent
Feet
25 50 60 70 80
Maximum
E.S.P (.15) (.25) (.25) (.25) (.50)

15
INSTALLATION INSTRUCTIONS
RECEIVING—INSPECTION
Upon receiving your PAC unit, inspect the packaging for any damage. All units are
shipped on a skid, and packaged in a triple-wall carton for added protection.
BEFORE INSTALLING
Check the unit for any damage. All OceanAire products are thoroughly inspected at the
factory and carefully packaged. If any damage is evident, contact OceanAire
IMMEDIATELY.
ELECTRICAL REQUIREMENTS
Check the nameplate located on the back of the unit to confirm the proper power is
available for the unit. Refer to "Specifications" section for voltage and amperage
requirements. For proper NEMA receptacles, refer to "Electrical service plug
configuration". When using extension cords, use the proper gauge cord, and check
cord voltage to the unit.
TIME DELAY FUSES/CIRCUIT BREAKERS ARE RECOMMENDED
WARNING—OPERATING THE UNIT ON IMPROPER
VOLTAGE WILL VOID THE WARRANTY
ACCESSORIES
Verify that all accessories are correct for the model, and are installed in accordance
with all instructions.
START-UP
Install the unit in accordance with all local and state building codes, and install all
accessories. Allow for a clearance around the unit for future maintenance and/or
service. Level unit and lock casters, when available. Connect power and test the
LCDI on the power cord (if available). Power up unit, via thermostat and check for
proper operation. Refer to Thermostat Operation for more details.

16
THERMOSTAT OPERATION
FAN SLIDE SWITCH
The FAN Slide Switch allow you to set the fan mode from ON (fan is on all the time) to
AUTO (fan cycles under thermostat control)
MODE SLIDE SWITCH
To turn the unit ON, slide the Mode Slide Switch down to the COOL position. To turn the
unit OFF, slide the Mode Slide Switch to the OFF Position.
TEMPERATURE BUTTONS
Once the MODE switch has been put into the COOL mode, push the corresponding arrow
button to lower or raise the set point to the desired temperature. The display will show
the set-point temperature with the word “SET” and will blink for 5 seconds. Then it will
return to display the room temperature. After the time delay has been satisfied, the fan
motor and compressor will start, beginning the cooling cycle. Remember, the set-point
must be lower than the room temperature for the unit to start.
AUTO
ON
COOL
OFF
TEMPERATURE
CHANGE
BUTTONS
FAN
SLIDE
SWITCH
MODE
SLIDE
SWITCH
TEMPERATURE
DISPLAY
DIGITAL, NON-PROGRAMMABLE THERMOSTAT
This is a cooling only thermostat *. Select the temperature you want by pressing the ▲ or
▼ buttons.
No batteries are required. If there is a power failure, the thermostat will start up at the last
known set point, when the power is restored.
Compressor short cycle protection is a built-in feature of the thermostat. A 4-minute time
delay will occur on start-up or when power has been restored after a power interruption.
*New cooling thermostat , effective 01-25-2016 , on units with S/N: U1

REPLACEMENT PROCEDURE FOR PARTS
IT IS RECOMMENDED THAT ALL OCEANAIRE UNITS BE SERVICED
BY A QUALIFIED AIR CONDITIONING SERVICE TECHNICIAN
WARNING—TO AVOID INJURY, DISCONNECT UNIT POWER
PRIOR TO SERVICING
A. FAN MOTORS
1. Remove cabinet left-side panel (when looking at the front of the unit).
2. Evaporator fan motor—disconnect evaporator motor wires from evaporator fan
contactor and fan speed rocker switch. Condenser fan motor—disconnect condenser
motor wires from condenser fan contactor.
3. For all model sizes 12, 18, 24, and 36, remove the screws securing motors and
inlet-ring to blower housings (all screws are external and visible), and remove blower
wheel-motor assembly. Remove the blower wheel set screw and disassemble the blower
wheel from the motor shaft and remove the motor.
For model size 60 loosen blower wheel shaft set screw, remove the screws
securing the motor mount to the blower housing and then remove motor and mount.
4. Install the new motor assembly, reversing the removal procedure.
B. THERMOSTAT (NO BATTERIES REQUIRED)
1. Along both sides of the thermostat, insert a small flat blade screwdriver in the groove. With
a twisting motion, remove the cover plate from the sub base. Make sure the small
thermistor located near the top of the casing for temperature sensing, is not bent or
damaged.
2. To remove the thermostat sub-base, remove the 2 mounting screws and the 4 wires
(black, red, white, green). Make sure the 4 wires do not fall into the cabinet. Install
Sub-base by reversing removal procedure.
C. TANK FULL LIGHT
1. To replace the Condensate Alarm Light on all models, disconnect the wires from the
lamp and bend the tinnerman clip retaining light and pull out.
2. Install new light, reversing the procedure.
D. CONDENSATE PUMP (ON ALL PAC60 UNITS, OR ON UNITS
WHERE THE CONDENSATE PUMP KIT HAS BEEN INSTALLED)
1. Open panel door to allow access for condensate pump service.
2. Remove brackets securing condensate pump in base pan, or condensate tank tray pan.
3. Disconnect pump wire leads at Molex connectors. Remove retainer clamp and tubing.
4. Replace pump, install by reversing procedure.
E. HIGH PRESSURE SAFETY SWITCH
1. Remove cabinet left hand side panel, or left rear side panel of size 60 models.
2. Remove flare nut that secures capillary to the refrigeration system high pressure side.
A Schrader valve is located in the discharge port, and allows removal without losing
the refrigerant charge.
3. Remove two screws that secure high pressure switch.
4. Disconnect wire leads from compressor contactor and condensate pump safety switch.
5. Install new High Pressure Control, reversing the procedure.
To gain access to compressor and compressor run capacitor, remove left side panel(s).
17

TROUBLESHOOTING GUIDE
The following steps and procedures are recommended for correcting the problems
indicated. In the event that the problem can not be corrected, service may be required.
SERVICE SHOULD BE PERFORMED BY A QUALIFIED
AIR CONDITIONING SERVICE TECHNICIAN
PROBLEM: UNIT DOES NOT POWER UP
CAUSE: Power interruption
REMEDY: Check LCDI (on models with LCDI), and reset LCDI. Check external power
supply making sure that the disconnect is ON. Check for blown fuses or tripped circuit
breakers. Reset or replace if needed.
PROBLEM: NO DISPLAY ON THERMOSTAT
CAUSE: Faulty thermostat or faulty transformer
REMEDY: Thermostat may be defective...remove and replace. Transformer may be
defective...remove and replace.
PROBLEM: EVAPORATOR FAN RUNS BUT
COMPRESSOR AND CONDENSER FAN DO NOT
START
CAUSE: Thermostat — setting may be too high.
REMEDY: Make sure set-point is lower than room temperature.
Note—there is a time delay for the compressor
CAUSE: Thermostat—Loose wiring
REMEDY: Examine the control unit for loose wires. Tighten any loose connections.
CAUSE: Condensate Alarm—Check for Condensate Alarm Light.
REMEDY: Check condensate level and empty tank if needed, or (if installed) check
condensate pump and make sure pump is working properly. Confirm that there is no
restriction in the drain line from the pump.
CAUSE: High Pressure Cut-out—Check High Pressure Cut-out Switch.
REMEDY: Press Reset and clear away any air flow obstructions to the condenser
intake or condenser discharge.
CAUSE: Voltage — Check power supply for voltage outside the range of 106-126 volts
on the 115 Volt unit and 187-253 Volts on the 208/230 Volt unit.
REMEDY: Have power checked by electrician and repaired.
CAUSE: Compressor contactor open or burned.
REMEDY: Replace contactor.
18
