QBA JLT-PC001 User manual

Jlt-pc002 Intelligent insertion manual
Thank you for choosing to use our USB smart plug product.
1. Product display drawing
2. The characteristics of
a.4 USB charging ports. Intelligent identification, automatic shunt.
b.2 American gauge jack. Power: 1200W, 10A.
c. Power cord: 1.8m ETL certified wire rod.
d. Shell: Use high strength flame retardant material.
e. Surge protection, overload protection: if current, voltage,
temperature are overloaded. The product will automatically shut down to
protect your device. Resume, please turn on the overload protection power
switch again.
f. Power switch: Controls the total power supply of the product.
g. Display screen: HD VA screen, displaying time, date, alarm, room
temperature, daylight saving time.
h. Electronic clock: equipped with external battery box, 2 no. 7 AAA
batteries can be placed to prevent power outage, electronic clock memory
function.
Parameters of 2.
Model: JLT - PC001
Input voltage: AC100-250V, 50-60Hz Rated power: 1200W 10A

USB output voltage: DC 5V 3.1A [Max] Impact energy: 1700J
USB output voltage: DC 5V 3.1A each port intelligent identification,
automatic shunt
3. Operation process
A. Open the package and take out the host machine. Browse the instruction
manual
Put 2 no. 7 AAA batteries into the battery box at the bottom of the main
engine [Pay attention to +/- pole direction]
a.Plug in the power cord of the main engine and turn on the power switch
behind the main engine. At this point, the main engine drops a sound,
the electronic clock display light up, display content is normal.
b. Adjust the normal time and alarm clock time of the electronic clock
according to the operation process of the electronic clock.
5. Function description of electronic clock
a: ALARM/CLOCK,DST, SNOOZE/DIMMER,UP, DOWN, plus/minus.
b. 4-digit display time.
c. Clock 12H, alarm 24 hours
d. Buzzer alarm sound
e. LED backlight level 3 brightness
6. Full display of the screen:
7. Operation instructions of electronic clock:
a. Power-on operation

boot for the first time; The LCD is fully displayed, the backlight
is lit for 2 seconds, and BI goes into normal time mode with one sound
the default display:
Time: 6:00 AM
The alarm is off unless the alarm time is designed.
B. Time setting：
*in interface, long press "ALAM/CLOCK", enter the time setting, digital
is set time on flicker
single press "ALAM/CLOCK" set order to:
Hour and minute exit
in the process of setting, single press "UP", setting value plus one.
in the process of setting, single press "DOWN" key, set the value minus
1.
set up, single press the ALAM/CLOCK or 10 seconds don't press any key
to exit the setup mode
C. Alarm setting:
standard mode, short press the ALAM/CLOCK button to turn off the alarm
CLOCK, and then press enter the alarm Settings, be set a time Numbers
in flashing
set order: alarm clock hour clock minutes to exit the Settings
in the process of setting, single press "UP", setting value plus one.
in the process of setting, single press "DOWN" key, set the value minus
1.
set up, single press the ALAM/CLOCK or 10 seconds don't press any key
to exit the setup mode and return to normal time display mode.

Turn off alarm: Short press ALAM/CLOCK key to turn off the alarm function.
The alarm symbol disappears
C4. Alarm mode
*alarm sound BIBI 60 seconds at a time.
* when is the alarm, press any key to exit the alarm sound
* while in alarm, press the "SNOOZE/DIMMER" button to suspend the alarm,
SNOOZE mode, alarm ringing again after 5 minutes. A repeated SNOOZE
function occurs when an alarm goes off.
C5. Backlight function
single press the "SNOOZE/DIMMER" circulation adjust the backlight
brightness: brightness level 3 - > 2 - > brightness level - > out - >
brightness level brightness - > 2 - > brightness level 3 - > brightness
cycle
short opened/closed by DST daylight savings time.
C6. Celsius/Fahrenheit conversion display function
Short press DOWN to convert the Celsius/Fahrenheit display mode.
C7. If the product is not used for a long time, it is recommended to unplug
the power cord and not supply power to the machine.
