Qbic Technology Phantom BXP-100 User manual

Box PC
Quick Start Guide
BXP-100
This quick guide will help you go through installation quickly
Color and appearance may be subject to changes upon
product enhancements or updates without prior notice.
QUICK START GUIDE
DCARE AND WARNING
QUICK START GUIDE
Qbic Technology Co., Ltd.
www.qbictechnology.com
Tel: [phone]
Power Adaptor information:
Model No.: PSM10R-050
INPUT: 100~240VAC, 0.25~0.5 A
OUTPUT: 5V 2A MAX 10.0W
Adaptor must be used with this equipment to ensure
compliance with the Class B FCC limits.
RTC Battery Caution
Risk of explosion if battery is replaced by an
incorrect type. Disposed of used batteries
according to the instructions.
Correct Disposal of this product. This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
To return your used device, please use the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmental safe recycling.
Operation Temperature: 0~60°C (32~140°F)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
FCC Radiation Exposure Statement
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also
complies with Part 15 of the FCC RF Rules. This equipment must be installed and operated in accordance with
provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter. End-users and installers must be provided with antenna installation instructions
and consider removing the no-collocation statement.
NOTE: 4k60p outputs only in YUV420 color space.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio / box PC technician for help.
P49.06C01.0001
To download QSG in different language, please go to the website:
https://qrgo.page.link/NtCC8
Additionally, please also check with your contact window or Qbic FAE
for the authority to log in

Indicators
B
M4*8mm x 4
M3*6mm x 2
Content
Box PC
HDMI Cable (Option)
Quick Start Guide
VESA Mounting Kit Velcro Tie x 2 Power Plug
(Provided by regions)
for US for CE
for UK for AUS
A
Power Adaptor
Installation
C
21 6 9873 54
DC-IN
1
USB 3.0
2
USB 2.0
3
HDMI
4
LAN
5Status Light 7Micro SD 9
ADB (Service)
6 Reset Button 8
3. Velcro Mount
1. Cable Connections
Step 1. Step 2. Step 3. Step 4.
* Please ensure the mounting surface is smooth and clean before using the velcro strip.
* Velcro mount should only be used when device height is less than 2 meters from the ground.
QUICK START GUIDEQUICK START GUIDE
2. VESA Mount
Step 1. Step 2.
Screw 2 screws to secure the
VESA mount bracket onto the system
Screw 4 screws onto the back of a
VESA 75/75-compatible display
Surface
• Metal
• Glass
• Plastic
Power USB
3.0
USB
2.0
HDMI LAN
