QBOX User’s Manual

Trademark:
All trademarks are the property of their respective owners.
Version:
User’s Manual V1.1 for QBOX-N270.
P/N: 3A221LE00-000-G
Symbol description:
Caution : refers to important information that can help you to use QBOX better,
and tells you how to avoid problems.
WEEE:
The use of this symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could other-
wise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city ofce, your
household waste disposal service or the shop where you purchased this product.
CAUTION
!
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
All images are for reference only, please refer to the physical product for specic features.

Before using this product, please read the below safety notice carefully, this
will help to extend the product’s lifecycle, and work normally.
■ When QBOX is working, please make sure its ventilation system is working.
■ The power adapter is dissipating heat during normal use, please be sure not
to cover it and keep it away from your body to prevent discomfort or injury
by heat exposure.
■ Please use the power adapter that comes with the product’s package,
wrong power adapter may damage your device.
■ Make sure all the peripherals are properly connected before using QBOX.
■ This product should only be used in an environment with ambient tempera-
tures between 0◦C and 40◦C.
■ To reduce the risk of re, use only No. 26 AWG or larger UL listed or CSA
certied telecommunication line cord.
■ Always shut down the computer before installing or uninstalling the periph-
eral which does not support hot plug.
■ Disconnect all peripherals before servicing or disassembling this equipment.
■ Please do not disassemble this product by yourself, any disassembly not
approved by the original manufacturer may result in malfunction, and void
warranty.
■ Risk of explosion if battery is replaced by an incorrect type, please dispose
of used batteries according to the instructions.
CAUTION
!
Safety Notice :

TABLE OF CONTENTS
Chapter 1 Introducing the QBOX
Top View...................................................................................................2
Left Side View ..........................................................................................2
Right Side View........................................................................................3
Bottom View .............................................................................................3
Chapter 2 Placing and connecting the QBOX
Placement of QBOX.................................................................................5
Connection of QBOX................................................................................7
Chapter 3 Install Windows XP in QBOX
Install Windows XP.................................................................................10
Install Drivers in Windows XP ................................................................13
Chapter 4 FoxOS Introduction
First Boot................................................................................................15
Desktop ..................................................................................................17
Desktop Shortcut....................................................................................18
Chinese keyboard Input Mode ...............................................................19
Network Connection...............................................................................19
Chapter 5 Applications
Internet ...................................................................................................23
Ofce Applications..................................................................................24
Education and Learning .........................................................................26
Multimedia Applications..........................................................................26
Other Applications ..................................................................................28

The QBOX is a compact and easy to use desktop. It features all
the desktop capabilities but with a slim body design which enables
you to browse the internet in a relax and comfortable way.
This chapter includes the following information:
■ Top View
■ Left Side View
■ Right Side View
■ Bottom View

1
2
QBOX features all the desktop capabilities but with a slim body design which enables you to browse
the internet in a relax and comfortable way.
1-1 Top View
1-2 Left Side View
1
2
No. Name Description
1 Power Button Turning the power on/off
2 Computer Status
Indicators
From left to right: Num Lock Indicator
Caps Lock Indicator
Wireless Network Indicator
2
1 3 4 5 6
No. Name Description
1 Outlet Vents QBOX's ventilation system outlet
2 Power Input Port Connects to the power adapter
3Display Output Port (VGA) Connects to display device
4 USB Port Connects to USB device
5 Microphone In Connects to a microphone
6Headphone Out Connects to a headphone or amplied speaker

1
3
1-3 Right Side View
1-4 Bottom View
No. Name Description
1 Base Cushion Seat and protect QBOX when it is placed on the desk
2 Inlet Vents QBOX's ventilation inlet
1
2
2
1 4 53
No. Name Description
1Card Reader Supports MMC/SD/MS memory cards
2 USB Port Connects to USB device
3Modem Port (optional) Connects to a telephone line
4 Network Port Standard RJ-45 network port
5 Kensington® Lock Slot Connects to a security lock that prevent the
QBOX to be removed from a xed object

In this chapter, the placement and the connection of some neces-
sary peripherals will be introduced.
This chapter includes the following information:
■ Placement of QBOX
■ Connection of QBOX

2
5
2-1 Placement of QBOX
1. On the Desk
If there is enough space on your desk, you can simply put your QBOX on the tabletop as shown
below.
2. Under the Display
If you want to save the space on your desk, you can :
2.1 Adjust and t the QBOX body into the bracket as shown.
2.2 Place the whole unit under the LCD.

2
6
3.2 Fit the QBOX into the bracket with power button locating at the bottom for easy touch.
To install the bracket, your display must follow VESA75/VESA100 standard. The
bracket supports many holes to help you easily fasten it onto the display.
CAUTION
!
3. On the Display Back
This is the best space-saving way.
3.1 Use four screws come with the packaging to fasten the bracket onto the display back.
The diameter of screw is 4mm, and the length is 12mm.
