Qdis QNAVI II -STD-MAIN-V6.1 User manual

AUDI
Compatible with Audi 3G/3G+ MMI vehicles
LAST UPDATED: 2012.05.25
Model: QNAVIⅡ-STD-MAIN-V6.1
Product code: QNAVIⅡ-STD-MAIN-1112-007
Your best
partner
for better
driving
SUNE TECHNOLOGY CO.,LTD
No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN
TEL:[phone] FAX:[phone]
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
CarNavi-Tech

2
0. Contents
1. Before installation
1.1 Specification
1.2 Features
1.3 Components
1.4 Exterior
1.5 Dip switch
1.6 Original buttons in car
2. User interface
2.1 HOME
2.2 PHONE
2.3 MEDIA
2.4 SETUP
3. Installation
3.1 Pre-installation notices
3.2 Installation diagram
3.3 MMI, CAN Wiring
3.4 Connect of the Smart Phone
4. FAQ
4
3
5
7
12
13
15
21
23
24
25
28
9
10
30
CarNavi-Tech

33
1.1 System Spec.
INDEX
CONTENTS
INDEX
CONTENTS
CPU
Telechips TCC8900 (ARM11),
600MHz
Main memory
ROM NAND Flash MLC 128MB, DDR2
256MB
OS
Windows CE 6.0
External
memory
SDHC (~32GB)
Display
OEM LCD
USB
2.0 (support for recognition of HOST,
CLIENT )
GPS
U-BLOX5, 50 channels, NMEA 0183,
9600/1 (board rate/port)
SD card
SD/SDHC (TOSHIBA SDHC Class6)
Audio
MP3, WMA, MP2, OGG, AAC, M4A,
MA4, FLAC, APE, 3GP, WAV, RA
Movie
AVI, WMV, MPEG, MP4, RMVB, TS, M2TS,
TP, MOV, VOB, MKV, 3GP, 3GA, ASF,
DIVX, TRP, FLV, RM, DAT, M4V, M2V,
MPG
Power
AC power - DC 12V
Operation
Temperature
-20℃~ 70℃
Touch
panel
Non glare panel
Speaker
1watts, 2 way stereo
External
AV IN
Available
External AV
OUT
Available
CarNavi-Tech

44
1.2 Features
•Perfect compatibility with smart phones
(iPhone, Android phones, possible for charging and play media)
•TMC(Traffic Message Channel), user-intended function
•Able to control all the function via Audi OEM MMI Controller (except for Navigation)
•Various multimedia exteinsion (3*Video Input, 1*Rear Camera Input, 1*A/V Out)
•Bluetooth (Hands free call, A2DP music player, phone book)
•Powerful multimedia functions (Mp3, Music players via USB connection, iPod)
•Original Audi style Graphic User Interface
•Easy installation with Plug&play type cable
•AMI Aux Cable provided (To open Auxiliary, Optional)
•PAS (Parking assistance system)
CarNavi-Tech

55
1.3.1 Components
POWER cable * 1ea
(HPOWER0024)
Main board * 1ea
A/V (IN/OUT) cable * 1ea
(HAVCA0002)
REAR CAMERA POWER cable * 1ea
(HARETC0002)
SD/BT cable * 1ea
(HARETC0025)
BOOT –N.C
TMC –Option
MODE switch cable* 1ea
(HARETC0001)
Connect with powercable
TOUCH IN cable * 1ea
(HTOUCH0007)
LCD cable * 1ea
(HLCDCA0015)
LVDS cable * 1ea
(HLVDSC0013)
USB extention cable * 1ea
(HARETC0038)
SUB board * 1ea
(QCPASS0266)
CarNavi-Tech

66
1.3.2 Components
SD CARD/Bluetooth interface* 1ea
(QCPASS0269)
Microphone cable * 1ea
(MICPHO0001)
Speaker * 1ea
(SPEAKE0001)
iPOD cable * 1ea (Optional)
(HARETC0029)
GPS * 1ea
(GPSANT0004)
CarNavi-Tech

77
1.4.1 Exterior main board
Dimension/
ⓐ166mm *ⓑ108mm * ⓒ25mm
①USB USB cable connector
②SD/BT SD card slot/bluetooth sub board
connector
③REAR-CAM power cable of rear
camera connected
④A/V (IN/OUT) AV cable connector
⑤IPOD I-POD cable
⑥SPK SPEAKER cable
⑦LED
⑧LVDS/TOUCH cable (connecting main
board and LCD) connector
⑨GPS
⑩TMC (Traffic Message Channel) traffic
message receiver (transmitted on the real-
time basis)
⑪BOOT Not for driver’s use; ONLY for
manufacturer
⑫POWER power cable connector
⑬DIP S/W set up DIP switch
⑧⑨⑩
ⓑ
⑪⑫⑬
①②③④⑤⑥
ⓐ
ⓒ
⑦
CarNavi-Tech

88
1.4.2 Exterior SD card/ Bluetooth interface
①②③
④⑤⑥
ⓐ
ⓑ
ⓒ
Dimension/ ⓐ87mm *ⓑ57mm * ⓒ18mm
①LED
②SD CARD SD card slot
③RESET Not for driver’s use; ONLY for
manufacturer
④TEST Not for driver’s use; ONLY for
manufacturer
⑤Mic. microphone cable connector
⑥DATA cable connector (connecting main
board and navigation)
CarNavi-Tech

9
#PIN Function Select DIP S/W
1 N.C
2 N.C
3
Select
car
model
3G
OFF : Q5
ON : Q7 and other available for compatibility
vehicle
3G+ OFF : A6, A7
On : A8
4
Select
original NAVI
(3G, 3G+)
ON : Changing mode ; Main-Main-NAVI-AV1~3
(This is for original Navi)
OFF : Changing mode ; Main-NAVI-AV1~3
※ ON : DOWN, OFF : UP
▷DIP S/W : 1 ON
▷DIP S/W : 2 OFF
▷DIP S/W : 3 ON(Q5 : Off)
▷DIP S/W : 4 ON(using original NAVI)
1.4.3 Dip switch
CarNavi-Tech

10
Qnavi implementation
①Confirm
②Move leftward
③Move rightward
④Select left-up menu
⑤Select left-down menu
⑥Select right-up menu
⑦Select right-down menu
⑧Mode change(using original Navi : OEN↔Qnavi, not using orginal Navi : →Qnavi)
⑨, ⑩, ⑪Change the OEM display
⑫Move to the previous menu, press long 4~5seconds –Qnavi Reset
1.4.4 Original buttons in car(3G+)
⑥
⑦
①
⑫
②③
④
⑤
⑧
⑨
⑩
⑪
CarNavi-Tech

11
1.4.4 Original buttons in car(3G)
⑥
⑦
①
16
②③
④
⑤
Qnavi implementation
①Confirm
②Move leftward
③Move rightward
④Select left-up menu
⑤Select left-down menu
⑥Select right-up menu
⑦Select right-down menu
⑧Mode change(using original Navi : OEN↔Qnavi, not using orginal Navi : →Qnavi)
⑨,⑩,⑪,⑬,⑭,⑮Change the OEM display
Move to the previous menu, press long 4~5seconds –Qnavi Reset
⑧
⑨
⑩
⑪
⑫
⑬
⑭
⑮
16
CarNavi-Tech

①NAVIGATION : Navigation function
②PHONE : Bluetooth function
③MEDIA : Domestic(DMB, AV), Overseas(DVD, DTV-Option), USB, IPOD function
④SETUP : User environment
2.1 User interface / MAIN MENU
12
※Driver can control the Menu by touching screen and Original MMI
①②
③④
CarNavi-Tech

13
2.2.1 User interface /PHONE
①Move to the main menu while music is played.
②Displaying current status
③Close the current application
④Select and play the media file
⑤Phone number : Outgoing call number
⑥Phone book
⑦Option
⑧Make receive or hang up a phone call.
※Before using this Bluetooth function, driver MUST take PAIRING process between the phone intended to use and
the device
⑦
②
⑤
④
①
②
③
①③
⑧
⑥
⑧
①Displaying incoming or outgoing call
②Sorted in alphabetical order
③List of name
CarNavi-Tech

2.2.2 User interface /PHONE /OPTION
14
①PAIRING : Press driver’s password “0000” to register the phone on the device when you press
“PAIRING” button.
②DEVICE LIST : List of Bluetooth device connected in the past
③A2DP PLAYER : Transfer music by Bluetooth.
④VOLUME : Adjusting the sound volume of Bluetooth function
⑤SYNCHRONIZATION : Synchronization of Phone Book in mobile phone
①
②
③
④
⑤
CarNavi-Tech

2.3.1 User interface /MEDIA /MUSIC
15
①MUSIC : Music output from USB
(If you connect Android phone, It will be
recognized as USB)
②MOVIE : Output of movie via connecting USB
(If you connect Android phone, It will be
recognized as USB)
③DVD : Connect the external DVD(option)
④AV : Connecting other external A/V devices
⑤iPod : : Media or Music output from driver’s iPod
via iPod cable
①Move to the main menu
②Close the current application
③Select and play the music file
④Displaying Music list
⑤Displaying player mode
⑥Sound volume control
⑦Equalizer option –Sound Jazz, classic, pop, etc.
⑧control bar of the playing music
③
④
①
②
⑤
①
③
④
⑤
⑥
⑦
⑧
②
CarNavi-Tech

2.3.2 User interface /MEDIA / MUSIC
16
①Move to the previous music
②Play / Pause
③Move to the next music
④Stop
⑤Rewind
⑥Fast-forward
⑦Repeat option –Repeat all, repeat one, none
⑧Shuffle play
①
②
③
④⑧⑦
⑤⑥
CarNavi-Tech

2.3.3 User interface / MEDIA /MOVIE & DVD & AV
17
①Move to the main menu
②Close the current application
③Select and play the media file
④Displaying Music list
⑤Dlsplaying Player mode
⑥Sound volume control
⑦Full screen
①
④
⑤
⑥
⑦
③
②
①Move to the previous media
②Play / Pause
③Move to the next media
④Stop
①
②
③
④
CarNavi-Tech

2.3.2 User interface / MEDIA /MOVIE & DVD & AV
18
①Move to the main menu
②Close the current application
③Move downward in DVD disk of DVD changer
④END of the DVD
⑤Move upward in DVD disk of DVD changer
⑥Full screen
⑦Move to the previous chapter
⑧Rewind
⑨Play / Pause
⑩Fast forward
⑪Move to the next chapter
⑫Stop
①
③
④
⑤
⑥
⑦⑧⑨⑩⑪⑫
②
①Move to the main menu
②Close the current application
③Power of AV
④Full screen
⑤Move upward in the list
⑥Move downward in the list
⑦Move to the previous level
⑧Selection / Confirm
⑨Menu in AV
⑩Move to the right
①
③④
⑤⑥⑦⑧⑨⑩
②
CarNavi-Tech

2.3.3 User interface / MEDIA /IPod
19
①
④
⑤
⑥
⑦
①Move to the main menu
②Close the current application
③Select and play the music file
④Displaying list
⑤Dlsplaying Player mode
⑥Displaying current mode : music or movie
⑦Connect or disconnect with I-POD
①③
④⑧⑦
⑤⑥
①Move to the previous music
②Play / Pause
③Move to the next music
④Stop
⑤Rewind(10 Seconds of every one click)
⑥Fast-forward(10 Seconds of every one click)
⑦Repeat option –Repeat all, repeat one, none
⑧Shuffle play
③
②
②
CarNavi-Tech

2.3.3 User interface / MEDIA /IPod
20
①
②
③
④⑧⑦
⑤⑥
①
④
⑤
⑥
⑦
③
②
①Move to the main menu
②Close the current application
③Select and play the media file
④Displaying list
⑤Dlsplaying Player mode
⑥Displaying current mode : music or movie
⑦Connect or disconnect with I-POD
①Move to the previous media
②Play / Pause
③Move to the next media
④Stop
⑤Rewind(10 Seconds of every one click)
⑥Fast-forward(10 Seconds of every one click)
⑦Repeat option –Repeat all, repeat one, none
⑧Shuffle play
CarNavi-Tech
