ODORGAS
Digital instrument for Odorant measurement.
For professional use only

OMODORGAS Iss 01
Page 2 of 20
Contents
EU Declaration of Conformity ............................................................................... 3
Warnings ATEX ................................................................................................. 4
General Description ........................................................................................... 4
Safety Instructions ............................................................................................ 5
Overview of the instrument ................................................................................. 6
User Interface ............................................................................................ 6
Battery Charger Connections ........................................................................... 7
Display ..................................................................................................... 7
Instrument functions .......................................................................................... 8
Switch On ................................................................................................. 8
Switch OFF ................................................................................................ 8
Pump Function ........................................................................................... 8
Backlight .................................................................................................. 8
TAKING READINGS ............................................................................................. 9
Measuring and storing readings ........................................................................ 9
Recommended accessories ................................................................................. 11
RC-1 Adapter for high pressure & flow. ............................................................. 11
Odorsoft Download PC software. H-707068 ......................................................... 11
Function Key Menu .......................................................................................... 13
User calibration ......................................................................................... 13
Escape Option ........................................................................................... 14
To alter the passcode? ................................................................................. 15
WARRANTY ................................................................................................... 15
APPENDIX A – Safe Use of The Instrument ............................................................... 16
Other precautions for the usage ........................................................................ 16
Testing and maintenance ................................................................................ 16
Repair .................................................................................................... 17
Conformity ............................................................................................... 17
APPENDIX B – Technical Specifications ................................................................... 18
APPENDIX C - Information On Disposal For Users Of Waste Electrical & Electronic Equipment . 19

OMODORGAS Iss 01
Page 3 of 20
E U D e c l a r a tio n of C o n f o r m i ty

OMODORGAS Iss 01
Page 4 of 20
W a rnin g s A T EX
The operating manual must be read and fully understood before using the equipment
This warning is in place so that the operator fully understands the product and its use within
the application.
Battery must be replaced in a non-hazardous, safe area
Do not charge the device in a hazardous area OR only charge in a non-hazardous, safe area
Battery charging and communication (USB) must only be done in a non-hazardous, safe area
with adapter
Do not use any other charging device
Do not open the device
Only the manufacturer or its authorised representatives can open the device for maintenance
and repair
Unauthorised opening of the device invalidates the integrity, certification and guarantee of the
product
Special conditions for safe use
 The equipment is intended to be used in ambient temperatures range from -20°C to
+40°C. / -4°F to +104°F
 Data communication shall be performed in non-hazardous area with the appropriate
accessory. Recharging of the equipment is only allowed in non-explosive environments by
using the original recharging equipment.
 For maintenance or repair purposes the equipment may only be opened by the
manufacturer
G e ne r a l De s c r i p ti o n
The ODORGAS is a hand-held digital gas detection instrument manufactured by QED
Environmental Systems Ltd. The intended use of the ODORGAS is to measure concentrations of
odorants in piped gas network applications.
The primary odorant measured is THT (Tetrahydrothiophene), the instrument is available with or
without an integral pump.
With an internal memory for data storage of up to 3,000 readings, size of 145 x 70 x 33 mm / 5.7
x 2.75 x 1.3 inches and a weight of 350g / 12.34 Oz, the ODORGAS is an excellent and convenient
instrument for measuring odorants.
ODORGAS has been certified with the intrinsic safety protection mode and has obtained the
following marking:
II 2G Ex ib d IIC T4 Gb

OMODORGAS Iss 01
Page 5 of 20
Sa f e t y I n st r u c ti on s
It is the responsibility of the owner of the equipment to ensure that all personnel are adequately
trained and the equipment is serviced and maintained in accordance with the applicable code of
practice and this operating manual.
It is the responsibility of the owner to ensure that all personnel are adequately trained in the
safety aspects of the gases being surveyed and appropriate procedures are followed.
The equipment should not be altered in any way other than described within this operating
manual. Alterations or changes outside of this operating manual could make the equipment
unsafe and invalidate the hazardous area certification.
Repair and maintenance of this equipment should be carried out in accordance with the
applicable code of practice and this operating manual.
Only QED approved components are to be used with this equipment.

OMODORGAS Iss 01
Page 6 of 20
O v e rv ie w o f t h e i n s t r u m e n t
User Interface
Description
[1]
ON/OFF button +
Backlight + Enter key
[2]
Function button
[3]
Scroll Key
[4]
Buzzer
[5]
LED Alarm Lights
●●
[6]
Gas inlet port
1b
[1]
[2] [3]
[4]
[5]
[6]
1a

OMODORGAS Iss 01
Page 7 of 20
Battery Charger Connections
The ODORGAS comes complete
with its own charging base. Simply
locate the ODORGAS into the
charging cradle and switch on the
power supply.
Display
SECTOR
DESCRIPTION
[A]
Pump status
[B]
Battery status
[C]
Unit of measurement
[D]
Odorant type
[E]
Measurement of
Odorant
2b
[A]
[
B
]
[C]
[D]
[E]
2a

OMODORGAS Iss 01
Page 8 of 20
I n s t ru m e n t f u nc t i o n s
Switch On
Press the ON/OFF [1] button for 2
seconds, until the display is activated.
The start sequence includes several steps:
- Display check.
- Information about the firmware
version of the instrument, serial
number of the instrument and next
calibration date.
The instrument will warm up and calibrate
itself. This typically will take up to 30
seconds. The instrument’s functions are not
available during the warm up period.
Once the warm up and calibration are
complete, the two LED lights ●● [5] will
blink and the alarm will sound.
The ODORGAS is now ready for use.
Switch OFF
Press and hold the ON/OFF key for a few seconds.
A counter on the display will count down from 4 to 0 and the instrument will then power down.
You must hold the ON/OFF key for the duration of the count down.
Pump Function
The pump (if fitted) will automatically begin to run when the instruments enters its main read
screen.
Backlight
To operate the backlight, short-press the ON/OFF key once.

OMODORGAS Iss 01
Page 9 of 20
T A KI NG RE A D IN G S
Measuring and storing readings
To begin the measurement process,
press and hold the function key.
The screen will display these symbols.
Press the ON/OFF key to begin the
measurement process.
If successfully measuring, the screen
will display two arrows moving in a
circular motion.
The reading process will take
approximately 4 minutes.
Once the reading cycle is complete, the
two LED lights ●● [5] will flash and the
buzzer [4] will sound intermittently.

OMODORGAS Iss 01
Page 10 of 20
The user will be prompted to save the
reading against an identification
number.
At the identification number prompt,
the digit ready to be altered will flash.
To change the number, use the scroll
key.
To move to the next number, use the
function key.
To store the reading, short-press the
ON/OFF key.

OMODORGAS Iss 01
Page 11 of 20
R e co mm e n d e d a c c es so r i e s
RC-1 Adapter for high pressure & flow.
To ensure you achieve the most accurate readings possible from your device, the ideal sampling
conditions should be met (Between 150 – 300ml / 0.005 ft3 - 0.01 ft3 per minute flow & Less
than 0.4 bar / 5.8 PSI pressure). In the event of high sample pressure and flow (above 300ml /
0.01 ft3 per minute and over 0.4 bar / 5.8 PSI pressure) QED recommends using the RC-1
adapter to reduce your sample to a controlled level similar to the ideal window of operation.
Connect your RC-1 between your sample point and your Odorgas unit as per the diagrams
below:
Odorsoft Download PC software. H-707068
RC-1 Order Reference
Number H
-
900035

OMODORGAS Iss 01
Page 12 of 20
For downloading and exporting of all collected Odorgas data.
Please contact sal[email protected] for more information.

OMODORGAS Iss 01
Page 13 of 20
F u nc ti o n K e y M en u
User calibration
Press and hold the left function
key until ‘INIT’ appears.
Use the right scroll key to reach
‘PASS’ then press ON/OFF key
to select.
Enter the default passcode ‘1001’ then
the ON/OFF key for OK.
This will take you back to the reading
screen.
Press and hold the left scroll key again,
until ‘INIT’ appears.
Press the right scroll key to reach
‘CAL’.
Type
-
in and
Deliver your concentration
of gas and then press ON/OFF key for
OK.
An internal timer will start, lasting 4
minutes, after which the instrument
will automatically store the updated
calibration data.

OMODORGAS Iss 01
Page 14 of 20
Allow the instrument to reset to zero
gas reading.
Press and hold the left function key
until ‘INIT’ appears again.
Use the right scroll key to find ‘TEST’
screen.
The Instrument will say
test fail
or
test
pass depending on whether the result
is within tolerance.
Escape Option
To quit an active reading, or quit the function menu, press the left function key once, then
the right scroll key until the abbreviation ‘ESC’ appears. Select it using the ON/OFF key.

OMODORGAS Iss 01
Page 15 of 20
To alter the passcode?
Use the scroll key until the word ‘PASS’ is displayed then
use the ON/OFF key to select.
At the passcode number prompt, the digit ready to be
altered will flash.
To change the number, use the scroll key.
To move to the next number, use the function key.
To store the passcode use the ON/OFF key.
W A RR A NT Y
The QED Warranty terms and conditions for the Odorgas can be found on the QED website in the
downloads section, or alternatively by using the link below & searching ‘warranty’.
‘https://www.qedenv.com/downloads’

OMODORGAS Iss 01
Page 16 of 20
A P PE ND I X A – S af e U s e o f T h e I n s t r u m en t
The information contained in these safety instructions must be followed in addition to the
warnings in the user manual supplied to the customer.
 It is recommended to the user to have knowledge of the PPE Regulation (EU) 2016/425
relative to the personal protective equipment.
It is advised to the user operating in ATEX area, to be equipped with a complete antistatic
Personal Protection Equipment (PPE), in combination with conductive or dissipative ground, and
shoes with a resistance below 108Ω, in agreement with the following regulation and standard:
Regulation (EU) 2016/425 on personal protective equipment (PPE) to be applied as of 21 April
2018; EN 1127-1:2019 (Explosive atmospheres. Explosion prevention and protection - Basic
concepts and methodology); the PD CLC/TR-60079-32-1 2018 ‘explosive atmospheres,
Electrostatic hazards guidance. and IEC TS 60079-32-1-2013+AMD1 2017.
Other precautions for the usage
 The charging of the batteries must be in a safe place with the appropriate external
adapter.
 The instrument is dedicated to measurements in ambient air or can accept gas mixture
containing non-corrosive chemical products. In case of the presence of gas mixture except
that hydrocarbon and neutral gases, contact your QED distributor to verify the
compatibility with the device.
Testing and maintenance
The checks and maintenance of certified equipment should be performed according to the
criteria of the standard EN60079-17.
WARNING: Do not use the instrument ODORGAS in a classified area if the version of the apparatus is not
certified ATEX.
WARNING: Do not open the device.

OMODORGAS Iss 01
Page 17 of 20
Repair
In the event of malfunction or damage, please contact QED (or an authorised distributor) for
support.
Conformity
The apparatus type ODORGAS is usable in gas explosive atmosphere of group IIC and
temperature class T4 for an ambient temperature from -20°C to +40°C.
The apparatus is category 2 and may be used in areas 1 and 2.
The following are applied to the apparatus:
Certificate number:
PS 11 ATEX 1 572 X
FTZU 10 ATEX 0315X
Marking: II 2 G Ex ib d IIC T4 Gb
II: 2nd group equipment intended for use in areas with an explosive gas atmosphere other
than mines
2: Category two (suitable for installation in zone 1 and zone 2, not for zone 0)
G: Only for gas, not for dust
d Flameproof protection method
ib: Intrinsically safe protection method
IIC Gas group, suitable for gases of IIA (e.g. Methane), IB (e.g. Ethylene) and IIC (e.g.
Hydrogen)
T4: Temperature class (max. surface temperature 135°C)
Gb: Equipment protection level EPL, high protection

OMODORGAS Iss 01
Page 18 of 20
A P PE ND I X B – T e c hn ic a l S p e c i f ic a t i o n s
Target gas
TetraHydroThiophene (THT)
Measurement ranges
Minimum threshold
Accuracy
+/
-
10% relative to reading
Environmental working
conditions
Temperature:
-
20°C to
4
0°C /
-
4°F to +1
04
°F
(in a non
-
condensing atmosphere)
Relative humidity: <90% non-condensing
Power supply
Nickel metal hydride
rechargeable battery pack
Recharging duration: 4 hours
Operational
time
1
2
hours at 20°C / 68
°
F
Case
Carbon reinforced polyamide with fiberglass
Dimensions: L x w x h = 145 x 70 x 33 mm / 5.71” x 2.76”
x 1.30”
Weight: 0.35Kg / 0.77lbs(in operation)
Protection level
IP65
Environmental storage
conditions (excluding
batteries)
Humidity: < 95% relative humidity
Temperature: -40°C to +60°C / -40°F to +140°C
Sampling flowrate
0.
2
l/min /
2
00cc/min
User interface
Display:
40
mm x
20
mm /
1.
5
7
” x
0.79
”
3 ‘Tactile’ soft membrane push buttons
Alarms
Audio / Visual
Sound level of the buzzer
(30cm)
85dBA
Indicators of the device
status
Measurement mode
Battery level
Pump
Electrical connections
Multiplug for battery charger and for a communication
with a computer.
Gas connections
Quick
-
connect gas inlet coupling with locking mechanism:
suction rod on the right side.
Quick-connect gas outlet coupling.

OMODORGAS Iss 01
Page 19 of 20
A P PE ND I X C - I n f o r m a t i o n On Di s p o sa l F o r
U s e rs O f Wa s t e E l e c t r i ca l & E l e ct r o n ic
E q u i pm e nt
The wheelie bin symbol displayed on electrical equipment
supplied by QED signifies that the apparatus must not be
disposed of through the normal municipal waste stream but
through a registered recycling scheme.
The Waste Electrical and Electronic Equipment Directive
(WEEE) make producers responsible in meeting their
obligations, with the fundamental aim of reducing the
environmental impact of electrical and electronic equipment
at the end of its life.
QED is registered with the Environmental Agency as a producer and has
joined a recycling scheme provider that manage and report on our electrical
waste on our behalf.
Note: When your instrument is at the end of its life, please contact your local distributor, or our sales
team at QED on [phone] or email [email protected], who will advise you on the
next step in order to help us meet our obligations.

QED Environmental Systems
Cyan Park, Unit 3
Jimmy Hill Way
Coventry
CV2 4QP
United Kingdom
[email protected]
