Endress+Hauser Cerabar S PMC71 Manual

Pressure transmitter with ceramic and
metal sensors
Applications
The device is used for the following measuring tasks:
• Absolute pressure and gauge pressure measurement in gases, steams or liquids in
all areas of process engineering and process measurement technology
• Level, volume or mass measurements in liquids
• High process temperatures
– up to 150 °C (302 °F)without diaphragm seal
– up to 400 °C (752 °F)with typical diaphragm seals
• High pressures up to 700 bar (10 500 psi)
• Low-energy version with voltage output (1-5V DC), e.g. for operation on solar-
operated control units (Remote Terminal Unit (RTU))
Your benefits
• Very good reproducibility and long-term stability
• High reference accuracy up to ±0.025 %
• Turn down up to 100:1, higher on request
• Used for process pressure monitoring up to SIL 3, certified to IEC 61508 by TÜV
SÜD
• High level of safety during operation thanks to function monitoring from the
measuring cell to the electronics
• Easy electronics replacement guaranteed with HistoROM®/M-DAT
