Qi PN-W05 User manual

1*Solar Power Bank 1*User Manual
1* 2A 11.8in Cable 1*Compass Ring
PRODUCT DETAILS
wireless charging indicator power button
wireless charging area
anti-slip mat
dual LED flashlight
Type C input
usb output
micro usb input
battery power indicator solar charging indicator
sunlight receiving panel
①
②
③
④
⑩
⑦
⑧
⑨
⑤
⑥
⑪
① wireless charging indicator
Press the “power button”, then the “wireless charging indicator” and
“battery power indicator”is going to turn on, if no Qi-enabled devices
get close to the qi wireless charging area within 20S, it will be off.
power button②
Press the “power button”, then the function of wireless charg-
ing and cable output charging turns on.
③ wireless charging area
The wireless charging feature only suit for qi-enabled devices, pls
figure out whether your phone is Qi-enabled before charging it.
anti-slip rubber mat④
A circle of premium anti-slip rubber mat is designed for preventing
your phone from falling off.
dual led flashlight⑤
Press the power button for at least 5 seconds to turn on/off the
flashlights.
Type C input⑥
DC 5V 2.1A type C port is a new tech designed for future use.
usb output ⑦
DC 5V 2.1A
⑧ micro usb input
DC 5V 2.1A
solar charging indicator⑨
Color-green, When the sunlight intensity is above 25,000lux and
the solar panel are fully exposed to the sunlight, so the solar charger
can charge itself with max 180ma currency.
battery power indicator⑩
Color-blue, press the “power button”, the indicator is going to turn on.
Fours lights from left to right represent 25%/50%/ 75%/100% power
capacity, When you charge the power bank by micro USB port, all the
indicator lights flash in sequence till it’s fully charged.
sunlight receiving panel⑪
Minimum sunlight intensity 25,000LUX, 180ma charging currency.
PRODUCT PARAMETERS
Product Name Wireless Solar Power bank
Micro USB Input DC 5V 2.1A
Type C Input DC 5V 2.1A
USB Output DC 5V 2.1A
Wireless Output DC 5V 1.0A
Battery Capacity 10,000mah
Battery Type Polymer Lithium Battery
All Qi-Enabled Devices
QI Compatible Devices
IPX4（Splash Proof）
Waterproof Rating
Product Size 5.9*3.1*0.8in
Product Weight 9.6oz
PACKAGE CONTENTS

HOW TO USE
NOTE：In theory, it needs around 56hours to get the power bank
fully charged with constant minimum 25,000lux sunlight. Yet its
adviced to take the solar charging feature as the emergency back-up
solution instead of main power sources due to sunlight intensity and
panel conversion rate.
NAME：Qi Solar Power Bank
NO：PN-W05
Make sure that your power bank is fully charged by power outlet
before starting your long journey.
Check Battery Power
Get it Charged by Power OutlePress Down Power Button
Wireless Charging
Micro USB Charging
Put Devices on the Qi Area Connect the Cable(Included) with Your Phone
Low Battery Power
Charge by SunlightCharge by Power Outlet
Fully Exposed to Minimum 25,000LUX Sunlight
Connect the Power Bank with Power Outlet
Green Indicator Light is OnBlue Indicator Lights Flash
no
yes
PRODUCT MAINTENANCE
For longer battery life span, make sure its completely out of power
capacity before charg ing it.
If you are not using the device for a long time, charge it by power
outlet at least every six months.
Do not use wireless charging function while charging the power
bank.
IMPORTANT NOTICE
The product is suit for 5V/2V devices, or it will be in protection
status and wo n’t work.
Keep it away from wet environment and corrosive substances.
Do not try to refit, disassemble it.
QUALITY WARRANTY
All products sold by BLAVOR enjoy 12 months warranty, the
guarantee period begins from the date you purchase it.
During the period if there are any problems , which is verified by our
engineer team as not being damaged by man-made factors, BLAVOR
is responsible for it and our team will be with you until its solved.
CUSTOMER SERVICE
BLAVOR offers timely and considerable customer services, if there
are any problems, feel free to contact us, we will get back to you
within 12hours.
We’d love to get some feedbacks from you, so it could help us
improve our products and customer services.
