Qomo BUNDLEBOARD G PANEL User manual
Model Name:
QITBB55 G
QITBB65 G
QITBB75 G
QITBB86 G
User's Manual for BundleBoard G Interactive Flat Panel
Note: Please read this Manual carefully before using the product!
Do not attempt to disassemble the product. Ifthe product does not work,
please contact us or our dealer
in
your area.
[Foreword ,
Thanks for purchasing our LCD interactive flat panel.
Please carefully read all accompanying documents before installing and using this product,
as failure to operate according to the manual, or misoperation attributable to wrong understanding
or
other reasons, may result
in
electric shock, fire
or
other hazards. Pictures provided in this
manual are
for
reference only.
In
case
any
picture deviates from the actual product, the latter
shall prevail.
To
provide better services, we reserve the right to improve and modify this manual
without further notice. Please keep this manual properly for future reference.
Contents
Safety
Warnings
······································································································1
Precautions ············································································································1
Product Features······································································································2
Accessories ············································································································3
Wall
Mount
············································································································3
Port
Connection ······································································································4
Instruction
of
Panel
Buttons
·······················································································7
Remote
Control
······································································································8
Basic Operations ······································································································9
Startu
pf
Shutdown·····························································································9
Sidebar Setting································································································9
Signal
Source Switching····················································································9
Signal
Source Setting·······················································································10
Mode···································································································11
Voice
Mode
···································································································
11
Menu
Setting ·········
··
·····
··
·········
··
·····
··
·········
··
·····
··
·
··
·········
··
·····
··
·········
··
·····
··
···
12
Network
Settings·····························································································
12
Date
and Language Setting ···
··
·····
··
·········
··
·····
··
·········
··
·
··
·····
··
·········
··
·····
··
·········
13
System Setup and
Applications
·········
··
·····
··
·········
··
·····
··
·········
··
·····
··
············
··
····
14
Control
Lock
and Centralized
Control
Setting ·
··
·········
··
·····
··
·········
··
·····
··
·········
··
····
15
Power
On/Off
Setting·······················································································
15
Comments ···································································································
16
Android
Homepage··························································································16
Writing
Software ·····························································································
17
Documents manager·······················································································
17
Quick
Operation
··
·····
··
·········
··
·
··
·····
··
·········
··
·····
··
·········
··
·····
··
·········
··
·
··
·····
··
······
18
Technical
Parameters
··
·
··
·····
··
·········
··
·····
··
·········
··
·····
··
·········
··
·
··
·····
··
·········
··
·····
··
······
19
Troubleshooting ······································································································
20
Important
Statement
of
Network
Service ·····································································21
Toxic/Hazardous Substances/Elements
in
the Product
··
·····
··
·········
··
·
··
·····
··
·········
··
·····
··
···22
1.Use only the power supply and voltage indicated
on
the label.
2.Athree-prong power cord
is
included. Confirm that the ground terminal
of
the wall outlet is well
grounded before installation. Route the power cord away from passageways to avoid treading;
also keep away from areas where the power cord may get pressed.
3.
Do not overload the power outlet, and use a certified power outlet.
4.ln case ofthunderstorms, please pull out the power plug and the network cable and disconnect
the product from the antenna to avoid damage.
5.lf it is to be left unused for a long period oftime, please power it off and pull out the power plug.
6.ln case of any abnormal sound or smell, please power it off immediately and pull out the power
plug. Ifnecessary, stop using it and contact the maintenance personnel as soon as possible.
?.Keep away from flammable and explosive materials (e.g., candle, electric stove, bulb).
8.Be careful to prevent any liquid
or
metal objects from entering into the product; if so, stop using
it immediately and contact the maintenance personnel.
9.When it is moved from a low-temperature environment to a warm area, condensate may form
inside
it.
In
such case, the product should be placed still for at least 24h prior to restart to air-dry
the condensate.
1a.Handle it with at least two persons; avoid impact and pay special attention to the display
screen during the transfer.
11.To
avoid injury, please install the base according to the instructions, and then place the product
on
an even and steady ground;
or,
ifthe base is not installed, the product should be firmly fixed
to a wall according to the wall-mount bracket installation instructions.
12.Do not place the product
in
any environment:
•
To
direct sunlight, moisture, high/low temperature,
or
dust.
•
To
poor ventilation or
an
enclosed environment.
•
To
where any flammable
or
explosive material is present.
•
To
where any combustible or corrosive gas is present.
13.ln order to avoid the risk
of
explosion, do not expose the batteries to sunlight, fire or high
temperature.
[Precautions,
♦
Do
not attempt to disassemble/assemble this product as you may get exposed to dangerous
voltage
or
other hazards. Ifnecessary, please contact the maintenance personnel.
♦
If
the product is dirty, first disconnect the power plug, then dampen the cloth with water and
wipe with the slightly wet cloth. Do not apply force while wiping the display screen as it may
scratch the screen. Do not wipe with such solvents as alcohol,gasoline, acid, alkali, detergent,
volatile oil and diluents since these solvents may damage the product.
♦
Condensate
may appear inside the screen
in
high humidity, and this is a normal phenomenon
as generally temperature difference between the external and internal glass surfaces may
lead to
water
droplets
on
the
internal
glass
surface.
Such
water
droplets
will
disappear
automatically after 24h
of
normal use. Please rest assured to use the product.
[Precautions,
♦
Do
not insert any sharp
or
metal object into the vent or touch the signal connector with any
sharp or metal object; otherwise short circuit or electric shock can
be
caused.
♦
Do
not exert pressure on the LCD screen as it
is
made ofglass.
♦
Do
not place the product on an unsteady trolley, shelf
or
table; otherwise it may turn over.
Move the product carefully when it
is
on
a trolley. Emergency stop, excessive force or uneven
ground can result
in
tipping over ofthe trolley and the product.
♦
Openings
on
the product are designed for heat dissipation to ensure good performance. Vent
holes should not be covered with objects such as newspaper, tablecloth and curtain as they
may impede ventilation.
♦
Do
not allow a still picture
or
an active picture containing stationary text or icon to remain on
the screen for too long because this will leave a "ghost image" on the screen, and it will not
disappear long after shutdown.
Product Features
This product uses HD LED-backlit panel, IR and multi-touch technologies. Equipped with
a writing software, it is convenient, highly interactive, safe and environmentally friendly.
eHigh
interconnectivity (optional)
This product can connect to other devices. It allows wireless connection with PCs, PADs
and mobile phones, realizing wireless transmission
of
documents, wireless push ofvideos and
wireless screen cast.
eExtraordinary Display
This product uses a high-quality
HD
LCD panel featuring original display color, vivid pictures,
uniform display,
no
flickering, and quick response.
You
can
enjoy
HD
pictures from different angles.
eAccurate
Touch Control
This product incorporates the advanced touch technology featuring quick response, high
positioning accuracy, strong environmental adaptability, accurate operation, etc. No stylus is
needed; you can operate with your hand by clicking, dragging and other actions.
eHighly
Interactive
This product is preinstalled with a professional writing software. It provides multiple types
ofpens, drawing tools and other functions, and you
can
write and move the contents
as
you like.
2
[Accessories,
User Manual Warranty Card
I
Remote
Control User Manual Warranty Card
DJ
I@l
//
Battery x 2 Disc (Optional) Stylus x 2 I
Wall
Mount
1.
Precautions for Installation
/
/'-
Pointer
USBA-B
Cable x 1
~
r
Power Cord
..,,
r
HDMI
Cable
x 1
Wall Mount
Instructions
Wall Mount
Instructions
(Optional)
Wall Mount
Screws x 1
eFor
installation ofthe wall-mount bracket, at least two professional workers are required; you
should not attempt to install
it,
otherwise injury may result.
l
eouring installation, assistance from professional workers is needed to designate the installation
also, measures should
be
taken to make sure it can bear certain amount
of
external force. Make
sure the bracket is installed onto a firm wall rather than plaster board or other surface which can
not provide strong support.
eThis
product should be installed on a vertical plane, not on an oblique plane; also, it should not
be installed with the front facing upwards; otherwise falloff
of
the product or personal injury may
be caused.
eTo
avoid damage ofthe product or injury, keep the bracket out
of
the reach
of
children.
•Tighten
the screws during installation to avoid product damage and injury.
eThe
installation
is
shown
in
the figure below; ventilation space should
be
kept around the product.
-----
Mount the product to the wall
-----
......
30cm
Impede air circulation
,-------,--,,'------,
Wall
10cm
2.
For specific installation steps, see the wall mount instructions.
3
Port Connection
Note: The port connection instructions are provided below. The listed port types are for reference
only, and do not cover all ports
on
this product.
■
Power
port
■
Signal
input ports
•uss
port
wmc]
LJ
USB flash drive
Ports
Power cord ·•
I~
I
To
power socket
AC
100-240V, 50/60Hz
♦
Note:
1.
The output current
of
USB2.0 port is 500mA,and that
of
USB3.0 port is 900mA.
In
orderto ensure normal operation, please do not simultaneously use all USB ports
to charge external devices.
2. Media USB port is used to connect external devices to the Android system
of
the
product. which enables data reading via the file
manager
of
this product. PC USB
port is used to connect OPS equipment. PUBLIC-USB port serves as both Media
USB port and
PC
USB port, and is automatically switchable with the signal source.
3.This product is connected with wireless keyboard and mouse. In case
of
stuck
operation or slow response, change the wireless receiver to another USB port,
or
use the USB extension cable to connect the wireless receiver, thus to enlarge the
reception range.
4.
Some nonstandard USB devices may be unrecognizable, please use standard USB
devices.
5.
For upgrading software with a flash drive, please use a USB2.0 flash drive.
•HDMI-IN
port
♦
Note:
The maximum resolution supported by HDMI port is 4K@60HZ, please see the section
of
technical parameters for the detailed signal formats. When 4K@60HZ signals are
played, the EDID version
in
the OSD menu should be switched to EDID2.0.
•TOUCH
USB port
[
,i,orn
l
[J6
USB touch control
cableJ[J
o
PC
♦
Note:
When the TOUCH USB port
is
connected to the same device with the signal source,
the external device can
be
operated by the TOUCH function.
4
Port Connection
•VGA audio/video port
• PC audio port PC
♦
•AV-IN port r
♦
•YPBPR port
r
]
GN GN
♦
5
Port Connection
■
Signal
output ports
• AV-OUT port
8]
~
-f
~~ o::\
□
<DIIIC:JlYL~YL ~
YL
..
Monitor
♦
Note:
the type
of
AV-OUT port is
<D3.5mm
MINI port. For outputting signals, a MINI
adapter
cable and an AV cable are required;
for
connecting signals, a MINI
adapter
is required
and connected as indicated
by
the figure.
•HDMI-OUT
port
1Ffi1
>-
HDMI cable
1Ffi1
rn
I
m=P
----
cn
rn
1
□
..
Monitor
♦
Note:
the HDMI-OUT port can outputAudio&Video signals to the HDMI-IN port
of
the second
product, thesecond product can replay the Audio&Video signals to the third product, so
on and so forth. The maximum relaying
amount
depends
on
quality
and length
of
the
HDMI cable, so it
suggests
using the cables provided
by
us.
■
Audio
ports
•optical
fiber port
~
Optical fiber cable R ,
11!1
~
.~
,______
___
TTIOJ
□
~
'9J
Stereo
♦
Note:
this port can output audio signals
of
this product to speakers with a SPDIF-IN port.
• Audio-OUT port
tr
Earphone
♦
Note:
Audio-OUT port can be connected with a headset
or
an external speaker.
■
Control
ports
• RS232 port I
JJ]
~i
0
-----
a PC
♦
Note:
RS232-IN port is connected to the PC; the product is operated via the PC.
6
Instruction
of
Panel Buttons
Model Name: QITBB55 G
QITBB65 G
QITBB75 G
QITBB86 G
~OMO
2 3 4 5 6 7 8
1.
Indicator light, remote control receiver and light sensing receiver;
2.@
:Power;
3.
@ : Homepage 4. ® :Return and touch unlock;
5.
® :Setting;
6.
@)
:Vol-;
7.
@ : Vol+;
8.
Switch.
7
Remote Control
Precautions for Use of Remote Control:
eAim
the remote control at the remote receiver when using the remote control. Any
object placed between the remote control and the remote receiver may disturb the
operation.
eProtect the remote control from vibration. Do not expose the remote control to direct
sunlight as heat may deform it.
ewhen
the remote receiver
is
subject to direct sunlight
or
strong light, the remote
control may malfunction.
In
such case, please change the angle
of
lighting or the
product, or operate the remote control close to the remote receiver.
eReplace the batteries
in
case
of
low battery as it will reduce the range
of
the remote
control. Ifthe remote control
is
to
be
left unused for a long period oftime or the batteries
are depleted, please remove the batteries as battery leakage may damage the remote
control.
eDo
not use batteries
of
different types
or
mix a new battery with a used one. Always
replace batteries
in
pair.
eDo
not throw batteries into a fire or recharge or disassemble batteries.
Do
not recharge,
short-circuit, disassemble/assemble, heat or burn any used batteries. Please dispose
of
waste batteries according to applicable environmental regulations.
Do
not expose
batteries to any hot environment, like direct sunlight, over the fire.
Keys
on
the Remote Control
Type A Remote Control
KEY
POWER ((!))
SOURCE(
i;i)
NAVIGATION
KEYS((
)Av)
OK(OK)
MEUN(-)
HOME(C)
BACK(":))
OPS
FREEZE(*)
SNAPSHOT(li.l)
VOL-(-)
MUTE(o~<)
VOL+(+)
Function
Switch between power-on and standby states
Open / close the signal source list
Select or adjust menu options
Confirm the operation
Show/hide the main menu
Display the Android home page
Return to the previous interface
Switch
to
OPS source
Enable or disable freeze function
in
the system
Take
a screenshot
Decrease the volume
Enable/disable sound
Increase the volume
1.The picture is for reference only, subject to the actual remote control.
2.Functions
of
keys on the remote control may vary, subject to actual
functions.
8
Startup/Shutdown
♦
Startup/shutdown
Use 100-240VAC as the power supply.
C)
on
the panel and the remote control can
be
used to switch between power-on and
standby states.
CD
on
the rear panel has two ends. Press the O end to power off the
product; press the I end to power it on.
♦
Auto
standby
In
the Android main interface, whether there is signal input
or
not, the product will not enter the
standby mode.
In
the non-Android main interface,
if
there is no signal input within 15min, the product will
automatically enter the standby mode.
♦
Save
before shutdown
Before shutdown, the product will save the picture and sound settings. Upon restart, these
settings will be used.
♦
OPS
ON/OFF
Ifthe product
is
installed with the OPS module and it
is
in
OPS signal source, the OPS module
will start automatically. Ifnot, start it manually.
Before turning off the product, first use the touch function or mouse to turn off the OPS module
from the Start menu. The Standby key
on
the panel
or
remote control can be used to turn off
the product only after the OPS module completely shuts down.It is not allowed to press the
Standby key
or
directly disconnect the power supply without turning off the OPS module as it
will damage the OPS module.
When the OPS module enters the OFF state and no operation is performed on the PC for a
long period
of
time, this product will enter standby.
To
use the module, just restart the product.
Note: The OPS module
is
optional.
Sidebar Setting
Press the sidebar shortcut key arrow, or slide the edge
of
the screen inwards(when turn offthe
touch signal switch) to tune out the sidebar menu that are respectively system setting, signal
source/menu setting, small tools, progress management, switch to Android homepage, return
and comments.
Signal Source Switching
You
can use the remote control ortouch function to switch the source by the following
methods:
Method one: press the "Signal Source" key
on
the remote controller to call "Signal Source
Menu", press the cursor key
on
the remote control to select a signal source,
press the"OK" key, and then the
product
will switch to
the
input
signal
source
that
you
selected.
9
Basic Operations
Method two: selected the side bar menu > Signal Source Settings, select signal source,
and then the product will switch to the input signal source you select.
Remark: the picture is for reference only, subject to the actual signal source menu.
Signal Source Setting
Upon the signal source menu, select the right one and enter the signal source setting
submenu, it can set the signal source auto-switching, signal source lock, power-on
signal source and auto-powero without singal.
10
Image Mode
To
access the Image Menu, select the sidebar menu, press the setting icon to enter the
signal source page, press the menu icon
on
the bottom right corner, and then select
Image Mode. Here you can adjust the image mode, display settings, and scaling.
<
mode
>
i'",ar,c
"icdc
< S:andarc >
[Jn:rasl
ral,o
•
Br
t;f·1l
..
c·.i'.i
•
Tur·l'
•
i\cc.rlv
•
SdlUdllJT)
•
Color
temperature < Standard >
Zoom
mode
<
16:9
>
fd'Wl'
<
Auto
>
Voice Mode
To
access the Voice Menu, select the sidebar menu, press the setting icon to enter the
signal source page, press the menu icon
on
the bottom right corner, and then select
Voice Mode. Here you can adjust the volume and sound settings for your panel.
<
Voice
mode
>
Volume
-
?S
Sound
equalrzat,on
-
SC
Bass
-
SC
A
treble
-
SC
Voice
output (
Bui
lt
in
device
)
11
Menu Setting
To
access the Menu Setting, select the sidebar menu, press the setting icon to enter
the signal source page, press the menu icon
on
the bottom right corner, and then select
Menu Setting. Here you can adjust the backlight, EDID version, and HDMI settings.
<
Menu
setting
>
Backhght
----
•
IOU
Auto
backl1ght
..
-llJM
CL=
-
·IDM
[DJ
<
~DID'
4 >
·IDR
< 1\ulu >
HOMIOUT
<
3840x2160
>
Network Settings
Select sidebar menu, press the setting icon and then enter systems setting page where
it can conduct wireless network, wired network, wireless hot spot setting.
♦
Wireless
Network (optional)
1 .Select sidebar menu > System Settings > Wireless Network.
2.Turn
on
WLAN switch.
3.Select the network to
be
connected from Network List, enter the connecting
password, and then success to connect the wireless network.
4.
Ifthere
is
no desired network
in
the Network List, it can be manually added.
♦
Wired
Network
1.Connect one end
of
the network cable to the network port
of
this machine before
using wired network, and then connect the other end to a router.
2.Select sidebar
menu>
System Settings> Wired Network.
3.Turn
on
connecting switch.
4.Select "DHCP"
in
IP
settings, and then the machine will automatically obtain
an
IP
address and connect to network.
5.Select "Static"
in
IP
settings, manually input
IP
address, gateway, network prefix
length,
DSN
address, and then click "Finish" to connect to network.
12
*Remark:
there are two network ports
on
this machine, either
of
which can be
connected to wired network (choose one
of
them). When one network port
is
connected with a router, the other port can
be
connected with
an
external
device.TheAndroid system
of
this machine, OPS (Windows
system only) and the external device from a LAN, can be connected
to network at the same time.
♦
Wireless
Hot Spot(optional)
1 .Select sidebar Menu > System Settings > Wireless Hot Spot.
2.Turn
on
hot spot switch.
3.Enter the hot spot name
in
the text box. The system default name
is
"Android
AP-7654" which can be changed.
4.Select encryption type.
In
case
of
opening network, no password
is
required, but
any device that finds this network can connect to the WIFI network
of
this machine.
In
case
of
WPA PSK/WPA2 PSK encryption, a protective password over 8 digits
shall be entered, and the correct password
is
required for other device that finds
choosing can
be
entered into the password field.
5.After encryption
is
selected, the system will automatically configure a password or
a password
of
choosing can be entered into the password field.
6.Click "OK" to save setting, and then this network can
be
found by other WIFI
devices within the range when they search WIFI networks.
*Note:
A secure password
is
recommended.
Date and Language Setting
Select the sidebar menu, press the setting icon, enter the system setting page. Here
you can set the time zone to be manual or automatic, the time display settings, inputs
method, system language, etc.
13
System Setting and Applications
Select the sidebar menu, press the setting icon, enter the system setting and applications
page. Here you can adjust the wallpaper, screen-lock background, password, factory
reset, Android application management, etc.
Remark:
1.The format for wallpaper and screen lock background images can
be
PNG or
JPEG. The suggested resolution sizes are 1920*1080 and 3840*2160 pixels.
To
ensure images are imported successfully and to avoid slowing down the
machine, please do not use oversized documents.
2.The password
is
blank by default. Please set the password
in
the setting menu
and keep a record
of
password modifications. Ifthe password is forgotten,
contact QOMO after-sales support for password reset directions.
3.Please do not arbitrarily restore factory settings. When encountered malfunction,
please conduct the operation
of
factory data resetting under the guide
of
after-sales personnel.
~
Apps
Wallpaper
>
~ Screen
saver
>
m
No
S1
~nal
Backgroun
d >
Days
Left
>
e
Change
Password
>
Boot
l
ock
screen -
~
Restore
factory settings >
Auto
check
update -
CD
Check
update >
14
Control Lock and Centralized Control Setting
Select sidebar menu, press the setting icon and enter system setting page, it can set
remote control lock, touch lock, panel lock, smart screen refreshing, gesture on/off,
centralized control etc.
Remark:1.Touch lock can only be removed via the return key
of
remote control and
keyboard plate.
2.The function
of
Smart Screen Refreshing is to prevent image retention due to
static frame displayed for a long time which may causes electric burning injury
to LCD.
3.Gesture on/off can set gesture to switch to sidebar menu( slide from the side
of
screen to the central), bottom-bar menu( slide upwards from bottom left
of
the screen), and floating ball menu( tune-out with three-finger touch).
~
Centralized
control
~
Remote
Lock
ID
Touch
Lock
ID
*
Keypad
lock
ID
I Intelligent Protective
Screen
••
Gesture switch >
l0
(D
Power On/off Setting
Select sidebar menu, press the setting icon, enter system setting page, select the
Power On/off Setting icon. Here you can access the functions for wake on LAN and
timed startup and shutdown.
15
Basic
Operations
Comments
Select sidebar menu, press comments icon, then it can annotate the page and conduct
relevant operation.
(Note: The homepage background and icons are subject to practical products.)
, I
1.,,
'.
M -
,.
1
•
II
a
--
•
04:
47
am
I •
what
should
our
main
focus
be
t
oday?
I
• bund
le
board
·
~3
~-
:::
........
OIi
=
Qr,
0 ,
I)
'4'
=~
._
e,.
0im
000
Android Homepage
There are time, date, flash drive information, network information, hot spot information
and shortcuts for whiteboard and file manager
on
the home page. All apps include
system apps and third party apps.
(Note: The homepage background and icons are subject to practical products.)
, I
·1.,,
'.
M -,.1
•
II
a
IC:II
-
•
04:
47
am
I •
what
should
our
main
focus
be
t
oday?
I
• bund
le
board
·
~3
~-
::
.......
=
Qr,
0 ,
I)
'4'
=~
._
e,.
0im
000
*Special
tips
User can install new application and the operations may vary. The operation methods
detailed
in
this Manual are for reference only. User shall operate the
machine
according
to the actual situation. 16
Writing Software
The electronic whiteboard writing software contains selection, background setting, brush
setting, undo, restore, text, clear screen, save, import picture, spot light and split screen
and other functions.
(Note: The writing software function will be updated
in
real time and are subject to
practical products.)
Documents Manager
The document manager supports the playback
of
images, videos, audio, etc. Long
pressing can move, copy, delete selected document.
@ .,
ll,;J
'
'"'"'
• • • • •
cm
Ml/SIC
.......
-·
"'
" -•
G
va~
.±.
""
• • • • •
.,
,...,,.
"""'
.....,
CJ
""
'
~
US8
A •
--
-
...
( 1/1 ,
17
Other manuals for BUNDLEBOARD G PANEL
1
This manual suits for next models
4
Table of contents
Other Qomo Monitor manuals
