Qtx Mesmerizer User manual

www.avsl.com 152.745UK User Manual
3D Animation Laser
Item ref: 152.745UK
User Manual
Thank you for choosing the QTX Mesmerizer 3D animation Laser With a stunning set of 440 dynamic and
static patterns available including jaw-dropping 3D laser animations, colourful RGBW patterns and wall
washes, the Mesmerizer is sure to pack a punch at any party, show or event. 4 control modes including
auto, sound to light and DMX512 make this compact and lightweight unit perfect for any occasion large or
small.
In the box:
Your Mesmerizer should arrive with you in a single carton in good condition. The carton should contain
1x main unit with bracket, 1x UK IEC mains lead, 1x laser key and 1x user guide.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally. Qualified personnel should then
check the unit before continuing use.
Please read through this manual thoroughly before use, any damage
Caused by misuse of product will not be covered by warranty.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.

www.avsl.com 152.745UK User Manual
Caution: Laser radiation
Avoid pointing directly towards eyes. Laser output can cause injury if viewed directly.
This product is a Class 3B laser and should only be installed and used by persons who
are trained in the management of laser radiation and are able to operate in accordance
within the guidance given by the Health and Safety Executive (HSE) in HS(G)95: “The
Radiation Safety of Lasers used for Display purposes”. Copies of this guide can be
downloaded from: www.avsl.com/assets/documents/hsg95.pdf
Placement:
•Use the included mounting bracket to fix to a stand or lighting truss
•Use secondary safety fixings if mounting overhead.
•Keep away from damp or dusty environments.
•Ensure adequate air-flow around the fixture housings.
•Ensure adequate access to controls and connections.
•Do not aim LED or laser output directly into line of sight, as this can result in eye injury.
Cleaning:
•Use a soft cloth with a neutral detergent to clean the casing as required.
•Use a vacuum cleaner to clear ventilation grilles of any dust or debris build-ups.
•Do not use strong solvents for cleaning the unit.
Rear panel controls:
1. LCD display
2. Laser key
3. Mounting point
4. IEC mains in
5. LCD control panel
6. DMX signal in
7. DMX signal out
Manual control menu:
Press the “MENU” button to enter the settings menu.
Press “UP” and “DOWN” buttons to navigate through various setting functions.
Press “ENTER” button to confirm the desired setting.
2.
1.
3.
4.
5.
6.
7.

www.avsl.com 152.745UK User Manual
Menu
Function
Description
Addr
A001-A512
DMX address settings
CHND
21CH
DMX 21CH select
7CH
DMX 7CH select
Auto
Au0
Auto random mode
Au1-Au15
Auto group selections
SPEE
SP0-SP9
Auto mode speed adjust-slow to fast
SoUn
So0-So15
Sound to light range selections
SoSE
SE0-SE9
Sound to light sensitivity adjust-low to high
vEr
vE10
Software version 1.0
DMX modes:
The Mesmerizer can be controlled by DMX signal, simply connect the DMX signal source to the DMX input
on the unit via a balanced XLR lead. Extra fixtures can be controlled by the same DMX signal by looping
through the DMX out on the unit. To enter DMX mode, select A001 from the menu and confirm the correct
start address by using the “UP”and “DOWN”buttons and “ENTER”. The A on the LED display will begin
to flash once it’s received the DMX signal from the controller. This unit has either 7 or 21 DMX channels as
indicated in the tables below:
7-CH (start address A001 for 1st unit, A008 for 2nd unit etc):
Channel
Function
Value
Details
CH1
Dimmer
0-9
No function
10-255
Total dimmer, laser on and LED for dimmer
CH2
Strobe
0-9
LED No function
10-255
LED Strobe from slow to fast
CH3
LED colour control
0-9
LED No function
10-79
LED colour macro
80-159
LED jump from slow to fast
160-255
LED gradual change from slow to fast
CH4
Laser colour
control
0-1
Laser off
2-69
W-R--B-P-CYAN-Y-G (Fixed colour)
70-79
Total colour change (chase speed controlled by CH5)
80-89
Default colour (chase speed controlled by CH5)
90-94
Rainbow colour (chase speed controlled by CH5)

www.avsl.com 152.745UK User Manual
95-114
2-Segment colour option, 5 datas as one step
(chase speed controlled by CH5)
115-139
3-Segment colour option, 5 datas as one step
(chase speed controlled by CH5)
140-164
4-Segment colour option, 5 datas as one step
(chase speed controlled by CH5)
165-189
8-Segment colour option, 5 datas as one step
(chase speed controlled by CH5)
190-224
16-Segment colour option, 5 datas as one step
(chase speed controlled by CH5)
225-229
Colour dynamic chase 1 (speed controlled by CH5)
230-234
Colour dynamic chase 2 (speed controlled by CH5)
235-239
Colour dynamic chase 3 (speed controlled by CH5)
240-244
Colour dynamic chase 4 (speed controlled by CH5)
245-249
Colour dynamic chase 5 (speed controlled by CH5)
250-255
Colour dynamic chase 6 (speed controlled by CH5)
CH5
Colour chase speed
0-9
No function
10-127
Clockwise colour chase from slow to fast
128-255
Anti-clockwise colour chase from slow to fast
CH6
Inner dynamic
effect
0-1
No function
3-183
Inner dynamic effect single option, 2 datas as one
effect, speed and colour controlled by CH7
184-248
Inner dynamic effect group option, 5 datas as one
effect, speed and colour controlled by CH7
249-255
Random auto, speed and colour controlled by CH7
CH7
Inner dynamic
effect speed
0-127
Speed from fast to slow by inner programme
128-255
Speed from fast to slow by DMX controller
21-CH (start address A001 for 1st unit, A022 for 2nd unit etc):
Channel
Function
Value
Details
CH1
Dimmer
0-9
No function
10-255
Total dimmer, laser on and LED for dimmer
CH2
Strobe
0-9
LED No function
10-255
LED Strobe from slow to fast
CH3
LED colour control
0-9
LED No function
10-79
LED colour macro

www.avsl.com 152.745UK User Manual
80-159
LED jump from slow to fast
160-255
LED gradual change from slow to fast
Laser colour
control
0-1
Laser off
2-69
W-R--B-P-CYAN-Y-G (Fixed colour)
70-79
Total colour change (chase speed controlled by CH5)
CH4
80-89
Default colour (chase speed controlled by CH5)
90-94
Rainbow colour (chase speed controlled by CH5)
95-114
5-Segment colour option, 5 datas as one step
(chase speed controlled by CH5)
115-139
6-Segment colour option, 5 datas as one step
(chase speed controlled by CH5)
140-164
7-Segment colour option, 5 datas as one step
(chase speed controlled by CH5)
165-189
8-Segment colour option, 5 datas as one step
(chase speed controlled by CH5)
190-224
16-Segment colour option, 5 datas as one step
(chase speed controlled by CH5)
225-229
Colour dynamic chase 1 (chase speed controlled by CH5)
230-234
Colour dynamic chase 2 (chase speed controlled by CH5)
235-239
Colour dynamic chase 3 (chase speed controlled by CH5)
240-244
Colour dynamic chase 4 (chase speed controlled by CH5)
245-249
Colour dynamic chase 5 (chase speed controlled by CH5)
250-255
Colour dynamic chase 6 (chase speed controlled by CH5)
CH5
Colour chase speed
0-9
No function
10-127
Clockwise colour chase from slow to fast
128-255
Anti-clockwise colour chase from slow to fast
CH6
Patterns option
0-255
Patterns option (patterns group controlled by CH7)
CH7
Patterns group
option
0-24
Inner patterns group 1
25-49
Inner patterns group 2
50-74
Inner patterns group 3
75-99
Inner patterns group 4
100-124
Inner patterns group 5
125-149
Dynamic patterns group 1
150-174
Dynamic patterns group 2

www.avsl.com 152.745UK User Manual
175-255
No function
CH8
Pattern size
0-255
Pattern size option by manual
CH9
Pattern auto zoom
0-15
Pattern size option
16-55
From small to big speed option
56-95
From big to small speed option
96-135
Big and small zoom speed option
136-175
Cycle zoom effect 1
176-215
Cycle zoom effect 2
216-255
Cycle zoom effect 3
CH10
Patterns middle
rotation
0-127
Rotation angle option
128-191
Clockwise rotation speed option
192-255
Anti-clockwise rotation speed option
CH11
Patterns X rotation
0-127
X location option
128-255
X speed option
CH12
Patterns Y rotation
0-127
Y location option
128-255
Y speed option
CH13
Horizontal remove
0-127
Horizontal location option
128-255
Horizontal remove speed from slow to fast
CH14
Vertical remove
0-127
Vertical location option
128-255
Vertical remove speed from slow to fast
CH15
X wave
0-9
No function
10-255
Wave range and speed adjust
CH16
Patterns drawing
0-1
No function
2-63
Manual drawing 1
64-127
Manual drawing 2
128-153
Auto drawing increase
154-179
Auto drawing decrease
180-205
Auto drawing, reverse from increase to decrease
206-255
Auto drawing, syntropy from increase to decrease
CH17
Patterns trace
0-15
No function

www.avsl.com 152.745UK User Manual
option
166-255
Trace option, range from big to small
CH18
Trace speed
0-255
Trace speed from slow to fast
CH19
Gobo wheel
0-255
Laser gobos wheel change
CH20
Inner dynamic
effect
0-1
No function
3-183
Inner dynamic effect single option, 2 datas as one effect,
speed and colour controlled by CH21
184-248
Inner dynamic effect group option, 5 datas as one effect,
speed and colour controlled by CH21
249-255
Random auto, speed and colour controlled by CH21
CH21
Inner dynamic
effect speed
0-127
Speed from fast to slow by inner programme
128-255
Speed from fast to slow by DMX controller
Specifications:
Power supply
110-240Vac, 50/60Hz (IEC)
Power consumption
40W (max)
Fuse rating
F2A
Laser power
1500mW
Laser Class
3B
DMX channels
7/21
LED power
6x 3W RGBW
Modes
Auto/Sound/DMX512/Master-Slave
Connections
IEC power, DMX in/out (XLR), Laser key
Dimensions
210 x 217 x 235mm
Weight
2.1kg
Troubleshooting:
No power (mains)
Check mains voltage is correct and outlet is switched on
Check IEC lead and fuse (if fuse continually blows, refer to your
dealer)
No laser or light
output
Check control panel mode settings
Check DMX settings from controller (dimmer levels, blackout etc.)
Check laser key on rear panel is turned on
Unresponsive to DMX
Check that unit is in DMX mode and ensure the A on the DMX
address flashes to confirm it’s receiving a DMX signal
Check DMX controller is on correct fixture/page
Check master dimmer value
Check correct DMX address is set
Check DMX connection and leads
Overheating/
cutting out
Ensure adequate ventilation and unit is not too close to a heat
source

www.avsl.com 152.745UK User Manual
This product is classed as Electrical or Electronic equipment and should not be disposed
with other household or commercial waste at the end of its useful life.
The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted.
Copyright© 2022 AVSL Group Ltd, Unit 2 Bridgewater Park, AVSL (Europe) Ltd, Unit 3D North Point House,
Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland.
