Quanmax ECX-SLU0 Series User manual

I
ECX
-
SLU0 / KLU0 Series Use r’s Manual
ECX-SLU0 / KLU0 Series
3.5" ECX Single Board Computer
with Intel®Skylake / KabyLake U-Series Processors
User’s Guide

II
ECX
-
SLU0 / KLU0 Series Use r’s Manual
Contact Info: Quanmax Inc.
4F, No. 415,Ti-Ding Blvd. Sec.2NeiHu District,
Taipei 114Taiwan
Tel: [phone]
Fax:[phone]
Visit our site at: www.quanmax.com
© 2017 Quanmax Inc. All rights reserved.
Theinformationin this user’sguideisprovided for reference only.Quanmax does notassume any
liabilityarising outof the application oruseof theinformation or productsdescribedherein. Thisuser’s
guide may contain or reference informationand productsprotected bycopyrightsor patentsanddoes
not convey anylicense under the patent rightsof Quanmax, nor the rights of others.
Quanmax is aregisteredtrademark ofQuanmax. All trademarks, registered trademarks, andtrade
names usedin this user’sguideare the property oftheir respectiveowners.All rights reserved.This
user’sguide containsinformation proprietary toQuanmax. Customers may reprintand use this user’s
guide in other publications.Customers may alter thisuser’sguide and publish it onlyafter they remove
theQuanmax name, cover,andlogo.
Quanmax reserves the right tomake changeswithoutnoticeinproductor componentdesign as
warranted byevolutionin user needs orprogressin engineering or manufacturing technology.
Changeswhich affectthe operationoftheunitwill bedocumentedin thenext revisionof this user’s
guide.

Content
3
ECX
-
SLU0 / KLU0 Series Use r’s Manual
Content
Content......................................................................................................................................3
Figures ......................................................................................................................................5
Tables........................................................................................................................................6
Safety Instructions...................................................................................................................8
Before You Begin....................................................................................................8
When Working Inside a Computer.......................................................................8
Preventing Electrostatic Discharge......................................................................9
Preface....................................................................................................................................11
How to Use This Guide........................................................................................11
Unpacking..............................................................................................................11
Regulatory Compliance Statements ..................................................................11
Warranty Policy .....................................................................................................12
Maintaining Your Com puter.................................................................................13
Chapter 1 Introduction.......................................................................................................16
Overview ................................................................................................................16
Product Specifications..........................................................................................17
Sys tem Block Diagram.........................................................................................18
Mechanical Dimensions.......................................................................................19
Chapter 2 Hardware Settings ...........................................................................................20
Overview ................................................................................................................20
Jumper Settings and Pin Definitions..................................................................21
Jumper Settings..................................................................................................22
Internal Connector Pin Assignment.................................................................24
Rear Panel Pin Assignm ents ............................................................................32
Chapter 3 System Installation...........................................................................................35
Memory Module Installation................................................................................35
Chapter 4 AMI BIOS Setup...............................................................................................37
Overview ................................................................................................................37
Main Menu .............................................................................................................38
Advanced Menu....................................................................................................39
Power Menu...........................................................................................................49
Boot Menu..............................................................................................................50
Security Menu .......................................................................................................51
Save & Exit Menu .................................................................................................52

Content
4
ECX
-
SLU0 / KLU0 Series Use r’s Manual
Chapter 5 Driver Installation.............................................................................................54
Appendix A DIO (Digital I/O) Sam ple Code....................................................................55
Appendix B WatchDog Timer Sample Code.....................................................................59

Figures
5
ECX
-
SLU0 / KLU0 Series Use r’s Manual
Figures
Figure 1 Block Diagram........................................................................................18
Figure 2 Mechanical Dimensions........................................................................19
Figure 3 Jumper Connector.................................................................................20
Figure 4 Jumper and Connector Locations.......................................................21
Figure 5 Rear Panel IO.........................................................................................32
Figure 6 Align the SO-DIMM MemoryModule with the onboard socket......35
Figure 7 Press down on the SO-DIMM MemoryModule to lock itin place.36

Tables
6
ECX
-
SLU0 / KLU0 Series Use r’s Manual
Tables
Table 1 ECX-BW00 Specification........................................................................17
Table 2 Jumper Lis t...............................................................................................22
Table 3 JP1 MPCIE1 Activity LED Pin Header .................................................22
Table 4 JP2 Panel & Backlight Power Selection for LVDS1...........................22
Table 5 JP3 NGFF M.2 Activity LED Pin Header.............................................22
Table 6 JP4 Backlight Power Enable Selection for LVDS1.............................23
Table 7 JP6 AT / ATX Power Mode and NGFF mSATA/mPCIe Selection....23
Table 8 JP7 SIM Card and MPCIE mSATA/mPCIe Selection, USB Power
Selection .........................................................................................................23
Table 9 JP8 Flash Des criptor Security Override Selection.............................23
Table 10 JP9 RTC RESET Selection.................................................................23
Table 11 JP10 Clear ME Regis ter.......................................................................23
Table 12 BAT1 RTC Power Input Wafer ............................................................25
Table 13 FAN1 +12VDC CPU FAN Wafer .........................................................25
Table 14 MPCIE1 Full Size Mini-PCI Expres s v1.2 Socket............................25
Table 15 CON1 NGFF M.2 KE Y B Socket ........................................................26
Table 16 SATA1,2 Serial ATA Port-1,2 Connector............................................27
Table 17 CN1 HDD Power Wafer........................................................................27
Table 18 CN2 DC12V Power Input Wafer.........................................................27
Table 19 CN4 SIM Interface Wafer.....................................................................27
Table 20 CN5 Digital Input / Output Wafer ........................................................28
Table 21 CN6 Serial Port 1 Wafer.......................................................................28
Table 22 CN7 Serial Port 2 Wafer.......................................................................28
Table 23 CN8 USB2.0 Port 5,6 Pin Header ......................................................29
Table 24 CN9 Audio Input / Output Pin Header................................................29
Table 25 CN10 Left Channel 3W Audio AMP Output Wafer ...........................29
Table 26 CN15 Right Channel 3W Audio AMP Output Wafer ........................29
Table 27 CN16 LCD Panel Power Connector for LVDS1 ...............................30
Table 28 LVDS1 Primary 24-bit, 2-channel LVDS Panel Connector.............30
Table 29 FP1 Front Panel Pin Header 1............................................................30
Table 30 FP2 Front Panel Pin Header 2............................................................31
Table 31 Rear Panel Connector Lis t...................................................................32
Table 32 HDMI1 HDMI Port Connector..............................................................32
Table 33 DP1 DisplayPort Port-1 Connector.....................................................33

Tables
7
ECX
-
SLU0 / KLU0 Series Use r’s Manual
Table 34 CN12 GbE LAN1 RJ-45 Connector....................................................33
Table 35 CN11 GbE LAN2 RJ-45 Connector....................................................33
Table 36 CN13 USB3.0/3.1 Port-1,3.1-1b Type-AConnector........................34
Table 37 CN14 USB3.0 Port-3,4 Type-AConnector........................................34
Table 38 ECX-SLU0 / KLU0 Series BIOS Main Menu.....................................38
Table 39 Ad vanced Menu.....................................................................................39
Table 40 Advanced Menu – Display Configuration..........................................40
Table 41 Advanced Menu – Super IO Configuration.......................................41
Table 42 Advanced Menu – Super IO Configuration – Serial Port 1
Configuration..................................................................................................41
Table 43 Advanced Menu – Super IO Configuration – Serial Port 2
Configuration..................................................................................................42
Table 44 Advanced Menu – CPU Chipset Configuration................................43
Table 45 Advanced Menu – SATAConfiguration..............................................44
Table 46 Advanced Menu – USB Configuration...............................................45
Table 47 Advanced Menu – TPM Configuration...............................................46
Table 48 Advanced Menu – DIO Configuration................................................47
Table 49 Advanced Menu – H/W Monitor..........................................................48
Table 50 Power Configuration .............................................................................49
Table 51 Boot Menu..............................................................................................50
Table 52 Security Menu........................................................................................51
Table 53 Save & Exit Menu..................................................................................52

Safety Instructions
8
ECX
-
SLU0 / KLU0 Series Use r’s Manual
Safety Instructions
Before You Begin
Before handling the product, read the instructions and safety guidelines on the
following pages to prevent damage to the product and to ensure your own personal
safety. Refer to the “Advisories” section in the Preface for advisory conventions used
in this user’s guide, including the distinction between Warnings, Cautions, Important
Notes, and Notes.
Always use caution when handling/operating a computer. Only qualified,
experienced, authorized electronics service personnel should access the
interior of a computer. The power supplies produce high voltages and
energy hazards, which can cause bodily harm.
Use extreme caution when installing or removing components. Refer to the
installation instructions in this user’s guide for precautions and procedures.
If you have any questions, please contact Quanmax Post-Sales Technical
Support.
WARNING
High voltages are present inside the chassis when the unit’s power cord is
plugged into an electrical outlet. Turn off system power, turn off the power
supply, and then disconnect the power cord from its source before
removing the chassis cover. Turning off the system power switch does not
remove power to components.
When Working Inside a Computer
Before taking covers off a computer, perform the following steps:
1. Turn off the computer and any peripherals.
2. Disconnect the computer and peripherals from their power sources or
subsystems to prevent electric shock or system board damage. This does not
apply when hot swapping parts.

Safety Instructions
9
ECX
-
SLU0 / KLU0 Series Use r’s Manual
3. Follow the guidelines provided in “Preventing Electrostatic Discharge” on the
following page.
4. Disconnect any telephone or telecommunications lines from the computer.
In addition, take note of these safety guidelines when appropriate:
To help avoid possible damage to system boards, wait five seconds after
turning off the computer before removing a component, removing a system
board, or disconnecting a peripheral device from the computer.
When you disconnect a cable, pull on its connector or on its strain-relief loop,
not on the cable itself. Some cables have a connector with locking tabs. If you
are disconnecting this type of cable, press in on the locking tabs before
disconnecting the cable. As you pull connectors apart, keep them evenly
aligned to avoid bending any connector pins. Also, before connecting a cable,
make sure both connectors are correctly oriented and aligned.
CAUTION
Do not attempt to service the system yourself except as explained in this
user’s guide. Follow installation and troubleshooting instructions closely.
Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation
and follow proper ESD procedure to reduce the risk of damage to components.
Quanmax strongly encourages you to follow proper ESD procedure, which can
include wrist straps and smocks, when servicing equipment.
You can also take the following steps to prevent damage from electrostatic
discharge (ESD):
When unpacking a static-sensitive component from its shipping carton, do not
remove the component’s antistatic packing material until you are ready to install
the component in a computer. Just before unwrapping the antistatic packaging,
be sure you are at an ESD workstation or grounded. This will discharge any
static electricity that may have built up in your body.

Safety Instructions
10
ECX
-
SLU0 / KLU0 Series Use r’s Manual
When transporting a sensitive component, first place it in an antistatic container
or packaging.
Handle all sensitive components at an ESD workstation. If possible, use
antistatic floor pads and workbench pads.
Handle components and boards with care. Don’t touch the components or
contacts on a board. Hold a board by its edges or by its metal mounting bracket.
Do not handle or store system boards near strong electrostatic, electromagnetic,
magnetic, or radioactive fields.
