Quanmax MITX-SLS0/KLS0 Series User manual

MITX-SLS0/KLS0 Series
Industrial Motherboard in Mini-ITX Form Factor with
6th / 7th Generation Intel®Core™ i Processor
User’s Guide

II
MITX-SLS0/KLS0 Series User’s Manual
Contact Info: Quanmax Inc.
4F, No. 415, Ti-Ding Blvd. Sec. 2NeiHu District,
Taipei 114Taiwan
Tel: [phone]
Fax: [phone]
Visit our site at: www.quanmax.com
© 2016 Quanmax Inc. All rights reserved.
The information in this user’s guide is provided for reference only. Quanmax does not assume any
liability arising out of the application or use of the information or products described herein. This user’s
guide may contain or reference information and products protected by copyrights or patents and does
not convey any license under the patent rights of Quanmax, nor the rights of others.
Quanmax is a registered trademark of Quanmax. All trademarks, registered trademarks, and trade
names used in this user’s guide are the property of their respective owners. All rights reserved. This
user’s guide contains information proprietary to Quanmax. Customers may reprint and use this user’s
guide in other publications. Customers may alter this user’s guide and publish it only after they remove
the Quanmax name, cover, and logo.
Quanmax reserves the right to make changes without notice in product or component design as
warranted by evolution in user needs or progress in engineering or manufacturing technology.
Changes which affect the operation of the unit will be documented in the next revision of this user’s
guide.

Content
3
MITX-SLS0/KLS0 Series User’s Manual
Content
Content.......................................................................................................................3
Figures.......................................................................................................................5
Tables.........................................................................................................................6
Safety Instructions......................................................................................................9
Before You Begin.........................................................................................9
When Working Inside a Computer...............................................................9
Preventing Electrostatic Discharge............................................................10
Preface.....................................................................................................................12
How to Use This Guide..............................................................................12
Unpacking..................................................................................................12
Regulatory Compliance Statements ..........................................................12
Warranty Policy .........................................................................................13
Maintaining Your Computer.......................................................................14
Chapter 1 Introduction...........................................................................................17
Overview ...................................................................................................17
Product Specifications...............................................................................18
System Block Diagram..............................................................................19
Mechanical Dimensions.............................................................................20
Chapter 2 Hardware Settings ................................................................................21
Overview ...................................................................................................21
Jumper Settings and Pin Definitions..........................................................22
Jumper Settings ......................................................................................23
Rear Panel Pin Assignments...................................................................26
Main Board PinAssignments...................................................................30
Chapter 3 System Installation ..................................................................................41
Expansion Interfaces.................................................................................41
Memory Module Installation.......................................................................41
Chapter 4 AMI BIOS Setup....................................................................................43
Overview ...................................................................................................43
Main Menu.................................................................................................44
Advanced Menu.........................................................................................45
Power Menu..............................................................................................58
Security Menu............................................................................................59
Boot Menu.................................................................................................60

Content
4
MITX-SLS0/KLS0 Series User’s Manual
Save & Exit Menu......................................................................................61
Chapter 5 Driver Installation.....................................................................................63
AppendixA DIO (Digital I/O) Sample Code............................................................64
Appendix B WatchDog Timer Sample Code.............................................................67

Figures
5
MITX-SLS0/KLS0 Series User’s Manual
Figures
Figure 1 Block Diagram .............................................................................19
Figure 2 Mechanical Dimensions...............................................................20
Figure 3 Jumper Connector .......................................................................21
Figure 4 Jumper and Connector Locations................................................22
Figure 5 Front Panel IO .............................................................................26
Figure 6 Align the SO-DIMM Memory Module with the onboard socket.....42
Figure 7 Press down on the SO-DIMM Memory Module to lock it in place 42

Tables
6
MITX-SLS0/KLS0 Series User’s Manual
Tables
Table 1 Product Specifications...................................................................19
Table 2 Jumper List....................................................................................23
Table 3 JP1 AT / ATX Power Mode Selection.............................................23
Table 4 JP2 Clear ME Register..................................................................23
Table 5 JP3 RTC Reset Selection..............................................................23
Table 6 JP4 mPCIE / mSATA Selection for MPCIE2 (models w/ Q170 only)
............................................................................................................24
Table 7 JP5 mPCIE / mSATA Selection for MPCIE1 (models w/ Q170 only)
............................................................................................................24
Table 8 JP6 Keyboard Lock Selection........................................................24
Table 9 JP7 MPCIE LED Indicator Pin Header..........................................24
Table 10 JP9 PCIE Configuration Setting for PEG1 (models w/ Q170 only)24
Table 11 JP10 Backlight Power Enable Selection for LVDS1.....................24
Table 12 JP11 Panel & Backlight Power Selection for LVDS1 ...................25
Table 13 JP12 Pin-9 Selection for COM1...................................................25
Table 14 JP13 ME F/W Selection...............................................................25
Table 15 JP14 Pin-9 Selection for COM2...................................................25
Table 16 Rear Panel Connector List ..........................................................26
Table 17 CN17 GbE LAN1 & USB3.0 Port-1, 2 Connector........................26
Table 18 CN18 GbE LAN2 & USB3.0 Port-3, 4 Connector........................27
Table 19 CN19 DVI-D Connector...............................................................27
Table 20 CN20 3 Stack-up Azalia Audio Phone Jack.................................27
Table 21 CN21 USB2.0 Port-0,1 Type-A Connector...................................28
Table 22 CN22 RS-232 / 422 / 485 Port 1, 2 Connector............................28
Table 23 CN23 Display Port Connector .....................................................29
Table 24 CN24 Display Port Connector .....................................................29
Table 25 Internal Connector List ................................................................30
Table 26ATX1 2x12-Pin ATX Power Supply Wafer....................................31
Table 27 ATX2 2x4-Pin ATX Power Supply Wafer......................................31
Table 28 CN1 USB3.0 Port-5, 6 Box Header (models w/ Q170 only).........31
Table 29 CN2 SIM Interface Wafer for MPCIE2.........................................32
Table 30 CN3 USB2.0 Port 11, 12 Pin Header...........................................32
Table 31 CN4 USB2.0 Port 7, 8 Pin Header...............................................32
Table 32 CN5 Digital Input / Output Wafer.................................................32

Tables
7
MITX-SLS0/KLS0 Series User’s Manual
Table 33 CN6 Serial Port 3 Wafer..............................................................33
Table 34 CN7~9 RS-232 Port 4, 5, 6 Wafer...............................................33
Table 35 CN10 VGA Header......................................................................33
Table 36 CN11 Left Channel 3W Audio AMP Output Wafer .......................33
Table 37 CN12 Backlight Power Output Wafer for LVDS1.........................34
Table 38 CN13 Front PanelAudio Pin Header...........................................34
Table 39 CN14 SPDIF–OUT Pin Header ...................................................34
Table 40 CN15 PS/2 Keyboard & Mouse Wafer.........................................34
Table 41 CN16 Right Channel 3W Audio AMP Output Wafer.....................34
Table 42 FAN1 CPU FAN Wafer.................................................................35
Table 43 FAN2 System FAN Wafer ............................................................35
Table 44 FP1 Front Panel Pin Header 1 ....................................................35
Table 45 FP2 Front Panel Pin Header 2 ....................................................35
Table 46 MPCIE2 Full Size mPCIE / mSATASocket (models w/ H110 have
mPCIE only)........................................................................................36
Table 47 MPCIE1 Half Size mPCIE / mSATASocket (models w/ H110 have
mPCIE only)........................................................................................37
Table 48 PEG1 PCIE Express x16 Slot......................................................38
Table 49 SATA1,2,3,4 Serial ATA Port-3,2,1,0 Connector ..........................39
Table 50 DIMM1,2 DDR4 Memory SO-DIMM Socket ................................39
Table 51 LVDS1 Primary 24-bit, 2-channel LVDS Panel Connector...........40
Table 52 BIOS Main Menu.........................................................................44
Table 53 Advanced Menu...........................................................................45
Table 54 Advanced Menu – Display Configuration.....................................46
Table 55 Advanced Menu – Super IO Configuration..................................47
Table 56 Advanced Menu – Super IO Configuration – Serial Port 1
Configuration ......................................................................................47
Table 57 Advanced Menu – Super IO Configuration – Serial Port 2
Configuration ......................................................................................48
Table 58 Advanced Menu – Super IO Configuration – Serial Port 3
Configuration ......................................................................................49
Table 59 Advanced Menu – Super IO Configuration – Serial Port 4
Configuration ......................................................................................50
Table 60 Advanced Menu – Super IO Configuration – Serial Port 5
Configuration ......................................................................................51
Table 61 Advanced Menu – Super IO Configuration – Serial Port 6
Configuration ......................................................................................52
Table 62 Advanced Menu – CPU Chipset Configuration............................53

Tables
8
MITX-SLS0/KLS0 Series User’s Manual
Table 63 Advanced Menu – SATA Configuration........................................54
Table 64 Advanced Menu – USB Configuration.........................................55
Table 65 Advanced Menu – DIO Configuration..........................................56
Table 66 Advanced Menu – H/W Monitor...................................................57
Table 67 Power Menu................................................................................58
Table 68 Security Menu .............................................................................59
Table 69 Boot Menu...................................................................................60
Table 70 Save & Exit Menu........................................................................61

Safety Instructions
9
MITX-SLS0/KLS0 Series User’s Manual
Safety Instructions
Before You Begin
Before handling the product, read the instructions and safety guidelines on the
following pages to prevent damage to the product and to ensure your own personal
safety. Refer to the “Advisories” section in the Preface for advisory conventions used
in this user’s guide, including the distinction between Warnings, Cautions, Important
Notes, and Notes.
Always use caution when handling/operating a computer. Only qualified,
experienced, authorized electronics service personnel should access the
interior of a computer. The power supplies produce high voltages and
energy hazards, which can cause bodily harm.
Use extreme caution when installing or removing components. Refer to the
installation instructions in this user’s guide for precautions and procedures.
If you have any questions, please contact Quanmax Post-Sales Technical
Support.
WARNING
High voltages are present inside the chassis when the unit’s power cord is
plugged into an electrical outlet. Turn off system power, turn off the power
supply, and then disconnect the power cord from its source before
removing the chassis cover. Turning off the system power switch does not
remove power to components.
When Working Inside a Computer
Before taking covers off a computer, perform the following steps:
1. Turn off the computer and any peripherals.
2. Disconnect the computer and peripherals from their power sources or
subsystems to prevent electric shock or system board damage. This does not
apply when hot swapping parts.

Safety Instructions
10
MITX-SLS0/KLS0 Series User’s Manual
3. Follow the guidelines provided in “Preventing Electrostatic Discharge” on the
following page.
4. Disconnect any telephone or telecommunications lines from the computer.
In addition, take note of these safety guidelines when appropriate:
To help avoid possible damage to system boards, wait five seconds after
turning off the computer before removing a component, removing a system
board, or disconnecting a peripheral device from the computer.
When you disconnect a cable, pull on its connector or on its strain-relief loop,
not on the cable itself. Some cables have a connector with locking tabs. If you
are disconnecting this type of cable, press in on the locking tabs before
disconnecting the cable.As you pull connectors apart, keep them evenly
aligned to avoid bending any connector pins. Also, before connecting a cable,
make sure both connectors are correctly oriented and aligned.
CAUTION
Do not attempt to service the system yourself except as explained in this
user’s guide. Follow installation and troubleshooting instructions closely.
Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation
and follow proper ESD procedure to reduce the risk of damage to components.
Quanmax strongly encourages you to follow proper ESD procedure, which can
include wrist straps and smocks, when servicing equipment.
You can also take the following steps to prevent damage from electrostatic
discharge (ESD):
When unpacking a static-sensitive component from its shipping carton, do not
remove the component’s antistatic packing material until you are ready to install
the component in a computer. Just before unwrapping the antistatic packaging,
be sure you are at an ESD workstation or grounded. This will discharge any
static electricity that may have built up in your body.
