THANK YOU
for purchasing The QUANTUM X Vacuum
RECORD THIS INFORMATION
Model Number: _______________________________
Date Code: __________________________________
Date of Purchase (Keep receipt): _________________
Store of Purchase: ____________________________
TECHNICAL SPECIFICATIONS
Voltage: 110/120V., 60Hz
Watts: 800±8%W
Amps: 7.0A
PLEASE READ CAREFULLY AND KEEP
FOR FUTURE REFERENCE
This Owner’s Guide is designed to help you get a complete
understanding of your new QUANTUM X Vacuum.
If you have any questions, please call the customer service
line at (844) 324-1411
REGISTER YOUR PURCHASE
(844)324-1411
QuantumXVac.com
2018-10-22 v18 color QX.indd 2 22.10.2018 19:40:00
3
TABLE OF CONTENTS
SAFETY PRECAUTIONS..................................................5
Warnings.....................................................................................5
Important Precautions..................................................................6
WHAT’S IN THE BOX?.............................................................10
Quantum X Unit..........................................................................10
Accessories...............................................................................11
Additional Accessories (Optional).................................................13
Assembling the Quantum X.........................................................14
OPERATION......................................................................15
Operating your Quantum X....................................................15
Filling the Water basin..........................................................15
Attaching your water basin....................................................16
Attaching Power cord..........................................................17
How to Extend the Body........................................................18
Powering On the Quantum X..................................................19
Disengage Power Head Handle...............................................19
Resetting Power Head..........................................................20
HOW TO USE AS A WET MOP.............................................21
Wet Kit Assembly................................................................21
Connecting Wet Kit to Vacuum...............................................21
WHEN YOU’RE FINISHED VACUUMING.............................22
Where To Dump Your Dirty Water............................................22
Turbine Separator Maintenance..............................................23
Storage.............................................................................23
CUSTOMER SERVICE INFORMATION................................24
Contact Us .......................................................................24
Limited Warranty..................................................................25
Policies and Procedures........................................................28
Quantum X Technical Specications........................................31
2018-10-22 v18 color QX.indd 3 22.10.2018 19:40:00
X
INTELLICLEAN
SOLUTIONS
presents
QuantumXVac.com
2018-10-22 v18 color QX.indd 4 22.10.2018 19:40:01
5
IMPORTANT SAFETY NOTICES & INSTRUCTIONS:
for household use only
READ ALL INSTRUCTIONS BEFORE USING
WARNING
To reduce the risk of re, electrical shock, or injury: the Quantum X should
be inspected regularly. Do not use if the wires inside are damaged, cut, or
punctured. Avoid picking up sharp objects. Do not use or repair any damaged
parts. Contact an Authorized Customer Service Technician for repairs. Do
not immerse the Quantum X in liquid for cleaning. Always turn o this
appliance before connecng or disconnecng the motorized Power Head.
WARNING
Because of danger of shock, any electrical appliance should be used
only as directed. There should be no unapproved use of any electrical
product. Electrical leakage and shorts can occur whenever there is
electricity. If the user is standing on the ground, in a basement or in a
room where a lm of water can reach the ground, severe shock could
result. Therefore, use the Quantum X only as directed in this manual.
Do Not Use The Power Head For Picking Up Any Liquids!
CAUTION
The Quantum X water basin will not trap materials that are resistant
to the weng acon of water, including oily or greasy compounds like
soot or ashes, and powdery substances like ceramic, drywall, or plaster
dust. Do not use the Quantum X near any volale or toxic materials.
2018-10-22 v18 color QX.indd 5 22.10.2018 19:40:01
6
IMPORTANT PRECAUTIONS
Unplug the Quantum X when
not in use. Turn it o at the
main switch before unplugging.
Grasp the plug to disconnect
it from the back of the main
unit or from the wall outlet
to avoid damage to cord,
plug, prongs or receptacle.
DO NOT pull or carry by cord,
use cord as a handle, close
a door on cord, pull or carry
around sharp edges or corners.
DO NOT run appliance over
cord, Keep cord away from
heated surfaces. Do not use
with damaged cord or plug.
When used as a vacuum
cleaner, DO NOT leave
appliance when plugged in.
Unplug main unit from the
back of the machine or wall
outlet when unaended
and before servicing or
replacing the motorized
power head drive belt.
DO NOT use the main electrical
power head to pick up liquids.
The Quantum X is intended for
small wet spills. Do not use on
wet surfaces such as: standing
water, excess water, large
1
2
3
4
5
6
7
spills, or liquid volumes larger
than one and a half quarts.
If your Quantum X unit or
accessory is in disrepair,
DO NOT aempt to operate.
If the main unit is not working
properly, has been dropped,
damaged, le outdoors or
dropped in water, contact
an Authorized Quantum X
Service Center for inspecon.
DO NOT clean the unit or
unplug the hose unl the
Quantum X is switched o
and the plug is removed
from the back of the
Quantum X or wall outlet.
DO NOT connect to the
receptacle of an incandescent
light xture or use any
extension cords other than
what’s approved by Quantum
X Company. DO NOT use
with portable transformers
or voltage converters.
DO NOT allow to be used as
a toy. This appliance can be
used by children aged 8 years
and above and persons with
2018-10-22 v18 color QX.indd 6 22.10.2018 19:40:01
7
SAVE THESE INSTRUCTIONS
8
9
10
11
12
reduced physical, sensory
or mental capabilies or
lack of experience and
knowledge if they have
been given supervision or
instrucon concerning use
of the appliance in a safe
way and understand the
hazards involved. Cleaning
and user maintenance shall
not be made by children
without supervision.
DO NOT use the Quantum
X or accessories to unclog
drains. If sewer gas is drawn
into the Quantum X, it
could cause an explosion.
Never touch a metal sink,
cold or hot water pipe with
one hand while touching the
metal parts of any electrical
appliance, light xture or
switch with the other hand.
Your body could complete
an electrical circuit with the
ground. Addionally, wet
skin surfaces can greatly
increase this hazard. DO NOT
handle the Quantum X or
accessories with wet hands.
DO NOT plug any objects
into opening; Do not use with
any openings blocked; keep
free of dust, lint, hair, and
anything that may reduce
airow; Keep hair, loose
clothing, ngers and all parts
of the body from opening and
moving parts; Use extra care
when cleaning on stairs.
DO NOT pick up anything
that is burning or smoking,
such as cigarees, matches
or hot ashes. DO NOT use
to pick up ammable or
combusble liquids, such
as gasoline, or use in areas
where they may be present.
To avoid the possibility of
re or explosion, do not use
Quantum X or accessories in
areas where ammable and/
or explosive vapor or dust is
present. Some cleaning uids
can produce such vapors. Areas
where ammable cleaning
uids have been used should be
completely dry and thoroughly
aired before being vacuumed.
2018-10-22 v18 color QX.indd 7 22.10.2018 19:40:01
8
IMPORTANT PRECAUTIONS
This appliance is provided
with double insulaon. No
grounding means is provided
on a double insulated
appliance, nor should a means
for grounding be added to the
appliance. Servicing a double-
insulated appliance requires
extreme care and knowledge
of the system, and should be
done only by qualied service
personnel. Replacement
parts for a double-insulated
appliance must be idencal
to the parts they replace.
The QuantumX is equipped
with an interlock switch
that prevents the unit from
operang if the water basin is
not properly latched;
DO NOT ATTEMPT
TO OVERRIDE THIS
SAFETY FEATURE.
The Quantum X Power Head
contains a powerful rotang
brush. To avoid bodily injury,
the Power Head should not
be placed against, or close
to: loose clothing, jewelry,
hair, or body surfaces while
unit is connected to electrical
outlet. The Power Head does
NOT protect against bodily
injury or damage to objects that
contact the rotang brush.
To reduce the risk of electric
shock, this appliance may have
a polarized plug (one blade is
dierent than the other).
This plug will t in a polarize
outlet only one way. If the plug
does not t fully in the outlet,
reverse the plug. If it sll does
not t, contact a qualied
electrician to install the proper
outlet.
DO NOT change the
plug in any way.
If the power cord is damaged,
turn o the power switch on
the Quantum X and unplug
the unit. Power cord must be
replaced by an Authorized
Quantum X Service Technician.
DO NOT run power cord under
carpeng. Do not cover cord
with throw rugs, runners or
similar coverings. DO NOT
route cord under furniture or
appliances. Arrange cord away
from trac area and where
it will not be tripped over.
15 18
17
14
16
13
2018-10-22 v18 color QX.indd 8 22.10.2018 19:40:01
9
THIS APPLIANCE IS INTENDED FOR
HOUSEHOLD USE ONLY.
USE THE QUANTUM X ONLY AS
DIRECTED IN THIS OWNER’S MANUAL
Service & Warranty: (844) 324-1411
SAVE THESE SAFETY NOTICES & INSTRUCTIONS
PLEASE READ ALL OF THE SAFETY NOTICES
AND INSTRUCTIONS
IN THIS MANUAL BEFORE USING THE VACUUM.
VISIT
QuantumXVac.com
TO READ THE USER MANUAL, INCLUDING A
COPY OF THE SAME SAFETY PROCEDURES
IN THIS MANUAL AND THE QUANTUM X
WARRANTY INFORMATION.
2018-10-22 v18 color QX.indd 9 22.10.2018 19:40:01
10
GETTING TO KNOW YOUR QUANTUM X VACUUM
WHAT’S IN THE BOX
OPTIONAL
ACCESSORIES
MAIN UNIT
(Do Not Use) Electric Power Head for Picking Up Liquids!
1. WATER BASIN
2. UPHOLSTERY
BRUSH
3. DUSTING BRUSH
4. CREVICE TOOL
5. WET/DRY HOSE
6. 3-PLASTIC WANDS
7. POWER HEAD
WITH ROTATING
BRUSH
8. ELECTRIC
POWER CORD
9. ACCESSORIES
BAG
• AIR DRIVEN MINI
POWER HEAD
• LARGE SQUEEGEE
HEAD
• HARD FLOOR BRUSH
• 35FT ELECTRIC CORD
REWIND
• 4-PACK FRAGRANCE
2018-10-22 v18 color QX.indd 10 22.10.2018 19:40:01
11
WHAT’S IN THE BOX
1. WATER BASIN 2. UPHOLSTERY BRUSH
3. DUSTING BRUSH 4. CREVICE TOOL
5. WET/DRY HOSE 6. 3-PLASTIC WANDS
2018-10-22 v18 color QX.indd 11 22.10.2018 19:40:06
12
WHAT’S IN THE BOX
8. ELECTRIC POWER CORD7. POWER HEAD WITH
ROTATING BRUSH
9. ACCESSORIES BAG
(Dry Use Only)
Go to www.QuantumXVac.com or Call (844) 324-1411 for Assistance
2018-10-22 v18 color QX.indd 12 22.10.2018 19:40:08
13
OPTIONAL ACCESSORIES
(Not Included)
LARGE SQUEEGEE HEAD
AIR DRIVEN MINI POWER HEAD
4-PACK FRAGRANCE
35FT ELECTRIC CORD REWIND
Go to www.QuantumXVac.com or Call (844) 324-1411 for Assistance
HARD FLOOR BRUSH
2018-10-22 v18 color QX.indd 13 22.10.2018 19:40:10
14
HANDLE ASSEMBLY
ATTACH THE QUANTUM X HANDLE
AS SHOWN AND SCREW IN WITH
HANDLE SCREW (INCLUDED)
PLACE THE RUBBER PLUG
TO COVER THE SCREW HOLE
Go to www.QuantumXVac.com or Call (844) 324-1411 for Assistance
ATTACHING THE POWERHEAD
FULLY EXTEND TELESCOPING
TUBE OUT BEFORE CONNECTING
WITH THE POWER HEAD.
PULL THE EXTEND BUTTON
TO TELESCOPE THE TUBE AND
THEN CONNECT TO THE TUBE
ON THE POWER HEAD
(make note to match the electrical
connection on the stainless-
steel tube with the electrical
connection with the power head).
THEN LOWER THE QX BODY ONTO
THE POWER HEAD. THERE WILL
BE AN AUDIBLE “CLICK” WHEN
BOTH ARE ENGAGED. LOWER THE
MAIN BODY TO THE LOWERED
POSITION, READY TO USE.
2018-10-22 v18 color QX.indd 14 22.10.2018 19:40:11
15
OPERATING YOUR QUANTUM X
1. FILLING THE WATER BASIN
WITH REGULAR TAP WATER
***MUST ALWAYS BE
OPERATED WITH A PROPERLY
FILLED WATER BASIN
WHEN PICKING UP
LIQUIDS, START WITH AN
EMPTY WATER BASIN
Go to www.QuantumXVac.com or Call (844) 324-1411 for Assistance
2018-10-22 v18 color QX.indd 15 22.10.2018 19:40:12
16
OPERATING YOUR QUANTUM X
2. ATTACHING THE UPRIGHT
WATER BASIN AND PUSH
IN TILL BASIN CLICKS AND
BASIN IS SECURE IN PLACE
PUSH FIRMLY AT THE BOTTOM
END OF THE CANISTER
TO LOCK INTO PLACE
Go to www.QuantumXVac.com or Call (844) 324-1411 for Assistance
Ensure the insert is tight
in the water canister
2018-10-22 v18 color QX.indd 16 22.10.2018 19:40:14
17
OPERATING YOUR QUANTUM X
3. ATTACHING THE POWER CORD
4. PUSH PLUG IN TILL LOCKS
2018-10-22 v18 color QX.indd 17 22.10.2018 19:40:15
18
OPERATING YOUR QUANTUM X
6. PUT FOOT
ON TOP OF
POWER HEAD
AND WHILE
YOU’RE
PRESSING
THE RED
LEVER LIFT
UP TO THE
APPROPRIATE
POSITION YOU
REQUIRE.
EXTEND THE
QUANTUM X
TO GET UNDER
FURNITURE,
BEDS, COFFEE
TABLES OR
HARD TO
REACH AREAS
THAT ARE
LOW TO THE
GROUND
HOW TO LOWER
THE BODY
BACK DOWN
IN THE LOWER
POSITION.
REVERSE #6
DIRECTIONS
TO LOWER
UNIT BACK
TO REQUIRED
POSITION.
Go to www.QuantumXVac.com or Call (844) 324-1411 for Assistance
5. EXTENDING
BODY IN LIFT
POSITION:
PRESS UP ON
RED LEVER
ON BACK SIDE
OF UNIT.
2018-10-22 v18 color QX.indd 18 22.10.2018 19:40:16
19
OPERATING YOUR QUANTUM X
7. POWERING ON YOUR QUANTUM X
8. DISENGAGING
THE POWER
HEAD HANDLE
ON
SWIPE OR HOLD POWER ICON
MAKE SURE THE
QUANTUM X IS
IN THE UPRIGHT
POSITION, PRESS
THE FOOT RELEASE
BUTTON AND PULL
HANDLE BACK
INTO VACUUMING
POSITION.
OFF
2018-10-22 v18 color QX.indd 19 22.10.2018 19:40:17
20
OPERATING YOUR QUANTUM X
Reset Button for Power Head
RESET BUTTON FOR POWER HEAD
IF ANY OBJECT IS
CAUGHT IN THE
ROLLER BRUSH IT
COULD CAUSE THE
ROLLER BRUSH
TO BOG DOWN
AND SHUT OFF.
UNPLUG THE
QUANTUM X POWER
CORD FROM THE
WALL OUTLET
BEFORE YOU TRY
TO CLEAR THE
OBJECT FROM THE
ROLLER BRUSH.
CLEAR ALL OBJECT
OUT FROM AROUND
ROLLER BRUSH
SO THAT IT’S FREE
AND TURNING
PROPERLY.
PUSH THE RED
RESET BUTTON ON
THE BACK SIDE OF
THE POWER HEAD;
PLUG THE POWER
CORD BACK INTO
THE WALL OUTLET,
AND POWER ON
THE QUANTUM
X TO CONTINUE
VACUUMING.
Go to www.QuantumXVac.com or Call (844) 324-1411 for Assistance
If No Power?
2018-10-22 v18 color QX.indd 20 22.10.2018 19:40:18
Table of contents
