Quantum Q SM 150 User manual

© 2004
GB
Page 129 June 2005 Version 1.1 QSM Bench grinder
quantum
MASCHINEN - GERMANY
OPERATING MANUAL
Version 1.1
Bench grinder
Q SM 150
Q SM 175
Q SM 200
Type
Keep for future reference!

© 2004
GB
Page 2 Bench grinder QSM Version 1.1 29 June 2005
quantum
MASCHINEN - GERMANY
Table of contents
1 Safety
1.1 Safety warnings (Warning notes) .....................................................................4
1.1.1 Classification of hazards .................................................................4
1.1.2 Other pictograms .............................................................................5
1.2 Proper use ........................................................................................................5
1.3 Possible dangers caused by the grinder ..........................................................6
1.4 Qualification of personnel .................................................................................6
1.4.1 Target group ...................................................................................6
1.4.2 Authorised personnel ......................................................................7
1.5 User positions ..................................................................................................7
1.6 Safety devices ..................................................................................................8
1.6.1 Transparent spark-guard .................................................................8
1.6.2 Protective covers on grinding wheels ..............................................8
1.7 Safety check .....................................................................................................9
1.8 Individual protection gear .................................................................................9
1.9 Safety during operation ..................................................................................10
1.10 Safety during maintenance ............................................................................10
1.10.1 Disconnecting the bench grinder and making it safe ....................10
1.10.2 Mechanical maintenance work ......................................................11
1.11 Accident report ...............................................................................................11
1.12 Electrical system ............................................................................................11
2 Technical data
2.1 Characteristics plate .......................................................................................12
2.2 Power connection ...........................................................................................12
2.3 Grinding wheels .............................................................................................12
2.4 Dimensions ....................................................................................................12
2.5 Ambient Conditions ........................................................................................13
2.6 Emissions .......................................................................................................13
3 Assembly
3.1 Parts list .........................................................................................................14
3.2 Storage ...........................................................................................................14
3.3 Installation and assembly ...............................................................................14
3.3.1 Requirements of installation site ...................................................14
3.3.2 Assembly .......................................................................................15
3.3.3 First use ........................................................................................15
4Operating
4.1 Before beginning work ...................................................................................16
4.2 During work ....................................................................................................16
4.2.1 Workpiece bearing plate ...............................................................16
5 Maintenance
5.1 Safety .............................................................................................................17
5.1.1 Preparation ...................................................................................17
5.1.2 Restarting ......................................................................................17
5.2 Revision and maintenance .............................................................................17
5.2.1 Changing the grinding wheels .......................................................18
5.3 Repair .............................................................................................................19
5.4 Optional accessories ......................................................................................19
5.5 Exploded view ................................................................................................20
4.3 Spare parts list ...............................................................................................21
6 Appendix
6.1 Copyright ........................................................................................................22
6.2 Terminology/Glossary ....................................................................................22
6.3 Warranty .........................................................................................................23
6.4 Product follow-up ...........................................................................................24
6.5 EC Declaration of Conformity .........................................................................25
7 Index

© 2004
GB
Page 329 June 2005 Version 1.1 QSM Bench grinder
Safety quantum
MASCHINEN - GERMANY
1 Safety
Glossary of symbols
This section of the instruction manual
• explains the meaning and use of the warning notes used in the manual,
• explains how to use the bench grinder properly,
• highlights the dangers that might arise for you or others if these instructions are not obeyed,
• tells you how to avoid dangers.
In addition to following the instructions in this manual, observe
• relevant laws and regulations,
• the legal provisions regarding prevention of occupational accidents.
European standards must be observed during installation, operation, maintenance and repair of
the bench grinder.
If European standards are not applied in the national legislation of the country of destination, the
specific applicable regulations of each country must be observed.
Where necessary, the required measures must be taken to comply with the specific regulation of
each country before the bench grinder is used.
ALWAYS KEEP THE DOCUMENTATION CLOSE TO THE BENCH GRINDER.
INFORMATION
If you are unable to solve a problem using this manual, please contact us for advice:
OPTIMUM Maschinen GmbH
Dr. Robert-Pfleger-Str. 26
D- 96103 Hallstadt

gives additional indications
calls on you to act
• Enumerations

© 2004
GB
Page 4 Bench grinder QSM Version 1.1 29 June 2005
Safety
quantum
MASCHINEN - GERMANY
1.1 Safety warnings (Warning notes)
1.1.1 Classification of hazards
We classify the safety warnings into various levels. The table below gives an overview of the
classification of symbols (pictograms) and warnings for the specific danger and its (possible)
consequences.
Pictogram Alarm expression Definition/Consequences
DANGER! Imminent danger that will cause serious injury or death
to personnel.
WARNING! Risk: A danger that might cause serious injury or death
to personnel.
CAUTION! Danger or unsafe procedure that might cause injury to
personnel or damage to property.
ATTENTION!
Situation that could cause damage to the machine and
product and other types of damage.
No risk of injury to personnel.
INFORMATION
Application tips and other important or useful informa-
tion and notes.
No dangerous or harmful consequences for personnel
or objects.
In the case of specific dangers, we replace the pictogram
or
General
danger with a warning of injuries to hands, hazardous elec- trical
voltage,
automatic
start-up.

© 2004
GB
Page 529 June 2005 Version 1.1 QSM Bench grinder
Safety quantum
MASCHINEN - GERMANY
1.1.2 Other pictograms
1.2 Proper use
Use
The bench grinder is designed and manufactured exclusively for grinding and polishing metals
using properly authorised abrasive and polishing grinding-wheels.
The bench grinder must be used exclusively for this purpose.
The bench grinder must not be used to machine material that is hazardous to health or materials
that generate dust, such as, for example, wood, Teflon
®
etc.
Improper
use! If the grinder is used in any way other than as described above, if it is modified without the authorisation of Optimum Maschinen GmbH or if it is operated with different process data, then it
is being used improperly.
We do not take liability for damage caused by improper use.
We would like to stress that any modifications to the construction, or technical or technological
modifications which have not been authorised by Optimum Maschinen GmbH will also render
the guarantee null and void.
It is also part of proper use that
• the operating values and adjustment data of the grinder are complied with,
• the instruction manual is observed,
• review and maintenance instructions are observed.
WARNING!
Very serious injury.
It is forbidden to make any modifications or alterations to the operating values of the
grinder! These could endanger personnel and cause damage to the grinder.
Warning -
flammable
substances!
Activation
forbidden! Pull the mains plug! Use protective goggles! Use ear protection!
Use protective
gloves! Use protective boots! Wear a safety suit! Protect the environment! Contact address

© 2004
GB
Page 6 Bench grinder QSM Version 1.1 29 June 2005
Safety
quantum
MASCHINEN - GERMANY
1.3 Possible dangers caused by the grinder
The grinder has undergone a safety inspection (analysis of danger with assessment of risks).
Design and construction based on this analysis were carried out with the latest technological
advances.
Nonetheless, there remains a residual risk, given that the grinder features
• high revolutions,
• rotating parts
• grinding wheels (emission of sparks)
• electrical voltage and currents.
We have used construction resources and safety techniques to minimise the health risk to per-
sonnel resulting from these hazards.
If the grinder is used by personnel who are not duly qualified, there may be a risk resulting from
incorrect operation or unsuitable maintenance.
INFORMATION
All personnel involved in assembly, commissioning, operation and maintenance must
• be duly qualified,
• follow this instruction manual.
In the event of improper use
• there may be a risk to personnel,
• there may be a risk to the machine and other items,
• correct functioning of the grinder may be affected.
Disconnect the machine whenever cleaning or maintenance work is being carried out.
WARNING!
 “Safety
devices“ on
page 8
The grinder may only be used with the safety devices activated.
Disconnect the grinder immediately if a failure is detected in the safety devices!
All additional installations carried out by the operator must incorporate the prescribed
safety devices.
As the machine operator, this will be your responsibility!
1.4 Qualification of personnel
1.4.1 Target group
This manual is addressed to
• operators
•users
• maintenance staff.
The warning notes therefore refer to both operation and maintenance of the bench grinder.
Determine clearly and unequivocally who will be responsible for the different activities on the
machine (use, maintenance and repair).
Vague or unclear assignment of responsibilities constitutes a safety hazard!
Always disconnect the grinder plug from the mains. This will prevent it being used by unauthor-
ised personnel.

© 2004
GB
Page 729 June 2005 Version 1.1 QSM Bench grinder
Safety quantum
MASCHINEN - GERMANY
1.4.2 Authorised personnel
WARNING!
Incorrect use and maintenance of the grinder causes danger for personnel, objects and
the environment.
Only authorised personnel may operate the bench grinder!
Personnel authorised to use and perform maintenance are the trained and instructed technical
staff working for the operator and manufacturer.
The operator must
Obligations
of the
operator
•trainstaff,
• instruct staff regularly (at least once a year) on
- all safety standards that apply to the machine,
- operation,
- accredited technical guidelines,
• check staff's understanding,
• document training/instruction,
• require staff to confirm participation in training/instruction by a signature,
• check whether the staff are aware of safety and of dangers in the workplace and whether
they observe the instruction manual.
The user must
Obligations
of the
user
• have received training in operation of the bench grinder,
• know the function and principle of operation,
• before the machine is first used
- have read and understood the instruction manual,
- be familiar with all safety devices and regulations.
additional
qualification
require-
ments
For work on the following machine components there are additional requirements:
Electrical machine: Only an electrician or person working under the instructions and supervi-
sion of an electrician.
1.5 User positions
The user must stand in front of the bench grinder.
INFORMATION
The bench grinder’s mains plug must be accessible.

© 2004
GB
Page 8 Bench grinder QSM Version 1.1 29 June 2005
Safety
quantum
MASCHINEN - GERMANY
1.6 Safety devices
Use the grinder only with properly functioning safety devices.
Stop the grinder immediately if there is a failure in the safety device and when the grinder is not
being used.
It is your responsibility!
If a safety device has been activated, the grinder must only be used when
• the cause of the failure has been removed,
• it has been verified that there is no resulting danger for personnel or objects.
WARNING!
If you bypass, remove or override a safety device in any other way, you are endangering
yourself and other personnel working with the grinder. The possible consequences are
• very serious injury resulting from a blow-out of the grinding wheels,
• injuries to the eyes resulting from emission of sparks,
• hand injuries,
• fatal electrocution.
The bench grinder includes the following safety devices:
• A transparent spark-guard for each grinding wheel
• An adjustable protective guard with a shaft cover on each grinding wheel.
1.6.1 Transparent spark-guard
The transparent spark-guard in each grind-
ing wheel reduces emissions of sparks
towards the eyes during machining.
It is essential to use protective goggles!
Illustr.1-1: Transparent spark-guard
1.6.2 Protective covers on grinding wheels
The protective covers on the grinding wheels and the ends of the drive shaft prevent accidental
contact.
The operating aperture in the grinder is sized to intercept and retain any fragments from the
grinding wheels.
WARNING!
Adjust the protective cover when the
grinding wheel is worn down.
The operating aperture in the protective
cover should not exceed the space
required for machining the parts.
Try to use a well-fitting work suit.
Illustr.1-2: Protective cover
Transparent spark-guard
Resetting device
Protective cover

© 2004
GB
Page 929 June 2005 Version 1.1 QSM Bench grinder
Safety quantum
MASCHINEN - GERMANY
1.7 Safety check
Check the bench grinder at least once per shift. Inform the person responsible immediately of
any damage, defect or change in operating function.
Check all safety devices
• at the beginning of each shift (with the machine stopped),
• once a week (with the machine in operation),
• after every maintenance and repair operation.
Check that "Forbidden“, Warning and Information labels and the markings on the bench grinder.
• can be clearly made out (if not, clean them),
• are complete.
1.8 Individual protection gear
For specific work, equipment for personal protection as protection equipment is required. This
includes:
• a safety helmet,
• protective goggles or face guard,
• safety gloves,
• safety shoes with steel toe cap,
• ear protection.
Before starting work check that the proper gear is available in the workplace.
CAUTION!
Dirty or contaminated body protection gear can cause disease.
Clean your individual protection gear
• each time after it has been used,
• regularly, at least once a week.
Individual protection gear for special work
Protect your face and eyes: During all work, and specifically work during which your face and
eyes are exposed to hazard, a safety helmet with a face guard should be worn.
Use safety gloves when you lift or handle sharp-edged components manually.
Wear safety shoes when you position, dismantle or transport heavy components.

© 2004
GB
Page 10 Bench grinder QSM Version 1.1 29 June 2005
Safety
quantum
MASCHINEN - GERMANY
1.9 Safety during operation
This operation manual will alert you to actual danger involved in operating the bench grinder.
WARNING!
Prior to activating the bench grinder please double-check whether this will
• not lead to any danger with respect to people,
• will not cause any damage to equipment.
Avoid unsafe working practises:
• Check that no one can be endangered as a result of the work to be initiated.
• The instructions in this manual must be observed during assembly, handling, maintenance
and repair.
• Do not work on the grinder if your concentration is reduced, for example, because you are
taking medication.
• Observe the rules for preventing accidents issued by your association for the prevention of
occupational accidents and safety in the workplace or other inspection authorities.
• Inform the inspector of any danger or failure.
WARNING!
Danger of fire and explosion from emission of sparks.
Do not operate the bench grinder close to flammable or explosive substances.
1.10 Safety during maintenance
Report and
document
any changes
Inform operators timely on maintenance and repair work.
Report all safety relevant changes or performance details of the bench grinder. Document all
changes, have the operation manual changed accordingly and train the machine operators.
1.10.1 Disconnecting the bench grinder and making it safe
Unplug the machine from the mains before beginning any maintenance or repair work.
Check that all machine components and hazardous voltages have been disconnected.
Place a warning sign on the machine:
WARNING!
Before reconnecting the plug to the mains, make sure
that the bench grinder's power (I / O) switch is in the OFF
(O) position.
Illustr.1-3: Power (I / O) switch

© 2004
GB
Page 1129 June 2005 Version 1.1 QSM Bench grinder
Safety quantum
MASCHINEN - GERMANY
1.10.2 Mechanical maintenance work
Remove all protection and safety devices before beginning maintenance work and re-install
them once the work has been completed. These include:
• Covers
• Safety indications and warning signs
• Earth (ground) connection
If you remove protection or safety devices, refit them immediately after completing the work.
Check that they are working properly!
1.11 Accident report
Inform your superiors and Optimum Maschinen GmbH immediately in the event of accidents,
possible sources of danger and any actions which almost led to an accident (near misses).
There are many possible causes.
The sooner they are notified, the faster the causes can be eliminated.
INFORMATION
In the description of work with and on the grinder we highlight the specific dangers of this work.
1.12 Electrical system
 “Maintenance“ on page 17
Have the machine and/or the electric equipment checked regularly, and at least every six
months.
Eliminate immediately all defects such as loose connections, defective wires etc.
A second person must be present during work on live components, to disconnect the power in
the event of an emergency.
Disconnect the bench grinder immediately if there are any anomalies in the power supply!

© 2004
GB
Page 12 Bench grinder QSM Version 1.1 29 June 2005
Technical data
quantum
MASCHINEN - GERMANY
2 Technical data
2.1 Characteristics plate
Illustr.2-1: Characteristics plate
2.2 Power connection
The following information gives the dimensions and weight and is the manufacturer's authorised
service information.
2.3 Grinding wheels
 “Optional accessories“ on page 19
2.4 Dimensions
QSM 150 QSM 175 QSM 200
Motor
230 V or 240V or 110V
~ 50Hz 450 W
Insulation class
FFF
[ mm ]
QSM 150 QSM 175 QSM 200
Dimensions
150 x 20 x 32 175 x 20 x 32 200 x 25 x 32
Turning speed
2850 rpm 2850 rpm 2850 rpm
[ mm ]
QSM 150 QSM 175 QSM 200
Width
456 456 461
Height
278 291 310
Depth
194 220 246
Total weight
14 15 18

© 2004
GB
Page 1329 June 2005 Version 1.1 QSM Bench grinder
Technical data quantum
MASCHINEN - GERMANY
2.5 Ambient Conditions
2.6 Emissions
State-of-the-art acoustic protection methods are used. The level of acoustic intensity is below 73
dB(A).
INFORMATION
We recommend the use of sound insulation and ear protection.
The duration of the noise pollution, the type and characteristics of the working area, such as
other machines which are operated simultaneously, all influence the level of noise in the work-
place.
Temperature 5-35 °C
Humidity 25 - 80%

© 2004
GB
Page 14 Bench grinder QSM Version 1.1 29 June 2005
Assembly
quantum
MASCHINEN - GERMANY
3 Assembly
INFORMATION
Before the machine is first used the transparent spark-guards and the supports for tools must be
fitted on the bench grinder.
(
 Illustr.1-1: “Transparent spark-guard“ on page 8)
Take into account the following maximum distances:
• Transparent spark-guard and grinding wheel: max. 2mm
• Tool support and grinding wheel: max. 2mm
WARNING!
Adjust the protective cover when the grinding wheel is worn down.
The operating aperture in the protective covers should not exceed the space required for
machining the parts.
3.1 Parts list
Check the bench grinder immediately on delivery for transportation damage or missing compo-
nents. Remove all separate parts from the cardboard box and check them against the following
list.
• Bench grinder
• 2 supports for workpieces
• 2 transparent spark-guards
• Operating manual
3.2 Storage
NOTICE!
Inappropriate storage could damage or ruin important machine components.
Store the packed or already unpacked components only when the specified ambient con-
ditions are observed:
 “Ambient Conditions“ on page 13
Request information from Optimum Maschinen GmbH if the bench grinder and auxiliary units
are to be stored for a period longer than 3 months under ambient conditions other than those
specified.
3.3 Installation and assembly
3.3.1 Requirements of installation site
Organise the work area so that the bench grinder can function in accordance with the safety pre-
cautions.
The operating area for operation, maintenance and repair must not be obstructed.
INFORMATION
Access to the bench grinder’s power plug must be kept free.

© 2004
GB
Page 1529 June 2005 Version 1.1 QSM Bench grinder
Assembly quantum
MASCHINEN - GERMANY
3.3.2 Assembly
 “Qualification of personnel“ on page 6
Check the horizontal orientation of the base of the grinder with a spirit level.
Secure the bench grinder to the base using the holes bored for this purpose.
ATTENTION!
Tighten the securing screws into the bench grinder only until they are secure and tight
enough for the grinder not to move during operation.
If the securing screws are too tight and the base is uneven, the bench grinder's base
plate may break.
3.3.3 First use
WARNING!
If the bench grinder is first used by inexpert personnel, it can endanger personnel and
equipment.
We do not take responsibility for damage caused by incorrect commissioning.
Power supply
 “Power connection“ on page 12
Connect the bench grinder's mains plug to the power supply. Check the fuse protection of the
power supply against the technical information for the grinder's input power.
ATTENTION!
Check the rotating direction of the motor.
If the motor turns in the wrong direction, it can cause the grinder to break down.
The turning direction of the motor is marked on the protective cover of the grinding
wheel.
The motor should turn clockwise!
ATTENTION!
The grinding wheels may have been damaged during transport.
Let the bench grinder run empty for approximately five minutes.
 “Individual protection gear“ on page 9. Use the prescribed protection equipment.

© 2004
GB
Page 16 Bench grinder QSM Version 1.1 29 June 2005
Operating
quantum
MASCHINEN - GERMANY
4 Operating
Only operate the bench grinder when the following conditions have been met:
• The bench grinder is in perfect technical condition.
• The bench grinder is being used only for the intended use.
• The operating manual is being adhered to.
• All safety devices are in place and active.
Immediately remedy failures or have them remedied. Immediately stop the machine as soon as
a failure of the functions occurs and secure the machine against accidental or unauthorised
operation.
Immediately report any change to the responsible person.
4.1 Before beginning work
Before beginning work always check that the piece is free of oil, grease and remains of paint.
This will ensure that the grinding wheels do not become blocked or dirty.
Check the state of the grinding wheels. If they are dirty or muddied, they must be scraped clean
or replaced.
4.2 During work
If necessary, make a first grind of the piece
using the rough grinding wheel and then re-
grind it using the fine wheel.
 “Proper use“ on page 5
Illustr.4-1: Support for workpieces
4.2.1 Workpiece bearing plate
For certain grinding operations, the work-
piece bearing plate can be inclined. Use
the washers to level the difference in alti-
tude.
Please note that the inclination may reduce
the loading absorption of the support for
workpiece bearing plate.
The distance between the grinding wheel
and the workpiece bearing plate must be
as little as possible. Avoid overheating the
bench grinder.
Apply only slight pressure to the piece.
If a wheel has become very dirty, the sur-
face should be scraped with a hand-held
leveller.
Illustr.4-2: inclination bearing area
Respect the environment when disposing of grinding wheels.
Support for tools
washers
counter bearing work-
piece bearing plate
workpiece bearing plate
clamping

© 2004
GB
Page 1729 June 2005 Version 1.1 QSM Bench grinder
Maintenance quantum
MASCHINEN - GERMANY
5 Maintenance
In this chapter you will find important information about
• Inspection
• Maintenance
• Repairs
of the bench grinder.
ATTENTION !
Properly-performed regular maintenance is an essential prerequisite for
• safe operation,
• fault-free operation,
• long service life of the bench grinder and
• the quality of the products you manufacture.
Installations and equipment from other manufacturers must also be in optimum condition.
5.1 Safety
WARNING!
The consequences of incorrect maintenance and repair work may include:
• Very serious injury to personnel working on the bench grinder
• Damage to the bench grinder
Only qualified personnel should carry out maintenance and repair work on the bench
grinder.
5.1.1 Preparation
WARNING!
Only carry out work on the bench grinder if it has been unplugged from the mains power
supply.
 “Disconnecting the bench grinder and making it safe“ on page 10
5.1.2 Restarting
Before restarting run a safety check.
WARNING!
Before connecting the bench grinder you must check that
• there is no danger for personnel,
• the bench grinder is undamaged.
5.2 Revision and maintenance
The type and extent of wear depends to a large extent on the individual usage and service con-
ditions.
If the bench grinder is used in accordance with the instructions, it is largely maintenance-free.

© 2004
GB
Page 18 Bench grinder QSM Version 1.1 29 June 2005
Maintenance
quantum
MASCHINEN - GERMANY
5.2.1 Changing the grinding wheels
The grinding wheel must be replaced whenever the distance between the external diameter of
the wheel and the edge of the grinding wheel cover is greater than 6 mm.
WARNING!
Before assembly check the grinding wheels for damage and cracks.
If this type of defect is observed in a new grinding wheel, it must not be installed under
any circumstances.
You can check for small defects in the grinding wheel by removing it and knocking it gently. A
low-pitched sound can be heard in damaged wheels.
 “Disconnecting the bench grinder and
making it safe“ on page 10
Make sure the bench grinder cannot be
connected without authorisation.
Loosen the three securing screws of the
protective cover.
Illustr.5-1: Protective cover
Loosen the nut on the shaft and remove
the securing disc.
Remove the grinding wheel from the
drive shaft.
Illustr.5-2: Shaft nut
Make sure that the counter-disc is cor-
rectly positioned on the shaft.
Place the new wheel on the shaft and
secure it using the securing disc and the
shaft nut.
Illustr.5-3: Drive shaft
ATTENTION!
Tighten the shaft nut only by hand.
Fit the protective cover and re-adjust the protective cover.
Check the adjustment and position of the transparent spark-guard and the tool-support.
Securing screws
Securing disc
Shaft nut
Protective cover for
adjusting device
Counter-Disc
Drive shaft

© 2004
GB
Page 1929 June 2005 Version 1.1 QSM Bench grinder
Maintenance quantum
MASCHINEN - GERMANY
5.3 Repair
Ask Optimum Maschinen GmbH's technical service to send a technician to perform any repair or
send us the bench grinder.
If the repairs are carried out by qualified technical staff, they must follow the indications given in
this manual.
Optimum Maschinen GmbH does not take responsibility nor does it guarantee against damage
and operating anomalies resulting from failure to observe this instruction manual.
For repairs, only use
• faultless and appropriate tools,
• original spare parts or parts from series expressly authorised by Optimum Maschinen GmbH.
5.4 Optional accessories
We recommend that you only use original high-quality accessories from Optimum Maschinen
GmbH. Only by using these original accessories can perfect operation and optimum results be
ensured.
Name Reference
Wall support 310 7050
Infrastructure 310 7100
Normal thick corundum grinding wheel G 36
Ø 150x20x Ø16 mm 310 7150
Ø 175x20x Ø32 mm 310 7170
Ø 200x25x Ø32 mm 310 7200
Normal fine corundum grinding wheel G 80
Ø 150x20x Ø16 mm 310 7155
Ø 175x20x Ø32 mm 310 7175
Ø 200x25x Ø32 mm 310 7205

© 2004
GB
Page 20 Bench grinder QSM Version 1.1 29 June 2005
quantum
MASCHINEN - GERMANY
5.5 Exploded view
Illustr.5-4: Exploded view
