Quasar SQ4044 User manual

29

2

Instructions
3

EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE
ANTENNALEADIN WIRE
ANTENNA
DISCHAGRE UNIT
(NEC SECTIO N 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250,RARTH)
GROUND
CLAMP
ELEC TRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
27) Explanation of symbol, marking, signal lamp or similar means indicate that apparatus
is completely disconnected from the mains. This equipment is a Class II or double
insulated electrical appliance. It has been designed in such a way that it does not require a
safety connection to electrical earth.
28) Correct Disposal of this product. This marking indicates that this product should
not be disposed with other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste disposal, recycle it responsibly
to promote the sustainable reuse of material resources. To return your used device, please
use the return and collection systems or contact the retailer where the product was purchased.
26) Where the mains plug is used as the disconnect device, the disconnect device shall
remain readily operable.
Instructions
4

Warning: batteries(pack or batteries installed) should not be exposed to excessive heat
such as sunshine, fire or other heat sources.
Instructions
5

Instructions
6

7
A wall mount kit (purchased separately) would allow you to mount your
Quasar TV on the wall. For detailed information on installing the wall mount,
refer to the instructions provided by the wall mount manufacturer. It is
strongly recommended to contact a technician for professional assistance
for wall mount installation. Quasar is not responsible for any damage to the
product or injury to yourself or others resulting from the wall-mounting.
Instruction for Wall Mount
This TV is compatible with a 200mm x 100mm mounting hole pattern.
4 pcs of type M6 screws are required for installing the wall mount bracket
to your TV. Do not use screws that are longer than 10 mm. Screws that are
too long may cause damage to the inside of the TV set.
Do not fasten the screws too tight for this may damage the TV or cause the
TV to fall, resulting in personal injury. Quasar is not liable for these kinds
of incidents.
Do not mount your TV at more than a 15 degree tilt.
Always use two people to mount the TV to a wall.
Do not install your Wall Mount Kit while your TV is turned on. It may result
in personal injury due to electric shock.

TABLE OF CONTENTS
Instructions
8
2
Logos & Licenses
3
9
10
11
12
12
13
15
16
18
20
21
22
25
27
27
28
29
30
Picture Menu
31
34
35
36
33
Media
Media

Logos & Licenses
9

TV Buttons and Connections
TV Buttons
:Turn ON/OFF Power.
SOURCE:External Signal Input Selection.
MENU:Display Main MENU And Confirm MENU Item Selection.
CH+/-:Select Channel.
VOL+/-:Adjust Volume.
Connections
HDMI(1-3) Input
Connect to a HDMI output
connection on your external device.
ANT 75/RF Connection
Connect to the antenna/cable TV
output of your device or wall plate.
VGA Input
Connect to your PC using a VGA
cable(not provided).
PC Audio Input
Connect to your PC Audio Out
using 1/8 line cord.
HEADPHONE JACK
Plug earphones into jack for private
listening. Overrides speakers.
Output
Audio Out Right/Left
Connect to your external device.
OPTICAL
Digital Audio Output.
OPTICAL
OUTPUT
RL
HDMI
HEADPHONE
USB
INPUT
RL
Input
Audio in Right/Left
Connect to your external device.
VIDEO/Y
Pb Pr
Component Input / Video Input
Connect to a component or AV
output connection on your
external device.
10
USB Input
Connect to your USB device.
AC 120V~ 60Hz
VIDEO/Y
Pb Pr
OUTPUT
HEADPHONE
OPTICAL
Side Terminal
Down Terminal

VIDEO/Y Pb Pr
RL
11
Component (Y,Pb,Pr) input connection
VIDEO/Y Pb Pr
RL
5V 0.5A

13

14

15

/ Power saving
Power saving Produces a lower power consumption mode.
16
