Questtel 1B-SDI-PTGM2-HD User manual

3G-HD/SD SDI Monitor
User Manual

Safety and Notice
The 1B-SDI-PTGM2 3G-HD/SD SDI Monitor has been tested for conformance to safety regulations
and requirements, and has been certified for international use. However, like all electronic equipments,1B-SDI-
PTGM2 should be used with care. Please read and follow the safety instructions to protect yourself from
possible injury and to minimize the risk of damage to the unit.
Follow all instructions and warnings marked on this unit.
Do not attempt to service this unit yourself, except where explained in this manual.
Provide proper ventilation and air circulation and do not use near water.
Keep objects that might damage the device and assure that the placement of this unit is on a stable surface.
Use only the power adapter, power cords and connection cables designed for this unit.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before
cleaning.

~ 1 ~
The 1B-SDI-PTGM2 3G-HD/SD SDI Monitor offers the highest compatibility among SDI, including 3G/HD/
SD formats. This device also supports composite (NTSC/PAL) input through the same input. With the embedded
advanced de-interlacer, interlaced video inputs, such as SD-SDI or composite, can be further improved. For SDI,
1B-SDI-PTGM2 can display support up to 8 channel audio bars to indicate the embedded digital audio channel in
SDI stream and make 1B-SDI-PTGM2 a perfect mini monitor to watch closely on SDI signal quality.
1B-SDI-PTGM2 is especially designed to ease the SDI security monitoring with affordable cost. With 1B-
SDI-PTGM2, SDI will not become a bottleneck in your advanced SDI applications, such as SDI video editing and
HD surveillance system. The handy SDI monitoring includesCRC status, SMTPE 352M indicator, audio bars, EDH,
video format detection, and Sync status etc. With versatile IR remote control and push buttons, 1B-SDI-PTGM2
offers a very easy way to control the display layout and status demonstration.
Features
SD/HD/3G SDI compliant
Up to 8 SDI channel audio bar display
Built-in advanced scaler to scale up and down the input to fit on screen
Advanced video processing supports: noise reduction, color management, fleshtone control, dynamic
contrast control, closed caption support for CVBS, 3-D de-interlacing, 3:2/2:2 pull down detection and
recovery.
RS-232 Firmware upgradable to guarantee the functionality revised.
Supports two up to 3G SDI loop-outs
Versatile IR control
Push button control
Wall-mounting ear for easy installation
Introduction

~ 2 ~
Specifications & Package Contents
Model Name
1B-SDI-PTGM2
Technical
LCD size & resolution
5.7”& 640x480
LCD color depth
18 bit RGB
Composite bandwidth
13.5MHz
Audio support
Up to 8 CH decoding and audio bar display
SDI Support
SD/HD/3G
Input
1 x SDI [CVBS]
Output
2x SDI [Loopout]
Audio FS support
48KHz
ESD protection
[1] Human body model —±19kV [air-gap discharge] & ±12kV [contact discharge]
[2] Core chipset —±2kV
PCB stack-up
6-layer board [impedance control —differential 100; single 50]
IR remote control
Electro-optical characteristics: = 25/ Carrier frequency: 38kHz
HDMI connector
HDMI type A
RS-232 connector
DE-9 [9-pin D-sub female]
BNC connector
75inter-locked socket
DIP switch
Restore default
Mechanical
Housing
Metal enclosure
Dimensions
[L x W x H]
Model
172 x 148 x 46mm [6.8”x 5.8”x 1.8”]
Package
200 x 325 x 93 mm [7.9”x 12.8”x 3.7”]
Carton
495 x 440 x 380mm [1’7”x 1’5” x 1’3”]
Weight
Model
1000g [2.2 lbs]
Package
1800g [3.9 lbs]
Fixedness
Wall-mounting case with screws
Power supply
Interlocked 5V 4A DC
Power consumption
10 Watts [max]
Operation temperature
0~40C [32~104F]
Storage temperature
-20~60C [-4~140F]
Relative humidity
20~90% RH [no condensation]
Package Contents
1x 1B-SDI-PTGM2
1x 5V 4A interlocked power adapter
1x User Manual
1x IR Remote Control
2x 75 ohm terminator
1x RCA to BNC connector

~ 3 ~
The buttons not listed above are not in use for this model.
IR Remote Control
Idle
Menu
Control Buttons
Sleep ON
Freeze Video
Exit OSD
Menu On
Source: No use in this model
Info: Display input type and time
Auto: No use in this model
C.C.: No use in this model
HDMI: No use in this model
Aspect: Aspect ratio change
TV:No use in this model
CV1:CVBS
CV2:No use in this model
YUV1:No use in this model
YUV2: No use in this model
SV1: No use in this model
SV2: No use in this model
VGA: No use in this model
DV1:SDI
F1:No use in this model
F2:Input timing information
F3:Auto color balance

~ 4 ~
Front Panel
1. DIO: Reserved.
2. Dip Switch: Mode setting
3. RS-232: Serial control
Rear Panel
4. SDI BNC loop-out connectors: SDI loop outs
5. SDI BNC input connector: Input SDI/CVBS
6. Power LED: Indicate power up and signal lock
7. HDMI: HDMI loop out
8. 5V DC power jack
Panel Descriptions

~ 5 ~
Top Panel Buttons
9. IR: Remote control
10. Menu: OSD Menu
11. Down/Left: OSD up or left operations
12. Up/Right: OSD down or right operations
13. Enter/Mode: OSD selection or zoom/pan
14. INC+: Zoom in or move the center of zoomed
video to left or up
15. DEC-: Zoom out or move the center of zoomed
video to right or down
16. Display: Display mode selection
17. Status: SDI status indicator
18. Source: SDI/CVBS selection
19. Reset: Reset error flags of SDI status indicator
Bottom DIP Switch
Switch Position
-
-
Input 1
Normal
Reset
Input 2
Normal
Reset
Connect your SDI/CVBS video sources to the input connectors.
1. Connect your HDMI enabled monitors into the device’s HDMI output port.
2. Power up the 1B-SDI-PTGM2.
Hardware Installation

~ 6 ~
1. Power up the 1B-SDI-PTGM2.
2. To reset 1B-SDI-PTGM2 back to the factory default values, pull up-and-down the DIP switch 1&2 from OFF to
ON to complete the process. You NEED to pull back the DIP switch back to OFF in order to get 1B-SDI-
PTGM2 work normally.
Software Interface:
Default Setting
Firmware Update Pr
ocedure
ComPort Settings:
Select ComPort of PC connected
to the device. Push “auto scan”to
start the automatic scan on each
ComPort.
1024 bytes as the default.
Please check all the power and serial port
connection to avoid any further
unexpected damages during firmware
update. Check “Agree”to enable the
firmware update procedure.
Execute firmware update.
Baud Rate is default as 115200.

~ 7 ~
Window Messages
The connection is not correct. Please check:
Power
Cable
Baud Rate
The whole firmware update procedure fails. Please check
Power
Cable
Baud Rate
The firmware update procedure requires a power cycle.
Please turn off the device, wait for a couple of seconds, and power on
the device.
Congratulations. The whole process is successfully completed!

~ 8 ~
[SDI-IN] Socket
Supported Mode
Resolution
(SDTV) 625i
625i @50Hz
(SDTV) 525i
525i @59.94Hz
(HDTV) 720p
1280x720 @50Hz
(HDTV) 720p
1280x720 @59.94Hz
(HDTV) 720p
1280x720 @60Hz
(HDTV) 1080i
1920x540 @50Hz
(HDTV) 1080i
[email protected]Hz
(HDTV) 1080i
1920x540 @60Hz
(HDTV) 1080p
1920x1080 @25Hz
(HDTV) 1080p
1920x1080 @30Hz
(3G) 1080p
1920x1080 @50Hz
(3G) 1080p
1920x1080 @59.94Hz
(3G) 1080p
1920x1080 @60Hz
Appendix –Supported Resolution
