User Manual
for Quictent Party Tent
Please read, understand, and practice this user manual before use, and keep
it for future reference.
13' x 26'
20' x 32'
16' x 32'
20' x 40'
20' x 20'

Tableof Contents
About Quictent
...........................................................................
2
.............................................
26
20' x 32' Party Tent (Model #GM1412W)
...........................
32
20' x 40' Party Tent (Model #GM1413W &#GM1421WB)
.......................................................................
3
Safety Instructions
.............................................
6
13' x 26' Party Tent (Model #GM1404W)
.............................................
20
20' x 20' Party Tent (Model #GM1409W)
...........................
10
16' x 32' Party Tent (Model #GM1408W &#GM1416W)
1
..............................................................................
Maintenance 44
..................................................................................
45
Appendix
..................................................................................
44
Warranty

About Quictent
IMPORTANT
We’d love to hear from our customers. If you have any questions about the manual, have any comments or
suggestions about our products and our services, or would like us to help in any way, please feel free to contact
the support team. We will reply in 12 hours (business days).
Our Vision
Creating unique spaces to meet every specific need, and become a part of America's landscape.
Our Mission
To keep innovating and provide a wide range of reliable shelters and shades at consumer-grade prices with
customer-first service.
Check the Spam and your email Settings if you do not receive a reply in time as it is probably blocked because
our support team will always get back to you no later than the timeframe.
Add the following email address to your CONTACT LIST in case of any blocking.
Email: [email protected], [email protected].
This user manual applies to Quictent party tents in 13' x 26', 16' x 32', 20' x 20', 20' x 32', and 20' x 40'. It will help you to
get to know your Quictent party tent. Please read the guidelines in this manual and keep the manual for future reference.
We may update the manual without notice in advance. You can always search “Quictent Instructions” online for the
latest version.
About QuictentAbout Quictent
Founded in the early 21st century, Quictent has grown into a popular brand with reliable products and excellent
customer services during the past decades. We started with pop up canopies, and then expanded to other 6 categories
for shelters and the like including party tents, carports, greenhouses, shade sails, patio umbrellas and grow tents.
Driven by the vision to create unique spaces to meet every specific need and become a part of America's landscape,
we at Quictent would spare no effort to keep innovating.
About Quictent
2222

2
Our Service
The customer-centric services are what we at Quictent take great pride in. In addition to the hassle-free warranty
covering all Quictent products, an industrial-leading support team is standing behind at all times. Whenever you need
help or have any suggestions and comments about our products, do not hesitate to reach us via [email protected]
or [email protected]. You’re sure to get a to-the-point reply in 12 hours.
Do NOT insert the Auger Anchors
vertically. Always form an angle
with the ground as shown.
Do NOT leave a tent unattended
overnight.
Do NOT light a fire inside the party
tents and keep any heat source
away from your tent.
Do NOT throw away the original
packaging cartons in case of a
return or an exchange.
You can ALWAYS contact the
support team for replacement
parts whenever in need.
Do NOT leave a tent outdoors too
long as it’s designed to be used as a
temporary structure.
45°
90°
Safety Instructions
You should read, understand, and practice safety instructions in this chapter. For any damages due to not obeying
guidelines as instructed, the owner (user) should take full responsibility.
223

4
Reminder
Do not use and leave the structure outside in inclement weather. The owner (or user) should take down the structure
for any potential inclement weather, including high winds, heavy rain, sleet, snow, and the like, or he (she) should take
the loss.
IMPORTANT
Please disassemble your tents and put all the parts in the Carry Bags whenever you
need to transport or store your tent.

5
Warning
Order number
√
Required parts (name, quantity, and parts number)
√
Any photos (or video clips, if applicable) to help us understand your concerns would be greatly appreciated.
√
Stop using the party tent immediately if any damage is found, or Quictent will not be liable for any loss thereafter
Please do NOT place heavy objects on top of a Quictent party tent, or leave it outside overnight because it’s
designed to be used as a temporary structure.
You can find the Parts List and the Assembly steps for Quictent party tents in 13’ x 26’, 16’ x 32’, 20’ x 20’, 20’ x 32’,
and 20’ x 40. Please check the shipping cartons and the parts inside accordingly upon arrival. If you have any ques-
tions, please email [email protected] or [email protected] to get in touch with our customer support team,
we will reply to your queries within 12 hours (business days). By the way, if you’re requiring replacement parts, please
include the following information in your message so that we can take action as soon as possible:
IMPORTANT! Please disassemble your tents and put all the parts in the Carry Bags whenever you need to transport
or store them.

6
13' x 26' (Model #GM1404W)
Parts List
There is only one model (Model #GM1404W) for this size. You’ll receive three (3) boxes for an order. Please check to
identify the packages by referring to Table B below. Pay particular attention to making sure all parts are numbered and
graphically indexed as shown on the Parts List (Table A), so does the quantity for each part. If you need any help,
please contact us promptly ([email protected] or [email protected]) with the order number, required parts
(name, quantity, and part number), and photos (or video clips, if applicable), we will get back to you within 12 hours
to help out.
#1
#2
#5
#3
#4
Part Number DescriptionDiagram
4
4
5 5
5 5 5
5
55 5
44
2222
22
3
3
33
3 3
3
3 3
3
22
1 1 1 1 1 11111
2222 4
4
Quantity
(PCS)
Table A. Parts List
Steel Pipe
Steel Pipe with Adjusting Holes
3-Way Corner Connector
4-Way Corner Connector
Steel Pipe 10
12
10
6
9
#A Short L-Shaped Peg (4 x 180 mm)
Short L-Shaped Peg (6 x 180 mm)
38
#B 10

5
7
#C
#F
#D
#E
Part Number DescriptionDiagram Quantity
(PCS)
Guy Rope
Roof Cover
Sidewall with Window
Zipper Door
4
1
8
2
#G Bungee Cord 52
#I Carry Bag 3
#H Auger Anchor 4
Carton Number Parts Included
Table B. Package Contents for Shipping Cartons
Box #1
Box #2
Box #3
1 x Part #D (Roof Cover)
8 x Part #E (Sidewall with Window)
2 x Part #F (Zipper Door)
1 x Part #I (Carry Bag)
All the Other Accessories not Mentioned in this Table
10 x Part #1 (Steel Pole)
6 x Part #2 (Steel Pole)
1 x Part #I (Carry Bag)
6 x Part #2 (Steel Pole)
10 x Part #3 (Steel Pole)
1 x Part #I (Carry Bag)

8
Assembly
Before the assembly, please check to make sure that you have all the parts listed on the Parts Lists.
Step 1
Step 2 Tighten the Roof Cover (#D) with the assembled top frame with Bungee Cords (#G).
Layout the top frame with poles of (10 x part #1 &12 x part #2) and connectors of (6 x #4 &9 x # 5).
1
2
Step 3 Assemble the 10 x poles (#3) by connecting the end without
adjusting holes into the connectors (#4 &#5) on the top. There
are 2 reminders:
Please tighten/loosen the leg cover by placing the hooks into different adjusting holes.
Please secure the structure by inserting all the Long L-Shaped Pegs (#B) into the holes on the bottom of
the top cover.
1 1 1 1 1
1 1 1 1 1
22
4 5 5 5
5 5 5
5 5 5
4
4
4
4
4
2 2
2 2 2 2
2 2 2 2

9
Step 4 Attach the 8 x Sidewalls with Window (#E) and the 2 x Zipper Doors (#F) as instructed below.
Firstly, you need to fix all the sides and doors to the top frame with the Bungee Cords (#G).
Fix the bottom of all the window sidewalls to the ground with all the 4x180 L-Shaped Pegs (#A). After fixing
the window sides to the ground, please fix thte sides to the poles by wrapping up the built-in velcros.
Please fix the structure to the ground with the 4 x Guy Ropes (#C) and the 4 x Auger Anchors (#H). When
inserting the Auger Anchors, we highly recommend you form an angle with the ground (best at the
45-degree).
3
33
3
a)
b)
c)
4
Long L-Shaped Peg
Auger Anchor
Short L-Shaped Peg
4x180mm

There are 2 models (Model #GM1408W & #GM1416W) for this size.
Please pay particular attention to making sure all parts are numbered and graphically indexed as shown on the Parts
List (Table A.1 &Table A.2), so does the quantity for each part. Please also check to identify the packages by referring
to (Table B.1 &Table B.2) below. If you need any help, please contact us promptly ([email protected] or
[email protected]) with the order number, required parts (name, quantity, and part number), and photos (or
video clips, if applicable), we will get back to you within 12 hours to help out.
Model #GM1408W has a frame made of powder-coated poles and a white roof cover.
Model #GM1416W is made of galvanized poles and has a blue-striped roof cover.
10
16' x 32' (Model #GM1408W & #GM1416W)
Parts List for Model #GM1408W
#1
#2
Part Number DescriptionDiagram Quantity
(PCS)
Table A.1 Parts List for Model #GM1408
Steel Pole
Steel Pole 12
12

Top 3-Way Corner Connector 2
Top 4-Way Corner Connector 4
L-Shaped Foot Base (2-Corner) 4
Steel Pole 25
#7
#8
#11
#9
#10
Long L-Shaped Peg
(6 x 180 mm)
Short L-Shaped Peg
(4 x 180 mm)
Auger Anchor
Hook
Guy Rope
Roof Cover
Sidewall with Window
Zipper Door
Bungee Cord 98
46
12
4
4
#A
#B
#D
#C
#E
#F
#H
#G
#I
#J Carry Bag
12
1
10
2
4
T-Shaped Foot Base (3-Corner) 8
11
#4
#3
Part Number DescriptionDiagram Quantity
(PCS)
Steel Pole with Adjusting Holes
4-Way Corner Connector
Metal Clip (M6*50) 24
3-Way Corner Connector 4
12
8
#5
#6

5
12
Part Number Parts Included
Table B.1 Package Contents for Shipping Cartons
Box #1
Box #2
Box #3
1 x Part #G (Roof Cover)
2 x Part #I (Zipper Door)
10 x Par #H (Sidewall with Window)
1 x Part #J (Carry Bag)
4 x Part #1 (Steel Pole)
1 x Part #J (Carry Bag)
All Connectors & Other Accessories not Mentioned in this Table
2 x Part #1 (Steel Pole)
25 x Part #11 (Steel Pole)
1 x Part #J (Carry Bag)
Box #4
6 x Part #1 (Steel Pole)
12 x Part #2 (Steel Pole)
12 x Part #3 (Steel Pole)
1 x Part #J (Carry Bag)
Assembly Steps for Model #1408W
Step 1 Assemble the top frame with poles of 12 x #1, 12 x #2, 15 x #11 and connectors of 4 x #5, 8 x #6, 2 x #7, 4 x #8.
You should also reinforce the joints of the poles (#1 &#2) with the 24 x Metal Clips (#4).
1
1111 1 1
444444
4
2
44444
1 1
2
11 1
222
1
2
11
11 66 6
6 6 6
8 8 8 8
7
5
55
7
5
11 6 11 11
11 11 11 11
22222 2
11
11 11 11 6
11 11

13
2
Step 3 Connect the 6 x poles (#3) (the end WITHOUT the adjusting holes) with the connectors (#5 &#6) on the top
frame, then lift the structure from the other side (SEVERAL ADULTS REQUIRED!).
Step 2 Tighten the Roof Cover (#G) with the assembled top frame with Bungee Cords (A).
Step 4 Finish assembling the whole mainframe by:
Connecting the left 6 x poles (#3) with the connectors (#5 &#6) on the top frame.
Connecting the 12 x Hooks (#F) into the leg cover, then tightening/loosening the leg cover by placing the
hooks into a proper adjusting hole (on the poles #3).
Connecting the rest 10 x poles (#11) with the poles (#3) on the ground by using the foot bases of (4 x #10
&8 x #9).
Securing the poles (#3) by inserting the 12 x Long L-Shaped Pegs (#C) into the holes of the foot
bases (#9).
3
a)
b)
c)
d)
3 3 3 33 3

14
Step 5 Attach the 10 x Sidewalls with Window (#H) and the 2 x Zipper Doors (#I) as instructed below.
Firstly, you need to fix all the sides and doors to the top frame with the Bungee Cords (#A).
After fixing the window sides to the ground with the Short L-Shaped Pegs (#B), please also fix them to the
poles by wrapping up the built-in velcros.
Finally, please fix the structure to the ground with the 4 x Guy Ropes (#E) and the 4 x Auger Anchors (#D).
To secure the tent better, it is recommended that you insert the Auger Anchors diagonally into the ground.
As shown, a 45-degree to the ground is the best position.
a)
b)
c)
11 11 11 11 11
11 11 11 11 11
6x180
mm
Long L-Shaped Peg
5
Auger Anchor Short L-Shaped Peg
4x180mm
4

15
#1
#2
Part Number DescriptionDiagram Quantity
(PCS)
Table A.2 Parts List for Model #GM1416W
Steel Pole
Steel Pole 12
12
Parts List for Model #GM1416W
4 4
Top 3-Way Corner Connector 2
Top 4-Way Corner Connector 4
L-Shaped Foot Base (2-Corner) 4
Steel Pole 25
#7
#8
#11
#9
#10
Supporting Pole 12
#12
T-Shaped Foot Base (3-Corner) 8
#4
#3 Steel Pole with Adjusting Holes
4-Way Corner Connector
Metal Clip (M6*50) 12
3-Way Corner Connector 4
12
8
#5
#6
13
12
12
BRAKET TO HOLD
PIPE 12

16
Part Number Parts Included
Table B. 2 Package Contents for Shipping Cartons
Box #1
Box #2
Box #3
1 x Part #J (Roof Cover)
2 x Part #L (Zipper Door)
10 x Part #K (Sidewall with Window)
All connectors &Other Accessories not Mentioned in this Table
12 x Part #1 (Steel Pole)
9 x Part #3 (Steel Pole)
12 x Part #12 (Steel Pole)
6 x Part #13 (Steel Pole)
Long L-Shaped Peg
(4 x 180 mm)
Bungee Cord
U-Shaped Peg
Guy Rope
Auger Anchor
Hook
Long Screw with Nut (M6*50)
Screw with Nut (M6*30)
98
46
10
4
#A
Vertical Supporting Pole 6
#13
#C
#B
#D
#E
#G
#F
#H
#I Pole Holder
4
12
24
24
12
#J Roof Cover 1
#K Sidewall with Window 10
#L Zipper Door 2
Part Number DescriptionDiagram Quantity
(PCS)

17
Assembly Steps for Model #1416W
Step 1 Assemble the top frame with poles of 12 x #1, 12 x #2, 15 x #11 and connectors of 4 x #5, 8 x #6, 2 x #7, 4 x #8.
You should also reinforce the joints of the poles (#1 & #2) with the 12 x Metal Clips (#4).
A
1
1111 1 1
444444
4
2
44444
1 1
2
11 1
222
1
2
11
11 66 6
6 6 6
8 8 8 8
7
5
55
7
5
11 6 11 11
11 11 11 11
22222 2
11
11 11 11 6
11 11
Step 2 Reinforce the top frame with 12 x Supporting Poles (#12) and 6 x Vertical Supporting Poles (#13). You'll
use all the 24 x Screws with Nut (M6*30, #H) and 12 x Pole Holders (#I) in this step.
Part Number Parts Included
Box #4
Box #5
12 x Part #2 (Steel Pole)
3 x Part #3 (Steel Pole)
5 x Part #11 (Steel Pole)
20 x Part #11 (Steel Pole)
2
44 4 4
5
2
1
7
118
5
11
12 12
13

3 3 3 3 33
Step 5 Finish assembling the whole mainframe by:
Connecting the left 6 x poles (#3) with the connectors (#5 &#6) on the other side.
Connecting the 12 x Hooks (#F) with the leg cover, then tightening/loosening the leg cover by placing the
hooks into a proper adjusting hole (on the poles #3).
Connecting the rest 10 x poles (#11) with the poles (#3) on the ground by using the foot bases of (4 x #10
&8 x #9).
Securing the poles (#3) by inserting the L-Shaped Pegs (#B) into the holes of the foot bases (#9 &#10).
a)
b)
c)
d)
Step 3 Tighten the Roof Cover (#J) with the assembled top frame with Bungee Cords (A).
3
Step 4 Connect the 6 x poles (#3) (the end WITHOUT the adjusting holes) with the connectors (#5 &#6) on the
top frame, then lift the structure from the other side (SEVERAL ADULTS REQUIRED!).
4
18

5
Auger Anchor U-Type Peg
11 11 11 11 11
11 11 11 11 11
4x180
mm
5
19
Step 6 Attach the 10 x Sidewalls with Window (#K) and the 2 x Zipper Doors (#L) as instructed below.
Firstly, you need to fix all the sides and doors to the top frame with the Bungee Cords (#A).
Please fix the sidewalls to the poles by wrapping up the built-in velcros, then secure the poles (#11) with
the 10 x U-Shaped Pegs (#B).
Finally, please fix the structure to the ground with the 4 x Guy Ropes (#E) and the 4 x Auger Anchors (#D).
To secure the tent better, it is recommended that you insert the Auger Anchors diagonally into the ground.
As shown, a 45-degree to the ground is the best position.
a)
b)
c)
