QUIK CORP QUIKSPRAY QR400 UTV SYSTEM User manual

QUALITY • PERFORMANCE • RELIABILITY •SERVICE
37 Production Avenue
Warana, QLD 4575
[email protected]
www.quikspray.com.au
T
F
07 5493 8944
07 5493 8957
A
U
S
T
R
A
L
I
A
N
M
A
D
E
A
U
S
T
R
A
L
I
A
N
O
W
N
E
D
QUIK SPRAY
INSTRUCTION MANUAL
12VOLT • 400L
QR400
UTV SYSTEM

QR400 Manual
1
20 years of partnership with Bertolini Pumps has allowed us to use of the highest quality
pumps on the market. This guarantees optimum performance from your spray unit, first time,
every time.
BERTOLINI PUMPS
Every engine that sports the ‘Green and Gold Approved’Honda symbol has been “matched”
specifically to its product to make sure it’s the right Honda engine for the job. The Honda
motors pack a punch and are designed to work hard from day one, so we’ve made sure it’s
the right Honda engine for each Quik Spray model.
POWERED BY HONDA
Our Quik Spray units are radio controlled by a hand-held transmitter. Our advanced radio
technology gives you superior, independent radio range, without interference between
operators. Over 30 years in the business means we have weeded out the inferior
technologies used by others. Beware of out-dated technology. Comes with 5-year full
comprehensive warranty on the RCM module (radio transmitters and radio control box).
REMOTE CONTROLLED TRANSMITTERS
KEY FEATURES
SUPA-SLIP HOSE
Quik Spray’s own Supa-Slip® Hose is a high grade Nylon which is a polyamide bio plastic
derived from vegetable oil which offers advanced performance and strength as opposed to
the lower grade of Nylons commonly used.
The Quik Spray hose has higher operating pressures and tensile strength. It is also more
resistant to cold and hot extremes. The additives in the hose mean it is less likely to kink or
stretch giving it a longer life cycle.
IMPORTANT

QR400 Manual 2
IMPORTANT

WARNING
READ THIS INSTRUCTION MANUAL
CAREFULLY BEFORE ATTEMPTING TO
OPERATE THIS UNIT
No part of this manual may be reproduced without written permission
from QUIK CORP PTY LTD. All information contained in this manual is
based on the latest product information available at the time of printing.
This manual should be considered a permanent part of your Quik Spray
spraying system and should remain with it at all times for technical
reference. Information given in this manual will provide the operator with
the safest and most effective use of this machine. The machine shown in
this manual may differ slightly from your machine, but should be similar
enough to help you understand our instructions.

WARNING
Not maintaining this unit or failing to correct a problem before operating
could cause a malfunction in which serious damage to the unit or serious
personal injury could occur.
Always perform a pre-operation inspection before each operation and to
identify and correct any problems.
The right is reserved to make changes at any time without notice. COPYRIGHT © 2019 Quik Corp Pty Ltd All rights reserved. Previous editions.

QR400 Manual
3
WELCOME TO QUIK SPRAY
On behalf of the Quik Spray team, we would like to thank you for investing in a quality Quik Spray product. Our units are
manufactured to the highest standard of quality, with every individual unit hand-assembled to guarantee our customers the best
product and service possible. As an Australian owned business your investment has enabled our every success.
As a division of Quik Corp, our team have provided over three decades of high-quality agricultural products to the Australian
market. From our humble beginnings in 1988, our product range has continually expanded and our innovation sparks from the
passion and commitment we have for the agricultural industry.
All Quik Spray units are fabricated and hand-assembled right here in
Warana, Queensland. We control all aspects of the fabrication and
assembly process, ensuring you get the highest quality product. We are
extremely proud and dedicated to providing jobs to local employees in the
local manufacturing sector.
Producing the world’s first remote controlled retractable hose reel system in 1988, Quik Spray is the preferred choice of spray
units for farmers, councils, contractors and nurseries.
With innovation, valuable expertise and the most dedicated service, we produce superior equipement suited to the harsh
Australian environment. After 30 years, we know what it takes to make the most trusted sprayer on the market.

QR400 Manual 4
TABLE OF CONTENTS
05 Pre-operation checklist
06 Unpacking your unit
07 Product range overview - QR400 system
09 Product range overview - QR reel
11 Mounting instructions
12 Connecting power supply
13 Radio transmitter & receiver
15 Operation instructions
19 Trouble shooting
21 Machine specifications
23 Parts diagrams
27 Warranty

QR400 Manual
5

WARNING
PLEASE FOLLOW ALL WARNINGS AS FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY, PERMANENT
INJURY OR DEATH
1. DO NOT start the unit until you have read this manual carefully.
2. DO NOT let any person near the unit while it is operating.
3. DO NOT start motor with pressure lever in the “press position”
4. DO NOT pull the hose out too fast as the reel may run on, causing the hose to become entangled.
5. DO NOT alter the equipment in any manner. If repairs are necessary use only genuine factory repair parts.
6. DO NOT leave the unit running unattended at any time.
7. DO NOT operate the unit if there are any leaks from hoses, fittings ect. Fluids which are under high pressure can
penetrate the skin.
8. DO NOT operate near power lines, as contact could result in electrocution.
9. DO NOT refuel the engine until it has stopped and, if any fuel is spilled, make sure the area is dry before starting
the engine.
Prior to operating your spray system, please read the following
instructions carefully.
1. Check all spray guns are connected and water tight.
2. Ensure the water tank is filled.
3. Ensure there is fuel in the motor (unleaded).
4. Ensure the correct oil level in pump (pump manual).
5. Ensure the correct oil level in motor (motor manual).
6. Ensure the controller 2-way ball valves in the off position.
7. Ensure the pressure lever is in bypass position.
8. Ensure all safety guards and shields are in place.
9. Ensure all nuts, bolts, and screws are in place and tight.
10. Ensure the radio on/off switch in the off position.
11. Make sure that the unit is in an open space (exhaust gas
is poisonous).
12. All maintenance schedules have been completed.
13. Start engine (see engine manual).
14. Adjust engine revs to approximately 2400 rpm or ¾ revs.
PRE-OPERATION CHECKLIST

QR400 Manual 6
UNPACKING YOUR UNIT
When unpacking your new Quik Spray unit, please
check it thoroughly for any transport damage that may
have occured during transit. Check that all parts and
accessories that were ordered, have been included.
 Aerial/s
 Transmitter/s
 All accessories as ordered
FIT AERIALS TO MOUNTING BASES

WARNING
DO NOT OVER-TIGHTEN THE AERIAL TO THE AERIAL BASE
Finger tighten and a tiny bit more, is all that the aerials require to be attached properly. Overtightening the aerials can
cause the coax cable to break in the solder cap of the aerial base severing the connection to the aerial. This can result
in a radio range of only 20-40 meters rendering the aerial/s incapable of receiving a signal.

QR400 Manual
7
PRODUCT RANGE OVERVIEW
TWIN REEL SYSTEM - MODEL QR400
QR400 Description
1. Tank lid fill inlet
2. UV stabilised tank
3. Supa-Slip® hose
4. Hose roller guides
5. Karin pressure controller
6. Honda motor
7. Forklift tyne pockets
8. Tank drain
9. Pump filter
1
2
3
5
6
7
8
9
4
4
7

QR400 Manual 8
QR400 Description
1. Aerial for remote retraction
2. Karin pressure controller
3. Tank level sight gauge
4. Safety valve return line
5. Honda motor petrol fill point
6. Honda motor
7. QR50/QR100 12 volt reel
8. Tank drain
9. Gearbox oil sight glass
12
3
4
5
6
7
8
SINGLE REEL SYSTEM - MODEL QR400
9

QR400 Manual
9
PRODUCT RANGE OVERVIEW
QR50 | QR100
QR50 Reel Description
1. T-400 spray gun (additional accessory)
2. 915 MHz antenna aerial
3. 3/8” ID Supa-Slip® hose (50 or 100m options)
4. Hose roller head guide
5. Aerial base
6. Nozzle holder
7. 50A Anderson plug connection - Additional Outlet
8. Resettable circuit breaker
9. ON/OFF power switch for radio recevier and manual
operation
10. 50A Anderson plug connection - Input for 12V
power supply
1
23
4
6
7
89
5
10

QR400 Manual 10
QR50 | QR100
QR50 Reel Interior Description
1. 12V Motor
2. 50A Anderson plug connection. Additional outlet
3. Resettable circuit breaker 30amp
4. Operation switch momentary on/off
5. Feedback suppression diode
6. 915MHz radio receiver
7. Main receiver board power light
8. 915MHz receiver board function power light
9. Radio receiver dip-switch code (This must match the
radio transmitter)
10. Full integrated 915 MHz receiver board with relay and
pre-regulator board
11. 50A Anderson plug connection - Input for 12V power
supply
1
2
3
4
11
5
6
8
7
9
10

QR400 Manual
11
FILTER HOUSING
1. Filter housing and removal nut. The filter housing is
located behind the Honda motor. To clean filter with
water in the tank, turn valve OFF before loosening filter
nut. Ensure O-ring is seated properly before tightening
nut.
MOUNTING YOUR SPRAY UNIT TO YOUR VEHICLE
To mount your QR400 securely, attach the bolt down brackets to the tank using bolts and washers supplied with your unit.
FIGURE 1
At the base of the tank, you will find brass threaded inserts
so you can attach the mounting plate. Measure the holes
where you need to drill into the vehicle tray.
FIGURE 2
NOTE: Washers must be fitted between the bracket and tank
as per this example, when fitting the bracket to the tank.
FIGURE 3
Attach hold down brackets to the tank using the bolts and
washers supplied. Fit securely to tank and vehicle tray.

QR400 Manual 12
To connect your sprayer to a power sounce, you will
need to connect the power supply to your vehicle battery.
Connecting the Anderson Plug from your battery supply
to the Anderson plug on the Hose Reel as shown here will
vary, depending on whether you have a single or twin reel
unit and electric or manual start motor.
CONNECTING POWER SUPPLY FROM YOUR VEHICLE
Single Hose Reel
1. Insert a 50 amp Anderson Plug from the 12v battery into the Power Supply Anderson Plug on the front of the
QR50/QR100 Hose Reel.
Twin Hose Reels
1. Insert a 50 amp Anderson Plug from the 12v battery into the Power Supply Anderson Plug on the front of the
QR50/QR100 Hose Reel.
2. Insert a 50 amp Anderson Plug from the Primary Hose Reel to the Secondary Hose Reel Additional Outlets on
the rear of the QR50/QR100 Hose Reels. ONLY REQUIRED IF UPGRADING FROM A SINGLE HOSE REEL. IF
ORDERED AS A TWIN HOSE REEL THIS CONNECTION HAS ALREADY BEEN INSTALLED.
Single Hose Reel with Electric Start
1. Insert a 50 amp Anderson Plug from the 12v battery into the Power Supply Anderson Plug on the front of the
QR50/QR100 Hose Reel.
2. Insert a 50 amp Anderson Plug from the Electric Starter on the Motor into the Additional Outlet on the rear of the
QR50/QR100 Hose Reel.
Twin Hose Reels with Electric Start
1. Insert a 50 amp Anderson Plug from the 12v battery into the Power Supply Anderson Plug on the front of the
QR50/QR100 Hose Reel.
2. Insert a 50 amp Anderson Plug from the Primary Hose Reel to the Secondary Hose Reel on the rear of the QR50/
QR100 Hose Reel. ONLY REQUIRED IF UPGRADING FROM A SINGLE HOSE REEL. IF ORDERED AS A TWIN
HOSE REEL THIS CONNECTION HAS ALREADY BEEN INSTALLED.
3. Insert a 50 amp Anderson Plug from the Electric Starter on the Motor into the Power Supply Anderson Plug on the
front of the QR50/QR100 Hose Reel.
MANUAL START
ELECTRIC START

QR400 Manual
13
915 MHz
TUNING 915 MHZ TRANSMITTER TO RECEIVER
Your 12 volt reel is delivered pre-tuned from the factory. If
at some point you need a new radio transmitter or receiver
board you will need to follow these instructions to re-tune your
system:
1. In the labelled photo description, there is a set of two dip-
switch codes (blue panel with small white switches). There
is one set on the receiver and one set on the transmitter.
These codes can be moved to either the UP or DOWN
position.
2. Make sure that both the radio receiver dip-switch code
and the radio transmitter dip-switch codes match
exactly to each other. This will enable the remote control
to communicate with the recevier box, controlling the
retraction of your reel.
3. When changing the 9 Volt battery in your radio transmitter
make sure not to bump any of the dip-switch codes. This
would render your remote control feature unusable until
the dip-switch code was put back into its original position.
4. If two or more 915 MHz systems are in use in the near
vicinity make sure that the dip-switch codes from one
system to the other are different. If they are too close in
dip-switch combination radio interference or cancellation
can occur from one unit to another.

CAUTION
The working range of Quik Corp Radio transmitters can be affected by the many factors that typically affect all 915 MHz
and 433 MHz radio Transmissions. These include operating in the vicinity of high tension power lines, buildings and other
obstructions. Interference can also come from other radio transmitters, and certain atmospheric conditions.
A range of 100 meters or more can be achieved under ideal conditions.
1. Radio transmitter.
 Always use a high quality 9 volt battery to power your
radio transmitter. Replace the 9 volt battery at least every 3
months (or more frequently with continual use).
 As the battery voltage reduces, the radio range
effectiveness will reduce accordingly.
1
RADIO TRANSMITTER

QR400 Manual 14
915 MHz RADIO RECEIVER & TRANSMITTER
Radio Receiver Enclosure
1. 915MHz radio receiver
2. Main receiver board power light
3. 915MHz receiver board function power light
4. Radio receiver dip-switch code (This must match the
radio transmitter)
5. Full integrated 915 MHz receiver board with relay
and pre-regulator board
5
1
2
3
4

QR400 Manual
15
OPERATION INSTRUCTIONS
1. Ensure pre-operation checklist has been completed.
2. Turn motor ON (3).
3. Turn FUEL to the ON position.
4. Turn CHOKE ON (1).
5. Adjust the THROTTLE to help the engine start (2).
6. Pull start cord (4) OR if fitted, use the electric start by turning the key to the start position (5).
7. Once engine is running, close CHOKE.
8. Adjust revs on the THROTTLE (Rabbit vs. Turtle icon) to set the desired revs on the motor. 2400 RPM is ideal.
TURNING ON UNIT - MANUAL AND OPTIONAL ELECTRIC START

DANGER - HOT SURFACE
Honda motor exhaust will become hot when in use.

CAUTION
Always run the Honda motor at 2400RPM or 3/4 revs. This is optimal revolutions per minute for the pump and 1amp
charging coil to recharge the 12volt battery.
3
2
1
4
5
MANUAL START ELECTRIC START

QR400 Manual 16
OPERATION INSTRUCTIONS
SET PRESSURE & SPRAY
 When your unit arrives from the factory, the pressure controller is set at BYPASS. The pressure handle will be OUT.
To increase the pressure, you will need to wind the handle IN.
10. With the motor running, switch the controller lever to PRESS (PRESSURE). (Picture shown in BYPASS position)
11. Adjust the handle to set the desired pressure you want to spray with.
CLOCKWISE = To build pressure ANTI-CLOCKWISE = To reduce pressure (Refer indicators on handle)
12. To direct spray/liquid to the reel/s or fire reel, open the 2-way ball valve/s (Pictured in CLOSED positions).
13. Squeeze the trigger on the spray guns to spray.
14. To close down your spray unit, repeat the above steps in reverse order.
10
QUIK TIP
To extend the life of your pressure controller, we recommend releasing the pressure from your spray unit at the end of
operation. This can be done by reducing your pressure controller handle down to ZERO, and then adjusting the handle to
BYPASS. To release the pressure in the unit, CLOSE the ball valve/s to the reel and squeeze the guns to run out any pressure
and liquid from the hoses.
12
12
11

QR400 Manual
17
OPERATION INSTRUCTIONS
1. Turn radio ON/OFF power switch to the ON position.
Assign each operator with a transmitter. If you are using
a twin reel system, be sure that each operator is carrying
the correct transmitter to their corresponding reel.
2. Quik Spray reels will free-wheel out to the desired
distance.
 Do not pull the hose out too fast. This may cause the reel
to ‘run-on’ and become tangled.
3. When the operator is ready to retract the hose, press the
button on the transmitter to retract the hose back onto
the unit reel.
 Be aware of strong retraction! Be prepared to release the
transmitter button when approaching the reel/s as personal
injury or damage to the unit may occur.
4. When operation is complete, turn radio switch to OFF
position to prevent the 12 volt battery from discharging.
5. It is recommended that the 12 volt battery be connected
to an automatic battery charger when not in use.This will
help avoid any damage to the 12 volt battery and help
keep the unit working at peak performance.
TURNING ON TRANSMITTER
USING THE TRANSMITTER TO RETRACT HOSE

CAUTION
Do not pull hose out too fast, as the reel may “run on”, causing the hose to become entangled.
When you are ready to retract the hose, press and hold the transmitter button to retract the hose back to the unit.

CAUTION
Always ensure the hose is in front of the operator.
To operate the transmitter for retraction, the operator must be at least 2-3 meters away from the unit.
Ensure all set-up instructions are complete.
When you are ready to operate the reel, turn the radio switch ON and carry the transmitter with the operator.
The reel will free-wheel out to the desired distance.

QR400 Manual 18
For manual retraction of the reel, use the manual switch.
This unit has been designed to operate in a continuous start/stop mode without damage to the unit. Keep tension on the hose when
rewinding to enable the hose to slip into the low spot on the reel drum.
USING THE MANUAL BUTTON TO RETRACT HOSE

CAUTION
Use the manual button on the radio receiver box to retract any slack hose within 2 meters of the unit.

CAUTION
Be ready to release the radio transmitter button when approaching the reel, as injury may result.
TO FLUSH YOUR QUIK SPRAY
1. After use, flush your unit with Quik Flush Tank/Pump Cleaner according to the directions on the bottle. This will ensure your
unit is cleaned and lubricated to extend the life of the tank, pump, hoses, diaphragms, o-rings and seals.
2. Rinse tank with clean water through the guns until foaming reduces.
For winter storage, if freezing conditions are expected, empty pump
completely and flush with a mixture of water and anti-freeze to
prevent irrreparable damage to your unit.
For more information on our range of accessories, please call our friendly sales team on 1800 645 688 or visit
our website at www.quikspray.com.au/shop

QR400 Manual
19
TROUBLE SHOOTING
PUMPS AND PRESSURE CONTROLLER
PROBLEM PROBABLE CAUSE REMEDY
Pump does not deliver
pressure
If good flow is being achieved from bypass
back to the tank
Sting pressure regulator not set for pressure Set the lever to PRESS and adjust the
handle
Damaged or worn seat or spring in pressure
regulator
Replace with sting repair kit of new spring
Sticking pressure regulator slide Remove slid and lubricate with marine
grease
Spray nozzle/s worn, missing, or exceeding
pump capacity
Replace spray nozzle/s with correct size
If irregular flow from by-pass to tank
One of more of the pump valves not seating Clean or replace valves
Sucking air though the suction line, suction
ttings or lter
Examine and repair
Air has not been entirely evacuated from the
pump
Run pump in the BYPASS mode unitl all air
is evacuated
Blocked suction lter or ball valve closed Clean lter or open ball valve
Motor to pump drive belts loose/broken or
direct coupling damaged
Tension belts or replace. Replace direct
coupling sprockets and chain
Ruptured spray hoses or ttings Repair or replace
Pump delivers insufcient
pressure
If hoses are jumping
One or more of the pump valves not seating
properly
Clean or replace valves
Diaphragm split (Oil will go milky in colour) STOP PUMP! Replace all 3. See pump
manual
Air has not been entirely evacuated from the
pump
Run pump with lever in BYPASS position
until all air has been evacuated
Sucking air through the suction line or lter Examine and repair
Oil lever is low Top up with ASE30 or 10W30
