Quik Shade Shade Tech Installation instructions

Shade Tech® Set-Up and Safety Instructions
Limited Warranty
Subject to the following limitations, in addition to
any imposed by virtue of applicable law, Bravo Sports
warrants this Shade Tech® Canopy to be free of
defects in material or workmanship for a period of
30 days from the date of original purchase. This
warranty is limited to the repair and/or replacement
of defective parts only.
1. This Limited Warranty will apply only if the Shade
Tech® and/or its parts are properly returned to
the Bravo Sports customer service department listed
below and are determined by Bravo Sports in its
sole discretion, to be defective.
2. This Limited Warranty applies only to Bravo Sports
Shade Tech® Multi-Purpose Canopies purchased
from authorized dealers. This Limited Warranty is
extended only to the original consumer purchaser
and is not transferable.
3. Be sure to retain your original purchase sales
receipt for any warranty claim. All warranty claims
must be accompanied by the original purchase
receipt from the authorized dealer.
4. Before returning any Shade Tech® Canopy
and/or parts to Bravo Sports for warranty inspection,
the consumer purchaser must obtain prior
authorization from Bravo Sports. Such authorization
can be obtained by calling our customer service
representatives at the toll-free numbers listed
below or writing to the Bravo Sports customer
service department at the address listed below.
Customer is responsible for shipping costs.
5. Certain regions of the country have environmental
conditions that are extremely hard on covers of
any kind. If you live in Arizona, Florida, Nevada,
New Mexico,Texas, or in high altitudes [above
3000 feet], the warranty period for your canopy
top will be limited to 15 days from the date of
original purchase. [After expiration of that 6
month period and up to a period of one year
following date of original purchase, you may
purchase a replacement canopy top at a reduced
price from our customer services’ department.]
6. This Limited Warranty does not cover damage or
loss from: wind, rain, fire, snow, ice, or other forces
of nature; accident; normal wear; improper assembly,
disassembly, or adjustment during set-up or
take-down; or any abuse, neglect or misuse of this
Shade Tech® Canopy and/or its parts.
7. To the extent allowed by applicable law, any
implied warranty of merchantability or fitness
applicable to this Shade Tech® Canopy is limited
to the duration of this Limited Warranty. Bravo
Sports does not warrant against, and in no event
shall Bravo Sports or its authorized agents be liable
for, any personal loss, injury, or direct or indirect
incidental or consequential damage resulting
from the use of this product. Please note that
some states do not allow the exclusion or limitation
of incidental or consequential damages, so the
above limitation or exclusion may not apply to
you. This Limited Warranty gives you specific
legal rights and you may have other rights which
vary from state to state.
8. Upon receipt of authorization from our customer
service department, you must submit your warranty
claim to the address below, shipped prepaid and
accompanied by the original dated purchase
receipt. Do not return this product to the place of
purchase. For warranty service, or for missing
parts, replacement parts or any other problems,
call or write to our customer service department
below. We will send any replacement parts via
Fed - Ex.
Do not call store regarding set up
issues, missing parts or any questions.
Instead, please contact Bravo Sports directly
at 800-248-5327.
WARNING: KEEP ALL FLAME AND HEAT
SOURCES AWAY FROM THIS TENT FABRIC. This
tent meets the flammability requirements of
CPAI-84. The fabric may burn if left in continuous
contact with any flame source. The application of
any foreign substance to the tent fabric may
render the flame resistant properties ineffective.
©2007 Bravo Sports. All Rights Reserved.
U.S. Patent #4,779,635
Please read completely before setting
up your Shade Tech® Instant Canopy
It is your responsibility to read and save these
instructions before attempting to set up your Shade
Tech® Instant Canopy. We would also like to suggest
that you follow these safety precautions, care and
maintenance tips when using your Shade Tech®:
1. Never set up or continue to use in any rain, wind
or storm conditions, especially lightning storms.
Damage can occur to your Shade Tech® and put
you and others in potential danger.
2. We suggest that you take your time to avoid
bending the frame or pinching your fingers
or hands while opening or closing the frame.
3. Avoid setting up your Shade Tech® on steep
inclines.
4. Always use the provided stakes to secure your
Shade Tech® to the ground unless you set up
on concrete or asphalt.
5. Do not use your Shade Tech® for permanent
shelter. It was designed for temporary use only.
6. Keep your Shade Tech® canopy away from heat
and flames at all times. Do not barbecue or build
fires under you Shade Tech®.
7. Never leave your Shade Tech® unattended.
8. Hand wash the canopy using only mild soap
and water. Never use harsh detergents, abrasives
and/or bleach, etc. Do not machine wash.
9. Never fold or store your Shade Tech® when it
is wet or damp. Let it dry completely to avoid
mildew.
10. ALWAYS USE COMMON SENSE.
If you have any questions about your Shade Tech®
Instant Canopy, please call our customer service
representatives at [phone].
Code: ST - Set Up - Eng - Oct2007
Bravo Sports, 12801 Carmenita Rd, Santa Fe Springs, CA 90670
Customer Service Dept. Phone [phone]
E-mail: [email protected] Check us out at www.bravosportscorp.com

set up
nwodekat
Take Down
Shade Tech® Set-Up and Safety Instructions
J
K
L
M
N
Wheeled Bag
Step 1
Step 2
Step 3
Step 4
Reduce each leg to its shortest position (fig. I).
Hold the top of the middle frame section
where it says "CLOSE" (fig. K). Lift slightly
and slowly walk towards partner as the
frame folds in. Keep walking until the
frame is about halfway closed. Be sure to
avoid pinching your hands or fingers. Hold
outside legs and continue closing canopy
as you walk towards your partner. The
completely folded canopy should stand up
on its own (fig. L).
With the canopy standing, unzip the
wheeled bag (loosen cord for WX8) and
slide bag down slowly (fig. M) until entire
canopy is in. Invert the canopy and zipper
shut (fig. N).
If your canopy came with a polyethylene top,
please remove this before inserting the frame
intothe bag.
At each corner, push in the locking button
and pull the slider down slowly until the
button pops out above the slider (fig. J).
For commercial units, pull ring out and
move sliders down (fig. G).
Note: The canopy top may remain in place for easier
subsequent set-up, however, to prolong the life of the canopy
top, we recommend that you remove it during take-down.
WARNING: Before storing your Shade Tech®, be sure the
canopy top is not wet or damp. Storing your Shade Tech® while
it is even slightly damp may cause mildew. Allow your
canopy top to completely dry before taking it down. If you must
take down your Shade Tech® while the canopy top is damp,
remove the canopy top from the frame by unfastening the hook
and loop straps. Fold up the frame and lay the canopy top down,
fully open, as soon as possible and allow it to completely dry.
Set Up
Final
Step 1
Step 2
Step 3
Step 4
Step 5
Place your Shade Tech® in the center of
the set-up area. With a partner on the
opposite side of the frame, hold onto the
two outer legs and lift slightly for clearance
Take a few steps backward until you have
extended the frame a full arm’s length -
approx. 4 feet (figure A). To improve the
opening and closing action of your Shade
Tech®, spray some silicone lubricant on
the outer legs.
Hold the bottom of the middle frame
section where it forms a "V" and says
"OPEN" (fig. D). Lift slightly and slowly
walk backward until the frame is fully
extended (fig. E). Take care to avoid
pinching your hands or fingers.
At each corner, hold the leg of the frame
with one hand and lift the slider with the other
hand. Push the locking button in while pulling
the slider up until the button pops through
(fig. F). For the commercial series, sliders
will lock in place as shown (fig. G).
Place the canopy over the top of the frame
(fig. B). Use the hook and loop straps to
secure each corner of the cover to the
frame under the plastic caps or steel
bracket (fig. C).
Secure remaining side hook and loop
straps to the frame (fig. H). The adjustable
legs offer multiple height levels. Simply lift a
leg and adjust the inner leg up or down until
the button pops into place (fig. I). Repeat on
the other legs.
Before proceeding with the assembly of your Shade Tech®
Instant Canopy, please make yourself familiar with its parts
and how they make your Shade Tech® function.
Bravo Sports, 12801 Carmenita Rd, Santa Fe Springs, CA 90670
Customer Service Dept. Phone [phone]
The following parts are inside your Shade Tech® box:
1 Shade Tech® Assembled Frame
1 Wheeled Bag*
*NOTE: Your canopy may or may not come with a wheeled bag.
Please check box for list of contents.
1 Canopy Top
Do not call store regarding set up issues, missing parts or any
questions. Instead, please contact Bravo Sports directly at
800-248-5327.
E-mail: [email protected] Check us out at www.bravosportscorp.com
A
B
C
F
G
D
E
H
