RA BD-C Series User manual

BD-C Series
-7
Laser Displacement Sensor Communication Converter
▣Features
● Supports RS232C and RS485 communications in one device
: Separated ports of RS232C/RS485 for user convenience
● Maximum connection up to 8 ampli󹃋er units
● Power supply without extra wiring via ampli󹃋er unit
● Dedicated Device Management Program (atDisplacement)
: Batch parameter setting via save/load function
: Real-time monitoring of measured values and output status
● Communication speed and station number can be set by side DIP switch
without connecting host device
▣Manual
For the detail information and instructions, please refer to the manual, and be sure to follow cautions written in the technical
descriptions (catalog, website).
Visit our website (www.autonics.com) to download manuals.
▣Proper Usage
Before using the communication converter unit, depending on the usage environment, keep following items handy.
Visit our web site(www.autonics.com) to download.
• atDisplacement program, manual • SCM-38I (RS232C - RS485) Driver, Instruction manual
• SCM-US48I (USB - RS485) Driver, Instruction manual • SCM-WF48 (Wi-Fi, USB - RS485) Driver, Instruction manual
• BD Series manual
▣Dedicated Device Management Program (atDisplacement)
• atDisplacement is BD-C Series management program for convenient management of multiple device data monitoring.
• Visit our website (www.autonics.com) to download user manual and program.
◎ System requirement
Item Minimum requirements
System IBM PC compatible computer with 1GHz + processor
Operations
Microsoft Windows 7 +
Memory 2GB +
Hard disk 1GB + of available hard disk space
VGA Resolution: 1920×1080 or higher
Others RS-232 serial port (9-pin), USB port
Please read “Safety Considerations”
in the instruction manual before using.

Laser Displacement Sensor Communication Converter
-|Transparent setting
guide|-
▣ Product Composition
Sensor
Head
• Measuring displacement of object
• Using power from the ampli󹃋er unit
Ampli󹃋er
Unit
• Setting parameter and
communication input/output
• Connecting 1 sensor per 1 unit
• Max. 8 units mutual connection
Communication
Converter
• Supporting communication function
• Max. 8 units mutual connection
• Using power from the ampli󹃋er unit
Extension
Cable
• Extending connection distance
between sensor head and ampli󹃋er unit
▣Specifications
※1: Using power from the ampli󹃋er unit. To use BD-C Series communication converter, the ampli󹃋er unit needs 12-30VDCᜡ
power supply.
※2: This weight is with packaging and the weight in parentheses is only unit weight.
※The temperature or humidity mentioned in Environment indicates a non freezing or condensation environment.
BD-C Series Communication Converter
Model BD-CRS
Power supply※1
-
Power consumption Max. 2.3W
Communication function RS-232C, RS-485
Communication speed 9600, 19200, 38400, 115200bps (default)
Indication 4 LED status indicators
Function • Real-time monitoring
• Executes every BD-Series feature and sets parameter by external device (Master)
Environment
Ambient
temperature -10 to 50℃, Storage: -15 to 60℃
Ambient humidity Under 85%RH, Storage: under 85%RH
Vibration 1.5mm amplitude at frequency of 10 to 55Hz (for 1 min) in each X, Y, Z direction for 2 hours
Shock 300m/s2 (approx. 50G) in each X, Y, Z direction for 3 times
Protection structure IP40 (IEC Standards)
Material Case: Polycarbonate
Accessory Side connector, Connector for RS485
Sold separately Communication converter (SCM-38I, SCM-US48I, SCM-WF48)
Approval
Weight※2Approx. 91g (approx. 49g)

BD-C Series
-9
▣Dimensions (unit: mm)
25 75
37
43
▣Unit Description
5
6
1
2
3
4
1 RS485 Terminating Switch
Set the switch to 'RT' when the communication converter
is connected to the terminal of RS485 communication
connection.
2 RS232C Connector
A connector for RS232C communication.
3 Status Indicator
Displays power, communication input/output/error.
• Power indicator (POWER, Green): Displays power supply.
• Communication output indicator (TX, Green): Displays
communication output status from communication
converter to external device.
• Communication input indicator (RX, Green): Displays
communication input status from communication
converter to external device.
• Communication error indicator (ERROR, Red): Displays the
communication status of communication converter.
4 Communication Setting Switch
Sets communication speed, address, parity bit and stop bit.
5 RS485 Connector
A connector for RS485 communication.
6 Side Connector
A connector for connecting between communication
converter and ampli󹃋er unit.

Laser Displacement Sensor Communication Converter
-|Transparent setting
guide|-
▣Connections
◎ RS232C communication
Pin Name Description
1N.C. None
2TXD Converter output
3RXD Converter input
4N.C. None
5GND Ground
6N.C. None
7N.C. None
8N.C. None
9N.C. None
Pin Name
1CD
2RD
3SD
4ER
5SG
6DR
7RS
8CS
9CI
FG
BD-C External device
When connecting BD-C
to external device, use
D-SUB 9 pin cable.
1
6
2345
789
1
6
2345
789
◎ RS485 communication
Pin Name Description
1A(+) RS485 + signal
2B(-) RS485 - signal
Communication pin Terminating switch
Set the switch to 'RT' when the communication
converter is connected to the terminal of RS485
communication connection, and set to 'OFF' when it is
in the middle of the communication connection. 1
AB
2
Application of system organization
Computer
B(-)
A(+)
A(+) B(-) A(+) B(-) A(+) B(-)
Terminating resistance
(100 to 120Ω)
RS485
DEVICE
#1
RS485
DEVICE
#2
RS485
DEVICE
#31
RS485
DEVICE
#32
USB/Wi-Fi - RS485
Communication
converter B(-)
RT OFF
A(+)
RT OFF

BD-C Series
-11
▣Communication Setting
◎ Communication setting switch
Communication speed (Switch 1, 2):
Sets RS-232C, RS-485 communication speed to external device.
Communication
speed Switch 1 Switch 2
9600bps ON ON
19200bps OFF ON
38400bps ON OFF
115200bps OFF OFF
Parity bit (Switch 8, 9): Sets parity bit for RS-232C, RS-485
communication.
Parity Switch 8 Switch 9
Even ON ON
Odd OFF ON
None ON OFF
None OFF OFF
Stop bit (Switch 10): Sets stop bit for RS-232C, RS-485
communication.
Stop bit Switch 10
2-bit ON
1-bit OFF
Address (Switch 3 to 7): Sets the address of communication converter.
It is calculated in binary according to the ON/OFF status of each switch.
Switch No. Switch3 Switch4 Switch5 Switch6 Switch7 Address
Binary digit
OFF=0
ON=1
2 4 2 3 2 2 2 1 2 0 Address= Switch 3×2 4 ＋Switch 4×2 3 ＋Switch 5×2 2 ＋
Switch 6×2 1 ＋Switch 7×2 0 ＋1
Address 1 OFF OFF OFF OFF OFF 1=0×2 4 ＋0×2 3 ＋0×2 2 ＋0×2 1 ＋0×2 0 ＋1
Address 2 OFF OFF OFF OFF ON 2=0×2 4 ＋0×2 3 ＋0×2 2 ＋0×2 1 ＋1×2 0 ＋1
Address 3 OFF OFF OFF ON ON 3=0×2 4 ＋0×2 3 ＋0×2 2 ＋1×2 1 ＋1×2 0 ＋1
... ... ... ... ... ... ...
Address 16 ON OFF ON ON ON 16=1×2 4 ＋0×2 3 ＋1×2 2 ＋1×2 1 ＋1×2 0 ＋1
... ... ... ... ... ... ...
Address 31 ON ON ON ON OFF 31=1×2 4 ＋1×2 3 ＋1×2 2 ＋1×2 1 ＋0×2 0 ＋1
Address 32 ON ON ON ON ON 32=1×2 4 ＋1×2 3 ＋1×2 2 ＋1×2 1 ＋1×2 0 ＋1
ON
OFF
Communication
Speed
Address Parity
bit
Stop
bit
1 2 3 4 5 6 7 8 9
10
※Default: All switches OFF

Laser Displacement Sensor Communication Converter
-|Transparent setting
guide|-
▣Installations
◎ Mounting on DIN rail ◎ Communication system composition
◎ Connecting to ampli󹃋er unit
Mounting
① Insert bottom holder of
communication converter to 35mm
width DIN rail.
② Push the front part of the unit to
arrow direction to mount.
Detaching
① Side ampli󹃋er unit to ⓐ direction.
② Pull the assembly part to ⓑ direction
to detach.
ⓑ
ⓐ
① Remove the side cover at the connecting side.
② Connect the side connector to the units.
③ After mounting ampli󹃋er unit and communication unit on
DIN rail, push it to arrow direction tightly.
※In case of disconnecting, follow the upper sequence reversely.
①
②
③
Precautions when connecting amplifier unit
• Mount on DIN rail.
• Do not supply the power when adding ampli󹃋er unit.
• Supply power to each connected ampli󹃋er unit at the same
time.
• Up to 8 ampli󹃋er units can be connected, and only 1 calculation
function can be performed per 1 group of mutually connected
ampli󹃋ers.
• When the calculation function is activated, the setting values
(SV) of the slave units are disable and the mutual interference
prevention function for sensor heads is executed automatically.
Distinguishing master/slave amplifier units
• When the power cable direction is down, the ampli󹃋er at the
left end is the master unit, and the channel number of slaves
increases sequentially to the right.
Communication converter is connected to the left side of
master ampli󹃋er unit.
Comm.
converter Ampli󹃋er unit
MASTER
SLAVE 1 SLAVE 2 SLAVE 3 SLAVE 4 SLAVE 5 SLAVE 6 SLAVE 7
Master Slave
※Max. 8 units

BD-C Series
-PB
▣ Cautions during Use
1. Follow instructions in 'Cautions during Use'. Otherwise, it may
cause unexpected accidents.
2. Do not install where strong magnetic or electric field exist.
Otherwise, the resolution may be adversely affected.
3. Wire as short as possible and keep away from high voltage
lines or power lines, to prevent surge and inductive noise.
4. For the optimized performance, it is recommended to
measure after 30 minute from supplying power.
5. When detecting with the maximum sensitivity, an error may
occur depending on each characteristic deviation.
6. This unit may be used in the following environments.
①Indoors/Outdoors (in the environment condition rated in
'Specifications')
②Altitude max. 2,000m
③Pollution degree 2
④Installation category II
Power indicator (POWER): Green, Displays power supply.
Status Reason Solution
On Power is
supplied.
-
O󹃊 Power is not
supplied.
After checking the connection
between communication converter
and ampli󹃋er unit correctly,
reconnect the device.
Communication output indicator (TX):
Green, Displays communication output status from
communication converter to external device.
Status Reason Solution
Flashing Signal is
outputting.
-
O󹃊 Signal is not
outputting.
-
Communication input indicator (RX):
Green, Displays communication input status from
communication converter to external device.
Status Reason Solution
Flashing Signal is
inputting.
-
O󹃊 Signal is not
inputting.
-
Communication error indicator (ERROR):
Red, Displays the communication status of communication
converter.
Status Reason Solution
On
Connection is
bad between
communication
converter and
ampli󹃋er unit.
After checking the connection
between communication converter
and ampli󹃋er unit correctly,
reconnect the device.
Flashing
Communication
is bad between
communication
converter and
ampli󹃋er unit.
After checking the connection
between communication converter
and ampli󹃋er unit correctly,
reconnect the device.
Apply noise prevention to
communication converter and
ampli󹃋er unit.
O󹃊 Operation is
normal.
-
POWER TX RX ERROR
▣ Status Indicators
