RAD Cycle Products RAD MAX Prozone 1102 User manual
RAD Cycle Products MAX RACER PRO
Copyright 2011 DTX International
INSTRUCTION MANUAL
Replace
RAD Cycle Products 1102 Prozone Bike Trainer
INSTRUCTION MANUAL
Copyright 2012 DTX International
vRide Your Bike In Any Type of Weather
vFits Road and Mountain Bike with 26”, 28”
and 700cc Wheels
vThe Incredibly Quiet, State of the Art Magnet
System Instantly Creates Resistance
vSeven Levels of Resistance. Get the most out of your
workout with the handlebar resistance control
vWide Stance and Ultra-Strong Frame Offer Maximum
Stability and Safety
vFolds down to store anywhere, not to mention
making travel a snap
WARRANTY AND RETURN POLICY
CUSTOMER SERVICE
All RAD Cycle Products are warrantied against defects in material and workmanship for a period of one year.
Our return policy allows 30 days from the date of delivery to return products, provided it is new, unused and in
the original packaging as received. We highly recommend that the buyer thoroughly inspect the purchased prod-
uct before using it. We charge a 20% restocking charge on all returned items. Return shipping is the responsibil-
ity of the buyer. We cannot accept returns for any reason after 30 days from the date of delivery. A credit will be
issued after the item is inspected and accepted.
All shipping damages must be claimed with the designated shipper. Check the shipping carton for damage before
signing the bill of lading.
If an item is opened and deemed to be defective within 30 days from the date of delivery, please contact us at
www.radcycleproducts.com for return instructions. A RAD Cycle Products RMA is required when returning defec-
tive merchandise. When returning your order please include a copy of your order number with date purchased,
your RAD Cycle Products RMA and the reason for the return.
Warranty shall not apply to: products which are used for a purpose other than which they were designed for or
which have been altered in any way that would be detrimental to the performance or life of the product. Misappli-
cation, misuse, modication of the product or negligence will revoke the warranty.
Don’t cancel your workout just because the weather doesn’t cooperate!
Just start pedaling and experience the ultra-quiet resistance of the PROZONE Bike Trainer. The conve-
nient handlebar controller offers 7 different resistance settings offering you the optimum workout. Safety
and stability will never be an issue with the unique design, wide stance and strong construction. Com-
patible with road and mountain bikes with wheel sizes 26”, 28” and 700cc, the versatility of this trainer
is unparalleled. To top it all off, this trainer folds down to allow for easy storage and travel.
Keep ngers clear when folding the trainer and never use on an uneven surface. Children and pets
should be kept clear of wheels when in use.
Customer service and product support are available online at www.radcycleproducts.com
2
Copyright 2012 DTX International
SAFETY RECOMMENDATIONS
PARTS DIAGRAM
OPERATING INSTRUCTIONS
Frame
Rake Quick Clamp
Tightening Rod
Tightness Adjuster
Magnetic Resistance Set
WARNING! TO AVOID SERIOUS INJURY ALWAYS FOLLOW INSTRUCTIONS AND
SAFETY RECOMMENDATIONS.
vNEVER use trainer on uneven surfaces, always set up your PROZONE trainer on a at, even surface.
vHARD BREAKING during use of the PROZONE trainer may cause excessive wear on bike tires and the trainer.
vALWAYS make sure parts are tightened and that all equipment is in good working condition.
vKEEP PETS AND CHILDREN CLEAR of trainer when in use.
vNEVER touch wheels when they are in motion.
vALWAYS make sure bike tires are secure and properly inated before attaching to trainer.
vNEVER let go of the handlebars while riding your bike.
vALWAYS properly warm up before working out. Consult your physician prior to starting any workout regimen.
3
Copyright 2012 DTX International
Handlebar Resistance
Controller
Handlebar Resistance
Controller
RAD Cycle Products MAX RACER PRO
Copyright 2011 DTX International
INSTRUCTION MANUAL
Replace
A B
Part A part B
ASSEMBLING
4
Copyright 2012 DTX International
Snap the cylindrical piece of Part B
into the track in part A. Part B will
be placed into the trough on part A.
Tighten the knob on part a until snug.
Parts A & B together Cross the long bolt with washer
from the small holes marked A to A
for a 28" bike or B to B for a 26" bike.
Using the two wrenches tighten the
lock nut and washer onto the bolt.
Install the two hex screws with plastic
washers into the large holes (A or B)
and tighten with included allen wrench.
1) With a bicycle locked into the trainer, push
the blue locking lever down to push the mag
roller closest to the rear wheel. [Figure 1]
2) Begin adjusting the knob counter clockwise
[Figure 2] to increase friction, or clockwise
[Figure 3] to decrease friction until the mag
roller comes in contact with the rear wheel.
3) Push the
blue locking
lever back up to
bring the mag
roller away
from the tire. [Figure 4]
4) Turn the adjustment knob counterclockwise a
few turns and again push the blue locking lever
down so that the mag roller comes in contact with
the rear wheel.
5) Repeat step 4 until desired friction is achieved
and rear wheel does not slip when riding.
[NOTE] Too much friction between the mag roller and the rear tire will cause
excessive wear on your tire tread.
How to adjust the Prozone Trainer for Use
FIGURE 1
FIGURE 2
FIGURE 3 FIGURE 4
Copyright © 2012 DTX International
5
For best results make sure that your tires are
inflated to the maximum pressure
allowed for your tire.
To avoid unnecessary wear and tear on your
bike tires, when not using your PROZONE
trainer, make sure the resistance is set to
not touch the tires.
To attach your bike to the trainer, rst:
1. Unfold your trainer and place on a
level, at surface (Figure 2).
2. Release the quick release lever on
the back wheel of your bike and
replace it with the Tightening Rod
(Figure 3). Unscrew the end tting of
the rod and slide the Tightening Rod
through your bike’s rear wheel.
FIGURE 2
6
Copyright 2012 DTX International
FIGURE 1
FIGURE 6
FIGURE 7
FIGURE 3
FIGURE 4
FIGURE 5
ATTACHING YOUR BIKE TO THE PROZONE TRAINER
OPERATING INSTRUCTIONS
End Fitting
Rake Quick
Clamp
Rake Quick
Clamp
FIGURE 8
3. Please use the spanner and allen key to fitting the Magnetic
Resistance Set.
4. When screw is in Position A, It suitable for 28" wheels (Figure7).
When In position B, It is suitable for 26" wheels (Figure8).
5. Once your bike is held securely, the rest is easy. Simply close
the Rake Quick Clamp by pressing down firmly but gently
(Figure 4), then tighten the securing nut on the opposite side to
tighten completely (Figure 5).
7
Copyright 2012 DTX International
6. Thread the cable for the handlebar resistance controls around
your bike and mount the resistance controller to your handle-
bars. Be sure to attach the controller within easy reach of your
hands while riding (Figure 9).
7. Don’t forget to place the anti-slip leveling stand under the
front tire of your bike, and you’re ready to go! (Figure 10).
Your bike’s own gears in conjunction with the PROZONE Trainer’s
7 levels of resistance offers innite congurations for a
completely customized workout.
Make sure that the controller cable is clear of the wheels and that
the hub connections are secure. Always check that the front wheel
is secure in the anti-slip stand before using the PROZONE Trainer.
It is important to properly warm up before doing any kind of exercise
and check to make sure your bike tires are inated to the proper PSI.
ALWAYS keep both hands on your handlebars when riding.
1. Remove the resistance controller and cable from your
handlebars.
2. Open the Rake Quick Clamp on the top of the trainer by
pressing up rmly but gently (Figure 4), then loosen the
securing nut on the opposite side (Figure 5).
3. Unscrew the end tting of the rod and slide the Tightening
Rod out of your bike’s rear wheel (Figure 3). Remove the
anti-slip leveling stand and your bike is now free from the trainer.
4. To store your trainer simply fold and store out of the way
until your next use (Figure 11). Be careful to avoid pinching your
ngers when folding and avoid storing other equipment on top
of your trainer.
Take care to protect the magnetic resistance set, its adjustment knob
and the controller cable.
Customer service and product support are available online at
www.radcycleproducts.com.
ATTACHING YOUR BIKE TO THE PROZONE TRAINER
USING YOUR PROZONE TRAINER
OPERATING INSTRUCTIONS
REMOVING YOUR BIKE FROM THE TRAINER
