RADAC WaveGuide 5 Direction User manual

WaveGuide Onboard Explosion Proof
User Manual

WaveGuide Onboard Explosion Proof
User Manual
Applicable for product number:
WG5-OB-EX
Related to software versions:
wob 5.1
Version 5.1-1
1st of Dec. 2018
Radac B.V.
Elektronicaweg 16b
2628 XG Delft
The Netherlands
tel: [phone]
e-mail: [email protected]
website: www.radac.nl

Preface
This user manual and technical documentation is intended for engineers and technicians
involved in the software and hardware setup of the WaveGuide 5 Onboard system, Explosion
Proof version (WG5-OB-EX).
Note
All connections to the instrument must be made using shielded cables. The shielding must
be grounded at both ends of the cable. Please refer to Chapter 2 for more details regarding
wiring and cable specifications.
Legal aspects
The mechanical and electrical installation must be carried out by trained personnel with
knowledge of the local requirements and regulations for installation of explosion-proof equip-
ment in hazardous areas.
The information in this user manual is the copyright property of Radac BV.
Radac BV disclaims any responsibility for personal injury or damage to equipment or
property caused by:
•Deviation from any of the prescribed procedures.
•Execution of activities that are not prescribed.
•Neglect of the general safety precautions for handling tools and use of electricity.
The contents, descriptions and specifications in this user manual are subject to change
without notice. Radac BV accepts no responsibility for any errors that may appear in this
user manual.
Additional information
Please do not hesitate to contact Radac or its representative if you require additional
information.

Contents
Preface
Introduction 1
1 Safety and Security 3
1.1 General ...................................... 3
1.2 Safety Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2.2 Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3.2 EC Declaration of Conformity (for EU) . . . . . . . . . . . . . . . . 4
1.3.3 Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 Liability...................................... 4
1.5 Labels ....................................... 5
1.6 Personal Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.7 Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.7.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.7.2 Tools.................................... 6
1.7.3 Working Environment . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.7.4 Required Skills . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.8 Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.8.1 Commissioning and Maintenance . . . . . . . . . . . . . . . . . . . . 7
1.8.2 Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.9 Accordance with Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.9.1 Explosion Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.9.2 Compliance to RED . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 Radar positioning and installation 9
2.1 Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.3 Cable ....................................... 11
2.4 Gland ....................................... 11
2.5 Housing ...................................... 12
2.6 Wiring....................................... 12
2.7 Closing housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3 WaveGuide system commissioning 14
Step 1. Connect the WaveGuide system to a computer . . . . . . . . . . . . . . . 15
Step 2. Become an authorized user . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Step 3. Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Step 3.1: Set system date and time . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Step 3.2: Adjust network settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Step 3.3: Sensor configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Step 4: Perform system check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Step 4.1: Check system information . . . . . . . . . . . . . . . . . . . . . . . . . 21
Step 4.2: Check reflection diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Step 4.3: Check measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Step 5: Configure distribution of data . . . . . . . . . . . . . . . . . . . . . . . . 24
Step 6: Technical assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4 Using the system 27
4.1 Calculated parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.2 Datalogging ................................... 27
Appendix 1: System parameters 29
Appendix 2: System specifications 31

Introduction
The WaveGuide Onboard is a highly accurate wave and waterline monitoring system for
use on floating vessels. The system is robust, easy to install and explosion proof.
The WaveGuide Onboard includes two built-in sensors:
•A radar sensor that measures the distance to the water surface.
•An inertial measurement unit (IMU sensor) allows for motion compensation.
The WaveGuide radar is a low power X-band FMCW radar that measures the distance to
the water surface with an accuracy of < 1 [cm]. The IMU sensor measures acceleration and
hence requires a band-pass filter and a double integration cycle to obtain translation. The
position of the water surface is obtained by subtracting the calculated translation (IMU)
from the measured distance to the water surface (radar).
Filtering, integrating and aligning the raw data signals causes a 100 to 120 [sec] delay in
calculating resultant heave data. That in turn is further processed to provide wave height
parameters and wave spectra.
The measurements and calculated parameters are stored on the system and made available
to the user via a web-based interface or as a stream of UDP messages.
This manual describes the Explosion proof version of the WaveGuide Onboard system.
Please refer to the Radac website for all other manual versions.
Warning
Do not use the instrument for anything else than its intended purpose.
This manual consists of 4 chapters. Chapter 1 provides safety and security related informa-
tion. Chapter 2 specifies the WaveGuide radar positioning criteria for optimal measurement
quality and illustrates the mounting and installation procedure. Chapter 3 describes the
commissioning of the system via the user interface. Chapter 4 explains data processing,
data presentation and data distribution.
Please refer to Appendix 1 for a list of measured and calculated parameters. And to
Appendix 2 for specifications, information about certification and environmental conditions
applicable to the WaveGuide Onboard system.
1

Chapter 1
Safety and Security
1.1 General
For the correct and safe installing of this product, it is essential that all personnel follow
generally accepted safety procedures in addition to the safety precautions specified in this
document.
1.2 Safety Conventions
1.2.1 Warnings
The following warning box is used within this document to urge attention in order to
prevent personal injuries or dangerous situations.
Warning
Carefully read the message in the warning boxes.
1.2.2 Cautions
The following caution box is used within this document to urge attention in order to
prevent damages to the equipment.
Caution
Carefully read the message in the caution boxes.
1.3 Safety Instructions
The WaveGuide is a radar based level gauge for measuring wave and water-level information
in offshore environment, lakes and rivers.
Warning
Only use the instrument for its intended purpose.
1.3.1 Safety
The mechanical and electrical installation shall only be carried out by trained personnel
with knowledge of the requirements for installation of explosion proof equipment in (po-
tentially) an explosive atmosphere. The entire installation procedure shall be carried out
in accordance with national, local and company regulations and standards.
3

Warning - Risk of Explosion
Use only Explosion proof (Ex d) compound (due to >2 [Liter] & IIB) cable glands or
conduit seals, depending on local requirements.
Warning - Risk of Explosion
Cables and cable glands for at least 80 [◦C] shall be used! Improper installation of cable
glands, conduits or stopping plugs will invalidate the Ex approval of the WaveGuide. The
use of stopping plugs on thread adapters is strongly advised against, as this may create
unsafe Ex d characteristics.
Warning - Risk of Explosion
All lid bolts must be fastened with a torque of 30 [N·m] or 22 [lbf·ft] to prevent danger of
explosion!
Caution
To comply with the IP66/IP67 requirements the blanking elements, threaded adapters,
cable glands and their interface with the housing must also comply with IP66/IP67
requirements.
Warning - Risk of Explosion
To avoid risk of dangerous amounts of electrostatic charging, clean the instrument only
with a damp cloth.
1.3.2 EC Declaration of Conformity (for EU)
See the EC declaration of conformity shipped with the device.
1.3.3 Additional Information
If you require additional information, contact Radac or its representative.
1.4 Liability
The information in this installation guide is the copyright property of Radac, The Nether-
lands.
Radac disclaims any responsibility for personal injury or damage to equipment caused by:
•Deviation from any of the prescribed procedures.
•Execution of activities that are not prescribed.
•Neglect of the safety regulations for handling tools and use of electricity.
4

The contents, descriptions and specifications in this user manual are subject to change
without notice. Radac accepts no responsibility for any errors that may appear in this
Installation Guide.
Caution
Modification to the instrument may only be carried out by trained personnel that are
authorized by Radac BV. Failure to adhere to this will invalidate the approval certificate.
1.5 Labels
Figure 1.1: Example of identification label.
5

1.6 Personal Safety
Warning
In hazardous areas it is compulsory to:
•use personal protection and safety gear such as a hard hat, a fire-resistive overall,
safety shoes, safety glasses and working gloves.
•Avoid possible generation of static electricity.
•Use non-sparking tools and explosion-proof testers.
•Make sure no dangerous quantities of combustible gas mixtures that are present in
the working area.
•Never start working before the work permit has been signed by all parties.
Note
The emitted microwave energy is far below acceptable limits for exposure to the human
body. A maximum radiation of 0.1 [mW/cm2] is generated.
1.7 Warnings and Cautions
1.7.1 General
Warning
Make sure that all power to the instrument is switched off before opening the covers of
the WaveGuide radar. Failure to do so may cause danger to persons or damage to the
equipment. Also, all the covers must be closed before switching on the power.
1.7.2 Tools
Warning
Treat the flange surface of the cover and the housing with care. Keep the flange surface
free of dirt. The O-ring must be present and undamaged.
Warning
Use non-sparking tools and explosion-proof testers. Use suitable explosion-proof tools
(e.g. testing devices)!
6

1.7.3 Working Environment
Hazardous Zone
Warning
POTENTIAL ELECTROSTATIC CHARGING HAZARD
Avoid the generation of static electricity. Electrostatic charge/discharge of the device
from/to a person or a tool could ignite a surrounding hazardous atmosphere.
Safe Zone
Warning
Make sure that no explosive gas mixtures build up in the working area.
1.7.4 Required Skills
Warning
The technician must have technical skills to be able to safely install the equipment. The
technician also must be trained to work in accordance with the national requirements for
electrical equipment in hazardous areas.
1.8 Electrical
1.8.1 Commissioning and Maintenance
•The entire installation procedure must be carried out in accordance with national,
local, and company regulations. The entire electrical installation shall be carried out
in accordance with the national requirements for electrical equipment to be installed
in hazardous areas.
•All wiring entries must be closed using the correct thread type such that the approvals
are not invalidated. For installations using cable glands, use Ex d compound barrier
glands. For installations using conduits, each conduit must be sealed within 18 inches
of the enclosure.
•Improper installation of cable glands, conduits or stopping plugs invalidates the Ex
approval of this device.
•Make sure that the housing of the device is properly bonded to the Protective Earth
(PE).
•The temperature of the device’s coupling due to local heat sources (e.g. contents of
a tank or power dissipation) may not exceed a temperature of 80◦[C].
7

•Cables and cable glands for at least 80◦[C] (176◦[F]) shall be used, unless ambient
temperature is known to be always less than 50◦[C] (122◦[F]).
1.8.2 Grounding
Warning
Make sure the housing of the device is properly connected to the ground reference! Make
sure the electrical resistance of the ground connection is below the maximum prescribed
by local requirements!
1.9 Accordance with Regulations
1.9.1 Explosion Safety
ATEX
II 1/2 G Ex d IIB T6 Ga/Gb or Ex d [ia Ga] IIB T6 Ga/Gb
according to KEMA 07ATEX0010 X
IECEx
Ex d IIB T6 Ga/Gb or Ex d [ia Ga] IIB T6 Ga/Gb
according to IECEx KEM 07.0003X
1.9.2 Compliance to RED
This device complies with the Radio Equipment Directive. The device does not cause
harmful interference and accepts any interference received. For more information please
refer to the EC declaration of conformity shipped with the device.
8

Chapter 2
Radar positioning and installation
2.1 Positioning
Figure 2.1: The 5◦[deg] half
top angle of the F08 antenna
beam and the reference level
for mounting height measure-
ment.
For obtaining the best results from a WaveGuide Onboard the
following radar positioning criteria must be taken into account:
•It is advised to choose a mounting position such that the
WaveGuide radar beam is free of large reflecting obstacles
(the beam of the F08 antenna has a 5◦[deg] half top angle
as shown in Fig. 2.1). The minimum horizontal distance
between the radar and any obstacle in the beam’s path
should be at least 10% of the vertical distance between
the radar and the obstacle. This does not only include
horizontal objects in the beam’s path but also vertical
structures.
•Any structure that the WaveGuide radar is mounted to
might have some influence on the wave flow around it.
Hence, it is advised to mount the radar at a position facing
the mean wave direction so that the radar can measure
the least disturbed water surface. In most cases the ship’s
bow provides the optimal mounting position but as each
vessel has a unique shape, it is the user’s responsibility
to carefully identify the best position for mounting the
WaveGuide radar.
•The reference level for the mounting height of the radar
is shown in Fig. 2.1.
•Figure 2.2, shows the polarization plane of the signal emit-
ted from the radar antenna. If the WaveGuide radar is
mounted close to a large vertical wall, then the radar
should be mounted such that the polarization plane is
parallel to the wall. That is to minimize the effect of the
wall on the propagation of the signal. Nevertheless, the
horizontal distance between the radar and the wall should
comply with the previous criteria.
•A vertically mounted radar (0◦[deg] tilt angle) results
in optimal performance. But if necessary the WaveGuide
radar can be mounted with a maximum tilt angle of 15◦
[deg] (tilted to face the direction away from the structure
it is mounted on).
Figure 2.2: Top view of radar
antenna and its polarization
plane.
9

2.2 Installation
Figure 2.3: Optional mounting
plate for the WaveGuide radar
(Part no. WG-MP-EX).
To facilitate the mounting of the WaveGuide radar, an op-
tional mounting plate is available upon request (Part no.
WG-MP-EX). Figure 2.3 shows a sketch of the optional
mounting plate and its dimensions.
The mounting plate can be fixed to two horizontal beams
(Fig. 2.4). The length of the beams must take into account
the minimum horizontal distance between the WaveGuide
radar and any obstacles in the path of the radar signal (as
explained in the radar positioning criteria). Each beam must
have 2 holes either 200 or 270 [mm] apart depending on the
intended orientation of the mounting plate.
It is advised to mount the horizontal beams first. Then to
attach the mounting plate to the horizontal beams and fi-
nally to mount the WaveGuide radar to the mounting plate.
Mounting the radar is done by mounting the radar antenna
to the mounting plate and then mounting the radar housing
to the antenna.
Figure 2.4: Top view of the hori-
zontal mounting beams.
Radac can provide an optional dual-purpose wrench/spanner
(Part no. WG-EX-tool). One end of the wrench (Fig. 2.5)
is an open-end wrench that can be used to tighten the an-
tenna to the mounting plate. While the other end is a pin
wrench that can be used for tightening the radar housing to
the antenna. Upon request, Radac can supply an optional
frame (Part no. WG-MH-EX) that allows for mounting the
WaveGuide radar and mounting plate at angles 0, 5, 10,
15 and 20 [deg] away from vertical (see Fig.2.6). The radar
mounting plate (Part no. WG-MP-EX) is included with this
frame as well as brackets to allow mounting the frame to a
handrail.
Figure 2.5: Optional wrench
that allows mounting of the
WaveGuide radar (Part no.
WG-EX-tool).
Figure 2.6: Optional frame that
allows mounting of the Wave-
Guide radar at different angles
(Part no. WG-MH-EX).
10

2.3 Cable
Figure 2.7: Block diagram of the
Waveguide Onboard system.
When selecting a cable for use with a WaveGuide system,
the following requirements must be used:
•Two wires for power transmission. The choice of power
supply will influence the diameter and insulation thick-
ness of those wires.
•Four wires for data transmission. The use of an
Ethernet data connection necessitates the use of four
twisted-pair wires (22-24 [AWG] and minimum insu-
lation thickness of 0.245 [mm]).
•The cable must be shielded and can have a maximum
length of 80 [m].
Upon request, Radac can supply an optional cable that com-
plies with the WaveGuide system requirements for power
and data transmission.
2.4 Gland
Depending on local regulations, this device can be connected by using glands, direct entry,
or conduits
An explosion proof (Ex-d) compound cable gland (M20), plus a M20 to 3/4" NPT converter
are supplied with each WaveGuide radar for use as a safe and watertight cable entry point.
The supplied gland allows the installation of cables from 6.5 to 11.9 [mm] in diameter.
Two approved 3/4" stopping plugs are provided for sealing the unused cable inlets
Note
Instructions supplied by the manufacturer for installing the included cable gland are
provided separately in its packaging.
Caution
The use of Ex-d certified materials of an inappropriate IP value or the improper
installation of cable glands, conduits or stopping plugs will invalidate the Ex approval of
the WaveGuide.
11
