SSIHuset 2100.0461 Installation and operating instructions
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
XVR Rcorder with 8 channels (1080N)
Product nr. 2100.0461
User Manual / Installation guide
Side 1af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
Contents
1. Indicator lamps........................................................................................................................................ 2
2. Connections............................................................................................................................................. 3
3. Hard drive Installation ............................................................................................................................ 4
4. Start up..................................................................................................................................................... 6
5. Remote connection from Web............................................................................................................ 10
6. Access from Iphone, Ipad og Android ............................................................................................... 14
7. Specifications ........................................................................................................................................ 19
8. Box contents.......................................................................................................................................... 19
9. Troubleshooting .................................................................................................................................... 20
Side 2af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
XVR optager med 8 kanaler (1080N)
•This unit should be placed where there is good ventilation. Do not block
the side panels of the unit. Avoid heat.
•Horizontal mounting is recommended.
•Avoid contact to water and avoid wet or damp places.
•Avoid stacking.
1. Indicator lamps
Side 3af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
2. Connections
Side 4af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
3. Hard drive Installation
A. Remove 4 screws from the bottom plate:
B. Turn the unit over and remove the lid:
❶Power cable to hard drive.
❷Data cable to hard drive.
❸Mounting holes for the
hard drive
Side 5af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
C. Place the hard drive and align the screwholes on the hard drive with the
holes on the bottom plate. Tighten the screws to the hard drive.
D. Attach the cables to the hard drive.
E. Attach the lid with the 4 screws. See Fig 3A.
Side 6af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
4. Start up
•Connect the cameras –see Fig. 2 pkt. ❶
•Connect a TV, monitor or screen
•VGA –see Fig. 2 pkt. ❷
•HDMI –see Fig. 2 pkt. ❼
•Connect Network cable –see Fig. 2 pkt.❺
•Connect the USB Mus –see Fig. 2 pkt. ❽
•Connect the power adapter –se Fig. 2 pkt. ❾
A. The following will be displayed after start up. Press Next Step:
Side 7af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
B. Log in with admin as User Name and Password 12345:
C. Adjust Device settings and press Next step:
Side 8af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
D. Note IP Address for later use with remote access and press Next Step:
E. Press Next Step:
Side 9af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
F. Press Next step:
G. Press Next step og adjust recording preferences:
H. Press OK to save the preferences.
Side 10 af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
5. Remote connection from Web
A. Open the Internet Explorer browser on the PC and type in the IP
address noted earlier:
B. Download and install OCX controls by pressing Download:
Side 11 af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
C. Follow the Setup instructions. Press Next:
D. Press Next :
Side 12 af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
E. Press Next:
F. Press Install:
Side 13 af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
G. Press Finish:
H. Type in User Name –admin og Password 12345 (default):
Side 14 af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
I. Remote access from Web:
6. Access from Iphone, Ipad og Android
From Apple App Store:
•Search for FreeIP or scan the following QR code:
Side 15 af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
Press here to open the menu.
From Android Google Play store
•Search for FreeIP or scan the following QR code:
Open FreeIP App :
➊
Side 16 af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
Press SN Login.
Press QR sign or type the DVR
seriel nr. in.
➋
➌
Side 17 af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
To use the QR code allow the
app to use the kamera. Scan the
QR code from the box.
Type user name –admin and
password 12345 (default).
➍
➎
Side 18 af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
Press Login.
Login successful.
➏
➐
Side 19 af 20
SSIHuset
Svane Electronic
Arildsvej 27, Gråmose, DK-7442 Engesvang
7. Specifications
Video Input
AHD (1080P,720P)
TVI (1080P,720P)
CVI (1080P,720P)
960H
BNC tilslutning
IP: Max 12 kanaler
Monitor output
1 x VGA , 1 x HDMI
Sound input
2 channels RCA connection
Sound output
1 channel RCA connection
CVBS output
1 channel BNC connection
Video Compression
Standard H.264
Video frame rate
Pal:25 fps; NTSC: 30 fps
Sound Compression
G711u
Data storage
SATA hard drive interface max. 6TB
Backup
USB / Network
Network connection
RJ45 10M / 100M auto-adapt ethernet port
USB interface
2 x USB2 connection
Operating system
Embedded Linux
Power
12V DC / 2A
Working temperature
-10°C ~ 55° C
8. Box contents
•1 x USB mouse
•1 x Software CD
•1 x AC power adapter
•1 x Installation manual (english)
•1 x DVR (XVR)
•Screws for hard drive mounting
Hard drive purchased separately.
