Introduction
Overview
The Model 290X family of photoreceivers use a
combination of a quadrant cell photodiode and signal-
processing amplifiers to generate position-sensitive
signals from an incident light source.
Versions of the photoreceiver are available for visible
(Model 2901) or infrared (Model 2903) beams. The
photoreceiver can be operated from battery or a ±15 V
DC power supply (we recommend the low-noise
Newport Model 0901 power supply for best
performance).
Each model has a photodiode with a 3-mm diameter
active region.
Tips for Best Operation
Avoid Room Lights
The 290X quadrant cell photoreceiver has a large active
area. For a typically illuminated room of 1–10 µW/
mm2, the SUM output can reach 1 V on the 30-µW
saturation gain setting. The 120-Hz component of
fluorescent room lights is extreme, and will almost
certainly cause measurement difficulties.
290x quadcell rcvr RevA.fm Page 5 Monday, November 15, 2004 3:39 PM

6 • Introduction
The best solution is to shield the receiver as much as
possible from room lights. A Newport Model 1280
can be installed into the threads on the detector
housing to hold filters or a light shield.
Limiting Measurement Bandwidth
As seen in the discussion “Impact of Noise on Position
Measurement” on page 19, the measurement
bandwidth plays an important role in the noise of your
system. Select a measurement bandwidth consistent
with your measurement goals. For instance,
observation of thermal drifts in the sub-Hz range will
benefit greatly from signal averaging or other
bandwidth-limiting actions.
Using Optical Filters
Narrow-band optical filters, which transmit your
laser’s wavelength while blocking other light sources,
can be installed in a Newport Model 1280 1" filter
holder. Many filters are commercially available.
When using optical filters during position
measurement, please consider the effects of multiple
surface reflections. The ideal filter has a wedge shape,
and good anti-reflection coating on one surface to
ensure that the optical beam incident on the receiver
does not contain interference fringes.
290x quadcell rcvr RevA.fm Page 6 Monday, November 15, 2004 3:39 PM

Model 290X Operation • 7
Operation
Setting up the Receiver
1. Supply power. The Model 290X is powered
either by a single 9-V alkaline battery, or by a +/-
15 V DC power supply. If both battery and exter-
nal power are present, an internal relay connects
the external power to the amplifier circuitry. To
check the battery condition, push the red power
switch to the BATT CHK position. If the green
LED lights up, the battery is in good condition; if
the LED does not light, the battery needs to be
replaced (see page 8). Adjust the power switch to
ON.
Remember to switch the power OFF when not in use to
maximize battery life.
2. Mount the photoreceiver. Use the 8-32 thread
(M4 for metric versions) on the bottom of the
casing to mount the photoreceiver to a post or
pedestal.
Be careful not to over-tighten when attaching to a post or
pedestal, or the threaded insert can strip out of the plastic
pad.
3. Connect the receiver output. Connect your volt-
meter, oscilloscope, or other instrument to the
X, Y and SUM connectors on the back of the
receiver.
The threading is seated in a non-conductive plastic pad to
reduce the electrical noise associated with ground loops.
Note:
Note:
Note:
Note:
290x quadcell rcvr RevA.fm Page 7 Monday, November 15, 2004 3:39 PM

8 • Operation
Electrical ground is only introduced to the housing through
the BNC outer shells, and the power-supply ground pin. If
you use a floating measurement instrument or a floating
power supply, the photoreceiver may not be electrically
grounded.
4. Align an optical beam onto the detector. Be
careful to keep the optical power below the
stated limits to avoid damage to the photore-
ceiver and amplifier circuitry.
5. Adjust the gain. Use the rotary switch on top of
the receiver to set the gain. The table on page 13
gives a detailed description of the different chan-
nel gains and bandwidths associated with each
switch setting.
Checking and Replacing the Battery
The Model 290X is powered by a single, standard 9-volt
alkaline battery. Under normal operating conditions
with low light levels and a high impedance load
attached to the BNC connectors, the photoreceiver
draws about 25 mA from the battery, and the battery
lifetime will be approximately 40 hours.
To check the battery condition, push the power switch
to the BATT CHK position. If the green LED lights up,
the battery is in good condition.
When the battery voltage falls below about 6.5 volts,
the green LED will not light, and the battery should be
replaced.
1. Switch off the power and disconnect any exter-
nal power supply.
2. Remove the screw in the back of the photore-
ceiver casing and remove the back cover.
3. Unplug the old battery by rotating it away from
the circuit board about the snap-on terminal
contacts.
290x quadcell rcvr RevA.fm Page 8 Monday, November 15, 2004 3:39 PM

Model 290X Operation • 9
4. Install a new 9-volt alkaline battery.
5. Reinstall the back cover and screw. Take care not
to pinch the power wires from the external
power connector.
6. Test the new battery by pushing the power
switch to the BATT CHK position.
Using an External Power Supply
The Model 290X can be operated from any power
supply which can supply 50 mA of ±15V DC power.
Newport recommends use of the Model 0901 Power
Supply, which features three pairs of low-noise linear
±15 V DC outputs.
If using the Model 0901 Power Supply, connect the
Model 0923 M8B-to-M8B cable from the power supply
to the jack on the back of the Model 290X.
If using a third-party power supply, connect the Model
9024 banana-plug-to-M8B cable from the power
supply to the jack on the back of the Model 290X. The
red jack should be connected to +15 V DC, the black to
-15 V DC, both withrespect to the green jack, which
should be connected to the power supply COMMON
terminal. It is recommended, but not required to use
the green wire asan earth ground.
290x quadcell rcvr RevA.fm Page 9 Monday, November 15, 2004 3:39 PM

10 • Operation
