Radial Engineering Ltd. SAT-2™ User Guide
6
SPECIFICATIONS*
* Subject to change without notice.
Audio Circuit Type: ����������������������������������������������������������������������������������������������������������������������Passive Audio Signal Path
Number of Channels:�����������������������������������������������������������������������������������������������������������������������������������������������������������2
Frequency Response: ��������������������������������������������������������������������������������������������������������������������������������������20Hz-20kHz
Noise Floor: ������������������������������������������������������������������������������������������������������������������������������������������������������������� -115dBu
Dynamic Range: ���������������������������������������������������������������������������������������������������������������������������������������������������� >141dBu
Maximum Input:������������������������������������������������������������������������������������������������������������������������������������������������������ >+26dBu
Gain:������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 0dB
Intermodulation Distortion:������������������������������������������������������������������������������������������������������������������������� >0.001% @0dBu
Total Harmonic Distortion: ���������������������������������������������������������������������������������������������������������������������� >0.0005% @ 0dBu
Common-Mode Rejection Ratio: �������������������������������������������������������������������������������������������������������������������������������� >80dB
Phase deviation:������������������������������������������������������������������������������������������������������� 0° @ 20Hz, 0° @ 1kHz, +2° @ 10kHz
Input Impedance:�������������������������������������������������������������������������������������������������������������������������������������������������110k Ohms
Output Impedance:���������������������������������������������������������������������������������������������������������������������������������������������� 1�8k Ohms
Insertion Loss: ��������������������������������������������������������������������������������������������������������������������������������������������������������-0�73dBu
Power: ��������������������������������������������������������������������������������������������������������������������������������������� Passive, no power required
Construction: ��������������������������������������������������������������������������������������������������������������� 14 gauge steel chassis & outer shell
Finish:������������������������������������������������������������������������������������������������������������������������������������������������� Durable Powder Coat
Size (L x W x D):����������������������������������������������������������������������������������������������������������������������������������������� 5”x3�312”x1�78”
Weight: ��������������������������������������������������������������������������������������������������������������������������������������������������������0�70kg (1�55lbs)
Conditions:������������������������������������������������������������������������������������������������For use in dry conditions between 5°C and 40°C
Warranty: ������������������������������������������������������������������������������������������������������������������������������������ Radial 3-Year, transferable
