Before you begin
This guide describes the EPC-8A, a highly integrated PC-compatible computer designed
specifically for use in the VMEbus and extended VMEbus (VXIbus) environments.
About this guide
This guide explains how to install, configure, and troubleshoot the EPC-8A, and describes
the EPC-8A and how it works.
Guide contents
Chapters
Appendices
Chapter Description
1 Product description Provides an overview and specifications for the EPC-8A
2 Configuration and Installation Explains how to configure and install the EPC-8A.
3 BIOS Configuration Details the various menus and sub-menus used to
configure the system using the Phoenix BIOS.
4 Theory of Operation Explains how the EPC-8A works.
5 Programming the
VMEbus Interface Describes the EPC-8A VMEbus interface as seen by a program
Appendix Description
A Chipset and I/O Map Defines the I/O addresses decoded by the EPC-8A
B Interrupts and DMA Channels Lists the EPC-8A’s interrupt assignments.
C Connectors Specifies the EPC-8A’s connector details.
D Memory Lists the EPC-8A’s SIMM specifications.
E Subplanes Describes how to install subplanes in the EPC-8A.
F Registers Defines registers in the I/O space specific to the EPC-8A.
G XFORMAT Software for
the EPC-8A Explains when to use the XFORMAT utility.
H AUTOSET Software Describes how to use the AUTOSET program to
configure the Ethernet controller.
I SVGA Provides operating instructions for user utilities and
installation instructions for the display drivers supplied
with your Chips and Technologies SVGA for the EPC-8A

EPC-8A Hardware Reference
iv
Notational conventions
This manual uses the following conventions:
• All numbers are decimal unless otherwise stated.
• Bit 0 is the low-order bit. If a bit is set to 1, the associated description is true unless
otherwise stated.
• Data structures and syntax strings appear in this font.
Where to get more information
You can find out more about the EPC-8A from these sources:
•Readme file: Lists features and issues that arose too late to include in
other documentation.
•RadiSys web site: Go to www.radisys.com
J Error Messages and Diagnosis Provides troubleshooting information in these areas:
• Problems that do not display an error message.
• Beep codes (audible codes consist of patterns of
beeps and pauses).
• Error and warning messages.
K Configuring the Ethernet Drivers Provides instructions for configuring network interface
drivers after you install the EPC-8A.
Notes indicate important information
about the product. Cautions indicate situations that may result in damage to data or the
hardware.
Tips indicate alternate techniques
or procedures that you can use to
save time or better understand
the product.
Warnings indicate situations that may
result in physical harm to you or the
hardware.
Appendix Description

v
