RADLEY 5124-216 User manual

5124-216
WEAR A
FACE MASK
WEAR EAR
PROTECTION
WEAR CSA APPROVED
EYE PROTECTION
3042597
READ ALL INSTRUCTIONS BEFORE FIRST USE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
KEEP AWAY FROM CHILDREN.
*Maximum initial battery voltage (measured without a load)
is 20 volts. Normal voltage is 18 volts.
JD580320
3Year warranty
Includes 1 battery & 1 charger

1
PRODUCT SPECIFICATIONS
BATTERY AND CHARGER
Blower/Sweeper
20V 2.0 Ah Li-ion (Maximum charged
battery voltage, measured without load,
is 20V with a nominal value of 18V)
Need Assistance?
Call us on our toll free customer support line:
1-866-349-8665 (Monday through Friday 9am – 5pm Eastern Time)
Technical questions
Replacement parts
Parts missing from package
Battery voltage:
130 MPH
18.5” (470 mm)
92 dBA (maximum)
3 lbs 9 oz
Air speed
Blower/Sweeper tube
Noise level
Weight
Charger
Replacement battery
Replacement charger
Up to 70 minutes, Class 2
5350-547
DL125481
Cordless Blower / Sweeper - Owner’s Manual

2
5124-216
Product specifications
Table of contents
General safety warnings
Important safety instructions
Safety symbols
Electric gardening tool safety
General safety warnings
Work area safety
Electrical safety
Personal safety
Service
Specific safety rules
Battery & charger safety
Battery pack recycling
Symbols
Know your blower
Know your battery
Assembly and operating
Charging the battery pack
Installing the battery pack in the blower
Assemble & install nozzle
ON/OFF switch
Operating the blower
Cleaning the air intake
Maintenance
Battery pack removal and preparation for recycling
Exploded view
Parts list
Warranty
………….……………………………………………………………1
..………….……………………………………………………………2
...….……………………………………………………………3-5
..……………………………………………………………3
.……….……………………………………………………………3-5
.....………………………………………………………5-7
....…….……………………………………………………………5
..………….……………………………………………………………5
.……….……………………………………………………………5-6
.……….……………………………………………………………6-7
..………….……………………………………………………………7
...…….……………………………………………………………7-12
....……………………………………………………………12-13
.....…….……………………………………………………………13
...……….……………………………………………………………14
...……….……………………………………………………………15
...……….……………………………………………………………16
....……………………………………………………………17-20
...….……………………………………………………………17
..……………………………………………18
.…….……………………………………………………………18
...……….……………………………………………………………18
...……….……………………………………………………………19
...….……………………………………………………………19-20
………….……………………………………………………………21
……………………………21
………….……………………………………………………………22
………….……………………………………………………………23
………….……………………………………………………………24
TABLE OF CONTENTS

3
READ ALL INSTRUCTIONS BEFORE USING THIS BLOWER
GENERAL SAFETY WARNINGS
IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL SAFETY AND OPERATIONAL INSTRUCTIONS.
Failure to follow the safety rules listed below and other basic safety precautions
may result in serious personal injury. KEEP THIS MANUAL, SALES RECEIPTS
AND APPLICABLE WARRANTY FORMS FOR FUTURE REFERENCE.
Safety Symbols
SYMBOL MEANING
The purpose of safety symbols is to alert you of the potential safety RISKS.
Recognize and understand them. Follow the instructions provided.
Failure to obey a DANGER safety alert WILL result in
serious personal injury or death to you or to others.
Always obey all messages following this symbol to
reduce the risk of serious personal injury or death.
Failure to obey a WARNING safety alert MAY result in
serious personal injury or death to you or to others.
Always obey all messages following this symbol to
reduce the risk of potential serious personal injury or
death.
Failure to obey a CAUTION safety alert MAY result in
personal injury or property damage to you or to others.
Always obey all messages following this symbol to
reduce the risk of personal injury or property damage.
This instruction manual includes the following:
• General Safety Rules
• Specific Safety Rules and Symbols
• Functional Description
•Assembly
• Operation
• Maintenance
• Accessories
Cordless Blower / Sweeper - Owner’s Manual

4
5124-216
READ ALL INSTRUCTIONS BEFORE USING THIS BLOWER
SYMBOL MEANING
Failure to obey a NOTICE or a CAUTION (without a
safety alert) MAY result in property damage to you or to
others. Always obey all messages following this symbol
to reduce the risk of property damage.
ALWAYS WEAR EYE PROTECTION THAT CONFORMS
WITH CSA Z94.3 or ANSI SAFETY STANDARD Z87.1
Noncompliant eyewear can cause serious injury if
broken during the operation of a power tool.
Use hearing protection, particularly during extended
periods of operation of the tool, or if the operation is
noisy.
WEAR A DUST MASK THAT IS DESIGNED TO BE USED
WHEN OPERATING A POWER TOOL IN A DUSTY
ENVIRONMENT.
Always wear nonslip gloves that fit properly to protect
your hands and to help you grip the tool.
Always wear sturdy clothing with long sleeves and long
pants. Never operate the tool while wearing shorts, short
sleeve shirts or shirtless.
Always wear nonslip safety boots to prevent foot injuries
and slipping that could cause loss of control of the tool.
FLYING DEBRIS can cause permanent eye damage.
Prescription eyeglasses ARE NOT a replacement for
proper eye protection. The usage of a safety standard
compliant face shield placed over proper safety glasses
or goggles can reduce the risk of facial injury.

SAVE THESE INSTRUCTIONS FOR REFERENCE
5
ELECTRIC GARDENING TOOL SAFETY
GENERAL SAFETY WARNINGS
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the
liquids, fumes or dust.
Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
General Electric Gardening Tool Safety Warnings – Electrical Safety
Battery charger plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) chargers. Unmodified plugs
and matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces such as water pipes. There is
an increased risk of electrical shock if your body is earthed or grounded.
Save all warnings and instructions for future reference.
General Electric Gardening Tool Safety Warnings – Work Area Safety
SYMBOL MEANING
To avoid electrical hazards, fire hazards or damage to the
tool, use proper circuit protection.
This tool is wired at the factory for 120 V AC operations.
It must be connected to a 120 V AC, 15 A circuit that is
protected by a time-delayed fuse or circuit breaker. To
avoid shock or fire, replace power cord immediately if it
is worn, cut or damaged in any way.
WARNING: Ventilation openings in batteries and
chargers must always be open to allow cooling air to
circulate freely. Air vents that are blocked, restricted or
covered may result in the battery or charger overheating.
Overheating may lead to damage to the tool or cause a
fire, resulting in possible serious injury.
Cordless Blower / Sweeper - Owner’s Manual

6
5124-216
SAVE THESE INSTRUCTIONS FOR REFERENCE
Do not expose power tools, battery chargers or batteries to rain or wet conditions.
Water entering the tool, chargers or batteries will increase the risk of electric
shock.
Do not abuse the cord. Never use the power cord for carrying, pulling or unplugging
the charger. Keep the power cord away from heat, oil, sharp edges, and moving
parts. Damaged or entangled cords increase the risk of electric shock.
When operating the charger outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
Never operate a power tool in the rain.
If operating a charger in a damp location is unavoidable, use a residual current
device (RCD) protected supply. An RCD is also known as a ground fault circuit
interrupter (GFCI) or earth leakage circuit breaker (ELCB). Use of an RCD reduces
the risk of electric shock.
General Electric Gardening Tool Safety Warnings – Personal Safety
Stay alert, be aware of your surroundings, watch what you are doing and use
common sense when operating a power tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating a power tool may result in serious personal injury.
Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, nonskid safety shoes or boots, sturdy gloves,
durable long pants, long sleeve shirt and hearing protection will reduce the risk
of personal injuries.
Prevent unintentional starting. Ensure the switches are in the o-position before
connecting the battery to the power tool or plugging it into the power supply.
Never pick up or carry the power tool with your finger on the trigger switch.
Carrying power tools with your finger on the switch or energizing power tools
that have the switch on invites accidents.
Remove any adjustment key or wrench before turning the power tool on. A wrench
or a key left attached to a rotating part of the power tool may result in personal
injury.
Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothing, jewellery or long hair can be
caught in moving parts.

7
SAVE THESE INSTRUCTIONS FOR REFERENCE
SPECIFIC SAFETY RULES
Do not force the tool. Use the correct tool for the application. The correct power
tool will do the job better and safer when used at the rate for which it was
designed.
Do not use a power tool if the switch does not turn it on or o. Any power tool that
cannot be controlled using the switch is dangerous and must be repaired.
Remove the battery from the power tool or the plug from the power source before
making any adjustments, replacing or repairing parts, cleaning the tool, leaving the
tool idle or unattended, transporting or storing the tool. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may aect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
Use the power tool and accessories in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the
power tool for operations different from those intended could result in a
hazardous situation.
General Electric Gardening Tool Safety Warnings – Service
Have your power tool or charger serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool or
charger is maintained.
WARNING: Some dust created by power sanding, sawing, grinding, drilling,
and other construction activities contain chemicals known to cause cancer, birth
defects, or other reproductive harm. Some samples of these chemicals are:
• lead from lead-based paints
• crystalline silica from bricks and cement and other masonry products
• arsenic and chromium from chemically-treated lumber
Cordless Blower / Sweeper - Owner’s Manual

8
5124-216
SAVE THESE INSTRUCTIONS FOR REFERENCE
WARNING: Know your leaf blower. Do not plug in the charger or
install the battery onto the tool until you have read and understand this
Instruction Manual. Learn the tool’s applications and limitations, as well as
the general and specific potential hazards related to this tool. Following these
instructions will reduce the risk of electric shock, fire or serious injury.
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well-ventilated
area, and work with approved safety equipment, such as those dust masks that
are specially designed to filter out microscopic particles.
WARNING: Prevent foot injuries! Never operate when barefoot, or
wearing open toed shoes, or sandals. Always, wear sturdy protective
shoes or boots with nonslip soles when operating the leaf blower.
Steel-toed safety boots are recommended.
WARNING: Protect your hands by wearing heavy-duty, nonslip
gloves and to improve your grip and control when handling the blower.
WARNING: Glasses, goggles or face shields not in compliance with ANSI Z87.1
or CAN/CSA – Z94.3 could cause serious injury if they break upon impact.
WARNING: Avoid loose clothing such as scarves, neckties, jewellery, flared
or cuffed pants, loose-fitting shirts or jackets, unconfined long hair or anything
that can be pulled into the air intake of the blower. Secure hair to above
shoulder level. Wear long pants of durable material to protect your legs.
WARNING: Always wear appropriate eye protection. Any power
tool can throw foreign objects into your eyes and cause permanent
eye damage. ALWAYS wear appropriate safety goggles or properly
fitted safety glasses that comply with the most recent version of
ANSI Z87.1 safety standards. Ordinary vision or sunglasses generally
do not provide adequate impact or side shield / wrap around penetration
protection. Ordinary glasses ARE NOT safety glasses. To reduce the risk of
injury to your face you should also wear a face shield over your safety goggles
or safety glasses.
WARNING: Clothing must be durable and snug-fitting, yet allow
for freedom of movement.

9
SAVE THESE INSTRUCTIONS FOR REFERENCE
Cover as much of your body as possible to help protect you from debris and
pieces of toxic and allergenic plants being thrown by the blower.
Thrown objects may also ricochet and strike the operator or bystander.
Utilize extra caution, when the blower is being used near, or on paved or hard
surfaces, as pieces of metal, concrete, brick, stones, gravel, sand, glass, sticks
and other objects can be thrown at high speed and force and such objects can
be thrown, skip along or ricochet long distances off of hard surfaces.
Do not use this blower for sweeping debris that may contain hard objects, e.g.
pebbles, stones, sticks, glass, metal, etc. as such hard objects can be thrown
with great force and cause injury to the operator or bystanders, and / or
damage property, e.g., screens, windows, building siding, glass doors, or
vehicles.
Avoid operating the blower near property that can be easily damaged by
thrown or ricocheting objects such as screens, windows, building siding, glass
doors and vehicles.
WARNING: Use hearing protection. Use hearing protection such as
ear plugs or ear mufflers to protect your hearing, particularly if the
blower is used for extensive periods or if the surrounding environment
of operation exposes the operator to loud noises. When wearing hearing
protection, you will have impaired ability to hear alarms, warnings and shouts
from approaching people or approaching vehicles. Be extra diligent and
observant of hazards and bystanders when wearing hearing protection
devices. When someone approaches, turn the blower OFF immediately.
WARNING: Always wear breathing protection when operating
the blower. Bystanders should be encouraged to wear breathing
protection devices even if they are kept at a distance as hazardous
dust can travel considerable distances, especially if the dust is wind blown.
WARNING: The high velocity of the air flow coming through the
nozzle will throw objects and debris violently. These objects and
debris will ricochet in all directions. You or bystanders can be blinded or
injured. Keep children, bystanders, pets and other animals at least 50 feet (15
meters) away from the operating blower. Turn the blower OFF immediately if
approached, or if you are approaching such bystanders. Bystanders should be
encouraged to wear eye protection, even if they are kept at a distance.
Cordless Blower / Sweeper - Owner’s Manual
