RADLEY 5125-018 User manual

1
PRODUCT SPECIFICATIONS
40 V Max Lawn Mower
Owner’s Manual
Need Assistance?
Call us on our toll free customer support line:
1-866-349-8665 (Monday through Friday 9am – 5pm Eastern Time)
Technical questions
Replacement parts
Parts missing from package
BATTERY AND CHARGER
17” 40V BRUSHLESS LAWN MOWER
2x20V 5 Ah Li-ion (Maximum charged
battery voltage, measured without load,
is 20V with a nominal value of 18V)
Battery voltage:
Dual Charger
Replacement battery
Replacement charger
Up to 180 minutes
5350-014
5350-046
40V (2 x 20V) No Load
3300 RPM
15-3/4" (40cm)
45L (11.9 gal)
31.7 lbs (14.4kg)
Voltage
No load
Clearing Width
Bag Capacity
Weight

2
5125-018
Product specifications
Table of contents
General safety warnings
Electrical safety
Lawn mower safety
Battery Pack & Charger Safety
Recycling and disposal
Symbols
Know your lawn mower
Assembly
Operation
Maintenance
Exploded view
Parts list
Warranty
………….……………………………………………………………1
………….……………………………………………………………2
……….……………………………………………………………3
……………………………………………………………………3-4
……….……………………………………………………………4-6
…………………………………………………………6-8
……….……………………………………………………………9
…….……………………………………………………………10-12
…………………………………………………………13
….……………………………………………………………14-17
….……………………………………………………………17-20
.….……………………………………………………………21-23
……….……………………………………………………………24
….……………………………………………………………25-27
…….………………………………………………………………28
TABLE OF CONTENTS

3
SAVE THESE INSTRUCTIONS FOR REFERENCE
40 V Max Lawn Mower
Owner’s Manual
IMPORTANT SAFETY INSTRUCTIONS
Read and understand all safety and operational instructions. Failure to follow the
safety rules listed below and other basic safety precautions may result in serious
personal injury. Keep this manual, sales receipts and applicable warranty forms
for future reference.
GENERAL SAFETY WARNINGS
WARNING: Before using this tool or any of its accessories, read this manual
and follow all safety rules and operating instructions. The important precautions,
safeguards and instructions appearing in this manual are not meant to cover all
possible situations. It must be understood that common sense and caution are
factors which cannot be built into the product.
EYE, EAR & LUNG PROTECTION
ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH CSA
REQUIREMENTS OR ANSI SAFETY STANDARD Z87.1
FLYING DEBRIS can cause permanent eye damage. Prescription eyeglasses are
not a replacement for proper eye protection.
WARNING: Noncompliant eyewear can cause serious injury if broken during
the operation of a garden tool.
WARNING: Use hearing protection, particularly during extended periods of
operation of the tool, or if the operation is noisy.
Lead from lead-based paints.
Crystalline silica from bricks, cement, and other masonry products. Arsenic and
chromium from chemically treated lumber.
The level of risk from exposure to these chemicals varies, according to how often
this type of work is performed. In order to reduce exposure to these chemicals,
work in a well- ventilated area, and use approved safety equipment, such as a
dust mask that is specifically designed to filter out microscopic particles.
ELECTRICAL SAFETY
WARNING: To avoid electrical hazards, fire hazards or damage to the tool,
use proper circuit protection.
WEAR A DUST MASK THAT IS DESIGNED TO BE USED WHEN
OPERATING A GARDON TOOL IN A DUSTY ENVIRONMENT.
WARNING: Dust that is created by power sanding, sawing, grinding, drilling,
and other construction activities may contain chemicals that are known to cause
cancer, birth defects, or other genetic abnormalities. These chemicals include:

4
5125-018
READ ALL INSTRUCTIONS BEFORE USING THIS 40V BRUSHLESS LAWN MOWER
LAWN MOWER SAFETY
WARNING: Ventilation openings in batteries and chargers must always
be open to allow cooling air to circulate freely. Air vents that are blocked,
restricted or covered may result in the battery or charger overheating. Overheating
may lead to damage to the tool or cause a fire, resulting in possible serious injury.
This product is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the product by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
product. Cleaning and user maintenance shall not be made by children
without supervision.
SAFETY WARNINGS
1.
2.
Read the instructions carefully. Be familiar with the controls and the proper
use of the product.
Never allow children or people unfamiliar with these instructions to use the
product. Local regulations can restrict the age of the operator.
Never mow while people, especially children, or pets are nearby.
Keep in mind that the operator or user is responsible for accidents or
hazards occurring to other people or their property.
SAFETY WARNINGS FOR BATTERY POWERED LAWN MOWER OPERATION
1.
2.
3.
4.
While mowing, always wear substantial footwear and long trousers. Do not
operate the product when barefoot or wearing open sandals. Avoid wearing
clothing that is loose fitting or that has hanging cords or ties.
Thoroughly inspect the area where the product is to be used and remove all
objects which can be thrown by the product.
Before using, always visually inspect to see that the cutting device, cutting
device bolts and cutting device assembly are not worn or damaged. Replace
worn or damaged cutting devices and bolts in sets to preserve balance. .
Replace damaged or unreadable labels.
PREPARATION
1.
2.
3.
Operate the product in daylight or in good artificial light.
Avoid operating the product in wet grass, where feasible.
Always be sure of your footing on slopes.
Walk, never run.
OPERATION
1.
2.
3.
4.

SAVE THESE INSTRUCTIONS FOR REFERENCE
5
40 V Max Lawn Mower
Owner’s Manual
Keep all nuts, bolts and screws tight to be sure the product is in safe working
condition.
Check the grass catcher frequently for wear or deterioration.
Be careful during adjustment of the product to prevent entrapment of the
fingers between moving blades and fixed parts of the product.
MAINTENANCE AND STORAGE
1.
2.
3.
Allow the product to cool before storing in any enclosure.
When servicing the blades be aware that, even though the power source is
switched off, the blades can still be moved.
Replace worn or damaged parts for safety. Use only genuine replacement
parts and accessories.
4.
5.
6.
Mow across the face of slopes, never up and down.
Exercise extreme caution when changing direction on slopes.
Do not mow excessively steep slopes.
Use extreme caution when reversing or pulling the product towards you.
Stop the cutting device(s) if the product has to be tilted for transportation
when crossing surfaces other than grass, and when transporting the product
to and from the area to be mowed.
Never operate the product with defective guards, or without safety devices,
for example deflectors and/or grass catchers, in place.
Start the product or switch on the product carefully according to instruc-
tions and with feet well away from the cutting device(s).
Do not tilt the product when switching on the motor, except if the product
has to be tilted for starting. In this case, do not tilt it more than absolutely
necessary and lift only the part, which is away from the operator.
Do not start the product when standing in front of the discharge chute.
Do not put hands or feet near or under rotating parts. Keep clear of the
discharge opening at all times.
Never pick up or carry a product while the safety key is inserted.
Stop the machine, and remove the disabling device. Make sure that all
moving parts have come to a complete stop.
- Whenever you leave the product.
- Before clearing blockages or unclogging chute.
- Before checking, cleaning or working on the product.
- After striking a foreign object. Inspect the machine for damage and make
repairs before restarting and operating the product;
if the product starts to vibrate abnormally (check immediately).
- Inspect for damage.
- Replace or repair any damaged parts.
- Check for and tighten any loose parts.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.

6
5125-018
READ ALL INSTRUCTIONS BEFORE USING THIS 40V BRUSHLESS LAWN MOWER
WARNING! Only use the charger supplied with this kit to charge the 20V
Li-ion batteries for this tool. Charging any other batteries may damage the charger
and possibly cause serious injury.
WARNING! Do not store batteries in a garage or shed over the winter as it will
damage battery life.
BATTERY PACK & CHARGER SAFETY
Wear strong work gloves when removing and reassembling the cutting
device.
7.
Recharge only with the charger specified by the manufacturer. A charger that
is suitable for one type of battery pack may create a risk of fire when used
with another battery pack. Incorrect use may result in electric shock,
overheating or leakage of corrosive liquid from the battery.
Use machines only with specifically designated battery packs. Use of any
other battery packs may create a risk of injury and fire.
Be aware of possible hazards when not using your battery tool or when
changing accessories. To reduce risk, remove the safety key and battery pack
from the machine while not in operation. This will reduce the risk of electric
shock, fire or serious personal injury.
Do not place appliances or their batteries near fire or heat. Continuous
intense sunlight, fire or other heat sources may cause an increased danger of
explosion.
Do not crush, drop or damage the battery pack. Do not use a battery pack or
charger that has been dropped or received a sharp blow. A damaged battery
is subject to explosion. Properly dispose of a dropped or damaged battery
immediately.
Batteries can explode in the presence of a source of ignition, such as a pilot
light. To reduce the risk of serious personal injury, never use any cordless
product in the presence of an open flame. An exploded battery can propel
debris and chemicals. If exposed, flush with water immediately.
Do not charge battery in a damp or wet location. Following this rule will
reduce the risk of electric shock.
Longer life and better performance can be obtained if the battery pack is
charged when the air temperature is between 64 degrees F/18 degrees C and
105 degrees F/40.5 degrees C. Do not charge the battery pack in air temperature
below 41 degrees F/5 degrees C or above 105 degrees F/40.5 degrees C. This
is important as it can prevent serious damage to the battery pack.
Under extreme usage or temperature conditions, battery leakage may occur.
If liquid comes in contact with your skin, wash immediately with soap and
1.
2.
3.
4.
5.
6.
7.
8.
9.
BATTERY SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS FOR REFERENCE
7
40 V Max Lawn Mower
Owner’s Manual
When battery pack is not in use, keep it away from other metal objects like:
paper clips, coins, keys, nails, screws, or other small metal objects that can
make a connection from one terminal to another. Shorting the battery
terminals together may cause sparks, burns, or a fire.
Do not disassemble the battery and avoid mechanical damage to the battery.
Risk of short circuit and fumes may be emitted. Ensure fresh air and seek
medical assistance in the event of discomfort.
Always remove battery pack from your tool when you are assembling parts,
making adjustments, cleaning, or when not in use. Removing battery pack
will prevent accidental starting that could cause serious personal injury.
Always remove battery pack before storing the device. When battery
becomes fully charged, unplug the charger from the power supply and
remove the battery pack from the charger.
Keep battery pack dry, clean, and free from oil and grease. Always use a dry
cloth when cleaning. Never use brake fluids, gasoline, petroleum-based
products, or any solvents to clean battery pack.
Keep the battery pack out of the reach of children.
10.
11.
12.
13.
14.
15.
The plug of the charger must match the outlet. Never modify the plug in any
way. Unmodified plugs and matching outlets will reduce the risk of electric
shock.
Ensure the battery pack is charged indoors only, in a dry, cool and well
ventilated environment.
Do not subject the battery to strong sunlight over long periods and do not
leave it near a heat source. Heat damages the battery and there is a risk of
explosion.
Allow a hot battery to cool before charging.
Do not use non-rechargeable batteries!
Do not attempt to charge battery packs other than those supplied. The
charger and battery pack supplied with it are specifically designed to work
together.
Before each use, check the charger, cable and plug. Do not use a defective
charger and do not disassemble the charger. Incorrect reassembly may result
in the risk of fire, electric shock or electrocution.
Protect the charger against moisture and wet conditions. There is a danger of
electric shock.
Operate the charger only with the appropriate original batteries.
Charging other batteries may result in injuries and risk of fire.
1.
2.
3.
4.
5.
6.
7.
8.
9.
CHARGER SAFETY INSTRUCTIONS
water. If liquid gets into your eyes, flush them with clean water for at least 10
minutes, then seek immediate medical attention.

8
5125-018
READ ALL INSTRUCTIONS BEFORE USING THIS 40V BRUSHLESS LAWN MOWER
Avoid mechanical damage to the charger. This can result in internal short
circuits.
Do not operate the charger on easily inflammable surfaces (e.g. paper,
textiles, etc.). The heating of the battery charger during the charging process
could pose a fire hazard.
Do not abuse the cord of the charger. Never use the cord for carrying, pulling
or unplugging the charger.
Keep the cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
Do not operate the charger with a damaged cord or plug, which could cause
shorting and electric shock. If damaged, immediately discontinue use.
Replace the charger with the identical unit as listed in the Product
Specifications in this manual. If the power cord for this equipment is
damaged, it must be replaced by the manufacturer, a customer service agent
of the same or qualified person in order to prevent hazards.
Do not use a charger that has been dropped or received a sharp blow.
The voltage indicated on the charger rating plate must correspond to the
voltage of the power source.
Never touch the mains plug with wet hands.
The battery of the appliance is not fully charged at the time of delivery. It
therefore needs to be fully recharged before you use it for the first time. For
the first recharge cycle, charge the battery pack fully. Slot the battery into
the base and plug the battery charger into an outlet.
It is good practice to unplug the charger and remove the lithium-ion battery
pack when not in use.
This charger is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the charger by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
charger.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.

9
40 V Max Lawn Mower
Owner’s Manual
WARNING! Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with your local
authority or local store for recycling advice.
RECYCLING AND DISPOSAL
Old products are potentially recyclable and do not, therefore, belong in
your household garbage. You are requested to assist us and our contri-
bution to saving resources and protecting the environment by handing
in this product at an equipped collection centre (if there is one
available).
The product comes in a package that protects it against damage during shipping.
Keep the package until you are sure that all parts have been delivered and the
product is function properly. Recycle the package afterwards.
WARNING! Do not dispose of batteries/rechargeable batteries into household
waste!

Only use the battery
charger indoors.
Recycle electrical waste
products in an environ-
mentally safe way where
facilities exist.
10
5125-018
SAFETY SYMBOLS
Ampere
VoltsV
A
Hz
W
kW
L
kg
mA
mAh
Watts
Hertz
Kilowatts
Litres
Kilograms
Milliampere
Milliampere-hour
min-1
mm
dB(A)
S
m/s²
per minute
Millimetre
Metres per second
squared
Unlock / to loosen
Decibel (A-rated)
Seconds
Alternating current
Direct current
Double insulation
No load speed
Diameter
Directional arrow
Polarity
With fuse (xx °C)
Lock / to tighten or secure
WARNING! Please read all of the safety and operating instructions carefully
before using this tool. Please pay particular attention to all sections of this User
Guide that carry warning symbols and notices. Some of the following symbols
may be used on this tool.

Protection class II (Double
insulation)
Guaranteed sound power
level value in dB.
Read the operator’s manual.
Warning! Danger. Inspect the area where the
product is to be used and
remove all objects which
can be thrown by the
product.
If objects are hidden while
operating stop the product
and remove the object.
Cutting device continues
to rotate after the product
is switched off. Wait until
all machine components
have completely stopped
before touching the
product.
Objects thrown by the
product could hit the user
or other bystanders.
Always ensure that other
people and pets remain at
a safe distance from the
product when it is in
operation. In general,
children must not come
near the area where the
product is.
Keep hands and feet away
from sharp rotating parts –
danger of injury! When
cleaning, repairing, or
inspecting, make certain
the cutting device and all
mowing parts have
stopped.
Wear hearing protection.
WARNING! Beware of
electric shocks.
Wear CSA Approved Eye
Protection.
Switch the product off and
remove the battery pack
to disconnect from the
power supply before
assembly, cleaning,
adjustments, maintenance,
storage and transportation.
Wear a face mask.
Wear protective helmet
and eye protection.
Wear protective gloves.
Wear protective footwear.
Do not expose the product
to rain or wet conditions.
Mow across the face of
slopes, never up and down.
11
40 V Max Lawn Mower
Owner’s Manual

12
5125-018
Remove plug from the
power source immediately
if the power cord is
damaged or cut.
Beware of sharp blades.
Blades continue to rotate
after the motor is switched
off - Remove disabling
device before
maintenance.
GO – grass catcher ready
for grass collection STOP
- grass catcher full,
empty it.
Batteries and battery
packs should not be
disposed of with house-
hold waste. Please recycle
where facilities exist.
Check with your Local
Authority or local store for
recycling advice.
Batteries contain
Lithium-ion. Do not
dispose of batteries in
household waste. Do not dispose of battery
packs in rivers or immerse
in water.
Do not expose battery
packs to heat in excess of
45ºC.
Do not dispose of battery
packs in fire. They will
explode or leak and cause
injury.
This symbol designates that this tool is listed with Canadian and U.S.
requirements by cSGSus Testing Laboratories, Inc.
UL1447, CSA C22.2 No.147
GY225404
Approx. charging time

13
40 V Max Lawn Mower
Owner’s Manual
KNOW YOUR 40V BRUSHLESS LAWN MOWER
Quick release
lever
Upper
handlebar
Start lever
Foam
Grip
Lower
handlebar
Height adjustment
lever
Front wheel
Grass
catcher Rear wheel
Battery charger
5350-046 Battery
5350-014
Green
LED
Air vents
Red
LED
Safety
lock-off
switch
Control
cord
Cord
retainer

5125-018
14
UNPACKING
ASSEMBLY
WARNING: The product must be fully assembled before operation! Do
not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to battery power before it is completely
assembled!
NOTE: Take care of small parts that are removed during assembly or when
making adjustments. Keep them secure to avoid loss.
Unpack all parts and lay them on a flat, stable surface.
Remove all packing materials if applicable.
Make sure the delivery contents are complete and free of any damage. If
you find that parts are missing or show damage do not use the product but
contact Customer Service @ 1-866-349-8665. Using an incomplete or
damaged product represents a hazard to people and property.
Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
1.
2.
3.
4.
LOWER HANDLEBAR
Align the mounting hole of the lower handlebar with the bolt of handle
support (Fig. 1).
Attach the washer to the bolt and secure the lower handlebar by turning the
lever(1) up for tightening.
Make sure that the control cord runs up the upper side of the lower handle
bar (right) .
1.
2.
3.
FIG.1
1

15
40 V Max Lawn Mower
Owner’s Manual
UPPER HANDLE BAR
Align the upper handlebar to the lower handlebar and ensure the foam
handle is pointed up when viewed from behind.
Pass the bolts through the mounting holes of handles (Fig. 2).
Attach the washer to the bolt and secure the upper handlebar by turning the
lever up for tightening (Fig.2).
Secure the control cord with two wire clips (Fig. 3).
1.
2.
3.
4.
GRASS CATCHER/MULCHING OPTION
Align and insert the carry handle into the slots of top frame of grass catcher until
both ends "click" into place (Fig. 4). then use screw to fix handle both sides.
The grass catcher is ready for use.
If you choose the mulcher function, then ensure the plate is inserted over the grass
shute, Do not install the grass catcher. Remove plate to use the grass catcher.
1.
2.
3.
Open the deflector guard, hold it in position ; Insert the grass catcher (Fig.5).
Align and hook the grass catcher into the attachment slots of rear discharge
chute.
4.
5.
WARNING: Do not attempt to use the product unless you have either the
grass catcher attached,or if mulching, the mulching plate installed.
Danger of flying objects! The motor must be switched off and the blade
must have stopped rotating before you remove the grass catcher. The
grass catcher must be fully assembled with the top part, bottom part and
collection tongue all in position before first use.
FIG.2 FIG.3
FIG.4 FIG.5

5125-018
16
CHECKING THE BATTERY CHARGE STATUS
CHARGING THE BATTERY PACK
Press and hold the battery status button located on the end of the battery
One or more of the three LED lights in the LED window will come ON to
indicate the amount of charge that is remaining in the battery as follows:
1.
2.
Place the battery charger in a dry location near a 110-120V 60 Hz
electrical outlet (Fig. 7).
Plug the battery charger into the outlet and make sure the green LED
indicator light comes ON. If it does not, refer to the chart (Fig. 8) to identify
the problem.
Turn the battery pack upside down and slide it onto the charger .
1.
2.
3.
The level of charge remaining in the battery can be checked by using the battery
LED power indicator that is contained on the end of the battery.
NOTE: The battery charge remaining may be checked while the battery is
installed in the tool with the ON/OFF switch turned OFF. It may also be checked
while the battery is removed from the tool. DO NOT check the battery charge
remaining while the battery is in the charger.
NOTE: Make sure the grooves in
the sides of the battery slide over
the matching tabs on the charger
until the battery latch “clicks” into
place.
WARNING: Charge in a safe location away from moisture and heat
sources!
You will get a false reading and you may also damage the battery status system.
FIG.6
3. Release the battery status button to turn the LED’s OFF.
1 light
(Red light ON)
2 lights
(R
ed and Orange
light ON)
3 lights
(Red/Orange/Green
ON)
-Fully charged
1/3or less 1/3-2/32/3
Fig. 7

17
40 V Max Lawn Mower
Owner’s Manual
INSTALLING THE BATTERY PACKS
OPERATION
Open the battery compartment cover .
Unplug the safety key(1) (Fig.9).
Remove the discharged battery packs by pressing downward on the battery
release button and sliding the battery pack backward until it is removed from
the battery compartment (Fig. 9).
Slide the fully charged battery packs onto the matching tabs in the battery
compartment where the discharged battery packs have been removed.
Reinstall the safety key .
Close the battery compartment cover.
1.
2.
3.
4.
5.
6.
WARNING: Do not immerse the battery
pack in water. Sudden cooling could
cause a hot battery to explode or leak.
WARNING: Make sure the grooves in the sides of the battery slide over the
matching tabs of the battery compartment. The battery release button will
“click” into place when the battery is fully installed.
ON
OFF
ON
ON
OFF
ON
OFF
OFF
NO
YES
YES
YES
Charger connected to power supply.
Battery being charged.
Battery fully charged.
Battery is charged but not operational
on tool. This may indicate defective /
bad contact on battery or charging
conditions are either too hot or too cold.
Fig. 8
Fig. 9
Green Light Red Light Charging Status
Battery Inserted
Into Charger
NOTE: Mower will only operate when both
batteries are charged and installed.
1

5125-018
18
CUTTING HEIGHT ADJUSTMENT
Press the lever towards the rear wheel (Fig. 10).
Move forward or backward to adjust the cutting height.
Release the lever and ensure it is engaged in the slot properly.
1.
2.
3.
WARNING: Switch the product off and wait until the blade has come to
a complete stop before adjusting the cutting height!
Remove the safety key before adjusting the cutting height!
Adjust the cutting height according to the needs of your lawn. The cutting height
depends on the kind of lawn and its actual height. When mowing high grass, start
with the maximum cutting height and make a second cut with a lower cutting
height.
GRASS CATCHER
Always carry the grass catcher by its carry handle.
WARNING: Do not attempt to use the product without the grass catcher
attached when collecting grass – danger of flying objects!
Switch the motor off and wait that the blade had come to a complete
stop before removing the grass catcher!
INDICATOR
The grass catcher is equipped with a full bag indicator that indicates the filling
progress during operation.
WARNING: Ensure that the lever engages in the slot after each
adjustment.
NOTE: There are 6 cutting height levels available. The adjustable heights are
1" (25mm) to 3" (75mm).
FIG.10 FIG.11

19
40 V Max Lawn Mower
Owner’s Manual
When the hatch is open the grass catcher has sufficient volume left to collect
grass (Fig. 11).
When the hatch is closed, the grass catcher is full and must be emptied
(Fig. 11).
1.
2.
Release the start lever ensuring that the motor has stopped and the blade has
stopped rotating.
Lift the deflector guard and lift the grass catcher off the hooks.
Remove the grass clippings from the rear discharge chute into the grass
catcher. Use a proper tool such as a brush.
Remove the grass catcher by its carry handle .
Empty the grass clippings onto a compost heap.
Re-fit the grass catcher to the product.
1.
2.
3.
4.
5.
6.
WARNING: Never use your hands or feet to remove grass
clippings from the rear discharge chute !
WARNING: In some countries regulations define at what time of the day
and on what special days products are allowed to be used and what
restrictions apply! Ask your community for detailed information and observe
the regulations in order to preserve a peaceful neighbourhood and avoid
committing administrative offences!
EMPTYING THE GRASS CATCHER
Empty the grass catcher frequently during use. Do not wait until it is
completely full. We recommend emptying it when it is half full.
NOTE: A full grass catcher will reduce the performance of this product.
Check the product, its battery pack and charger as well as accessories for
damage before each use. Do not use the product if it is damaged or shows
wear.
Double check that accessories and blade are properly fixed.
Check the battery status. Recharge if necessary.
Always push the product by its handle. Keep the handle dry and free from
lubricant to ensure safe support.
Switch the product off immediately if you are disturbed while working by
other people entering the working area. Always let the product come to
complete stop before leaving it unattended.
Do not overwork yourself. Take regular breaks to ensure you can concentrate
on the work and have full control over the product.
1.
2.
3.
4.
5.
6.
GENERAL OPERATION
