Raisecom iTN8600-I Technical specifications

iTN8600-I (A)
Product Description
(Rel_01)
www.raisecom.com

Raisecom Technology Co., Ltd. provides customers with comprehensive technical support and services. For any
assistance, please contact our local office or company headquarters.
Website: http://www.raisecom.com
Tel: 8610-82883305
Fax: 8610-82883056
Email: export@raisecom.com
Address: Raisecom Building, No. 11, EastArea, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing,
P.R.China
Postal code: 100094
-----------------------------------------------------------------------------------------------------------------------------------------
Notice
Copyright © 2019
Raisecom
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means,
electronic or mechanical, including photocopying and microfilm, without permission in Writing from Raisecom
Technology Co., Ltd.
is the trademark of Raisecom Technology Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.

Raisecom
iTN8600-I (A) Product Description
Preface
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
i
Preface
Objectives
This document describes the iTN8600-I in terms of overview, system structure, product
features, and technical specifications. The appendix lists compliance standards and protocols,
terms, acronyms, abbreviations involved in this document.
Versions
The following table lists the product versions related to this document.
Product name
Hardware version
Software version
iTN8600-I
A.00 or later
7.9 or later
Conventions
Symbol conventions
The symbols that may be found in this document are defined as below.
Symbol
Description
Indicate a hazard with a medium or low level of risk which, if
not avoided, could result in minor or moderate injury.
Indicate a potentially hazardous situation that, if not avoided,
could cause equipment damage, data loss, and performance
degradation, or unexpected results.
Provide additional information to emphasize or supplement
important points of the main text.
Indicate a tip that may help you solve a problem or save time.

Raisecom
iTN8600-I (A) Product Description
Preface
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
ii
General conventions
Convention
Description
Times New Roman
Normal paragraphs are in Times New Roman.
Arial
Paragraphs in Warning, Caution, Notes, and Tip are in Arial.
Boldface
Buttons and navigation path are in Boldface.
Italic
Book titles are in italics.
Lucida Console
Terminal display is in Lucida Console.
Book Antiqua
Heading 1, Heading 2, Heading 3, and Block are in Book
Antiqua.
Change history
Updates between document versions are cumulative. Therefore, the latest document version
contains all updates made to previous versions.
Issue 01 (2019-12-01)
Initial commercial release

Raisecom
iTN8600-I (A) Product Description
Contents
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
iii
Contents
1 Overview.........................................................................................................................................1
1.1 Introduction......................................................................................................................................................1
1.2 Networking application....................................................................................................................................2
1.3 Ordering information........................................................................................................................................6
1.3.1 Device.....................................................................................................................................................6
1.3.2 Purchased parts .......................................................................................................................................8
2 System structure ..........................................................................................................................12
2.1 Hardware structure.........................................................................................................................................12
2.2 Software structure ..........................................................................................................................................13
3 Cards and parts............................................................................................................................14
3.1 iTN8600-I-XT4D...........................................................................................................................................14
3.1.1 Version ..................................................................................................................................................14
3.1.2 Appearance............................................................................................................................................14
3.1.3 Functions...............................................................................................................................................15
3.1.4 Interfaces...............................................................................................................................................17
3.1.5 LEDs.....................................................................................................................................................18
3.2 DC power supply RPD1304-48S12 ...............................................................................................................18
3.2.1 Version ..................................................................................................................................................18
3.2.2 Appearance............................................................................................................................................18
3.2.3 Functions...............................................................................................................................................19
3.2.4 Interface ................................................................................................................................................19
3.2.5 LED.......................................................................................................................................................19
3.2.6 Technical specifications ........................................................................................................................20
3.2.7 Cable.....................................................................................................................................................20
3.3 AC power supply RPA1171-220S12..............................................................................................................20
3.3.1 Version ..................................................................................................................................................20
3.3.2 Appearance............................................................................................................................................20
3.3.3 Functions...............................................................................................................................................21
3.3.4 Interface ................................................................................................................................................21
3.3.5 LED.......................................................................................................................................................21
3.3.6 Technical specifications ........................................................................................................................22
3.3.7 Cable.....................................................................................................................................................22

Raisecom
iTN8600-I (A) Product Description
Contents
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
iv
3.4 Fan FANS383.................................................................................................................................................22
3.4.1 Version ..................................................................................................................................................22
3.4.2 Appearance............................................................................................................................................22
3.4.3 Functions...............................................................................................................................................23
3.5 Default configurations....................................................................................................................................23
4 Technical specifications.............................................................................................................24
4.1 Overall specifications.....................................................................................................................................24
4.2 Laser safety class............................................................................................................................................25
4.3 Reliability specifications................................................................................................................................25
4.4 EMC specifications ........................................................................................................................................26
4.5 Security standards ..........................................................................................................................................26
4.6 Environmental requirements ..........................................................................................................................26
4.6.1 Storage environment .............................................................................................................................26
4.6.2 Transport environment..........................................................................................................................28
4.6.3 Operating environment .........................................................................................................................29
5 Appendix ......................................................................................................................................32
5.1 Lookup table of optical module parameters...................................................................................................32
5.1.1 USFP+...................................................................................................................................................33
5.1.2 DSFP+...................................................................................................................................................34
5.1.3 RSP .......................................................................................................................................................37
5.1.4 UQSP....................................................................................................................................................39
5.1.5 UQP ......................................................................................................................................................40
5.1.6 UC2.......................................................................................................................................................41
5.2 Cables.............................................................................................................................................................42
5.2.1 Fiber......................................................................................................................................................42
5.2.2 Ethernet cable........................................................................................................................................45
5.2.3 Configuration cable...............................................................................................................................47
5.2.4 Power cables .........................................................................................................................................48
5.2.5 Ground cable.........................................................................................................................................52
5.3 Compliant standards and protocols ................................................................................................................54
5.4 Terms..............................................................................................................................................................55
5.5 Acronyms and Abbreviations ......................................................................................................................... 57

Raisecom
iTN8600-I (A) Product Description
Figures
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
v
Figures
Figure 1-1 Front appearance of the iTN8600-I-XT4D-AC....................................................................................2
Figure 1-2 Front appearance of the iTN8600-I-XT4D-DC....................................................................................2
Figure 1-3 Appearance of the iTN8600-I-XT4D-AC and iTN8600-I-XT4D-DC..................................................2
Figure 1-4 Typical point-to-point application ........................................................................................................4
Figure 1-5 Typical point-to-point WDM application .............................................................................................5
Figure 1-6 Typical ring network application..........................................................................................................6
Figure 2-1 Hardware structure .............................................................................................................................12
Figure 2-2 Software structure...............................................................................................................................13
Figure 3-1 Appearance of the iTN8600-I-XT4D..................................................................................................15
Figure 3-2 Panel of the DC power supply............................................................................................................19
Figure 3-3 Panel of the AC power supply............................................................................................................21
Figure 3-4 Panel of the fan...................................................................................................................................23
Figure 5-1 LC/PC fiber connector........................................................................................................................ 42
Figure 5-2 MPO fiber connector..........................................................................................................................43
Figure 5-3 MPO-LC branch optical fiber jumper.................................................................................................44
Figure 5-4 Ethernet cable.....................................................................................................................................45
Figure 5-5 Wiring of the straight-through cable...................................................................................................46
Figure 5-6 Wiring of the 100 Mbit/s crossover cable...........................................................................................46
Figure 5-7 Wiring of the 1000 Mbit/s crossover cable.........................................................................................47
Figure 5-8 Configuration cable ............................................................................................................................48
Figure 5-9 DC power cable..................................................................................................................................48
Figure 5-10 Stripping dimensions and connector.................................................................................................50
Figure 5-11 European AC cable ...........................................................................................................................50
Figure 5-12 American AC cable...........................................................................................................................51
Figure 5-13 Ground cable ....................................................................................................................................52
Figure 5-14 OT terminal ......................................................................................................................................52

Raisecom
iTN8600-I (A) Product Description
Tables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
vi
Tables
Table 1-1 Ordering information about device ........................................................................................................6
Table 1-2 Client-side service modes ......................................................................................................................7
Table 1-3 Ordering information about purchased parts..........................................................................................8
Table 1-4 Ordering information about purchased cables........................................................................................9
Table 1-5 Comparison table for services, quantity, panel interfaces, and optical modules ..................................10
Table 3-1 Version of the iTN8600-I-XT4D..........................................................................................................14
Table 3-2 Functions of iTN8600-I........................................................................................................................15
Table 3-3 Interfaces on the iTN8600-I.................................................................................................................17
Table 3-4 LEDs on the iTN8600-I .......................................................................................................................18
Table 3-5 Version of the DC power supply ..........................................................................................................18
Table 3-6 Functions of the DC power supply.......................................................................................................19
Table 3-7 Interface on the DC power supply........................................................................................................19
Table 3-8 LED on the DC power supply..............................................................................................................19
Table 3-9 Technical specifications of the RPD2153-48D483V3..........................................................................20
Table 3-10 DC power cable..................................................................................................................................20
Table 3-11 Version of the AC power supply.........................................................................................................20
Table 3-12 Functions............................................................................................................................................21
Table 3-13 Interface on the AC power supply......................................................................................................21
Table 3-14 LED on the AC power supply ............................................................................................................21
Table 3-15 Technical specifications of the AC power supply RPA1171-220S12.................................................22
Table 3-16 AC power cable..................................................................................................................................22
Table 3-17 Version of the fan ...............................................................................................................................22
Table 3-18 Functions of the fan............................................................................................................................23
Table 3-19 Default configurations of the iTN8600-I-XT4D................................................................................23
Table 4-1 Overall specifications...........................................................................................................................24
Table 4-2 Reliability indexes................................................................................................................................25

Raisecom
iTN8600-I (A) Product Description
Tables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
vii
Table 4-3 Requirements for climatic environment for storage.............................................................................26
Table 4-4 Concentration requirements for the mechanical active substance in storage .......................................27
Table 4-5 Concentration requirements for the chemical active substance in storage ...........................................27
Table 4-6 Climatic environmental requirements in transport...............................................................................28
Table 4-7 Concentration requirements for the mechanical active substance in transport.....................................29
Table 4-8 Concentration requirements for the chemical active substance in transport ........................................29
Table 4-9 Climatic environmental requirements during operation.......................................................................29
Table 4-10 Concentration requirements for the mechanical active substance in operation..................................30
Table 4-11 Concentration requirements for the chemical active substance in operation......................................30
Table 5-1 Parameters of USFP+ module (10 Gbit/s, LC/PC, dual-fiber bidirectional and single-fiber
bidirectional)........................................................................................................................................................33
Table 5-2 Parameters of DSFP+ module (10 Gbit/s, LC/PC, dual-fiber bidirectional, 40 km)............................34
Table 5-3 Parameters of DSFP+ module (10 Gbit/s, LC/PC, dual-fiber bidirectional, 80 km)............................36
Table 5-4 Parameters of RSP module (10 Gbit/s, LC/PC, dual-fiber bidirectional, 10 km).................................37
Table 5-5 Parameters of RSP module (10 Gbit/s, LC/PC, dual-fiber bidirectional, 20 km).................................38
Table 5-6 Parameters of RSP module (10 Gbit/s, LC/PC, dual-fiber bidirectional, 20 km).................................38
Table 5-7 Parameters of RSP module (10 Gbit/s, LC/PC, dual-fiber bidirectional, 40 km).................................38
Table 5-8 Parameters of the UQSP module (41.2Gbit/s, LC/PC, dual-fiber bidirectional)..................................39
Table 5-9 Parameters of the UQSP module (41.2 Gbit/s, MPO)..........................................................................39
Table 5-10 Parameter of the UQSP module (44.6 Gbit/s, MPO)..........................................................................40
Table 5-11 Parameters of the UQP module (103.1 Gbit/s and 111.8 Gbit/s, LC/PC, dual-fiber bidirectional,
UQP-100G/LR4 compatible with 100GE and OTU4, with other models supporting 100GE only) ....................40
Table 5-12 Parameters of the UC2 module (103.1 Gbit/s and 111.8 Gbit/s, LC/PC, dual-fiber bidirectional,
compatible with 100GE and OTU4) ....................................................................................................................41
Table 5-13 Parameters of the UC2 module (103.1 Gbit/s and 111.8 Gbit/s, MPO, compatible with 100GE and
OTU4)..................................................................................................................................................................42
Table 5-14 Wiring of the fiber..............................................................................................................................44
Table 5-15 Wiring of EIA/TIA 568 A and EIA/TIA568 B standards ..................................................................45
Table 5-16 Technical specifications of the Raisecom straight-through cable....................................................... 47
Table 5-17 Technical specifications of the configuration cable............................................................................48
Table 5-18 Technical specifications of the DC power cable.................................................................................48
Table 5-19 Technical specifications of the European AC power cable.................................................................51
Table 5-20 Technical specifications of the American AC power cable ................................................................51
Table 5-21 Technical specifications of the ground cable......................................................................................53
Table 5-22 Technical specifications of the OT terminal.......................................................................................53

Raisecom
iTN8600-I (A) Product Description
Tables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
viii

Raisecom
iTN8600-I (A) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
1
1 Overview
This chapter is an overview of the iTN8600-I, including the following sections:
Introduction
Networking application
Ordering information
1.1 Introduction
The iTN8600-I is an OTN device which belongs to Intelligent Transport Network series.
Cooperating with OTN devices, such as the iTN8600-A, the iTN8600-I provides an OTN
access transport platform which carries high-bandwidth uplink services and multiple access
services, meeting requirements for ever-increasing bandwidths and key customer service
bearing.
The iTN8600-I adopts a standard 19-inch wide and 1U high chassis. It can be installed in the
standard cabinet with depth of 600 mm and width of 19-inch, or on a workbench. The
compact design not only makes the device highly integrated but also reduces the overall space.
The iTN8600-I adopts front outgoing design. All interfaces and power supplies are
located on the front panel. So is the air intake vent for heat dissipation (hollowed part),
as shown in Figure 1-1 and Figure 1-2.
The fan is located on the rear panel. So is the air outlet for heat dissipation, as shown in
Figure 1-3.
Two ground terminals are located on the right part of the left side and right part of the
rear panel, thus facilitating selection of grounding location.
Figure 1-1 shows the front appearance of the iTN8600-I-XT4D-AC.

Raisecom
iTN8600-I (A) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
2
Figure 1-1 Front appearance of the iTN8600-I-XT4D-AC
Figure 1-2 shows the front appearance of the iTN8600-I-XT4D-DC.
Figure 1-2 Front appearance of the iTN8600-I-XT4D-DC
Figure 1-3 shows the appearance of the iTN8600-I-XT4D-AC and iTN8600-I-XT4D-DC.
Figure 1-3 Appearance of the iTN8600-I-XT4D-AC and iTN8600-I-XT4D-DC
1.2 Networking application
The iTN8600-I, oriented to the OTN access network, supports accessing services of 10 Gbit/s
to 100 Gbit/s. It can network with OTN aggregation devices to implement service access,
integration, and multiplexing at the network edge and transmit multi-point services uniformly
with large granularities, thus effectively saving fiber resources on the network.
Basic applications
The iTN8600-I supports accessing multiple types of services, and flexibly scheduling
and forwarding them.
−It supports the CFP2 optical module to transmit 2 ways of 100 Gbit/s OTU4 services
at the line side.
−It supports the QSFP28/QSFP+/SFP+ optical module to transmit 100/40/10 Gbit/s
100GE/OTU4/40GE/10GE/OTU2/OTU2e/STM-64 services and 8/10/16G FC
services at the client side.All client-side interfaces share up to 200 Gbit/s bandwidth.

Raisecom
iTN8600-I (A) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
3
−The line-speed forwarding bandwidth is 200 Gbit/s.
−The OTN cross-connection capacity is 400 Gbit/s.
The iTN8600-I supports multiple networking modes.
−Point-to-point networking: two iTN8600-I devices can transmit services point to
point. They adopt OCh 1+1 protection at the line side, or cooperate with other OLP
devices to implement protection.
−Ring networking: multiple iTN8600-I devices form a ring network to transmit
services. Each can transmit services upstream and downstream and transparently
transmit services. They adopt ODUk SNCP 1+1 protection at the line side to form the
ring network service route in two directions.
−Chain networking: multiple iTN8600-I devices form a chain network to transmit
services. Each can transmit services upstream and downstream and transparently
transmit services. No protection is adopted at the line side.
The iTN8600-I or iTN8600-A and iTN remote devices support uniform network
management, so they support services accessed through end-to-end management.
−The iTN8600-I supports Data Communication Network (DCN) network management
in both the in-band mode and out-of-band mode.
−Two iTN8600-I devices support GCC management channel at the line side between
them.
−The iTN8600-I client side and iTN8600-A line side supports the GCC or VLAN
management channel between them.
−The iTN8600-A and iTN remote device support the GCC or VLAN management
channel between them.
Typical point-to-point application
As shown in Figure 1-4, the iTN8600-I, as the access OTN device, can be directly
connected to the iTN8600 or the client device with services of multiple rates, and access
and carry services with high bandwidth.
OTN interfaces at the line side are connected point to point to aggregate accessed
services.

Raisecom
iTN8600-I (A) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
4
Figure 1-4 Typical point-to-point application
OTU1
OTU2
iTN8600-A
OTU2
FE/GE/10GE/
STM-N
Access OTN
remote device
iTN8600-I
10GE/STM-64
40GE/100GE
8G/10G/16G FC
customer device
NView NNM
DCN
iTN8600-I
OTU4
iTN8600-A
OTU1
OTU2
FE/GE/10GE/
STM-N
10GE/STM-64
40GE/100GE
8G/10G/16G FC
customer device
Access OTN
remote device
OTU2
Dual fibers
Typical point-to-point WDM application
As shown in Figure 1-5, based on point-to-point application, the iTN8600-I is connected
downstream to the WDM network, so it supports higher bandwidth, 10/100 Gbit/s hybrid
transmission, and smooth upgrade.

Raisecom
iTN8600-I (A) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
5
Figure 1-5 Typical point-to-point WDM application
OTU1
OTU2
iTN8600-A
OTU2
FE/GE/10GE/
STM-N
Access OTN
remote device
iTN8600-I
10GE/STM-64
40GE/100GE
8G/10G/16G FC
customer device
NView NNM
DCN
iTN8600-I
OTU4
iTN8600-A
OTU1
OTU2
FE/GE/10GE/
STM-N
10GE/STM-64
40GE/100GE
8G/10G/16G FC
customer device
Access OTN
remote device
OTU2
WDM
Dual fibers
Typical ring network application
As shown in Figure 1-6, line-side interfaces on the iTN8600-I support forming a ring
network.
The client-side interface supports transmitting multiple types of services upstream and
downstream and form the ring network service route of two directions through ODUk
SNCP 1+1 protection.

Raisecom
iTN8600-I (A) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
6
Figure 1-6 Typical ring network application
OTU1
OTU2
iTN8600-A
OTU2
FE/GE/10GE/
STM-N
Access OTN
remote terminal
10GE/STM-64
40GE/100GE
8G/10G/16G FC
customer device
NView NNM
DCN
OTU4
iTN8600-A
OTU1
OTU2
FE/GE/10GE/
STM-N
10GE/STM-64
40GE/100GE
8G/10G/16G FC
customer device
Access OTN
remote terminal
OTU2
iTN8600-I
100 Gbit/s ring
network
Dual fibers
1.3 Ordering information
1.3.1 Device
错误!未找到引用源。 lists ordering information about the iTN8600-I.
Table 1-1 Ordering information about device
Model
Description
iTN8600-
I-XT4D
The iTN8600-I-XT4D supports OTN Muxponder, Transponder, and ADM
applications.
The line side supports the CFP2 optical module to transmit 2 ways of 100
Gbit/s OTU4 services at the line side.
The client side supports the QSFP28/QSFP+/SFP+ optical module to
transmit 100/40/10 Gbit/s 100GE/OTU4/40GE/10GE/OTU2/OTU2e/STM-
64 services and 8/10/16G FC services. All client-side interfaces share up to
200 Gbit/s bandwidth.
Client-side interfaces support up to 2 ways of 100 Gbit/s (QSFP28)
services, 2 ways of 40 Gbit/s (QSFP+) services, 12 ways of 16G FC
(SFP+), and 20 ways of 10G Any services (16 ways of SFP+ services and 1
way of QSFP+ PSM4 services).
The line side supports OCh 1+1 protection and ODUk SNCP 1+1
protection.
When the iTN8600-I-XT4D accesses OTU2/OTU4 services at the client
side, it supports OCh 1+1 protection and ODUk SNCP 1+1 protection.
When it accesses other services, it supports interface protection.
The NMS channel supports SNMP out-of-band network management and

Raisecom
iTN8600-I (A) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
7
Model
Description
GCC or VLAN in-band network management.
Two types of power supplies support 1+1 protection. The iTN8600-I-
XT4D-DC is the dual -48 VDC power model. The iTN8600-I-XT4D-AC is
the dual 220 VDC power model.
The 10GAny services include 10GE/OTU2/OTU2e/STM-64/8G FC/10G FC
services.
Two power supplies support automatic 1+1 hot backup. They must be connected
to different power sourcing equipment or lines to prevent the iTN8600-I from being
powered off due to power failure of one power sourcing equipment or line.
There are 6 modes for client-side services. The maximum total bandwidth of
services on all client-side interfaces is 200 Gbit/s. Table 1-2 lists different modes,
and corresponding customer services, available interfaces on panels, matching
optical modules, and client-side ODUk cross connection.
When the QSFP+ PSM4 and MPO-LC branch optical fiber jumper are used on
interface 17 on the front panel, it supports being fanned out into four 10 Gbit/sAny
service SFP+ interfaces (numbering 19 to 22).
The iTN8600-I-XT4D does not support hybrid usage of one DC power supply and
one AC power supply.
Table 1-2 Client-side service modes
Mode
Client-side
service
Panel interface
Optical module
encapsulation type
Client-side
ODUk cross
connection
100GE
100GE
17–18
QSFP28
Not supported
OTU4
OTU4
17–18
QSFP28
Supported
40GE
40GE
17–18
QSFP+
Not supported
16G FC
5–16
SFP+(it needs to
supports 16G FC, up
to 6 ways)
10G Any
5–16
SFP+
Mappe
r
16G FC
1–8
SFP+(it needs to
supports 16G FC, up
to 6 ways)
Not supported
9–16
SFP+(it needs to
supports 16G FC, up
to 6 ways)
10G Any
1–16
SFP+
17 (fanned out into
4 interfaces
numbering 19–22)
QSFP+ PSM4

Raisecom
iTN8600-I (A) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
8
Mode
Client-side
service
Panel interface
Optical module
encapsulation type
Client-side
ODUk cross
connection
OTN
OTU2
1–16
SFP+
Supported
17 (fanned out into
4 interfaces
numbering 19–22)
QSFP+ PSM4
Hybrid
16G FC
9–16
SFP+(it needs to
supports 16G FC, up
to 6 ways)
Not supported
(namely,
Mapper mode)
10G Any
9–16
SFP+
OTU2
1–8
SFP+
Supported
(namely, OTN
mode)
17 (fanned out into
4 interfaces
numbering 19–22)
QSFP+ PSM4
The QSFP+ is a 40GE optical module, using the fiber with the Little Connector
(LC) interface.
The QSFP+ PSM4 is a 410GE optical module, using the fiber with the Multiple-
Fiber Push-On (MPO) interface.
QSFP+PSM4 fanout: when the QSFP+ PSM4 optical module uses the MPO-LC
branch optical fiber jumper, one MPO interface fiber can be fanned out into 4 dual-
fiber LC interface fibers to be connected to 4 SFP+ optical modules.
1.3.2 Purchased parts
Parts
The power supplies, fans, rack mount kits (brackets) can be additionally purchased.
Table 1-3 Ordering information about purchased parts
Model
Description
RPD1304-48S12
-48 VDC power supply
Power input: -48 V, 4 A
RPA1171-220S12
220 VAC power supply
Power input: 100–240 V, 1.9 A, 50/60 Hz
FANS383
Fan
Power supply black
panel/RoHS
Power supply black panel, with the ordering model of
RC8.041.1349
Rack mount
kit/RoHS
Bracket used for the 19-inch cabinet, with the ordering model of
RC8.043.169

Raisecom
iTN8600-I (A) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
9
When only one power supply is used, install a black panel over the position of the
other power supply. The black panel has the following functions:
Prevent human body from touching circuit boards inside the chassis, thus
avoiding danger.
Prevent dusty or foreign matter from entering the chassis.
Keep the chassis meeting requirements for EMC and electrostatic shielding.
Keep correct direction of cooling air flow inside the chassis.
Cables
The configuration cable and power cable are delivered with the iTN8600-I, and they can
be additionally purchased.
The power cable depends on the actual situation of the target area. When you order the
iTN8600-I, specify one power cable. You can also purchase multiple power cables.
For the DC power model, only the 3-pin connector, rather than the DC power cable, is
delivered, so you need to make the DC power cable according to the regional standard
and Table 5-19 by connecting the 3-pin connector with the DC power cable, as shown in
Figure 5-10.
Table 1-4 Ordering information about purchased cables
Model
Description
CBL-USB-USB-AM/USB-AM-
1.5m/RoHS
Configuration cable, used on the Console interface
POL-AC-European 3-
pin/receptacle-AC power cable-
0.75mm2-1.5m /RoHS
European AC power cable, used for the AC power
supply
POL-AC-American 3-
pin/receptacle-AC power cable-
18AWG-1.5m/RoHS
American AC power cable, used for the AC power
supply
POL-DC-unstripped/stripped-DC
power cable-1.0mm2-4m/RoHS
DC power cable, used for the DC power supply, used
with the 5.08-3Pin-header/RoHS connector.
Optical modules
Optical modules are used according to actual situations, so purchase them additionally.
For Raisecom optical modules and lookup table, see section 5.1 Lookup table of optical
module . For detailed parameters, see the corresponding user manual.

Raisecom
iTN8600-I (A) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
10
Table 1-5 Comparison table for services, quantity, panel interfaces, and optical modules
Class
Optical module
Services: client-side 10G Any
services
Quantity: up to 20 ways (16
ways of SFP+ services and 1
way of QSFP+ PSM4 services)
Panel interfaces: C1–C16, C17
(fanned out into C19–C22)
USFP+ (universal-wavelength optical module):
Commercial dual-fiber (0.3/10/40/80 km): USFP+-
192/M, USFP+-192/S1, USFP+-192/S2, and
USFP+-192/S3
Commercial single-fiber (20/20/40/40/80/80 km):
USFP+-192/SS12, USFP+-192/SS13, USFP+-
192/SS22, USFP+-192/SS23, USFP+-192/SS34,
and USFP+-192/SS35
Industrial dual-fiber (2/10/40 km): USFP+-192/S0-
I, USFP+-192/S1-I, and USFP+-192/S2-I
Industrial single-fiber (20/20/40/40 km): USFP+-
192/SS12-I, USFP+-192/SS13-I, USFP+-
192/SS22-I, and USFP+-192/SS23-I
DSFP+ (DWDM-wavelength optical module):
Commercial dual-fiber 40 km: DSFP+-192/S/21 to
DSFP+-192/S/60
Commercial dual-fiber 80 km: DSFP+-192/L/21 to
DSFP+-192/L/60
RSP (CWDM-wavelength optical module):
Commercial dual-fiber 10 km: RSP-10C10-27 to
RSP-10C10-37
Commercial dual-fiber 20 km: RSP-10C20-27 to
RSP-10C20-37
Industrial dual-fiber 20 km: RSP-10C20-27-I to
RSP-10C20-37-I
Commercial dual-fiber 40 km: RSP-10C40-47 to
RSP-10C40-61
UQSP (PSM4 optical module):
Commercial dual-fiber 0.0002–10 km: UQSP-
40G/PSM4
Services: client-side 16G FC
services
Quantity: up to 12 ways
Panel interfaces: C1–C16
Commercial dual-fiber 0.5–10 km: USFP+-16G/S1
Services: client-side 40GE
services
Quantity: up to 2 ways
Panel interfaces: C17–C18
Commercial dual-fiber 0.3 km: UQSP-40G/M3
Commercial dual-fiber 10 km: UQSP-40G/S1
Services: client-side 100GE
services
Quantity: up to 2 ways
Panel interfaces: C17–C18
Commercial dual-fiber 0.0005–0.1 km: UQP-
100G/SR4
Commercial dual-fiber 0.002–2 km: UQP-
100G/CW4
Commercial dual-fiber 10 km: UQP-100G/LR4
Commercial dual-fiber 30 km: UQP-100G/ER4L
Services: client-side OTU4
Quantity: up to 2 ways
Panel interfaces: C17–C18
Commercial dual-fiber 10 km: UQP-100G/LR4
This manual suits for next models
1
