X10 User Manual
Introduction
This wireless HiFi audio streamer is of great performance and especially designed to meet the
high demand of the installation market. This wireless HiFi can make your traditional audio system
smart. With the free iOS and Android applications you can easily control your smart audio system.
You can stream the same music to all zones or different music to different zones, no matter the
music from the local storage like cell phone memory, NAS, USB flash disk and hard disk or online
streaming services such as Spotify, Tidal, TuneIn, iHeartRadio, Napster and so on.
Contents
X10 x1
Power Adaptor x1
RCA cable x2
Antenna x1
Quick Start Guide x1

Interface and Functions
1WiFi Antenna: Used to WiFi connection
2Reset: Used to reset the device when it has problem in WiFi connection
3LED: Indicates the status of the device
White blink: Network Connecting
White solid: Power on, Network connected, WiFi and USB streaming
Green solid: Line in streaming
4Optical: Used to provide digital output to other device such as amplifiers
5Coaxial: Used to provide coaxial output to other device such as amplifiers
6Line out: Used to provide analog to other source receivers
7Network connector: RJ45 used to connect to wired Ethernet network
8USB input: Used to connect local storage devices
9Line input: Analog input used to connect audio devices with RCA cable
10 Power input: Used to connect the power adaptor

How it works
Installation Guide
1. Unpack
Verify all the accessories are included in the package.
2. Place
Fix the amplifier at a safe and proper location. An integrated mounting bracket allows
mounting to a wall or surface, but we suggest making sure you complete all
installation steps before permanently mounting.
3. Connect
-Power connection
Power the amplifier with the power adaptor included in the accessories.
-Audio Connection
Using the included RCA cable, connect your AS1 to the Line Input on your active
speaker or amplifier, or use one of the other outputs with an optional cable to
connect to a different source.
4. Download the App
Download the MUZO application from the App Store for iOS and Google Play for Android.

5. Configure
Option 1- Configuration via App
-Connect your mobile devices to your network.
-Open the application> press Add Device(+)>choose settings> choose the
SoundSystem_xxxx hotspot> after connected, press the ‘turn back’ on your WLAN
settings> the app will jump to the configuration step>choose the 2.4G network and enter
the password>wait for the device to be configured.

Option 2- Configuration via Web Console
-1. Power the device.
-2. Choose the hotspot(SoundSystem_xxxx) in the WiFi setting on your cell phone or
computer and connect.
-3. Open the browser and enter 10.10.10.254 in the address bar.
-4. Go for WiFi>choose you 2.4G router>enter the password> click “connect”> wait for the
device to be configured.
Option 3- Configuration via LAN
-Power the device
-Plug in the wired cable to the RJ45 Ethernet, the device will show on the app in about 10
seconds.
App Photo Gallery:
Playback
Your Device List will show all available zones. Press a zone to see the information on the current
source. While on the view for the source, swipe right to reveal the available sources. From there,
you can select what source you want to hear next, or swipe left to return to the currently
playing source.

Streaming from Cell phone memory/NAS/Online Music Services
These screens let you access your available music, whether it be hard files on your
network or connected to your a-live hardware, or what streaming options you’ve
selected to be available.
Device Settings:
Through device settings you can set an alarm clock or sleep timer, get technical
information on your speaker, or rename it.

Firmware update
RAKOSO will notify you in your app when there is a new firmware version available.
It’s recommended to update firmware whenever available as this might not only
correct bugs or improve security, but could also add new features or services.
Technical Specifications
Connectivity
WiFi
IEEE802.11 b/g/n 2.4G
LAN
single 10/100M RJ45
Frequency Response
20Hz to 20kHz
Power input
DC 5.5V, 1A
Audio Source Input
USB 2.0, Analog RCA
Audio Source Output
Analog RCA, Coaxial, Optical(2.1)
Dimensions:
3.9” L x 4.1” W x 1.1” H
Weight
0.4 Lbs
Music format
MP3/AAC/AAC+/ALAC/APE/WAV
Decoding
Up to 24bit/192kHz

FAQ
FAQ
Q: Do your devices support airplay and third-party DLNA apps?
A: Yes. They support airplay and third-party apps like BubbleUPNP…
Q: How many zones can you group in one system?
A: 12 rooms is the maximum, while 8 zones are recommended.
Q: What distance can your wireless audio system cover?
A: Once the system is connected to your WiFi router, you can stream your music
anywhere there is a WiFi signal.
Q: Can it play high resolution music?
A: Yes. Our devices can play APE and FLAC within the normal bit rate range. They
also support decoding 24bit/192kHz music files.
Q: How many languages do you support?
A: Our devices will auto-detect your mobile device language and change
automatically. Currently, we support English, French, German, Spanish, Chinese,
Portuguese, Korean and Japanese and more on the way.
Q: What online music services do you support?
A: Spotify, Tidal, iHeartRadio, Tunein, Napster, and more, with more pending.
Q: Can I play local music?
A: Yes. You can play music from “MY MUSIC” on the application from local storage
devices such as mobile device storage, USB thumb drives, portable hard disk and
NAS.
Q: Can RAKOSO work with Windows devices?
A: The Windows application is not available at the moment, but on the Windows PC,
users can use iTunes, Foobar2000 and Spotify connect as a line input.
