Hardware Reference Manual
CP945FP-12 CompactPCI,
RM945FP-12 VME, &
RM948 With Embedded
Layer 2 Switch,
Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
2 of 18
This page is intentionally left blank.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
3 of 18
Notice
The information contained in this manual has been carefully reviewed and is believed to be entirely accurate.
However, RAMiX shall not be liable for errors contained herein.
Users are encouraged to recommend improvements for future revisions.
RAMiX reserves all rights to make changes to improve reliability, function or design without notice.
Customer Support
To obtain quick technical support, use our email hot-link: [e-mail].
Corporate Headquarters
RAMiX Inc.
1672 Donlon Street, Ventura, CA 93003, USA
Tel: 1+805-650-2111
• Fax: 1+805-650-2110
http://www.gefanuc.com/embedded
RAMiX Europe Ltd.
3/2 Great Michael House, 14 Links Place
Edinburgh EH6 7EZ, United Kingdom
Tel: [phone]
• Fax: [phone]
Copyright 2005 RAMiX Inc. All rights reserved. No part of this document may be reproduced, by any means,
without the prior written consent of the copyright holder. Reproduction without written consent constitutes
infringement under the Copyright Law of the United States.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
4 of 18
•
•
•
•
1 Introduction
RAMiX has designed the CP945FP-12 CompactPCI and RM945FP-12 VME economical, configurable 10/100
Layer 2 embedded Ethernet switches. Both modules are available with:
Full wire speed Layer 2 switch fabrics
12 ports 10/100BaseTX, front I/O
Full duplex operation in both 10/100 modes
Auto negotiation capability on all ports
The CP945FP-12 and RM945FP-12 are fully integrated 12-port Ethernet switches with front panel I/O, designed
to support the low-cost requirements of unmanaged switch applications.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
5 of 18
1.1 Key Features
As with all CompactPCI products from RAMiX, the CP945FP-12 module offers Hot Swap insertion capability for
higher reliability and rapid service.
The RM945FP-12 is a standalone switch and will work independently of any operating system. On power-up, the
switch will automatically boot up and begin switching in Layer 2 mode without any input from the operator or host
central processing unit (CPU).
The key features of both modules are:
• 12 ports (via RJ45 connectors) of 10/100BaseTX, auto-negotiating, front I/O panel
• Full wire speed layer 2 switching on all ports
• 1k MAC address table
• Auto address learning
• Auto address aging Leading edge QoS capabilities, based on 802.1p and IP TOS/DS field
• Up to 8 port based VLANs
• Offers port trunking
• Supports port mirroring
• Provides both Full/Half duplex ports
• Flow Control capabilities
o Back pressure for half-duplex
o 802.3x flow control for full-duplex
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
6 of 18
2 Theory Of Operation
The switch architecture is illustrated in the block diagram below. Total port count is achieved by combining two
ZarlinkMDS 108 8 port fabrics via their uplink.
By definition, a Network Switch differs from a hub in that each packet received into the switch is transmitted to the
minimum number of ports. This greatly improves aggregate data rate (i.e., multiple pairs of ports can be involved
in data transfer at a single point in time). As each packet arrives at the switch, both the source and destination
address of the packet are examined. The source is retained and associated with the arrival port as the location of
that device. If the packet is unicast (i.e., destined for a single receiver) and the destination is known, the packet
will only be transmitted to the port associated with the destination address. Since the learning is automatic, no
operator intervention is needed. As attached workstations (or other network capable devices) communicate, their
locations are learned and traffic can be localized to the port.
Isolation*
Magnet
PHY
Isolation*
Magnet
PHY
Isolation*
Magnet
PHY
Isolation*
Magnet
PHY
PHY PHY PHY PHY
Isolation*
Magnet
Isolation*
Magnet
Isolation*
Magnet
Isolation*
Magnet
Buffer
Storage
SRAM
Buffer
Storage
SRAM
PHY PHY PHY PHY
Isolation*
Magnet
Isolation*
Magnet
Isolation*
Magnet
Isolation*
Magnet
Parallel
Port
SROM
Switch Fabric
Switch Fabric
Parallel
Port
SROM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
7 of 18
The xx945 switches are implemented with two fabrics connected by a private uplink. One fabric provides 8 of the
ports, the other the remaining 4. The ports and configuration of each fabric is initialized by a(n) (independent)
SROM device. The contents of the SROM may be modified using a standard PC Parallel port (connected via the
DB25 to RJ45 connector, see details in section 3 Handling and Installation.
In default configuration, the CP945FP-12 and RM945FP-12 switches deliver a fully auto-configuring interconnect.
Each port will negotiate speed and duplex with the connected interface. Once a link has been established,
incoming packets are examined and the source MAC address added to the table associated with that port. When
the destination address has been associated with a port (from an earlier transmission), the packet is forwarded
only to that port. This process is independent for each port, so that the aggregate throughput of the switch fabric
is much higher than that of a single channel.
Where the destination has not yet been acquired, the packet is sent to all ports. Refer to section 2.1.1 Port
Based VLAN for behavior when this option has been configured.
Because the negotiation and learning process is automatic, there is no operator or start-up interaction required.
The SRAM buffer provides local storage to allow for dealing with multiple incoming packets with a single
destination port. Packets will be sequenced and buffered to avoid data loss. The QoS (optional) offers a
mechanism to prioritize traffic.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
8 of 18
2.1 Operational Configuration Options
The switch fabric has a number of performance operations usually found only in managed switch products.
These options include:
• Port based VLAN
• QoS
• Port speed/duplex forced configuration
All of these parameters are set via the SROM. This can either be programmed prior to manufacturing or
configured in the field from the front panel parallel port.
2.1.1 Port Based VLAN
The switch fabric provides the designer with the ability to define a single port-based VLAN for each of the 12
ports. This VLAN is individually defined for each port, assigning a VLAN ID (value between 0–11) for each port.
When packets arrive at an input of the switch, the search engine will determine the VLAN ID for that port, and will
then determine which of the other ports are also members of that VLAN by matching their assigned VLAN ID
values. The packet will then be transmitted to each port with the same VLAN ID as the source port.
2.1.2 QoS
QoS provides a new level of capability to unmanaged switch applications with two transmit queues per output
port.
The fabric manages the output transmission queues for all ports of the fabric. Once the destination address
search is complete, the packet is inserted into the appropriate output queue. Packet entry into high or low priority
queue is controlled by either the VLAN tag information or the TOS field in the IP header. Each of these priority
fields can used to select the transmission queue priority as well as a packet drop probability. The mapping of the
tag and TOS fields to either the high or low priority queue is configured on power-up from the SROM.
The fabric utilizes Weighted Round Robin (WRR), Random Early Drop with In/Out (RED/RIO) bit, and a
timestamp method of scheduling packets for transmission. WRR uses an efficient method to ensure that each of
the transmission queues gets at least a minimum service level. With two output transmission queues, the fabric
will transmit “X” packets from the high priority queue before transmitting “Y” packets from the low priority queue.
The “X” and “Y” weights are user definable. The high priority weight can be set to a value between 0-16. The low
priority weight is fixed at the value 1. If the high priority weight is set to the value 4, then the fabric will transmit
four high priority packets before transmitting each low priority packet.
The timestamp method of scheduling packets for transmission allows the fabric to offer latency guarantees to high
priority packets. This is ideal for voice and video packets that have strict latency requirements. Packets are given
a timestamp when they arrive at the input port. Once they are scheduled into a transmission queue, the fabric will
keep track of the packets delay time through the chip. Under heavy congestion the timestamp may be utilized to
change the order of packet transmission to ensure timely delivery of packets and orderly service of congested
queues.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
9 of 18
The following are the transmission scheduling exceptions:
1. Packets with high priority and low priority drop will be transmitted before any in the low priority queue.
2. If the high priority delay is => 2ms, then transmit from the high priority queue.
3. If the high priority delay is < 1ms and the low priority queue is congested, then transmit from the low priority
queue.
4. If the high priority delay is < 2ms and the low priority queue is full, then transmit from the low priority queue.
The QoS capabilities of the fabric are enabled by loading the appropriate values into the configuration registers
and by either enabling or disabling the flow control. The values are loaded from SROM. To alter the QoS
characteristics, modify the SROM configuration.
When Flow Control and QoS are enabled, the fabric will utilize WRR to schedule packet transmission, and will
use either backpressure or 802.3x flow control to handle situations of buffer memory congestion. When Flow
Control is disabled and Qos is enabled, the fabric will use RED/RIO to drop random packets in order to handle
situations of buffer memory congestion. In this method, only certain packet flows are slowed down, while the
remaining see no impact from the network traffic congestion. RED/RIO is a method of handling traffic congestion
in the absence of Flow Control mechanisms. When Flow Control is enabled, all devices that are connected to a
switch node that is exercising flow control are effectively unable to transmit, even nodes that are not directly
responsible for the congestion problem. RED/RIO allows traffic to continue flowing into ports on a switch and
randomly drops packets with different probabilities based upon each packet’s priority markings. As the switch
congestion increases, the probability of dropping an input packet increases. As congestion decreases, the
probability of dropping an input packet decreases. In this manner, only traffic flows that have had packets
dropped will be affected by the congestion. Other traffic flows will see no effect.
2.1.3 Port Configuration
By setting parameters in the SROM, each port can be individually configured in speed (i.e., 10 or 100Mbs) and
duplex (i.e., full or half).
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
10 of 18
2.2 Setting Optional Characteristics
As described in section 2 Theory of Operation section, the switch fabric can be configured to support QoS,
VLAN and port profile information. This data is captured in an on-card SROM that is loaded into the fabric control
engine during power on. The contents of the SROM can be altered using a standard parallel port and PC.
Contact RAMiX to receive a copy of the programming tool (for Windows 95/98 and NT). There is no charge for
this program.
SROM contents may also be set at the factory, consult your RAMiX sales representative for information on this
service.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
11 of 18
3 Handling and Installation
3.1 Handling Precautions
Electronic assemblies use devices that are sensitive to static discharge. Observe anti-static procedures when
handling these boards. All products should be in an anti-static plastic bag or conductive foam for storage or
shipment. Work at an approved anti-static workstation when unpacking boards.
3.2 Unpacking and Verification
RAMiX products are shipped in individual, reusable shipping boxes. When receiving the shipping container,
inspect it for any evidence of physical damage. If the container is damaged, request that the carrier’s agent be
present during the unpacking of individual boxes and the inspection of each unit.
Remove the RM94X card from the shipping box and anti-static packaging. Verify that it is not damaged and that
all items are present by referring to the packing list.
3.3 Installation
Installation is done generically as with the commercial versions of the card. Follow any specific procedures
recommended by the manufacturer of the chassis used.
3.4 Cable Adapter Pin Outs
Both the CP945FP-12 and RM945FP-12 are designed for use with a female RJ45 to male DB25 cable adapter.
The cable adapter, RAMiX part number 06-0714025, is illustrated below, and can be wired using the DB25-1 and
DB25-2 cable pin outs shown below.
DB25-1 Pin Out DB25-2 Pin Out
P1 P2 P1 P2
1 1 1 7
2 2 2 8
10 4 10 5
21 6 21 10
P1 P2
DB25 RJ45
P1 P2
DB25 RJ45
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
12 of 18
4 Front Panel Connectors and Indicators
4.1 CP945FP-12 and RM945FP-12
The CP945FP-12 and RM945FP-12 use an identical front panel—face and side illustrations below not to actual
size. The RJ45 connectors have 10/100BaseTX network connections. They are wired per industry specification.
Any standard network cable may be used to connect them with a NIC card.
Link/Activity LEDs
Each of the 12 ports (0 – 11) has an
associated set of Link/Activity LEDs. The
LEDs will illuminate when valid links are
detected. Until a valid link is present, no
activity can take place on a port.
A
solid LED illumination indicates a valid
link, but no traffic. A blinking LED
indicates port activtata traffic is on the
port when packets are received o
r
transmitted.
Parallel Port
The parallel port can be connected to a
PC parallel port.
The contents of the SROM can be
altered using the parallel port and a PC.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
13 of 18
4.2 RM948
Link/Activity LEDs
Each of the 12 ports (0 – 11) has an
associated set of Link/Activity LEDs. The
LEDs will illuminate when valid links are
detected. Until a valid link is present, no
activity can take place on a port.
A solid LED illumination indicates a valid
link, but no traffic. A blinking LED
indicates port activity—data traffic is on
the port when packets are received o
r
transmitted.
Parallel Port
The parallel port can be connected to a
PC parallel port.
The contents of the SROM can be
altered using the parallel port and a PC.
Connectors
8 RJ45 Copper ports
4 LC Fiber ports
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
14 of 18
4.3 Network Connections (CPCI Products Only)
There is a single PCI/Ethernet chip which mates to the PCI Bus. This allows the host to connect directly to the
switch fabric without any external cables. This port can also be used as a second interface Ethernet in addition to
the host. The network interface runs at the 100Mbit full duplex into the switch fabric.
Note: Connecting to another Ethernet HUB or SWITCH: A “crossover” cable must be used, or the
connection must be to the “uplink” port of the hub or switch.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
15 of 18
5 Functional Specifications
5.1 CP945FP-12 Port CompactPCI Embedded Layer 2 Switch, Front I/O
Power 4 Total Watts
@ 3.3 V 1.2 Amps
Form Factor
cPCI 6U Single Slot
MTBF
MIL 217-F Nav Shel 25 Deg. C 283000 Hours
Temperature
Operating 0 to +60° C
Storage -40 to +85° C
Humidity
Operating 5% to 95% Non-Condensing
Storage 5% to 95% Non-Condensing
Conformal Coating Yes, additional charge
PCI Standards
Hot Swap Yes
Switches
Ports
10/100 Base-TX 12
Port Routing
Front (12) RJ45 10/100BaseTX
Switching
Management Unmanaged
Layer 2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
16 of 18
5.2 RM945FP-12 Port VME Embedded Layer 2 Switch, Front I/O
Power 4 Total Watts
@ 5 V 0.8 Amps
Form Factor
cPCI 6U Single Slot
MTBF
MIL 217-F Nav Shel 25 Deg. C 283000 Hours
Temperature
Operating 0 to +60° C
Storage -40 to +85° C
Humidity
Operating 5% to 95% Non-Condensing
Storage 5% to 95% Non-Condensing
Conformal Coating Yes, additional charge
PCI Standards
Hot Swap Yes
Switches
Ports
10/100 Base-TX 12
Port Routing
Front (12) RJ45 10/100BaseTX
Switching
Management Unmanaged
Layer 2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Hardware Reference Manual
CP945FP-12 CompactPCI, RM945FP-12 VME, & RM948 With Embedded Layer 2
Switch, Front Input/Output
DDC No. Rx-URMH 122 Rev A
Issued 5 December 2003
17 of 18
5.3 RM948
Power 4 Total Watts
@ 5 V 0.8 Amps
Form Factor
VME 6U Single Slot
MTBF
MIL 217-F Nav Shel 25 Deg. C 283000 Hours
Temperature
Operating 0 to +60° C
Storage -40 to +85° C
Humidity
Operating 5% to 95% Non-Condensing
Storage 5% to 95% Non-Condensing
Conformal Coating Yes, additional charge
Switches
Ports
10/100 Base-TX 12
Port Routing
Front (8) RJ45 10/100BaseTX
(4) LC 100BaseFX (Fiber)
Switching
Management Unmanaged
Layer 2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Corporate Headquarters
RAMiX Inc
1672 Donlon Street, Ventura, CA 93003, USA
Tel: 1+805-650-2111 • Fax: 1+805-650-2110
RAMiX Europe Limited
3/2 Great Michael House, 14 Links Place
Edinburgh EH6 7EZ, United Kingdom
Tel: [phone] • Fax: [phone]
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group is an independent supplier of quality pre-owned equipment
Gold-standard solutions
Extend the life of your critical industrial,
commercial, and military systems
with our
superior service and support.
We buy equipment
Planning to upgrade your current
equipment? Have surplus equipment taking
up shelf space? We'll give it a
new home.
Learn more!
Visit us at artisantg.com for more info
on price quotes, drivers, technical
specifications, manuals, and documentation.
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
We're here to make your life easier. How can we help you today?
[phone] [e-mail] Iartisantg.com
