RAMTONS RW/130 User manual

MODEL:
RW/130
Before using your washing machine, please read this
manual carefully and keep it for future reference.
Read This Manual
Inside you will find many helpful hints on how to
use and maintain your
properly. Just a little preventative care on your
part can save you a great deal of time and money
over the life of your .
You'll find many answers to common problems in
the chart of troubleshooting tips. If you review
the chart of troubleshooting tips first, you may
not need to call for service.
single tub washing machine
single tub washing machine
OWNER’S MANUAL
Single Tub Washing Machine
Maintenance
Capacity (dry Clothes)
Power Supply
Input Power (lower drain)
Maximum Time
Maximum water pressure
Overall dimension
Net weight
Pump Input Power
Wash
9.0kg
220V/50Hz
320W
15 min.
0.6Mpa
555x535x923(mm)
13kg
30W
Main Technical Parameters
-6-

-1-
Attention To Installation
Lay upper drain hose
Installation site
Preparation Instructions
Reference of laundry quantity
corresponding to different capacities
Name Of Parts
Accessories
Introduction Of Control Panel
Quick Start
Washing Method
Rinsing Method
Attention To Maintenance
Cabinet maintenance
Anti-freezing protection
Notes
Main Technical Parameters
Safety Precaution
1
2
2
2
2
2
3
3
3
4
4
4
4
4
5
5
6
SAFETY PRECAUTIONTABLE OF CONTENTS
Do not spray water directly to
the machine.
Avoid spraying wate r
Do not install the machine in
damp or rainy environment to
avoid electric shock, fire,
machine failure,or deformation.
Avoid dampness
Do not dismantle the machine
by yourself.
Forbid dismantling
Do not insert or unplug the plug
with wet hands to avoid electric
shock.
Forbid wet hands
To avoid electric shock
resulting from electric leakage,
please connect grounding wire
of the plug properly.
Grounding
Do not place inflammable
materials like burning candle,
mosquito incense, cigaret etc.
or heating source like electric
stove, calorifier etc. on the
machine.
Forbid
Wipe off dirty and dust on the
plug often to prevent poor
contact with power supply.
+
Do not exceed the max. water
level to avoid water overflowing
and machine failure.
Forbid
+
Make sure that the water inlet
hose is connected and the tap
is opened before washing.
Unplug the plug from socket
after use.
Unplug the plug
Do not put hands into the tub
before it stopping running.
Forbid putting into
Do not wash clothes that are
stained with kerosene, petrol,
alcohol, and other flammable
substance.
Forbid
Do not damage the power cord
and plug to avoid electric
shock , short circuit or fire.
Forbid
Do not let baby climb to the
machine or play near running
tub to avoid accident.
Forbid
If use warm water, the water
temperature should not
exceed 50℃.
Forbid
Do not replace power cord by
yourself.
Forbid
Do not let baby sit on it or place
heavy things on it.
Forbid
Do not pull the cord when
unplug the plug.
Do not wash down-filled coat,
raincoat or similar clothes.
wat er pro of
Forbid
Insert the plug tightly when
use.
Be sure to comply with the following to prevent damage to body and property of you and
others:
The sign stands for “pay attention” , and the picture of specific items needs attention shows in .
The sign stands for “forbid”, and the picture of specific items forbidden shows in .
The sign stands for “must do”, and the picture of specific items must be done shows in .

-3--2-
Installation
●
● Lay down the lower drain hose and connect it to the sewer , or lay the upper drain hose to places as
indicated in page 2.
● Check that there are no objects such as coins, hairpins, mud or sand in the pocket.
● Strings should be knotted in advance to prevent entanglement.
● Clothes can be classified for ccording to the texture, dirty
● For small pieces (e.g.,stockings) or fluffy clothes, put them into a nylon net
Plug in power and connect the water inlet hose.
degree and color.
for spinning.
washing a
Preparation Instructions
Attention To Installation
Lay upper drain hose
FOR UPPER DRAIN SYSTEM ONLY
●
●
Needs a drain hose with minimum diameter 3 cm, and minimum carry away capacity of
40 liters per minute.
For upper drain system, the drain hose must be placed at least 86 cm(30 inches) from the
bottom of machine , but not higher than 100 cm.
of
Installation site
in the following places:
In order to avoid electrical failure, discoloration and deformation, do not install the machine
Locations exposed to rain
or snow
●
● Locations exposed
to direct sunlight
Locations with uneven
or unstable ground
●
Shirt
about 500 g
Jacket
about 1600 g
Uniform
about 650 g
Jeans
about 900 g
Capacity
Laundry
...... ...... ...... ...... ......
Attachment: Reference of laundry quantity corresponding to different capacities
he figure above is for reference only, specific weights are subject to actual .●T clothes
86cm<H<100cm
2.0kg Capacity about 4 pcs. about 3 pcs. about 2 pcs. about 1 pcs.
4.0kg Capacity about 8 pcs. about 6 pcs. about 4 pcs. about 2 pcs.
6.0kg Capacity about 12 pcs. about 9 pcs. about 6 pcs. about 3 pcs.
8.0kg Capacity about 16 pcs. about 11 pcs. about 8 pcs. about 4 pcs.
Control panel
Wash cover
Pulsator
Base
Cabinet
Drain hose
Frame
(For lower drain only)
Drain hose
(For upper drain only)
Power plug
Accessories
Name Of Parts
Introduction Of Control Panel
※ he drawing above is for reference only, specific drawing is subject to actual models.T
●
●
● Drain selector: For washing or rinsing, select “ Normal”or“ Heavy”. For Draining ,select “Drain”.
Water inlet: be used to inject water.
Wash timer: be used to select required washing time.
Water inlet hose
Structure Instruction
0
3
6
12
15
9
Normal
Drain
Heavy
Wash Timer Wash-Drain Selector
Water inlet Wash timer Drain selector

Quick Start
Washing Method
Water level indicator
2.
3.
4. Turn the knob to set wash time.
1. Insert the inlet hose into the .water water inlet mouth
Set wash program “Normal” or “Heavy” as per amount and
texture of laundries.
Put the laundry into the wash tub, and add detergent into it.
When fill water to half of the desired water level, turn off the
water tap and let laundries soak in the solution for minutes,
then fill water to desired water level and turn off the water tap .
“Wash timer”
Drain out the water in the wash tub after wash.5.
Wash timer
Rinsing Method
-5--4-
Usage method
1. Install the washing machine
2. Load the laundry
detergent and water into
the wash tub
and add
3.
to set wash time
Turn the wash timer knob
4.
“Drain” position after washing
Set the wash drain selector to
5.
the wash tub
Take out the laundry from
1.
2.
3. the desired time (about 3-5 minutes)for rinsing.
4.Drain out the rinsing water in the wash tub.
5.The above steps can be repeated.
Put laundries which have already been washed into the wash tub.
After filling water to the desired level, turn off the water tap to save water.
Turn the “Wash timer” knob to
The appliance can not be used by children or persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
Do not wash waterproof clothes or clothes that float easily to avoid abnormal vibration or damage
to the clothes.
The new hose supplied with the appliance are to be used and that old hose should not be used.
Usage method
The maximum gradient of the supporting surface for the machine should not exceed 2º.
Do not tear down electrical wires and components in the machine by yourself.
There are holes on the base for ventilation. These holes should not be blocked by foreign objects
(carpets, etc.).
Never connect the grounding wire with the live wire, or it may lead to an electric shock.
If the power cord is damaged, it must be replaced by a qualified person to avoid a hazard.
●
●
●
●
●
After you use the machine, never forget to do the following two things:
Attention To Maintenance
Cabinet maintenance
After using the machine,wipe the moisture and stain on it with a piece of
soft cloth.To avoid damage to the surface, do not use corrosive or
volatile chemicals.
Anti-freezing protection
▲ To prevent from freezing:
▲ If the water is frozen, please take the following steps:
hose completely.
Lay the drain hose and then empty the water in the tub.
①water inlet
②
Turn off the water tap, remove the water inlet hose and empty water in the
①
②Keep about 2 liters of warm water below 50℃ in the spin tub for
about 10 minutes. and then lay the drain hose and empty the water .
③Fit the water inlet hose and turn on the water tap to
confirm water filling and draining work properly.
Put the water inlet hose into warm water of about 50℃.
2. Remove the water inlet hose.
1. Disconnect the power plug.
-8-
Notes
The washing machine employs alternative current with rated voltage and frequency . When voltage fluctuates
between -10% and 10% of the rated voltage, the machine can work normally.
Connection mode of the power cord of this machine is Y-shaped connection.Users
reconnect the wire by themselves. please contact the designated service center.
should not detach or
If this part needs to be repaired,
If the following symptoms occur, please disconnect the power plug and perform the
following checks:
Check that the power supply is in good condition.
Check that the power plug is inserted properly.
●
●
● Check that the wash timer knob or the spin timer knob is not
in the "0" position.
Check that the drain hose is not laid too high.
Check that the drain hose is not frozen.
Check that the drain hose is not blocked by foreign matter.
●
●
●
Check that there are no coins or any other foreign objects
dropped into the wash tub.
●
The washing
machine does
not work.
The drain hose
does not work.
There is abnormal
noise during washing.
Symptom Reason
