Randall Diavlo RD1C User manual

For detailed product videos please visit our
website at :www.randallamplification.com
Randall Warranty
Randall Amplifiers, a Division of U.S. Music Corporation warrants the
product you have purchased to be free of defects in materials and workmanship
in normal use for a period of two (2) years from the date of original purchase.
This warranty shall run to the original purchaser when purchased from an
Authorized Randall Dealer. The manufacturer warrants speakers for a period
of (1) years. The manufacturer warrants tubes for a period of (90) days.
Defective parts found during the applicable warranty period with proof of
purchase will be replaced or repaired without charge if the complete product is
returned to US Music Corp or any Authorized Randall Service Center within
the U.S.A. Randall reserves the right to use materials readily available at the
time of the repair. All Warranty service requires Proof of Purchase (sales
receipt) to be presented at time of service request. Any repair or service
performed by any person of entity other than an Authorized Service Center is
not covered by this limited warranty. The customer pays transportation to and
from Randall factory service or any Randall Authorized Service Center. Rental
stock is warranted for (1) year from date of invoice to the Authorized dealer.
Warranty on rental units is not transferable.
!What is covered against manufacturing defects
Parts and Labor to correct any defect in materials used and any defect
attributable to workmanship.
!What is not covered:
Shipping Damage. Report damage upon receipt of item to the carrier (i.e.
UPS). Freight carrier must be notified upon receipt of items to insure freight
damage claim resolution. Shipping damage not filed with carriers within (48)
hrs upon receipt will not be covered under warranty. Report any shipping
damage within (48) hrs of receipt to the Randall Customer Service Dept at
1-800-877-6863, ext. 5120. Keep all original documents and packing materials
to insure freight damage claim resolution. Merchandise that has been modified
after original shipment from the Randall factory. Products whose serial
numbers have been altered or removed. Exterior normal wear and tear damage
to the finish due to misuse, operation outside the specified ratings, neglect or
accident. Warranty claims by anyone other than the original purchaser. Randall
is not responsible for any items left in protective covers or cases, (We strongly
advise that all personal items such as chords, cables, tuners, etc… be
removed!) freight charges to and from the factory or an Authorized service
center on customer owned goods, any and all charges incurred from priority
service requests (Rush Service) or priority shipping for replacement parts. Any
and all charges if no problem is found.
Return Authorization
All items being returned for any reason must have a Return Authorization
number. This RA# must be placed on the outside of the carton of the item being
returned or the carton will be refused upon delivery. Please call the customer
service department at 1-800-877-6863, ext. 5120, for the return authorization
number. Dealer stock items will be returned to the dealer freight prepaid.
An Authorized Warranty Service Center must perform any and all field
warranty service work. Customer will not pay for parts and/or labor provided
the problem found is within warranty guidelines. Proof of purchase must be
provided at the time of service request. Transportation charges to and from the
Authorized Warranty Service Center are the responsibility of the customer.
Rush service charges and special freight charges for required parts are not
covered under warranty and are also the responsibility of the customer. If a
unit is not easily transported to an authorized service center, the customer is
responsible for technician travel charges. Any charges for labor or processing
when no problem is found are also not covered under warranty. Any charges
incurred for work performed by an unauthorized service center are the
responsibility of the customer.
Warranty terms may very per country, check warranty
terms with local Distributor or at point of purchase.
DIAVLO 1 watt & 5 watt combo amplifiers
RD1C = 1 Watt 1x8 Combo with (1) 12AU7
Power & (2) 12AX7 Preamp tubes
RD5C = 5 Watt 1x10 Combo with (1) 6V6
Power & (2) 12AX7 Preamp tubes
Gain + Tone + Master Volume
T.S.S. 3 way “tone stack shift”
Class A discrete Instrument level loop
Speaker emulated XLR output with Ground
lift and silent operation
OPERATION
MANUAL
Models:
RD1C/RD5C
A M P L IFIE R S
RM50/RM80
M O D U L A R T U B E C O M B O S
O W N E R S M A N U A L

Congratulations on the purchase of your new RANDALL DIAVLO SERIES Amplifier! We at Randall Amplification appreciate that you chose our brand of guitar instrument
amplifiers and wish you years of great tone and enjoyable playing time with your new machine. Please review the safety instructions and be aware that the documentation
provided in this manual references 120volt USA versions of the models covered. Note that the POWER listed on the power supply should be for your countries’ power standard.
Class A Discrete
instrument level effects
loop send. This plugs
into external pedal
effects unit input and
feeds signal from the
Gain and Tone knobs.
Also serves as
unbalanced preamp
output send but will mute
output unless return jack
receives return signal.
1/4” Guitar input - Plug
your guitar into this jack/
connector.
GAIN KNOB - This knob works as
an aggressive all tube overdrive
circuit. It dynamically responds with
more overdrive as more input is fed
from your pickups. Turn to the right
for more saturation. For cleaner
tones, keep at lowest setting, turn
volume all the way up and use gain
knob as volume output control.
T.S.S. - Stands for “Tone Stack Shift” 3-way Midrange frequency variance switch.
•Left- Midrange boost, with flat bass response and rolled off highs....great for smooth
burning lead tones
•Center- The stock position with an even bass, mid, and treble response....perfect for
Rock
•Right- Midrange scoop, with a boosted bass and treble response...perfect for metal
TONE KNOB - This is
an overall tonal sweep.
Turn to the left for more
bass (low frequencies)
and less treble (high
frequencies)
XLR ground lift
changes the ground
connection to fix
ground loops when
interfacing with other
equipment - use at
quietest setting for
best performance.
Speaker output - plug
any (8 ohm or greater)
speaker cabinet into
this jack. External input
will automatically mute
the internal speaker so
only external speaker
operates.
POWER CABLE:
Note that this unit will
only operate safely in
the country or region
in which it is sold.
please contact your
local Randall
distributor or dealer if
you are unsure of
mains voltage.
Class A Discrete
instrument level effects
loop return. This plugs
into external pedal effects
unit output to complete
signal “loop”. Also serves
as power amp input so
external preamp can be
plugged directly to power
amp section with active
volume control and
speaker emulator XLR
output.
VOLUME KNOB - Overall volume
output control. This feeds the
speaker output and balanced XLR
speaker emulator output.
Note that to achieve cleaner tones,
turn volume all the way up and use
GAIN KNOB as volume control.
XLR Balanced output is signal fed from the
output transformer including signal from the
output tube. This signal is then sent through
the speaker emulator which simulates the
sound and response of a mic’d up Randall
4x12 speaker cabinet. This function is useful
for direct (silent) recording, Direct send to
PA/FOH for silent stages, in ear monitor feed
or send to external power amp.
The Power
switch turns
the unit on
and off.
Speaker MUTE switch - This function
is only on combo versions RD1C &
RD5C. When depressed it mutes the
output of the internal speaker for silent
operation. All of the functions of the
amplifier operate as normal except the
speaker output. Note that the amplifier
has internal resistor to offer simulated
speaker impedance and protection.
