R&M STAGEMAKER SM1 Quick start guide

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
®
STAGEMAKER®Concert Hoist
Technical Guide

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
2
®
Contents
1Introduction .............................................................................................................4
1.1 Mounting Positions...........................................................................................................4
1.2 Installation Types .............................................................................................................4
1.3 Basic Configuration Description.......................................................................................5
1.4 Capacity, Speed, and Hoist Configuration Summary.......................................................6
2Performance ............................................................................................................7
2.1 Environment.....................................................................................................................7
2.2 Sound Level.....................................................................................................................7
2.3 Proper Installation............................................................................................................7
2.4 Hoists for Ground Supports .............................................................................................7
3Hoist Configurations...............................................................................................8
3.1 Hoist Configuration A – Direct Motor Control for Mobile Installations ..............................8
3.2 Hoist Configuration B – Three-phase Motor for Fixed or Mobile Installation .................10
3.3 Hoist Configuration C – Programmable Control.............................................................13
3.4 Hoist Configuration D – BGV-C1 Enhanced Safety Features........................................15
3.5 Hoist Configuration E – Without Motor Controls ............................................................17
3.6 Hoist Configuration S – Single-phase Motor for Fixed or Mobile Installation.................19
3.7 Hoist Configuration V – Variable Speed Control............................................................21
4Controllers.............................................................................................................23
4.1 Group Controllers for Configuration A Hoists.................................................................23
4.2 Group Controllers for Configuration B or S Hoists .........................................................23
4.3 Pistol-Grip Pushbutton Controller (Pickle) for Configuration B or S Hoists....................23
4.4 Pushbutton Pendant Controller for Configuration B (SM16 – SM25) or D.....................24
4.5 Programmable Controller for Configuration C................................................................24
4.6 Controller for Configuration D ........................................................................................24
4.7 Controller for Configuration E ........................................................................................24
4.8 Controller for Configuration V ........................................................................................25
5Controllers – Examples of Use ............................................................................26
5.1 Configuration A – 8 or 12 Channel Controller ................................................................26
5.2 Configuration A – SC Controller, Hoist & Cable.............................................................27
5.3 Configuration A – SC Controller, Hoist & Cable + Splitters ...........................................28
5.4 Configuration B & S – Hoist & Cables (separate power & control), 3rd-party Controller 29
5.5 Configuration B & S – Hoist & Cable (combined power & control), 3rd-party Controller.30
5.6 Configuration C – 8 Channel, 3rd-party Controller..........................................................31
5.7 Configuration D – Controller, Hoist, & Cable .................................................................32
5.8 Configuration E - 3rd-party Controller .............................................................................33
6Pigtails/Cables/Connectors..................................................................................34
6.1 Connector Rules ............................................................................................................34
6.2 Pigtail Options with Wiring Identification........................................................................35

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
3
®
6.3 Pigtails with Plug Options ..............................................................................................36
6.4 Cables with Connectors.................................................................................................37
6.5 Connector Types and Plug Wiring Identification ............................................................38
6.6 Suggested Cable Selection Table..................................................................................41
7Hoist Motor ............................................................................................................42
7.1 Features.........................................................................................................................42
7.2 Ambient Conditions........................................................................................................42
7.3 Motor Cooling.................................................................................................................42
7.4 Hoist Motor Thermal Protection .....................................................................................42
7.5 Brake Coil Resistance....................................................................................................42
8Hoist Gearbox........................................................................................................42
9Hoist Brake and Torque Limiting Device ............................................................43
10 Load Chain, Load Sprocket and Chain Guide..................................................44
11 Hooks ..................................................................................................................45
11.1 Load Block & Hook .....................................................................................................45
11.2 Load Hook Dimensions ..............................................................................................46
11.3 Swiveling Body Hook..................................................................................................47
11.4 Fixed Body Hook ........................................................................................................47
11.5 Body Hook Dimensions ..............................................................................................47
11.6 Self Locking Hooks.....................................................................................................48
12 Low Voltage Control ..........................................................................................48
13 Hoist Limit Switch..............................................................................................49
13.1 Upper and Lower Electrical Limit Switches.................................................................49
13.2 Geared Limit Switch ...................................................................................................49
14 Hoist Protection Rating .....................................................................................50
15 Capacity Plate.....................................................................................................50
16 Surface Treatment/Paint Specification.............................................................50
17 Incremental Encoder..........................................................................................51
17.1 SM1 Hoists .................................................................................................................51
17.2 SM5 or SM10 Hoists...................................................................................................51
18 Model Description..............................................................................................52
19 Conversions........................................................................................................53

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
4
®
1 Introduction
1.1 Mounting Positions
Normal position is where the hoist is mounted with load chain down and hoist body up. The load block
attaches to the load and moves up and down. The hoist body is stationary. All of the models (SM1
through SM25) when specially equipped can be mounted in the normal position.
Inverted position is where the hoist is mounted with load chain up and hoist body down. The hoist body
attaches to the load and moves up and down with the load. Hoists in the inverted position are easier to
install and setup because all the cabling is at the same level, and the hoist is at truss level. Only SM1,
SM2, SM5 or SM10 hoists when properly equipped can be mounted in the inverted position. For inverted
SM16, 20 or 25 positions, please contact the factory.
Normal position (chain down) Inverted position (chain up)
1.2 Installation Types
STAGEMAKER®concert hoists can be used in a mobile installation or a fixed installation. Careful
consideration of the installation type and the mounting position should be taken before ordering so that
the hoist can be properly equipped to meet the requirements.
Mobile installation means the hoist is used in temporary or short-term setup. Hoists used in a mobile
installation are typically mounted in the inverted position.
Some examples of mobile installations: “on-tour” concerts, ground and roof supports, exhibitions, product
presentations, and the circus.
Local safety regulations must be followed at all times. These regulations could require:
Additional safety such as a steel rope between the upper suspension point and the lower hook
point of the load or a redundant system.
De-rated capacity of the hoist
Second brake
For more advance lifting applications, use BGV-C1 Configuration D hoists providing enhanced
safety features
Fixed installation means the hoist is used in a more permanent or long-term setup. Some of examples of
fixed installations: theaters, studios, and arenas.
In fixed installations the hoist is mounted in the normal position and situated usually out-of-sight. Because
of the out-of-sight situation, over-travel electrical limit switches and low voltage control are mandatory. All
of the models (except the SM2) when specially equipped can be mounted in fixed installations.

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
5
®
1.3 Basic Configuration Description
STAGEMAKER®concert hoists are offered in many configurations, each with its own control type and
hoist features.
Configuration A: Utilizes three-phase direct motor control for easier setup and cabling. The hoist
is equipped for mobile installations so it can be mounted in the normal or inverted position. A direct
motor control hoist in the inverted position is best suited for temporary or short-term setups. Full line
voltage controller furnished separately.
Configuration B:Utilizes three-phase power and low voltage control. The hoist (SM1, SM2, SM5,
SM10) is equipped for mobile installations so it can be mounted in the inverted or normal position, but
when specially equipped the hoist (SM1, SM5, SM10) can also be used in the normal position of fixed
applications. Controller furnished separately. A “pickle”, which is used during stage setup, can be
connected directly to the low voltage hoist control. The SM16, SM20 and SM25 hoists must always
be mounted in the normal position and are furnished with a pushbutton pendant controller with E-
stop, for other SM16, SM20 and SM25 applications please contact the factory.
Configuration C:Utilizes three-phase power and low voltage control. The hoist is equipped for
fixed installations so it can be mounted in the normal position, but when specially equipped the hoist
can also be mounted in the inverted position. The hoist is readily equipped for programmable control
and sequencing. Controller furnished separately.
Configuration D:Used where a higher degree of safety is needed. The hoist complies with
enhanced safety regulations in accordance to DIN 56925. The enhanced safety features and low
voltage control are operated from a standard or programmable controller. The hoist is equipped for
fixed installations so it can be mounted in the normal position. When specially equipped the hoist can
also be mounted in the inverted position, but must be operated from a nonprogrammable controller.
Configuration E:Utilizes three-phase power and is set up for external controls (typically VFD),
which are not included. The hoist is equipped for fixed installations so it can be mounted in the normal
position, but when specially equipped the hoist can also be mounted in the inverted position.
Configuration S:Utilizes single-phase power and low voltage motor control. The hoist is
equipped for mobile installation so it can be mounted in the inverted or normal position, but when
specially equipped the hoist can also be used in the normal position of fixed installations. Controller
furnished separately. A “pickle”, which is used during stage setup, can be connected directly to the
low voltage hoist controls.
Configuration V:Utilizes three-phase power and low voltage control. The hoist (SM10) is
equipped for fixed installations so it can be mounted in the normal position, but when specially
equipped, the hoist can also be used in the inverted position. Controller furnished separately.

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
6
®
1.4 Capacity, Speed, and Hoist Configuration Summary
60 Hz 50 Hz Hoist Configuration
Cap.
(Ton) Cap. (kg) Frame Fall Speed (fpm) Speed (m/min) Speed (m/min) A B C D E S V
1/8 125 SM1 1 16 4.8 4 
1/8 125 SM1 1 32 9.6 8 ■
1/4 250 SM2 1 16 4.8 4 ▲▲
1/4 250 SM5 1 16 4.8 4 ■

1/4 250 SM5 1 32 9.6 8 ■
1/4 250 SM5 1 64 19.2 16 ■
1/4 250 SM10 1 64 19.2 16
■
1/2 500 SM5 1 16 4.8 4 ■
1/2 500 SM5 1 32 9.6 8 ■
1/2 500 SM10 1 16 4.8 4
■
1/2 500 SM10 1 32 9.6 8
■
1/2 500 SM10 1 64 19.2 16 ■■
1/2 500 SM10 1 4-64 1.2-19.2 1-16 ■
1 1000 SM10 1 16 4.8 4 ■■
1 1000 SM10 1 32 9.6 8 ■■
1 1000 SM10 2 8 2.4 2
■
1 1000 SM10 2 16 4.8 4
■
1 1000 SM10 1 2-32 0.6-9.6 0.5-8
■
1 ½ 1600 SM16 1 32/8 9.6/2.4 8/2 
2 2000 SM10 2 8 2.4 2 ■■
2 2000 SM10 2 16 4.8 4 ■■
2 2000 SM10 2 1-16 0.3-4.8 0.25-4 ■
2 2000 SM20 1 32/8 9.6/2.4 8/2 
2 1/2 2500 SM25 1 24/6 7.6/1.8 6 
5 5000 SM25 2 12/3 3.8/0.9 3 
Configuration available in Normal/Inverted position or Normal position if specially equipped
■Configuration available in Normal position or Normal/Inverted position if specially equipped
Configuration available in Normal position only (for other applications please contact factory)
▲Configuration available in Normal/Inverted position only

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
7
®
2 Performance
STAGEMAKER®concert hoists are designed for lifting and transporting of materials only. Under no
conditions or circumstances, either during initial installation or in regular use, are hoists to be used for
lifting or transporting of personnel. For additional safety, precautions such as redundant systems, safety
lines from load to structure or enhanced safety features such as the BGV-C1 hoist can be used.
2.1 Environment
The hoists are designed for indoor use and limited outdoor use where the ambient temperature is
between 14°F [-10°C] and 104°F [40°C], elevation is less than 3300 ft [1000 m] and the relative humidity
is less than 90%. The hoist control enclosure has protection rating of NEMA 3R type.
The hoists can be used outdoors with some precautions such as specifying the hoist with a drain hole in
the load sprocket compartment, covering the hoist body/enclosure with a vinyl rain cover, or protecting
the hoist under a shelter. The vinyl rain cover would cover the hoist body/enclosure after the hoist is in
position. The hoist cannot be operated when the vinyl rain cover is covering the hoist body/enclosure.
Without these precautions, continuous exposure to extreme weather conditions will lead to damage of
electrical components.
2.2 Sound Level
The sound intensity level of the hoist in the assumed operating location does not exceed 76 dB.
2.3 Proper Installation
Hoists must be installed clear of any obstruction that could prevent the top and bottom hooks from being
inline.
2.4 Hoists for Ground Supports
Use single fall SM10 hoists for ground supports. Using a SM10 hoist reduces chain wear and risk of chain
twisting. Idler wheels on the ground support must have matching grooves and proper pitch diameter.
Proper Improper

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
8
®
3 Hoist Configurations
3.1 Hoist Configuration A – Direct Motor Control for Mobile Installations
Configuration A utilizes three-phase direct motor control for easier setup and cabling. The hoist is
equipped for mobile installations so it can be mounted in the normal or inverted position. A direct motor
control hoist in the inverted position is best suited for temporary or short-term setups. Full line voltage
controller furnished separately.
Hoist features:
Black load chain
Non-reflecting matt black finish
Swiveling body hook
External chain guide (SM5 and SM10, Chainflux)
Disc Brake
Over-travel protection via the torque limiting device (1)
Steel electrical enclosure (except SM1, NORYL plastic)
ACF brake controller card
Chain bag for 100 ft [30 m] of chain
Handgrips
No pigtail or plug
Round cable gland for 5/16”-9/16” [8-15 mm] diameter cable
208V/230V-3Ph-60Hz motor rating
(1) Upper and lower electrical limit switches not available with direct motor control
Available options:
Self locking hook (SM5 and SM10)
Fixed body hook
Second brake (SM5 and SM10)
Steel control enclosure for SM1
Vinyl rain cover
Drain hole in the load sprocket compartment (SM5 and SM10 only)
Power pigtail – no plug (standard pigtail length is 18”, longer lengths available)
Blue CE male plug for pigtail
Twist-lock male plug for pigtail
Blue CE female receptacle
Twist-lock female receptacle
Controller:
4 channel compact controller in a hand case
8 channel compact controller in a hand case
Accessories:
Remote with GO button and E-stop and with 30 ft of cable
Motor cables
Single and twin flight cases (SM5, SM10 only)

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
9
®
Offering and Technical Data:
Capacity
(Ton)
Model Speed
(fpm)
Falls Chain
type
(mm)
Power
(HP)
Nominal
Current
230 V
Weight
of Unit (1)
(lbs)
Chain
weight
(lb/ft)
1/8 SM1 128 M1-A 32 1 3.1 x 9.3 0.33 2.0 29 0.148
1/4 SM2 254 M1-A 16 1 4 x 12 0.33 2.0 34 0.213
1/4 SM5 254 M1-A 16 1 4.8 x 12.5 0.65 2.0 58 0.363
1/4 SM5 258 M1-A 32 1 4.8 x 12.5 1.3 4.0 58 0.363
1/4 SM5 2516 M1-A 64 1 4.8 x 12.5 1.3 4.0 58 0.363
1/2 SM5 504 M1-A 16 1 4.8 x 12.5 0.65 2.0 58 0.363
1/2 SM5 508 M1-A 32 1 4.8 x 12.5 1.3 4.0 58 0.363
1/2 SM10 5016 M1-A 64 1 6.8 x 17.8 2.8 7.2 113 0.726
1 SM10 1004 M1-A 16 1 6.8 x 17.8 1.4 3.6 113 0.726
1 SM10 1008 M1-A 32 1 6.8 x 17.8 2.8 7.2 113 0.726
2 SM10 2002 M1-A 8 2 6.8 x 17.8 1.4 3.6 118 0.726
2 SM10 2004 M1-A 16 2 6.8 x 17.8 2.8 7.2 118 0.726
(1) approximate weight without chain
Metric Offering and Technical Data [60 Hz]:
Capacity
(Kg)
Model Speed
m/min
Falls Chain
type
(mm)
Power
(kW)
Nominal
Current
230 V
Weight
of Unit (1)
(Kg)
Chain
weight
(kg/m)
125 SM1 128 M1-A 9.6 1 3.1 x 9.3 0.25 2.0 13 0.22
250 SM2 254 M1-A 4.8 1 4 x 12 0.25 2.0 17 0.35
250 SM5 254 M1-A 4.8 1 4.8 x 12.5 0.5 2.0 26 0.54
250 SM5 258 M1-A 9.6 1 4.8 x 12.5 1.05 4.0 26 0.54
250 SM5 2516 M1-A 19.2 1 4.8 x 12.5 1.05 4.0 26 0.54
500 SM5 504 M1-A 4.8 1 4.8 x 12.5 0.5 2.0 26 0.54
500 SM5 508 M1-A 9.6 1 4.8 x 12.5 1.05 4.0 26 0.54
500 SM10 5016 M1-A 19.2 1 6.8 x 17.8 2.1 7.2 51 1.08
1000 SM10 1004 M1-A 4.8 1 6.8 x 17.8 1.05 3.6 51 1.08
1000 SM10 1008 M1-A 9.6 1 6.8 x 17.8 2.1 7.2 51 1.08
2000 SM10 2002 M1-A 2.4 2 6.8 x 17.8 1.05 3.6 54 1.08
2000 SM10 2004 M1-A 4.8 2 6.8 x 17.8 2.1 7.2 54 1.08
(1) approximate weight without chain

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
10
®
3.2 Hoist Configuration B – Three-phase Motor for Fixed or Mobile Installation
Configuration B utilizes three-phase power and low voltage control. The hoist (SM1, SM2, SM5, SM10) is
equipped for mobile installations so it can be mounted in the inverted or normal position, but when
specially equipped the hoist (SM1, SM5, SM10) can also be used in the normal position of fixed
applications. Controller furnished separately. A “pickle”, which is used during stage setup, can be
connected directly to the low voltage hoist control. The SM16, SM20 and SM25 hoists must always be
mounted in the normal position and are furnished with a pushbutton pendant controller with E-stop, for
other SM16, SM20 and SM25 applications please contact the factory.
SM1, SM2, SM5, SM10 Hoist features:
Black load chain
Non-reflecting matt black finish
Swiveling body hook
External chain guide (SM5 and SM10, Chainflux)
Disc Brake
Over-travel protection via the torque limiting device (1)
Steel control enclosure (except SM1, NORYL plastic)
Chain bag for 100 ft [30 m] of chain
Handgrips
Low voltage (115 VAC) control
No pigtail or plug for power or control
Two round cable glands - 5/16”-9/16” [8-15 mm] diameter cable
Hoist motor thermal protection
230V-3Ph-60Hz power supply
1) Upper and lower electrical limit switches (weight-operated) are not furnished on hoist in the inverted position
SM16, SM20, SM25 Hoist features:
Electro-zinc load chain
Non-reflecting matt black finish
Fixed body hook
Standard chain guide
Disc Brake
Upper and lower electrical limit switches (weight-operated)
Torque limiting device
ABS plastic control enclosure
Chain container
Low voltage (115 VAC) control
No pigtail or plug for power or control
Round cable gland for 5/16”-9/16” [8-15 mm] diameter cable
Hoist motor thermal protection
230V-3Ph-60Hz power supply
Note:
A mainline contactor is not furnished on SM1 or SM2 hoists
Mainline contactor is specially wired so it is always energized when power to the hoist (SM5
and SM10 only) is applied.
The mainline contactor in the hoist control panel for the SM16, SM20, and SM25 hoists is
controlled by the E-Stop on the pushbutton controller.

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
11
®
Available options:
Fixed applications (SM1, SM5 and SM10) – includes a standard chain guide, upper and lower
electrical limit switches (weight-operated), a plastic chain container and the handgrips are
removed.
Fixed body hook
Upper and lower electrical limit switches (weight-operated): normal position only (except SM2)
Self locking hook (SM5 and SM10)
Geared limit switch (excluding SM2)
Second brake (SM5 and SM10)
Steel control enclosure for SM1
Vinyl rain cover
Drain hole in the load sprocket compartment (SM5 and SM10 only)
Power pigtail – no plug (standard pigtail length is 18”, longer lengths available)
Control pigtail – no plug (standard pigtail length is 18”, longer lengths available)
Power & control pigtail – no plug (standard pigtail length is 18”, longer lengths available)
Twist-Lock male plug for power pigtail
7 pin Socapex male plug for power & control pigtail
P14 male plug for power & control
Twist-Lock female receptacle for control pigtail
Mating plug/receptacle for the supplied plug
Custom plug for pigtail
460V-3Ph-60Hz or 208V-3Ph-60Hz power supply (SM2 not available in 460V-3Ph-60Hz)
Controllers:
4, 8 or 12 channel controller with remote configured for combined power/control or separate
power and control
Pistol-grip pushbutton controller or “Pickle” (SM1, SM2, SM5, SM10) with pigtail (standard
pigtail length is 18”, longer lengths available). Plug is optional.
Pushbutton controller with E-Stop button (SM16, SM20, SM25)
Accessories:
Motor cables
Single and twin flight cases (SM5, SM10 only)

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
12
®
Offering and Technical Data:
Capacity
(Ton)
Model Speed
(fpm)
Falls Chain
type
(mm)
Power
(HP)
Nominal
Current
230 V
Weight
of Unit (1)
(lbs)
Chain
weight
(lb/ft)
1/8 SM1 128 M1-B 32 1 3.1 x 9.3 0.33 2.0 29 0.148
1/4 SM2 254 M1-B 16 1 4 x 12 0.33 2.0 34 0.213
1/4 SM5 254 M1-B 16 1 4.8 x 12.5 0.65 2.0 58 0.363
1/4 SM5 258 M1-B 32 1 4.8 x 12.5 1.3 4.0 58 0.363
1/4 SM5 2516 M1-B 64 1 4.8 x 12.5 1.3 4.0 58 0.363
1/2 SM5 504 M1-B 16 1 4.8 x 12.5 0.65 2.0 58 0.363
1/2 SM5 508 M1-B 32 1 4.8 x 12.5 1.3 4.0 58 0.363
1/2 SM10 5016 M1-B 64 1 6.8 x 17.8 2.8 7.2 113 0.726
1 SM10 1004 M1-B 16 1 6.8 x 17.8 1.4 3.6 113 0.726
1 SM10 1008 M1-B 32 1 6.8 x 17.8 2.8 7.2 113 0.726
1 1/2 SM16 1608 T1-B 32/8 1 9.0 x 27.0 5.6 15.4 243 1.209
2 SM10 2002 M1-B 8 2 6.8 x 17.8 1.4 3.6 118 0.726
2 SM10 2004 M1-B 16 2 6.8 x 17.8 2.8 7.2 118 0.726
2 SM20 2008 T1-B 32/8 1 9.0 x 27.0 5.6 15.4 243 1.209
2 ½ SM25 2506 T1-B 24/6 1 9.0 x 27.0 5.6 15.4 243 1.209
5 SM25 5003 T1-B 12/3 2 9.0 x 27.0 5.6 15.4 243 1.209
(1) approximate weight without chain
Metric Offering and Technical Data [60 Hz]:
Capacity
(Kg)
Model Speed
m/min
Falls Chain
type
(mm)
Power
(kW)
Nominal
Current
230 V
Weight
of Unit (1)
(Kg)
Chain
weight
(kg/m)
125 SM1 128 M1-B 9.6 1 3.1 x 9.3 0.25 2.0 13 0.22
250 SM2 254 M1-B 4.8 1 4 x 12 0.25 2.0 17 0.35
250 SM5 254 M1-B 4.8 1 4.8 x 12.5 0.5 2.0 26 0.54
250 SM5 258 M1-B 9.6 1 4.8 x 12.5 1.05 4.0 26 0.54
250 SM5 2516 M1-B 19.2 1 4.8 x 12.5 1.05 4.0 26 0.54
500 SM5 504 M1-B 4.8 1 4.8 x 12.5 0.5 2.0 26 0.54
500 SM5 508 M1-B 9.6 1 4.8 x 12.5 1.05 4.0 26 0.54
500 SM10 5016 M1-B 19.2 1 6.8 x 17.8 2.1 7.2 51 1.08
1000 SM10 1004 M1-B 4.8 1 6.8 x 17.8 1.05 3.6 51 1.08
1000 SM10 1008 M1-B 9.6 1 6.8 x 17.8 2.1 7.2 51 1.08
1500 SM16 1608 T1-B 9.6/2.4 1 9.0 x 27.0 4.2 15.4 110 1.80
2000 SM10 2002 M1-B 2.4 2 6.8 x 17.8 1.05 3.6 54 1.08
2000 SM10 2004 M1-B 4.8 2 6.8 x 17.8 2.1 7.2 54 1.08
2000 SM20 2008 T1-B 9.6/2.4 1 9.0 x 27.0 4.2 15.4 110 1.80
2500 SM25 2506 T1-B 7.2/1.8 1 9.0 x 27.0 4.2 15.4 110 1.80
5000 SM25 5003 T1-B 3.6/0.9 2 9.0 x 27.0 4.2 15.4 110 1.80
(1) approximate weight without chain

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
13
®
3.3 Hoist Configuration C – Programmable Control
Configuration C utilizes three-phase power and low voltage control. The hoist is equipped for fixed
installations so it can be mounted in the normal position, but when specially equipped, the hoist can also
be mounted in the inverted position. The hoist is readily equipped for programmable control and
sequencing. Controller furnished separately.
Hoist features for standard requirements:
Black load chain
Non-reflecting matt black finish
Fixed body hook
Standard chain guide
Disc Brake
Torque limiting device
Upper and lower electrical limit switch (weight-operated)
Steel control enclosure (except SM1, NORYL plastic)
Chain bag for 100 ft [30 m] of chain
Low voltage (48 VAC) control
Round cable gland – 5/8”-13/16” [15-20.5 mm] diameter cable
Hoist motor thermal protection
Sensor bearing with filter for positioning (SM5 and SM10)
Incremental encoder for positioning (SM1)
230V-3Ph-60Hz
Note:
Mainline contactor is specially wired so it is always energized when power to the hoist (SM5
and SM10 only) is applied.
Available options:
Inverted mounting position - includes an external (SM5 and SM10 Chainflux) chain guide,
handgrips, and a swiveling body hook. Upper and lower electrical limit switches (weight-
operated) are removed and a geared limit switch is added.
Swiveling body hook
Self locking hook (SM5 and SM10)
Geared limit switch (except SM1 due to the supplied incremental encoder)
Second brake (SM5 and SM10 only)
Steel control enclosure for SM1
Vinyl rain cover
Drain hole in the load sprocket compartment (SM5 and SM10 only)
Handgrips
Power & control pigtail – 19 pin male plug (standard pigtail length is 18”, longer lengths available)
Control pigtail – no plug (standard pigtail length is 18”, longer lengths available)
Twist-Lock female receptacle for control pigtail
208V-3Ph-60Hz
Controllers:
8 channel computer aided controller (plus one operator console per system)
Accessories:
Motor cables
Single and twin flight cases (SM5, SM10 only)

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
14
®
Offering and Technical Data:
Capacity
(Ton)
Model Speed
(fpm)
Falls Chain
type
(mm)
Power
(HP)
Nominal
Current
230 V
Weight
of Unit (1)
(lbs)
Chain
weight
(lb/ft)
1/8 SM1 128 M1-C 32 1 3.1 x 9.3 0.33 2.0 29 0.148
1/4 SM5 254 M2-C 16 1 4.8 x 12.5 0.65 2.0 58 0.363
1/4 SM5 258 M2-C 32 1 4.8 x 12.5 1.3 4.0 58 0.363
1/4 SM5 2516 M1-C 64 1 4.8 x 12.5 1.3 4.0 58 0.363
1/2 SM5 504 M1-C 16 1 4.8 x 12.5 0.65 2.0 58 0.363
1/2 SM5 508 M1-C 32 1 4.8 x 12.5 1.3 4.0 58 0.363
1/2 SM10 5016 M1-C 64 1 6.8 x 17.8 2.8 7.2 113 0.726
1 SM10 1004 M1-C 16 1 6.8 x 17.8 1.4 3.6 113 0.726
1 SM10 1008 M1-C 32 1 6.8 x 17.8 2.8 7.2 113 0.726
2 SM10 2002 M1-C 8 2 6.8 x 17.8 1.4 3.6 118 0.726
2 SM10 2004 M1-C 16 2 6.8 x 17.8 2.8 7.2 118 0.726
(1) approximate weight without chain
Metric Offering and Technical Data [60 Hz]:
Capacity
(Kg)
Model Speed
m/min
Falls Chain
type
(mm)
Power
(kW)
Nominal
Current
230 V
Weight
of Unit (1)
(kg)
Chain
weight
(kg/m)
125 SM1 128 M1-C 9.6 1 3.1 x 9.3 0.25 2.0 13 0.22
250 SM5 254 M2-C 4.8 1 4.8 x 12.5 0.5 2.0 26 0.54
250 SM5 258 M2-C 9.6 1 4.8 x 12.5 1.05 4.0 26 0.54
250 SM5 2516 M1-C 19.2 1 4.8 x 12.5 1.05 4.0 26 0.54
500 SM5 504 M1-C 4.8 1 4.8 x 12.5 0.5 2.0 26 0.54
500 SM5 508 M1-C 9.6 1 4.8 x 12.5 1.05 4.0 26 0.54
500 SM10 5016 M1-C 19.2 1 6.8 x 17.8 2.1 7.2 51 1.08
1000 SM10 1004 M1-C 4.8 1 6.8 x 17.8 1.05 3.6 51 1.08
1000 SM10 1008 M1-C 9.6 1 6.8 x 17.8 2.1 7.2 51 1.08
2000 SM10 2002 M1-C 2.4 2 6.8 x 17.8 1.05 3.6 54 1.08
2000 SM10 2004 M1-C 4.8 2 6.8 x 17.8 2.1 7.2 54 1.08
(1) approximate weight without chain

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
15
®
3.4 Hoist Configuration D – BGV-C1 Enhanced Safety Features
Configuration D utilizes three-phase power, low voltage control and must be operated with
STAGEMAKER®R8PRM-C1 controller (see Note). The hoist complies with enhanced safety regulations
in accordance to DIN 56925. The hoist is mounted in the normal position, but when specially equipped,
the hoist can also be mounted in the inverted position and must be operated from a nonprogrammable
controller.
Hoist features:
Black load chain
Non-reflecting matt black finish
Fixed body hook
Standard chain guide
Two brakes
Torque limiting device
Low voltage (48 VAC) control with mainline contactor (1)
Steel control enclosure
Geared limit switch – four position
Electronic type overload device
Connection pigtail with a Harting or equal (16 pin + ground) metallic male plug for control and
power (standard pigtail length is 18”, longer lengths available)
Diagnostic test plug
Capacity de-rated by 50% from standard
Chain container for 100 ft [30 m] of chain
Electronic overload relay
Test facility for brakes and limit switches
230V-3Ph-60Hz + neutral power supply
(1) Operation of the main line contactor is taken over by the controller.
Available options:
Inverted mounting position - includes a Chainflux chain guide, handgrips, and a swiveling
body hook
Swiveling body hook
Self locking hook
Vinyl rain cover
Drain hole in the load sprocket compartment
Hoist motor thermal protection
208V-3Ph-60Hz + neutral power supply
Handgrips
Controllers:
STAGEMAKER®8 channel R8PRM-C1 controller
Pushbutton controller with E-stop button
Accessories:
Motor cables
Note:
For group control of BGV-C1 hoists, the use of the R8PRM-C1 controller is mandatory. For
single hoist applications, the hoist could be used without any restrictions. It just needs a
pushbutton controller (pickle) with E-stop.

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
16
®
Offering and Technical Data:
Capacity
(Ton)
Model Speed
(fpm)
Falls Chain
type
(mm)
Power
(HP)
Nominal
Current
230 V
Weight
of Unit
(lbs)
Chain
weight
(lb/ft)
1/4 SM10 2516 M1-D 64 1 6.8 x 17.8 2.8 7.2 113 0.726
1/2 SM10 504 M1-D 16 1 6.8 x 17.8 1.4 3.6 113 0.726
1/2 SM10 508 M1-D 32 1 6.8 x 17.8 2.8 7.2 113 0.726
1 SM10 1002 M1-D 8 2 6.8 x 17.8 1.4 3.6 118 0.726
1 SM10 1004 M1-D 16 2 6.8 x 17.8 2.8 7.2 118 0.726
(1) approximate weight without chain
Metric Offering and Technical Data [60 Hz]:
Capacity
(Kg)
Model Speed
m/min
Falls Chain
type
(mm)
Power
(kW)
Nominal
Current
230 V
Weight
of Unit (1)
(kg)
Chain
weight (2)
(kg/m)
250 SM10 2516 M1-D 19.2 1 6.8 x 17.8 2.1 7.2 51 1.08
500 SM10 504 M1-D 4.8 1 6.8 x 17.8 1.05 3.6 51 1.08
500 SM10 508 M1-D 9.6 1 6.8 x 17.8 2.1 7.2 51 1.08
1000 SM10 1002 M1-D 2.4 2 6.8 x 17.8 1.05 3.6 54 1.08
1000 SM10 1004 M1-D 4.8 2 6.8 x 17.8 2.1 7.2 54 1.08
(1) approximate weight without chain

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
17
®
3.5 Hoist Configuration E – Without Motor Controls
Configuration E utilizes three-phase power and is set up for external controls (typically VFD), which are
not included. The hoist is equipped for fixed installations so it can be mounted in the normal position, but
when specially equipped the hoist can also be mounted in the inverted position.
Hoist features for normal mounting position:
Black load chain
Non-reflecting matt black finish
Fixed body hook
Standard chain guide
Disc brake
Brake rectifier
Torque limiting device
Upper and lower electrical limit switches (weight-operated)
Steel control enclosure
Chain container for 100 ft [30 meters] of load chain
No controls
Wiring to terminal strip
Two round cable glands - 5/16”-9/16” [8-15 mm] diameter cable
230V-3Ph-60Hz power supply
Available options:
Inverted mounting position - includes a Chainflux chain guide, handgrips, and a swiveling
body hook. Upper and lower electrical limit switches (weight-operated) are removed and a
geared limit switch is added.
Sensor bearing with filter for positioning/speed supervision - for inverter control
Geared limit switch
Vinyl rain cover
Drain hole in the load sprocket compartment
Second brake
Self locking hook
460V-3Ph-60Hz or 208V-3Ph-60Hz power supply
Handgrips
Note:
With inverter control, a separate contactor must be used to activate the brake.
The maximum frequency (Hz) that could be applied to the motor is noted in the applicable
Offering and Technical Data tables.
Notify the factory for use with VFD control applications.

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
18
®
Offering and Technical Data:
Capacity
(Ton)
Model Speed
(fpm)
Falls Chain
type
(mm)
Power
(HP)
Nominal
Current
230 V
Weight
of Unit (1)
(lbs)
Chain
weight
(lb/ft)
1/4 SM5 254 M2-C 16 1 4.8 x 12.5 0.65 2.0 58 0.363
1/4 SM5 258 M2-C 32 1 4.8 x 12.5 1.3 4.0 58 0.363
1/4 SM5 2516 M1-C 64 1 4.8 x 12.5 1.3 4.0 58 0.363
1/2 SM5 504 M1-C 16 1 4.8 x 12.5 0.65 2.0 58 0.363
1/2 SM5 508 M1-C 32 1 4.8 x 12.5 1.3 4.0 58 0.363
1/2 SM10 5016 M1-C 64 1 6.8 x 17.8 2.8 7.2 113 0.726
1 SM10 1004 M1-C 16 1 6.8 x 17.8 1.4 3.6 113 0.726
1 SM10 1008 M1-C 32 1 6.8 x 17.8 2.8 7.2 113 0.726
2 SM10 2002 M1-C 8 2 6.8 x 17.8 1.4 3.6 118 0.726
2 SM10 2004 M1-C 16 2 6.8 x 17.8 2.8 7.2 118 0.726
(1) approximate weight without chain
Metric Offering and Technical Data [60 Hz]:
Capacity
(Kg)
Model Speed
m/min
Falls Chain
type
(mm)
Power
(kW)
Nominal
Current
230 V
Weight
of Unit (1)
(kg)
Chain
weight
(kg/m)
250 SM5 254 M2-C 4.8 1 4.8 x 12.5 0.5 2.0 26 0.54
250 SM5 258 M2-C 9.6 1 4.8 x 12.5 1.05 4.0 26 0.54
250 SM5 2516 M1-C 19.2 1 4.8 x 12.5 1.05 4.0 26 0.54
500 SM5 504 M1-C 4.8 1 4.8 x 12.5 0.5 2.0 26 0.54
500 SM5 508 M1-C 9.6 1 4.8 x 12.5 1.05 4.0 26 0.54
500 SM10 5016 M1-C 19.2 1 6.8 x 17.8 2.1 7.2 51 1.08
1000 SM10 1004 M1-C 4.8 1 6.8 x 17.8 1.05 3.6 51 1.08
1000 SM10 1008 M1-C 9.6 1 6.8 x 17.8 2.1 7.2 51 1.08
2000 SM10 2002 M1-C 2.4 2 6.8 x 17.8 1.05 3.6 54 1.08
2000 SM10 2004 M1-C 4.8 2 6.8 x 17.8 2.1 7.2 54 1.08
(1) approximate weight without chain

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
19
®
3.6 Hoist Configuration S – Single-phase Motor for Fixed or Mobile Installation
Configuration S utilizes single-phase power and low voltage motor control. The hoist is equipped for
mobile installations so it can be mounted in the inverted or normal position, but when specially equipped
the hoist can also be used in the normal position of fixed installations. Controller furnished separately. A
“pickle”, which is used during stage setup, can be connected directly to the low voltage hoist controls.
Hoist features:
Black load chain
Non-reflecting matt black finish
Swiveling body hook
Chain guide (SM5, Chainflux)
Disc Brake
Over-travel protection via the torque limiting device (1)
Chain bag for 100 ft [30 meters] of load chain
Handgrips
Low voltage (115 VAC) control
Two round cable glands - 5/16”-9/16” [8-15 mm] diameter cable
Steel control enclosure (except SM1, NORYL plastic)
Hoist motor thermal protection
No pigtail for power or control
115V-1Ph-60Hz power supply
(1) Upper and lower electrical limit switches (weight-operated) do not work in the inverted position and are not furnished.
Available options:
Fixed applications – includes a standard chain guide, upper and lower electrical limit switches
(weight –operated), a plastic chain container and the handgrips are removed.
Fixed body hook
Upper and lower electrical limit switches (weight-operated) - normal position only
Steel control enclosure for SM1
Vinyl rain cover
Drain hole in the load sprocket compartment (SM5 only)
Power pigtail – no plug (standard pigtail length is 18”, longer lengths available)
Control pigtail – no plug (standard pigtail length is 18”, longer lengths available)
Power & control pigtail – no plug (standard pigtail length is 18”, longer lengths available)
Twist-Lock male plug for power pigtail
7-pin Socapex male plug for power & control pigtail
P14 male plug for power & control
Twist-Lock female receptacle for control pigtail
Mating plug/receptacle for the supplied plug
Second brake (SM5 only)
Controllers:
4 or 8 channel controller
Pistol-grip pushbutton controller or “Pickle” with pigtail and optional plug
Accessories:
Motor cables
Single and twin flight cases (SM5 only)

R&M Materials Handling, Inc STAGEMAKER®Concert Hoist
Springfield, Ohio USA Technical Guide
: 800 955-9967 June 2009
www.rmhoist.com
RM-STGMKR-TG-2002-6-ENG.doc
20
®
Offering and Technical Data:
Capacity
(Ton)
Model Speed
(fpm)
Falls Chain
type
(mm)
Power
(HP)
Nominal
Current
115 V
Weight
of Unit (1)
(lbs)
Chain
weight
(lb/ft)
1/8 SM1 124 M1-S 16 1 3.1 x 9.3 0.16 3.45 29 0.148
1/4 SM1 252 M1-S 8 2 3.1 x 9.3 0.16 3.45 29 0.148
1/4 SM5 254 M1-S 16 1 4.8 x 12.5 0.64 11.5 58 0.363
1/2 SM5 504 M1-S 16 1 4.8 x 12.5 0.64 11.5 58 0.363
(1) approximate weight without chain
Metric Offering and Technical Data [60 Hz]:
Capacity
(Kg)
Model Speed
m/min
Falls Chain
type
(mm)
Power
(kW)
Nominal
Current
115 V
Weight
of Unit (1)
(lbs)
Chain
weight
(lb/ft)
125 SM1 124 M1-S 4.8 1 3.1 x 9.3 0.12 3.45 13 0.22
250 SM1 252 M1-S 2.4 2 3.1 x 9.3 0.12 3.45 13 0.22
250 SM5 254 M1-S 4.8 1 4.8 x 12.5 0.5 11.5 26 0.54
500 SM5 504 M1-S 4.8 1 4.8 x 12.5 0.5 11.5 26 0.54
(1) approximate weight without chain
