PolyJohn MS02-1000 Instruction sheet

Page 1 of 9
July 2023
NOTE: We recommend reading through the entire Assembly Instructions prior to proceeding with use, service or maintenance.
LIFTING SLING
PRODUCT INSTRUCTIONS

LIFTING SLING
MS02-1000
Page 2 of 9
July 2023
DIMENSION IMPERIAL METRIC
Clearance Height when attached to Unit 104 in 264 cm
Legs Can Extend to length of the Unit 48 in 122 cm
Width of Lifting Arm 47.75 in 121 cm
Sling Set Weight 45 lbs 20.41 kg
Lifting Capacity 1000 lbs 453.59 kg
PRODUCT SPECIFICATIONS
NOTE: All dimensions are subject to change due to environmental factors. All materials, including resin, pigments and additives used to make
the plastic components as well as the plumbing components that come in contact with the fresh water are U.S. FDA food grade compliant.

LIFTING SLING
MS02-1000
Page 3 of 9
July 2023
The MS02-1000 Lifting Sling, made of a no rust galvanized steel. Designed to move most portable restrooms around
a construction site. Shipped with the MS01-0200 - Small Parts Bag which includes the necessary parts for easy
assembly.
GENERAL OVERVIEW
SAFE HANDLING INSTRUCTIONS
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN INJURY OR DEATH
1. This unit is made to lift portable restrooms only. It has a lifting capacity of 1000 lbs. This unit was designed to lift
PolyJohn brand portable restrooms. If using this product with a different portable restroom manufacturer, the unit must be
weighed to insure that the 1000 lb. lifting capacity is not exceeded. The unit must not be used to lift anything or anyone
inside of the portable restroom.
2. Only one (1) sling set/unit to be lifted by one (1) lifting device at a time.
3. The base of the portable restroom and the lifting sling must be visually inspected prior to any lift.
4. All lifting must be done from the center apex of the sling cross bar.
5. Any bent or damaged parts must be reported to supervisor immediately and taken out of service.

LIFTING SLING
MS02-1000
Page 4 of 9
July 2023
Note: Prior to fitting the sling set, be sure that the unit is clean and empty of all waste.
Step 1. For PJN3 units with a plastic base, lay the unit on it’s back. Measure up 8” from the ground and make a mark
on the side of the runner. Holding a straight edge, such as a 2x4 across bthe bottom of both runners, measure from the
2x4, 2-13/16” from the bottom of the runner of the base and make a mark right where the previous mark was made.
Drill a 11/16” hole through one wall of the base in the location marked. Repeat this step for the inside surface of the
runner (see diagram to the left). Repeat this procedure for the outside and inside surfaces of the other runner. When all 4
holes have been drilled, turn the unit over, laying it on it’s front, and repeat these steps.
2 x 4 placed underneath
both runners of base
2-13/16”
from 2 x 4
8” from
ground
PRODUCT INSTRUCTIONS

LIFTING SLING
MS02-1000
Page 5 of 9
July 2023
2-13/16”
from 2 x 4
8” from
ground
Step 2. Stand the unit upright.
Step 3. Attach one end of the MS01-0002G - Lifting Arm to the looped-end of one of the MS01-0001G -
Sling Legs. Repeat for the other end of arm and leg.
Step 4. Push the Portable Unit between the sling legs.
Step 5. Insert one foot of a sling leg through the hole in the runner. Place a PC-000129 washer over the foot
of the sling leg. Follow by inserting a PC-000132 hairpin cotter into the hole of the foot and push until the foot
is in the middle opening of the hairpin cotter to lock in place. Repeat this for the remaining sling legs.
Follow steps in reverse order to detach lifting sling.
PRODUCT INSTRUCTIONS

LIFTING SLING
MS02-1000
Page 6 of 9
July 2023
ATTACHING THE LIFTING SLING TO ALL OTHER UNITS
• For all skids whether plastic or wood, drill four 11/16” holes through the sides of the runners (two holes per runner).
The ideal drill locations should be 5” in from each end of the runner and 2” from the bottom of the skid. NOTE: Before
drilling check the inside of the runner for any obstructions and adjust drill locations accordingly.
• Attach one end of the MS01-0002G - Lifting Arm to the looped-end of one of the MS01-0001G - Sling Legs.
Repeat for the other end of arm and leg.
• Push the Portable Unit between the sling legs.
• Insert one foot of a sling leg through the hole in the runner. Place a PC- 000129 washer over the foot of the sling leg.
Follow by inserting a PC-000132 hairpin cotter into the hole of the foot and push until the foot is in the middle opening
of the hairpin cotter to lock in place.
• Repeat for the three other ends of the skid.
Follow steps in reverse order to detach lifting sling.
http://www.polyjohn.com/pc-000129
http://www.polyjohn.com/pc-000132
http://www.polyjohn.com/ms01-0001g
http://www.polyjohn.com/ms01-0002g
MS01-0002G - Lifting Arm
MS01-0001G - Sling Legs
PC-000132 Hairpin Cotter
PC-000129 Washer
PRODUCT INSTRUCTIONS

LIFTING SLING
MS02-1000
Page 7 of 9
July 2023
REGULATIONS
P
rop 65
P
olyJohn Corporation would like to inform any customers or end users that some products may contain chemicals listed in California’s Safe
Drin
king Water & Toxic Enforcement Act of 1986. Commonly referred to as Proposition 65, this Act establishes a list of chemicals known by the
State of
California to present a risk of cancer, birth defects, or other reproductive harm.
C
hemical exposure typically occurs through inhalation, ingestion, or adsorption. PolyJohn products are not intended to be used in these methods.
P
olyJohn Corporation cannot foresee all uses of their products (both intended and unintended uses) and as a result has opted to provide a
gene
ral warning of known chemical presence.
T
he Proposition 65 chemical list can be found at http://www.P65Warnings.ca.gov
T
he following warnings are labels placed on affected products. If these labels are not present then they do not apply to that product.
WARNING: This product can expose you to chemicals including 4-Vinylcyclohexene which is known to the State of California to cause
cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
4
-Vinylcyclohexene label above to be used any product made with Bayblend T85
WARNING: This product can expose you to chemicals including titanium dioxide, which is known to the State of California to cause
cancer. For more information go to www.P65Warnings.ca.gov.
Confli
ct Minerals Compliance Statement
Section
1502 of the Dodd-Frank Wall Street Reform and Consumer Protection Act, and the Securities and Exchange Commission Rules adopted in
connection t
herewith, require certain corporations to report the use of “Conflict Minerals” in the manufacture of their products. Generally, Conflict
Mine
rals collectively refers to cassiterite, columbite-tantalite, gold, wolframite, or their derivatives, including tantalum, tin and tungsten, which
originate f
rom the Democratic Republic of the Congo or specified adjoining countries (referred to herein as “Covered Countries”).
W
hile we, as a privately held corporation, are not subject to the Conflict Minerals rules and reporting requirements, we understand that our
custome
rs may be, and we are committed to helping our customers comply with their reporting requirements. In order to determine if our
manufactured p
roducts contain Conflict Minerals, we have asked our relevant suppliers, as of September 1, 2020, to ascertain their use of any
C
onflict Minerals in the materials they supply to us. Their responses demonstrate that our relevant suppliers (i) do not use Conflict Minerals in the
materials t
hey supply to us, (ii) have no reason to believe the Conflict Minerals they use may have originated in the Covered Countries, and/
or (iii) reasonably beli
eve that the Conflict Minerals they use are from recycled or scrap sources. Consequently, we can in turn represent that, to
t
he best of our knowledge, our manufactured products either do not contain Conflict Minerals, or to the extent they may, such products are “DRC
conflict free” as defined
by paragraph (e)(4) of Section 1502.
W
e will continue to work with our key suppliers to ensure that we are able to identify the use of Conflict Minerals in our supply chain, and the
representations made in t
his compliance statement remain accurate. To that end, we reserve the right to amend this statement at any time based
on subsequent d
evelopments or information.
S
hould you have any questions or concerns regarding this statement, please do not hesitate to contact us.

LIFTING SLING
MS02-1000
Page 8 of 9
July 2023
WARRANTY
Restrooms and Toilets
POLYJOHN PORTABLE RESTROOMS LIMITED 3 YEAR PRODUCT WARRANTY
PolyJohn Enterprises Corp. warrants the major plastic parts of its portable restrooms (plastic front, wall panels, roof, and tank) against any breakage
or other problems that prevent the PolyJohn portable toilet from functioning in accordance with usual practices used in the portable toilet industry
and in their intended manner. This warranty covers any damages in material or workmanship for a total period of 3 years (36 months). This warranty
extends only to the original purchaser of the PolyJohn portable restroom. Proof of purchase, serial numbers, and photos will be required.
sinks, tanks, trailers and sanistands
PolyJohn Enterprises warrants our sinks, tanks, trailers and sanistands from the date of purchase. Any misuse or abuse of our products or failure to
properly follow recommended procedures shall void this warranty. The warranty is a 1 year limited warranty and a 90 day limited warranty for
components thereof.
What is Not Covered By Warranty
This warranty does not cover damage or failure contributed to or caused by: Not following PolyJohn assembly procedures, unauthorized
modification, acts of God, mishandling, misuse, use of incompatible solvents or other damaging chemicals, vandalism or accident. In no event shall
PolyJohn be liable for labor costs or for incidental or consequential damages.
For full details on PolyJohn’s warranty policy, and to view instructions for submitting a claim please visit https://www.polyjohn.com/warranty/.
Warranty Disclaimer
PolyJohn’s terms of sale are FOB (Free on Board Shipping Point). Meaning buyer takes on responsibility once it leaves PolyJohn’s shipping dock.
The carrier is wholly responsible for any damage incurred during transit. Important notice: All concealed/non-notated damages must be reported
within 5 business days of delivery (1st day is the day of delivery) as per the National Motor Freight Classification (NMFC) – Rule 300100 - for a
damaged claim to be filed. Reporting after this time will void a claim.
In order to prevent warranty disputes follow these steps immediately when receiving your products:
Inspect the shipment immediately and insist that visible damages be indicated on your copy of the freight bill. If they are not noted on the
freight bill it is very likely a claim will be denied.
Open the shipment if necessary, and inspect for any concealed damages.
If there are any damages that you cannot operate with you may refuse shipment. After you do this contact us immediately
Filing Process for Warranty
PolyJohn reserves the right to request inspection of products for verification of defect, which may include returning some or all of the parts with
shipping paid for by the purchaser. Once the items have been returned, inspected, and PolyJohn is found at fault shipping costs will be reimbursed.
You may contact PolyJohn to arrange for return shipping if desired.
To file your warranty claim follow these steps:
1. Go to polyjohn.com/warranty/
2. Fill out necessary contact information
3. Fill in invoice number, date of purchase, product, and product serial numbers.
4. Upload an images of affected products
5. Submit and someone will be in contact with you as soon as possible.
